Notification of Compliance
Regulatory Compliance Information
This document includes user requirements for operating NETGEAR products in accordance with national laws
including usage of radio spectrum and operation of radio devices. Failure of the end-user to comply with the
applicable requirements may result in unlawful operation and adverse action against the end-user by the applicable
national regulatory authority.
The NETGEAR product firmware limits operation to only the channels allowed in a particular region or country.
Therefore, all options described in this document may not be available in your version of the product.
This document applies to both Class A and Class B devices:
x Class A devices are intended to be used in a commercial or industrial environment. They are not intended
to be used in a residential home or be available for general public use.
x Class B devices are intended to be used in a residential setting, and may also be used in commercial and
industrial applications. Examples of Class B devices are telephones, personal computers, and residential
data gateways.
x Fuses should only be installed by service personnel.
x NETGEAR recommends the use of 26 AWG or larger gauge phone line cords.
Europe – EU Declaration of Conformity
This section applies to products bearing the CE or CE! mark:
Products bearing the CE or CE! mark comply with the following EU directives:
x EMC Directive 2004/108/EC
x Low Voltage Directive 2006/95/EC
x Ecodesign Directive 2009/125/EC
x RoHS Directive 2011/65/EU
If the product has telecommunications functionality, it also complies with the requirement of the following EU
directive:
x R&TTE Directive 1999/5/EC
Compliance with these directives implies conformity to harmonized European standards that are noted in the EU
Declaration of Conformity. The EU CE Declaration of Conformity may be found at
http://support.netgear.com/app/answers/detail/a_id/11621/.
Caution for installing this equipment outdoors: (Valid in all EU member states, EFTA states, and Switzerland.) Be
aware that outdoor installations require special attention and will only be handled by trained and qualified installation
personnel. No one from the general public is permitted to install NETGEAR wireless products outdoors when
external antennas, power and grounding must be installed for use. Particular attention has to be given allowed
operational frequencies. Contact NETGEAR for instructions on how to contact an installer for outdoor operations if
this product requires the special considerations for outdoor installations. For detailed iformation concerning
installations in France, the user should contact the national spectrum authority in France (http://www.arcep.fr/ )
The following paragraphs apply to WN2500RP:
This device is a 2.4GHz and 5GHz wideband transmission system (transceiver), intended for indoor use only in all EU
member states, EFTA states, and Switzerland.
In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain authorization to
use the device for setting up outdoor radio links and/or for applying public access to telecommunications and/or
network services.
This device may not be used for setting up outdoor radio links in France and in some areas the RF output power may
be limited to 10mW EIRP in the frequency range of 2454-2483.5 MHz. For detailed information the end-user should
contact the national spectrum authority in France.
Warning
NETGEAR Class A products that may be utilized in domestic/residential environments may cause radio interference
in which case the user may be required to take adequate measures.
FCC Requirements for Operation in the United States
Information in this section applies to products bearing the FCC mark (or statement):
FCC Information to User
This NETGEAR product does not contain any user serviceable components and is to be used with approved
antennas only. Any product changes or modifications will invalidate all applicable regulatory certifications and
approvals.
The following statement applies to these products:
x C6300
x WN2500RP
x C6300XB3
x WN3000RPv2
x EX6100
x WN3500RP
x EX6200
x HMNC100
x STS7000
x VEGN2200
x WN370
This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or
transmitter except in accordance with FCC multi-transmitter product procedures.
FCC Guidelines for Human Exposure
This NETGEAR product complies with FCC radiation exposure limits set forth for an uncontrolled environment. The
equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body.
FCC Declaration of Conformity
We, NETGEAR, Inc., 350 East Plumeria Drive, San Jose, CA 95134, declare under our sole responsibility that this
product complies with Part 15 Subpart B of FCC CFR47 Rules. Operation is subject to the following two conditions:
x The device may not cause harmful interference, and
x The device must accept any interference received, including interference that may cause undesired
operation.
FCC Radio Frequency Interference Warnings & Instructions
The NETGEAR product has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following methods:
x Reorient or relocate the receiving antenna.
x Increase the separation between the equipment and the receiver.
x Connect the equipment into an electrical outlet on a circuit different from that which the radio receiver is
connected.
x Consult the dealer or an experienced radio/TV technician for help.
FCC RF Radiation Exposure and SAR Statements
The information in this section applies to products that transmit data or communicate wirelessly.
SAR Statement
The information in this section applies to NETGEAR wireless products that are intended to be operated close to
human body.
