NINGBO DOOYA MECHANIC and ELECTRONIC TECHNOLOGY DD6010 Emitter User Manual eDD6010 A 00

NINGBO DOOYA MECHANIC & ELECTRONIC TECHNOLOGY CO., LTD. Emitter eDD6010 A 00

Contents

User Manual

Technical support
T
Fucntion instructionTechnical specification
Input voltage3V(CR2430)
Transmitting frequency433MHz
Transmitting power10 milliwatt
Operating temperature-100C—500C
Transmssion distance200 meters open office
35 meters on two walls
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
Notice: transmitter do not exposed to moisture and strike, so as not to
affect life.When you use transmitter, if found emission distance obviously
short or less sensitive, please change another same new battery. Please
have batteries for recycling.
Type specification
T
Version NO. : A/00
5-channel emitter
DD6010 is 5-channel emitter,red light represents the currently selected
channel, press the current channel again, cancel selected channel,
when all the red light is bright, on behalf of the group control state.
Press stop, up, down key when the red light fast flash tips.
DD6010
EmitterSpecification
BackBracket
1
2
3
4
5
STOP
LED
Channel
selection
`
Up button Down button
When you press the Setting button, the
required use of tools,don’t be too sharp tool.
Setting
button
(P2)
