NINGBO CSTAR IMP and EXP 32080 Bluetooth speaker User Manual 7038421 BIC Instruction 3 7
NINGBO CSTAR IMP&EXP; CO., LTD Bluetooth speaker 7038421 BIC Instruction 3 7
User Manual
VOL+
VOL-
VOL+
VOL-
Button description:
1. "VOL+" Press for volume increase
2. "VOL-" Press for volume decrease
3. Press for next song
4. Press for last song.
5. Short press for pause or answer/off the phone; long
press for change mode.
The interface description:
1. The charging and line in combination port
2. The microphone site.
3. ON/OFF switch.
Under BT Model:
Put switch to "on" position, the blue light quickly flashes.
Bluetooth is now pairing with your device. After a successful
connection, the blue light slowly flashes, sound will be issued
"dong" a tone.
Long press disconnect Bluetooth to "line in" mode
Under Line-in Model:
AUX audio playback: appendix provides the 3.5mm Audio + Micro
USB Charging combination cable which can play music by linking
to mobile phones, MP3, MP4, PC, IPOD and other audio devices.
Long press Disconnect "Line in" to Bluetooth mode.
Reminder:
In the AUX state "VOL-, VOL+" 2 keys remain valid, but the
previous and next song is controlled by the connected device
1. Please read the instructions carefully before using.
2. Avoid touch with liquids; keep away from water and out of
damp conditions.
3. Do not be located the speaker or cord near heat sources such
as radiators, heaters, air ducts, or direct sunlight.
4. Do not place a naked flame source such as candles on the mini
Speaker.
5. Recharge the battery with suitable voltage output (5V/400mAh).
6. Do not hit the product severely or insert any conductive objects
into the speaker/ charging jack.
7. Do not block the speaker grill when the speaker is running.
8. Stop using at once if it becomes hot, smoke, burning smell,
non-normal noise, or fire is noticed coming from product.
9. Do not repair on your own. Seek the help of a professional.
10. To avoid electrical shock. Do not touch product with wet
hand.
11. Keep out of reach of children.
No Sound:
1. Audio cable is not fully plugged into the 3.5mm audio part on
Device.
2. Audio cable is damaged.
3. Source of audio is not working.
4. No LED Indication when audio cable is plugged.
5. Mini speaker is out of power.
No Charge:
1. Input power source is not normal.(5V/400mAh)
2. Charging cable is not fully plugged into the charging port.
3. Charging cable is damaged.
4. Battery failure
NO LED Indication:
1. LED indication failure.
2. No battery power left.
3. Charging cable is not fully plugged into the socket.
This mini audio box can be deemed as perfect Combination
of classical and modern performance. New aluminum vibration
film loud speaker which has clear alt and pure woof, that you
can take with you enjoy anywhere.
FEATURES:
1. Portable Speaker for your smartphone, tablet, laptop, or MP3
Player.
2. Lightweight, small in size but incredible sound.
3. Metal housing provides protection and a great sound.
4. UP to 2-3 hours playback time with full charge.
Components included
1. Mini speaker
2. 3.5mm Audio+Micro USB charging combination cable
3. User manual
TROUBLESHOOTING
SAFETY CAUTIONS:
Manual for Bluetooth speaker
Po wer supply DC5V
Output power : 3W
Frequency: 2402-2480MHz
Signal & Noise ratio: ≥75dB
Inpedance: 4OHM
Output: 3.7V-4.2V+0.05V
Input: 5V
Batter y capacity: 400mAh
Speaker unit: 45mm
Bluetooth version: V2.1+EDR
Transmission distance: 10 meters
Case material: Aluminum case
Dimensions: 5cm×5cm×5.3cm
Weight: 110g
SPECIFICATIONS:
90mm
220mm
USER GUIDE
FCC Caution：
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