NETGEAR products that are intended to be operated close to the human body are tested for body-worn Specific
Absorption Rate (SAR) compliance. The SAR limit set by the FCC is 1.6 W/kg.
The FCC has established detailed SAR requirements and NETGEAR products meet these requirements.
NETGEAR USB products were tested while installed in a host notebook computer.
RF Exposure Information
NETGEAR products have been evaluated under FCC Bulletin OET 65C (01-01) and found to be compliant to the
requirements as set forth in CFR 47 Sections, 2.1093, and 15.247 (b) (4) addressing RF exposure from radio
frequency devices. NETGEAR products meet the applicable government requirements for exposure to radio
frequency waves. To see the test results reporting the highest SAR level measured for this device, visit
http://www.netgear.com/about/regulatory/declarations-conformity/
Radiation exposure: NETGEAR products comply with radiation exposure limits set forth for an uncontrolled
environment and meet radio frequency (RF) exposure guidelines for wireless routers. NETGEAR products should be
installed and operated keeping the product 20cm or more away from a person’s body. For devices that are battery
powered and may be operated closer than 20cm to you, refer to the NETGEAR website for exposure levels.
FCC Caution
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate this equipment.
NETGEAR products comply with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1)
NETGEAR products may not cause harmful interference, and (2) NETGEAR products must accept any interference
received, including interference that may cause undesired operation.
For products available in the USA market, only channel 1~11 can be operated. Selection of other channels is not
possible.
The following statement applies to these products:
x C6300
x WN3500RP
x EX6100
x EX6200
x HMNC100
x VEGN2200
x WN370
x WN2500RP
x WN3000RPv2
The device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or
transmitter except in accordance with FCC multi-transmitter product procedures.
The following statement applies to these products:
x C6300
x C6300XB3
x EX6100
x EX6200
x HMNC100
x STS7000
x WN2500RP
The device operates in 5.15~5/25GHz frequency range. It is restricted in indoor environment only.
Non-DFS Warning
NETGEAR non-DFS products do not support operation in the 5600-5650MHz band. The firmware on the device
restricts the operation in this frequency band and does not utilize the channels in this band.
NETGEAR non-DFS products will not permit operations on channels 120–132 for 11a and 11n/a, which overlap the
5600–5650MHz band.
Country Code Selection Usage (WLAN devices)
The country code selection is for non-US model only and is not available to all US model. Per FCC regulation, all
WiFi product marketed in US must fixed to US operation channels only.
TV Tuner (on Selected Models)
The information in this section applies to NETGEAR products incorporating a TV tuner.
Note to CATV System Installer: This reminder is provided to call the CATV system installer’s attention to Section 820-
93 of the National Electrical Code, which provides guidelines for proper grounding and, in particular, specifies that the
Coaxial cable shield be connected to the grounding system of the building as close to the point of cable entry as
possible.
Canadian Department of Communications Radio Interference
Regulations
The information in this section applies to products bearing the statements:.
“This digital apparatus does not exceed the Class B limits for radio-noise emissions from digital apparatus
as set out in the Radio Interference Regulations of the Canadian Department of Communications.”
“Cet appareil numérique ne dépasse pas les limites de la classe B pour les émissions radio bruit des
appareils numériques, tel qu'énoncé dans le Règlement sur le brouillage radioélectrique du ministère des
Communications du Canada.”
CAN ICES-3 (B)/NMB-3(B)
CAN ICES-3 (A)/NMB-3(A)
Industry Canada
NETGEAR products comply with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) NETGEAR products may not cause harmful interference, and (2) NETGEAR products
must accept any interference received, including interference that may cause undesired operation.
x HMNC100
x WN370
Ce dispositif est conforme à la norme CNR d'Industrie Canada applicable aux appareils radio exempts de licence.
Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage
préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer
un fonctionnement indésirable.
x HMNC100
x WN370
IMPORTANT NOTE: Radiation Exposure Statement
NETGEAR products comply with IC radiation exposure limits set forth for an uncontrolled environment. NETGEAR
products should be installed and operated with minimum distance 20cm between the radiator and your body.
For products available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is
not possible.
The following statement applies to these products:
x EX6100
x EX6200
x HMNC100
x STS7000
x VEGN2200
x WN370
x WN2500RP
x WN3000RPv2
The device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or
transmitter except in accordance with IC multi-transmitter product procedures.
The following statement applies to these products:
x EX6100
x EX6200
x HMNC100
x STS7000
x WN2500RP
The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co-
channel mobile satellite systems.
