Neptune Technology Group NTGPKT1101 Pocket Proof Reader User Manual Neptune s

Neptune Technology Group Inc. Pocket Proof Reader Neptune s

Manaul

Pocket ProReader RF
READ key - used to interrogate a meter :
(transmits captured read via RF)
1. Position probe end onto remote pad.
2. Press the READ key
A short audible tone accompanies display
of meter data……
S:=meter reading S:123455 W ONE
I:= encoder ID # I: 12345678 00
This data remains on the screen until ;
another read is captured, a key is pressed,
or the unit powers down.
REVIEW key - used to review / re-transmit
the currently displayed reading. May review
/ re-transmit up to the last five captured
readings.
1. Press REVIEW to see the previously
captured readings.
When a low battery is detected, a message
will appear;
LOW BATTERY
Recharge the battery if you see this message.
The display will go blank after about 4
minutes of no activity.
Press REVIEW to re-start.
READING ERROR
Usually caused by;
a. end probe not aligned with remote pad
b. no encoder is connected to remote pad
c. encoder is not connected properly to
remote pad
d. connecting wire is cut or broken
Other Errors
SHORT : displayed as an “H”
indicates odometer contains a short circuit.
Displayed as………S: 12HH55
OPEN : displayed as a “-“ (dash)
indicates odometer contains an open circuit.
Displayed as………S: 12--55
RECHARGING : Use charger supplied with
this unit only. During daily use, recharge the
unit overnight, every night. During periods
of storage or "non-use", do not charge the
unit. Then, 12 hours prior to the next use,
recharge the unit.
Document Part # 12106-001
Form # OM-191C-D
Class B Digital Device
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference when the equipment is operated
in a residential environment. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
Information to User
Any changes or modifications to this equipment not
expressly approved by Neptune could void the user’s
authority to operate the equipment.
