Nedap N V UPRO1356 Inductive Proximity RFID Cardreader User Manual Brochure
N. V. Nederlandsche Apparatenfabriek NEDAP Inductive Proximity RFID Cardreader Brochure
Contents
- 1. Brochure
- 2. User Manual
Brochure
PHYSICAL SPECIFICATIONS SHIELDED READER
Article numbers: 9964657
Dimensions (mm): Reader: 240 x 118 x 53,5 (l x w x h)
Antenna: 275 x 275 x 15 (l x w x h)
Material: Metal / Trespa
Colour: Dark grey
Weight: 1.5 kg
Function: Check-in / check-out / staf f-station
Mo un tin g: Un der n eat h t abl e / d es k
ELECTRICAL SPECIFICATIONS
Supply voltage: 100- 230 V ac, 50-60 Hz.
Working voltage: 9 V
Power consumption: Max. 5 Watt
Le ng th po wer c abl e: 1.5 m
CONNECTION / COMMUNICATION SPECIFICATIONS
Communication ports: USB / UTP
Max. length communication cable: USB: 10 m / UTP: 90 m
Software installation procedure: CD
Min. system requirements OS: Windows 7 / XP with .Net2 sp3
Other: CD / DVD-drive
Compatibility (Software Nedap Librix): Bibliocheck4 Conversion / Lite / Selfservice
ENVIRONMENTAL SPECIFICATIONS
Operational temperature: +10 / +40 °C
Storage temperature: -10 / +55 °C
Min. distance between two antennae: 50 cm
Do not mount near: Metal
Do not mount up / under: Metal desk / table or
desk / table w ith metal f rame
RFID SPECIFICATIONS
Technology: RFID
Frequency: 13.56 MHz
Antenna power (electrical): Max. 1 mW.
Identifies: ISO 15693, ISO 18000-3.1
Dimensions detection field: Approx. 30 cm above antenna
EAS-function: Using EAS Bit (NXP-IC) / AFI
WARRANTY / CERTIFICATES
Certificate: CE / FCC / IC
Warranty: 1 year
FCC / IC identification: CGDUPRO1356, 1444A-UPRO1356
Approvals of the power adaptor: - c UL us according to UL/CSA 60950-1
- Japan PSE
- CE according to EN60950-1
- FCC compliant
Version 1.0
Specifications are subject to change without notice
proximity reader 13.56 mhz
beyond the book
proximity reader 13.56 mhz
replacing barcode scanners
the staff station functionally replaces the barcode scanner. the unit enables
staff to identify all rfid-labeled items.
out-of-view installation
This RFID reader offers a specially developed unshielded reader. This reader can be
installed on a desk or table. The reader can be connected to existing hardware (PC)
and/or Library Management Systems.
software
The Bibliocheck4 Lite software makes it possible for the reader to co-operate without
any adjustments to your existing Library Management System. Besides that Nedap
Librix offers software for libraries to fully integrate the reader in the LMS.
Books, CDs, DVDs and other materials containing an RFID-label can be converted
online or offline using the Bibliocheck4 Conversion software package. Optional
expansions are available as well.
benefits
- Easy to install
- Network or USB Connection
- Remote supervision
- EAS-activation / deactivation
- Multi-label ID
contact
Nedap Librix
Parallelweg 2d
7141 DC Groenlo
The Netherlands
T +31 (0) 544 47 11 11
F +31 (0) 544 46 58 14
E info@nedaplibrix.com
www.nedaplibrix.com
NOTE: Do not use these drawings for installation purposes. Ask your local supplier for technical drawings.
fcc and ic certifications
FCC for USA according to Part 15 with FCC ID: CGDUPRO1356
IC for Canada according to RS-210 with IC: 1444A-UPRO1356
Part 15.19(3) and RSS_Gen Labelling
This device complies with part 15 of the FCC Rules and to RSS-210 of Industry Canada.
Operating is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Cet appareil se conforme aux normes RSS 210 exemptés de license du Industry Canada.
L’opération est soumis aux deux conditions suivantes :
(1) cet appareil ne doit causer aucune interférence, et
(2) cet appareil doit accepter n’importe quelle interférence, y inclus interférence qui peut
causer une opération non pas voulu de cet appareil.
Warning (part15.21)
Changes or modifications not expressly approved by party responsible for compliance
could void the user’s authority to operate the equipment.
Tabletop reader:
Antenna (Tabletop):
172,5
12,5
240
118
53,5
88
210
210
14,4