DFS warning:
NETGEAR DFS (Dynamic Frequency Selection) products that operate in the bands 5250- 5350 MHz, 5470-
5600MHz, and 5650-5725MHz:
The following statements apply to this product:
x HMNC100
x STS7000
The maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz to comply with
the EIRP (Equivalent Isotropically Raditaed Power) limit.
Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands
5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN
devices.
SAR warning:
NETGEAR product is compliance with SAR for general population/uncontrolled exposure limits in IC RSS-102 and
had been tested in accordance with the measurement methods and procedures specified in IEEE 1528.
NOTE IMPORTANTE: Déclaration d'exposition aux radiations
Pour les appareils qui transmettent des données sans fil: Cet équipement est conforme aux limites d'exposition aux
rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un
minimum de 20 cm de distance entre la source de rayonnement et votre corps.
Pour les produits disponibles aux États-Unis / Canada du marché, seul le canal 1 à 11 peuvent être exploités.
Sélection d'autres canaux n'est pas possible.
La déclaration suivante s'applique à ces produits:
x EX6100
x EX6200
x HMNC100
x STS7000
x VEGN2200
x WN370
x WN2500RP
x WN3000RPv2
Cet appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association avec une autre
antenne ou transmetteur.
La déclaration suivante s'applique à ces produits:
x EX6100
x EX6200
x HMNC100
x STS7000
x WN2500RP
les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur
afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux.
DFS avertissement:
Sélection dynamique de fréquences (DFS) pour les dispositifs fonctionnant dans les bandes 5250-5350 MHz, 5470-
5600 MHz et 5650-5725 MHz :
Les instructions suivantes s'appliquent à ce produit:
x HMNC100
x STS7000
le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5250-5350 MHz et 5470-5725 MHz doit se
conformer à la limite de p.i.r.e.
De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars de haute puissance sont désignés
utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5250-5350 MHz et 5650-5850 MHz et que ces
radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
Avertissement SAR:
NETGEAR est le respect de SAR pour la population générale / limites d'exposition incontrôlée de CNR-102 et a été
testé en conformité avec les méthodes et procédures de mesure spécifiées dans la norme IEEE 1528.
Interference Reduction Table
The table below shows the Recommended Minimum Distance between NETGEAR equipment and household
appliances to reduce interference (in feet and meters).
Recommended Minimum Distance (in feet and meters)
30 feet / 9 meters
20 feet / 6 meters
40 feet / 12 meters
20 feet / 6 meters
30 feet / 9 meters
20 feet / 6 meters
ZigBee
20 feet / 6 meters
Japan Notices VCCI
This information in this section applies to products bearing the VCCI mark:
Class A ITE
ࡇࡢ⿦⨨ࡣࠊࢡࣛࢫ A ᝟ሗᢏ⾡⿦⨨࡛ࡍࠋࡇࡢ⿦⨨ࢆᐙᗞ⎔ቃ࡛౑⏝ࡍࡿ࡜㟁Ἴጉᐖࢆᘬࡁ㉳ࡇࡍࡇ࡜ࡀ࠶ࡾࡲ ࡍ
ࠋࡇࡢሙྜ࡟ࡣ౑⏝⪅ࡀ㐺ษ࡞ᑐ⟇ࢆㅮࡎࡿࡼ࠺せồࡉࢀࡿࡇ࡜ࡀ࠶ࡾࡲࡍࠋ
Class B ITE
ࡇࡢ⿦⨨ࡣࠊࢡࣛࢫB᝟ሗᢏ⾡⿦⨨࡛ࡍࠋࡇࡢ⿦⨨ࡣࠊᐙᗞ⎔ቃ࡛౑⏝ࡍࡿࡇ࡜ࢆ┠ⓗ࡜ࡋ࡚࠸ࡲࡍࡀࠊࡇࡢ⿦⨨
ࡀࣛࢪ࢜ࡸࢸࣞࣅࢪࣙࣥཷಙᶵ࡟㏆᥋ࡋ࡚౑⏝ࡉࢀࡿ࡜ࠊཷಙ㞀ᐖࢆᘬࡁ㉳ࡇࡍࡇ࡜ࡀ࠶ࡾࡲࡍࠋ
ྲྀᢅㄝ᫂᭩࡟ᚑࡗ࡚ṇࡋ࠸ྲྀࡾᢅ࠸ࢆࡋ࡚ୗࡉ࠸ࠋ
Japan Wireless Notice
ࡇࡢ〇ရ࡟ࡣࠊㄆド῭ࡳࡢ↓⥺ᶵჾࢆᦚ㍕ࡋ࡚࠸ࡲࡍࠋ
South Korea Notices
The information in this section applies to products bearing the KCC mark:
㞢Ⱂ : ╖䞲⹒ῃ㦒⪲ ⺆㏷♮⓪ 㩲䛞㧎 ἓ㤆
Class A :
A
  ₆₆
(
㠛ⶊ㣿
⹿㏷䐋㔶₆㧦㨂
)
㧊 ₆₆⓪ 㠛ⶊ㣿(A ) 㩚㧦䕢㩗䞿₆₆⪲㍲ 䕦ⰺ㧦 ⡦⓪ ㌂㣿㧦⓪ 㧊 㩦㦚
㭒㦮䞮㔲₆ ⹪⧒Ⳇ, Ṗ㩫㣎㦮 㰖㡃㠦㍲ ㌂㣿䞮⓪ ộ㦚 ⳿㩗㦒⪲ 䞿┞┺.
