NINGBO CSTAR IMP and EXP 0042 Bluetooth speaker with charging case User Manual SL165 HIT Instruction 6 1
NINGBO CSTAR IMP&EXP; CO., LTD Bluetooth speaker with charging case SL165 HIT Instruction 6 1
User Manual
2955
Charging case speaker Operation instruction:
Power On: To power on, long press the Power button,
the Bluetooth indicator will ash blue and you will
hear a tone.
Power O: long press the power button, the Bluetooth
indicator will turn o and you will hear a tone. Noted
the speaker can’t be power o in FM mode, please
press mode button to turn into Bluetooth mode)
Play music
Pause/Play : Short press the button to play or pause
the music
Vol+/Next track: Long press to increase the volume,
short press for next track
Vol-/previous track: Long press to decrease the
volume, short press for previous track
By pressing mode button you can choose the
following modes:
• FM radio
• Bluetooth
How to use FM radio:
1. The included charging cable can serve as an
antenna to improve the reception
2. Press the Mode button to enter FM mode, then
press search button once, the device will
automatically search and store the detected radio
frequencies.
3. Switch radio frequencies and adjust volume.
Vol+/Next radio frequencies: Long press to increase
the volume, short press for next radio frequencies
Warning:
the party responsible for compliance could void the
user's authority to operate the equipment.
FCC ID : 2ABHA0042
MADE IN CHINA
USER MANUAL
10. Multifunction Button
1. Vol-/previous track/ radio frequencies
2. Vol+/Next track/ radio frequencies
3. Open
4. Power On/O /Pause/Play/
Search FM button
5. Mode
6. Charging slot
7. Charging / battery
capacity indicator
8. Micro USB Charging port
9. Bluetooth indicator
11 Microphone
12. LED indicator
13. Ear Tips
Single Ear Bud Use
Power On: To power on, long press the multifunction
button for 3 seconds. The indicator light will show
Pairing: Once earbuds are turned on, using your
mobile device, search for Bluetooth devices and
select Bluetooth ID ‘ True Wireless headset ’. It will pair
automatically.
Long press the multifunction button for
you will hear a tone.
Charging
It is recommended to fully charge the earbuds and
case speaker
Earbuds: The earbuds when placed in the
charging slot, the LED indicator will display a solid red
light. When the earbuds are fully charged, the indicator
light will turn blue. Both Earbuds:
Please note: Once both earbuds are paired, the
Primary earbud will be the button to use for control,
and the microphone used for calling. The other
earbuds controls will be disabled for calling while
being paired with the Primary Earbud.
Power On: Press and hold the multifunction buttons
of both earbuds at the same time for 3 seconds, the
Pairing: Place the earbuds beside each other and
double press the button of one earbuds that you
want to it be primary, they will automatically pair
Primary Earbud and will be what you use to control
the functions when using two earbuds at once.
You can now use your mobile device to search for
Bluetooth devices. Select Bluetooth ID ‘ True Wireless
headset ’. It will pair automatically.
Answer/End Call: Press the multifunction button
once to answer an incoming call. Press the button
once again to end the call.
Redial: Double press the multifunction button to
redial the last number you called on your phone.
Reject Call: Press the control button for 2 seconds
to reject an incoming call.
Play/Pause: When listening to music, short press
the multifunction button to pause/play music.
Note: If you attempt to pair before the earbuds have
paired to each other, the earbuds will go into single
earbud use not both. In this case, restart the process.
Once they are paired successfully, the indicator will
Long press the multifunction button on
the Primary earbud for 5 seconds. The indicator light
Calling: Only the Primary earbud can operate phone
call functions.
Answer/End Call: Press the multifunction button
once to answer an incoming call. Press the button
once to end the call.
Redial: Double press the multifunction button to
redial the last number you called on your phone.
Reject Call: Press the multifunction for 2 seconds to
reject the incoming call.
Play/Pause: When listening to music, short press
Primary earbuds multifunction button to pause/play
music.
Next Song: When listening to music, short press the
Secondary earbuds multifunction button to go to the
next song.
3
4
1
2
8
9
6
7
10
11
12
5
13
Charging case speaker:
Earbuds:
Charging case speaker:
Connect the speaker to USB adapter with the cable
provided. The charging indicator will light blue in
charging.
Item No.: 2955
Battery capacity : 40 mAh
Earbuds
Model : SL165
Working Voltage: 3.7V - 4.2V
Mic Sensitivity: -42 3dB
Bluetooth Frequency: 2.4-2.48GHZ
Bluetooth Range: 10M
Charging case speaker
Speaker output power: 3W
Frequency: 20-20kHz
Input: DC 5V/ 200mA
Battery capacity: 500 mAh
Indicator LED 2 Lights 1 Lights
Power capacity
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use
of such marks by (ShenZhen C-Star Electronic Tech.
Co., Ltd.) is under license. Other trademarks and trade
names are those of their respective owners.
Bluetooth Listing Declaration ID: D026369
FCC ID : 2ABHA0026
Bluetooth Listing Declaration ID: D035790
How to use the Bluetooth function:
1. Make sure you turn on Bluetooth mode on your
mobile phone
2. Make sure the device is turned on and on Bluetooth
mode by pressing (Mode)
3. Once speaker is turned on, using your mobile
device, search for Bluetooth devices and select
Bluetooth ID “ BT Speaker “. It will pair automatically,
then you can play music now.
SAFETY PRECAUTIONS:
1. Do not modify, repair or dismantle the Earbuds.
Doing so may result in re, electric shocks or the
Earbuds not working.
2. Do not use any diluents or volatile liquids to clean
the Earbuds.
3. It is not recommended to use the Earbuds in any
hazardous location.
Vol-/previous radio frequencies: Long press to
decrease the volume, short press for previous radio
frequencies
4 Lights 3 Lights
75-100% 50-75% 25-50% <25&
FRONT
BACK
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1)This device may not cause harmful interference.
(2)This device must accept any interference received, including interference that may
cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Note:This equipment has been tested and found to comply with the limits for a class B
digital device,pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequence energy and,if not
installed and used in accordance with the instructions,may cause harmful interference to
radio communications.However,there is no guarantee that interference will not accor in a
particular installation.if this equipmemt does cause harmful interference to radio or
television reception,which can be determined by turning the equipment off and on,the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an autlet on a circuit different from that to which the
receiver is connectec.
• Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The devicecan
be used in portable exposure condition without restriction.
