CONFIDENTIAL
OEM User’s Manual
Product: Mini-PCIe 802.11 b/g/n WiFi with BT4.0 Combo
Model: SX-PCEGN-BT
For Navico integration – this device is not be sold to the
general public
FCC ID: RAYWIFIBT1
IC: 4697A-WIFIBT1
The OEM must follow the following instructions and include
the following notices as required by FCC/IC on the product
and in the User’s Manual.
![](/img.php?id=2472104&img=bg2.png)
Date: October 18, 2014
(2/4)
CONFIDENTIAL
1 Integrator Instructions
This mobile single modular approval allows this Mini-PCIe 1x1 802.11 bgn WLAN with Bluetooth 4.0 module to be used as
a client in a host product without further radio intentional/un-intentional emission testing, pursuant to the following
instructions.
Allowable Antennas
The antenna(s) used in testing is listed in the test report in the public FCC database website. Use of other antennas is
allowable without further testing or submission as long as it is an identical or equivalent type with equal or lower gain.
However, antennas with higher gain must be tested and submission for approval to the FCC is required.
OEM Integrators
Antenna to user separation must be a minimum of 20 cm for mobile applications.
End-users must be provided with specific information required to satisfy RF exposure compliance for
the final host product.
End-users must not have access to instructions on how to remove or install the radio.
The antenna of this radio must not be co-located or used in conjunction with any other antenna or
transmitter.
Compliance of this radio in all final host configurations is the responsibility of the grantee.
![](/img.php?id=2472104&img=bg3.png)
Date: October 18, 2014
(3/4)
CONFIDENTIAL
2 Notifications
FCC ID: RAYWIFIBT1
IC: 4697A-WIFIBT1
The following must be placed in the End-User manual.
NOTICE
Federal Communication Interference Statement (United States only)
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Re-orient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter.
FCC Rules, Part 15
This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference, including interference that may cause undesired operation of this
device.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC
radio frequency (RF) Exposure Guidelines in Supplement C to OET65 radio frequency (RF) Exposure rules. This
equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body
(excluding extremities: hands, wrists, feet and ankles).
Canadian Depertment of Communications Industry Canada Notice (Canada only)
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Industry Canada
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference, including interference that may cause undesired operation of this
device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes :
![](/img.php?id=2472104&img=bg4.png)
Date: October 18, 2014
(4/4)
CONFIDENTIAL
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets the radio
frequency (RF) Exposure Guidelines in RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should
be installed and operated keeping the radiator at least 20cm or more away from person’s body (excluding extremities:
hands, wrists, feet and ankles).
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non
contrôlé et respecte les règles les radioélectriques (RF) de d’exposition aux fréquences radioélectriques (RF)
CNR-102 de l’IC. Cet équipement doit être installé et utilisé en gardant une distance de 20 cm ou plus entre le
dispositif rayonnant et le corps (à l’exception des extrémités : mains, poignets, pieds et chevilles).
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or
lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the
antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than
that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une
antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but
de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type
d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité
nécessaire à l'établissement d'une communication satisfaisante.
This radio transmitter (identify the device by certification number, or model number if Category II) has been approved by
Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna
impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the
maximum gain indicated for that type, are strictly prohibited for use with this device.
Le présent émetteur radio (identifier le dispositif par son numéro de certification ou son numéro de modèle s'il fait
partie du matériel de catégorie II) a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne
énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les
types d'antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement
interdits pour l'exploitation de l'émetteur.
For product available in the USA/Canada market, only channels 1-11 can be operated. Selection of other channels is not
possible.
Antenna: TE Connectivity
Antenna gain information: Embedded Antenna: 4.2dBi (2.4 GHz)
Frequency Tolerance:+/-20ppm
WARNING:
The FCC / The Industry Canada regulations provide that changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
Manual and Product Labeling information For The OEM
The end user manual shall include all required regulatory information/warning as shown in this manual. And when this
module is installed in the host product, it will include "Contains FCC ID: RAYWIFIBT1" and “Contains IC: 4697A-WIFIBT1”
on the outside label of the host product.
