Netac Technology COOBAY Home Network Drive User Manual COOBAY Product description
Netac Technology Co., Ltd Home Network Drive COOBAY Product description
user manual
COOBAY User manual
Product instruction
With the coming of the family Digital life, home and family are the center of digital photos,
video and family members favorite Internet movie and hd movies, music, etc on storage space
and convenience requirement is more and more big, the family more than internal digital
content consumption source (all kinds of players, terminal) and source (various recording
terminal, network), need to be in all sorts of equipment back and forth between, frequent
mobile data to the computer hard disk or move hard disk storage and backup for individuals of
storage ways, already no longer for a screen family. A new storage concept, "for centralized
storage, also share, wireless transmission, simplify the management" become development
trend.
Coobay Personal Cloud Storage Device is designed for the SOHO and household design
entry-level and economical network storage equipment, with more than one server of the
function, and have low consumption electricity, high reliability and excellent performance of the
system, etc. Carrying Marvell high-performance processor and 512 MB DDRII memory, in
contrast to the traditional PC server the high power consumption, and cool the system
operation of power consumption is extremely low, users consider environmental protection and
energy saving is the first choice of plan.
Cool the support of cross-platform work environment, besides backup function besides,
with abundant server functions, in addition to general application of the FTP server, file servers,
printers outside the server, at the same time is also more multimedia platform terminal video
data storage center, as make digital family of good assistant. Built-in UPnP/DLNA media server,
can support a series of DLNA multimedia video player, such as: SONY PS3, Microsoft psu on
Xbox 360 game console, etc.; Can be compatible with NFS High Definition (High-Definition)
multimedia video player do the union, the existence of the video streaming data berry cool to
shown on TV High resolution video. In addition, the cool support of the high-speed BT/HTTP
download, tie-in PC clients and the download WEB management management tools, more may
at any time anywhere the management all download a task.
Product use features：
1. Will the media and file storage on his personal cloud
Create your own personal cloud, do not need to pay rental, grasps the trace of the data.
Will the media and file storage in the hard drive, can safely access them via the Internet. Or in
the translation of the computer or on a smartphone, through the mobile application to access
them with ease. Mobile equipment is equivalent to get BaiWanZhao bytes extra storage space.
2.Support will content streaming to the hd TV
On television daughter's birthday party enjoy video, or displaying the holiday slides. The
built-in media server can will music, photos, and movie streaming DLNA ® to any
authentication multimedia equipment, such as network media player, Blu-ray Disc ® player,
psu on Xbox 360 ™ or PlayStation ® 3 and connection of television, through DLNA 1.5 and
UPnP authentication.
3.All the sharing of computer storage device
1
Now the whole family can film, music, photos, and important documents stored in a
location for each member of the home sharing. Only need to cool the equipment boot, can use
the home any PC or Mac computer storage and access the file.
4.For all the computer provides automatic wireless backup
Will all the PC computer wireless network backup to a reliable position, protect precious
memory. Windows ® users can use the client software for backup.
5.Speed from bit effect
The built-in high-speed CPU, with high performance, for all application with streaming
remote access and support. This product USES the Ethernet chip field the most advanced
technology, read speed leading products, beyond the traditional USB 2.0 hard drive.
6. Use iTunes music played
Support iTunes server function, it can be the music and video collection on stored in
together, and then use their iTunes streaming to Mac or PC computer.
The character of our
1. IEEE 802.11 n 300 Mbps wireless transmission rate, provide high bandwidth wireless router
function.
2.Adaptive 10/100/1000 Mbps network port, speed, not be bit effect.
3. Great capacity data storage center, will the media and file storage on his personal cloud
4. Provide many user management and permission levels function, can be divided for
independent users illicit close storage interval, provide high security mechanism.
5. File sharing server functions, all the computer and mobile terminal of the Shared storage
devices. Mobile phones, tablet computer, the notebook and desktop computers, TV sets and
terminal more real-time sharing platform.
6. The built-in Web management function, provide the management interface Web form and
file management.
7. Smart phone data, support the telephone, terminal email backup and restore function.
8. Seamless integration with iTunes, but through the iTunes software visit cool music files of
the interior.
9. The built-in network to print the server, can will USB printer connected to the USB Port,
through the network to share printers function.
10. Offline BT download function, don't have to open the personal computer, realize the large
capacity movies and software download files.
11. The built-in media server, support DLNA compatibility digital multimedia equipment.
12. USB2.0 interface can be through expanded memory capacity, for external USB storage
devices provide Internet access functions.
13. Provide high-speed copying function for the external USB storage devices and cool the data
exchange offer high speed channel.
14. Support remote access, let you at any time, any place, can use a web browser remote
access your files, and away at need to exchange data with very convenient.
2
Specifications:
Support standards and
protocols IEEE 802.11g、IEEE 802.11b、IEEE 802.11n、IEEE 802.3、IEEE 802.3u 、
IEEE 802.3x 、IEEE 802.1X 、TCP/IP、DHCP 、PPPoE
LAN One 10/100M/1000M，RJ45 (Auto MDI/MDIX)
WAN One 10/100M/1000M，RJ45 (Auto MDI/MDIX)
USB two USB 2.0 HOST
Power mouth Power supply 12V 50Hz 3.0A
Port
RESET key Restore the default configuration, system reset button
Frequency range 2.412～2.462GHz
Transmission rate 11b ：1/2/5.5/11Mbps
11g ：6/9/12/18/24/ 36/48/54Mbps
11n ：150Mbps （maximum）
Working channel
number 11
Exhibition
frequency
technology DSSS
Data modulation
mode
11n ：OFDM（QPSK,BPSK,16-QAM,64-QAM）
11g ：OFDM（QPSK,BPSK,16-QAM,64-QAM）
11b ：CCK,QPSK,BPSK
Medium access
agreement CSMA/CA with ACK
Data encryption WPA/WPA2；64/128-WEP ；TKIP/AES
Antenna number 2PCS
Wireless
parameters
Antenna type built-in
10Base-T：3 types or3 types UTP above
Network media 100Base-TX ：5 types UTP above
port WAN/LAN
LED other WIFI，HDD，Power instructions
Dimension (L x W x H) 195mm x 195mm x 47mm
Working temperature：0ºC - 50ºC
Storage temperature：-40ºC-70ºC
Work humidity：10% - 90% RH no condensing
Use of the environment
Storage humidity：5% to 90% RH no condensing
3
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. In order to avoid the possibility of exceeding the FCC radio frequency
exposure limits, Human proximity to the antenna shall not be less than 20cm (8 inches)
during normal operation.
4