Class B :
B
  ₆₆
(Ṗ㩫㣿 ⹿㏷䐋㔶₆㧦㨂)
㧊 ₆₆⓪ Ṗ㩫㣿(B ) 㩚㧦䕢㩗䞿₆₆⪲㍲ 㭒⪲ Ṗ㩫㠦㍲ ㌂㣿䞮⓪ ộ㦚
⳿㩗㦒⪲ 䞮Ⳇ, ⳾✶ 㰖㡃㠦㍲ ㌂㣿䞶 㑮 㧞㔋┞┺.
Taiwan WWAN Wireless Notice
The information in this section applies to products bearing the Taiwan National Communications Commission mark:
This telecom equipment has complied with NCC regulations.
➨༑஧ᲄ→⥂ᆺᘧㄆㆇྜ᱁அపຌ⋡ᑕ㢖㟁ᶵ㸪㠀⥂チྍ㸪බྖ㸪ၟ⹰ᡈ౑⏝⪅ᆒ୙ᚓ᧩⮬ㆰ᭦㢖⋡ࠊຍ
኱ຌ⋡ᡈㆰ᭦ཎタィஅ≉ᛶཬຌ⬟ࠋ
➨༑ᅄᲄ→పຌ膚萳萛詒罁識萦蠯菘肥蝞蹫萌蹉虡訰缝糗蠃踵茽赦蘘க維苨躇袼糗蠃躇蒙藸ஆ褒覄騚詭蠯
ஆ閳紮蓙譱艸糗蠃藸苷肥緌蕔萦蠯ଟ
๓㡯ྜἲ㏻ಙ㸪ᣦ౫㟁ಙἲつᐃసᴗஅ↓⥺㟁㏻ಙࠋ పຌ膚萳萛詒罁薧襠蕯踵茽赦蘘軫縒蛩ଞ縢踕缝褧蠋
蠯詒赽距萳蔒詒罁蓿菤識糗蠃ଟ
ᅾ 5.25-5.35 ⛟㉪㢖ᖔ羧諀覥識艸蓧覣蘩訯薜蓿菤ஆ踥蛍蘯羧萦蠯ଟ
↓⥺㈨イബ㍺タഛᚸཷྜἲ㏻ಙஅᖸᨐୟ菘肥糗蠃踵茽赦蘘க蛰諠蔔糗蠃ஆ褒覄騚詭蠯ஆ萧艸糗蠃識衐ஆ
藮肥緌蕔萦蠯ଟ
↓⥺㈨イബタഛⓗ〇㐀ᘂၟ᠕☜ಖ㢖膚螾話蔒ஆ蛰褕誯諠诶蒁萦蠯蕻谓葽蔱藔誀蒇諀覥ஆ苨萳訝蘘軣褒裒
譞蛍諀覥萛耸譄ࠋ
Thailand Notice
The information in this section applies to products approved by the Thailand National Communications Commission:
เครืองโทรคมนาคมและอุปกรณ์นี มีความสอดคล้องตามข้อกําหนดของ กทช.
China Notices
The information in this section applies to products bearing the Chinese Complusory Certification Mark:
This device complies with the requirements in China for Safety and Quality
ṈᷢA乏ṏရ㸪ᅾ⏕ά䍗ቃ宍ṏရྍ⬟఍㐀ᡂ᪢乧䓝ᖸ㈘㸪ᅾ征⛇᝟෫ୗྍ⬟㟂
せ⏝㇟⮡඼ᖸ㈘㔗ྲྀ◴⭆ྍ⾜ⓗᥐ᪋ࠋ
Australia and New Zealand Notices
The information in this section applies to products bearing the Australia C-Tick and A-Tick Compulsory Marks:
This device equipment complies with the Australian and New Zealand regulatory approvals requirements.
