NINGBO CSTAR IMP and EXP 0038 Bluetooth earbuds User Manual EL147 SL067 STARLINE Instruction 7 27
NINGBO CSTAR IMP&EXP; CO., LTD Bluetooth earbuds EL147 SL067 STARLINE Instruction 7 27
User Manual
SAFETY PRECAUTIONS:
WARNING-When using this product,
basic precautions should always be
followed, including the following :
1. Read all the instructions before using the
product.
1. Multi-Function Keys
2. Charging Port
3. LED Indicators
Instruction
1. Power ON/OFF:
Power On: Press the multifunction button
until blue LED is lit
Power Off: Press the multifunction button
until red LED is lit
2. Paring: long press the multifunctional
button for 5 seconds, the indicator lights
will flashes red and blue alternately, then
turn on your cellphone Bluetooth, search
“EB42” and click connecting, It will pair
automatically.
Tech Specifications :
Made in China
True Wireless Ear Buds
Instruction Manual
EB42
Large Medium Small
1. Model: EB42
2. Magnetic catch USB charging
3. Frequency: 2.402-2.48GHz
4. Wireless range: 10m
5. Battery capacity: 80mAh
6. Charging time: 1-2 hours
3. Once the earbuds is successfully paired
and connected with your mobile phone,
you can use it to make a call and listen
music.
6. Do not use the device in excess of its output
rating. Overload output s above rating may
result in a risk of fire or injury.
7. Do not use the device if damaged or modified.
8. Damaged or modified batter ies may exhibit
unpredictable behavior resulting in fire,
explosion or injury.
9. Do not disassemble the device.
10. Exposure to fire or extreme high temperature
may cause explosion.
7. Music: short press Multifunction button
to pause music/play music.
4. Answer call/End call: Press the
multifunction button once to answer the
incoming call. Press the control button once
to end a call.
6. Redial: Double press the multifunction
button to redial the last number you called on
your phone.
5. Reject call: Press the multifunction button
for 2 seconds to reject the incoming call.
1. Make sure the earphone power off
2. Put the earphone to the USB dock ,
they will magnetic catch by itself
3. Connect the USB Port to computer
or any 5v USB adapter to charger it
4. The LED indicator will be solid red
when charging, and will turn into blue
when the earbuds fully charged.
Step 1 step 2 step 3 step 4
Charging for earphone
2.Upon initial use or after a prolonged storage
period, fully charge.
3.To reduce the risk of injury, close supervision
is necessary when the product is used near
children.
4. Product is not water resistant or water proof.
5. Use of a power supply or charger not
recommended or sold by device manufacturer
may result in a risk of fire or injury to persons.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1)This device may not cause harmful interference.
(2)This device must accept any interference received, including interference that may
cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Note:This equipment has been tested and found to comply with the limits for a class B
digital device,pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequence energy and,if not
installed and used in accordance with the instructions,may cause harmful interference to
radio communications.However,there is no guarantee that interference will not accor in a
particular installation.if this equipmemt does cause harmful interference to radio or
television reception,which can be determined by turning the equipment off and on,the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an autlet on a circuit different from that to which the
receiver is connectec.
• Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The devicecan
be used in portable exposure condition without restriction.