Warning
NETGEAR Class A products that may be utilized in domestic/residential environments may cause radio interference
in which case the user may be required to take adequate measures.
Powerline Device Safety Information
Follow these safety guidelines to ensure your own personal safety and to help protect your system from potential
damage:
x For national approvals (approval schemes other than CB), relevant national standards for plug, socket-
outlet, and direct plug-in units (for example, US) shall also be consulted while testing and approving such
products according to the national standards.
x Check the electrical current for any device plugged into the filtered AC socket. Do not exceed home and
product outlet ratings and electrical requirements.
x The socket-outlet shall be installed near the equipment and be easily accessible
x Only power cords and allowed to be inserted into the filtered AC socket; no other equipment with a direct
plug-in is allowed. Power cords needs to be a maximum of 1m long and a minimum of 0.75mm² of cross-
sectional area.
x Do not plug devices into the Powerline Pass Thru Adapter filtered AC outlet that exceed the product ratings.
The output voltage of the filtered AC outlet is the same as the power outlet that the Powerline Pass Thru
Adapter is plugged into. To help avoid damaging your system, be sure that the attached devices are
electrically rated to operate with the power available in your location.
x If the input AC voltage is less than 100 Vac, the device plugged into the filtered AC socket of the Powerline
Pass Thru Adapter might not perform as well as expected.
x DO NOT PLUG MAJOR HOME APPLIANCES into the filtered AC socket or into an attached power strip.
The device is not intended to be used with home appliances such as air conditioners, power tools, space
heaters, fans hair dryers, ovens, or refrigerators.
x Actual data throughput will vary. Network conditions and environmental factors, including volume of network
traffic, building materials and construction, and network overhead, lower actual data throughput rate.
x Do not service any product except as explained in your system documentation.
x Opening or removing covers that are marked with the triangular symbol with a lightning bolt can expose you
to electrical shock. Only a trained service technician should service components inside these
compartments.
x Use the product only with approved equipment.
x Allow the products to cool before removing covers or touching internal components.
x To help avoid damaging your system, be sure that the voltage selection switch (if provided) on the power
supply is set o match the power available at your location:
o 110 volts (V), 60 hertz (Hz) in most of North and South America and some Far Eastern countries
such as south Korea and Taiwan
o 100, 50 Hz in eastern Japan and 100, 60Hz in western Japan
o 230v, 50Hz in most of Europe, the Middle East, and the Far East
x The peripheral power cables are equipped with three-prong plugs to help ensure proper grounding. Do not
use adapter plugs or remove the grounding prong from a cable.
x Observe extension cable and power strip ratings. Make sure that the total ampere rating of all products
plugged into the extension cable or power strip does not exceed 80 percent of the ampere ratings limit for te
extension cable or power strip.
x To help protect your system from sudden, transient increases and decreases in electrical power, use a
surge suppressor, line conditioner, or uninterruptible power supply (UPS).
Rack Mount Safety Instructions
This information applies to the installation of NETGEAR rack mount products
x Ambient operating temperature. If the switch is installed in a closed or multiunit rack assembly, the
ambient operating temperature of the rack environment might be greater than the ambient temperature of
the room. Therefore, consider installing the equipment in an environment compatible with the maximum
rated ambient temperature.
x Reduced airflow. Mount the equipment into a rack so that the amount of airflow required for safe operation
is not compromised.
x Mechanical loading. Mount the equipment into a rack so that a hazardous condition does not arise due to
uneven mechanical loading.
x Circuit overloading. Consider the equipment’s connection to the power supply circuitry and the effect that
any possible overloading of circuits might have on overcurrent protection and power supply wiring. Consider
equipment nameplate ratings when addressing this concern.
x Reliable grounding. This product requires reliable grounding to be maintained at all times. To ensure this,
ground the rack itself. Pay particular attention to power supply connections other than the direct connections
to the branch circuit (for example, the use of power strips).
x Clearance. Leave enough clearance in front of the rack (about 25 inches) to enable you to open the front
door completely and in the back of the rack (about 30 inches) to allow for sufficient airflow and ease in
servicing.
NETGEAR, Inc., 350 E. Plumeria Avenue, San Jose, CA 95134 USA
February 2014

Navigation menu
