Dual Band 802.11ac Wireless Access Point Data Sheet
WAC120
Page 1 of 3
Features
The NETGEAR® Dual Band 802.11ac Wireless Access Point (AP) delivers
high performance for Small Oce and Home Oce (SOHO) deployments
and supports dual band concurrent operation at 2.4GHz and 5GHz with
combined throughput of 1.2 Gbps (300 Mbps at 2.4GHz and 867 Mbps GHz
at 5GHz). The WAC120 Wireless 802.11ac Access Point provides standalone
configuration with easy setup for a reliable, high-performance, and aordable
wireless solution.
High performance and superior coverage
•Up to 4x the speed of 802.11n networks
•Maximize coverage for optimal deployment
for SOHO
Comprehensive security
•Supports wireless security features
(WPA, WPA2)
•MAC based Access Control List to protect
against intruders
Interoperate with both new and legacy
clients
•Support latest 802.11ac wireless clients to
achieve maximum speed
•Backward compatible to allow legacy
devices to connect at their fastest speed
Easy to Configure
•Simple setup in minutes with intuitive
Graphical User Interface (GUI)
Standalone AP Deployment
GUEST
OFFICE
WAC120
Dual Band 802.11ac Wireless Access Point Data Sheet
WAC120
Page 2 of 3
Physical Characteristics
Power
•Country-specific plug: 12V / 1A (12W)
•1 Amp power adapter
•Power consumption:
8.1W (maximum)
Physical Dimensions
•Dimensions (L x W x H):
7.08 x 6.69 x 2.36 in
(180 x 170 x 60 mm)
Weight
•Weight: 0.71 lb (322 g)
Mounting
•Desktop
Interfaces and Indicators
Physical Interfaces
•One (1) 10/100/1000BASE-T Ethernet
(RJ-45) port with Auto Uplink™
(Auto MDI-X)
LEDs
•Power/Test, ACT, LAN, Wireless
Default Reset
Environmental Conditions
Operating Temperature
•32° to 113° F
(0° to 50° C)
Storage Temperature
•-4° to 158° F
(-20° to 70° C)
Operating Relative Humidity
•10-90%
Storage Humidity
•5-95%
MTBF
•@ 25° C > 375,000 hours
•@ 50° C >125,000 hours
RF Characteristics
Standards
•IEEE 802.11ac specification
•IEEE 802.11n 2.0 specification
•IEEE 802.11g
•IEEE 802.11b
•IEEE 802.11a
Frequency Band
•2.4GHz and 5GHz
concurrent operation
Maximum Theoretical Throughput
•300 Mbps (2.4GHz)
•867 Mbps (5GHz)
Network Management
Deployment options
•Standalone
•Web UI
Access Point
•Antenna: 2 dBi (internal)
Advanced Wireless
•WDS Point-to-point wireless bridge mode
•WDS Point-to-multipoint wireless
•Bridge mode
•Wireless client mode
Security
•Wired Equivalent Privacy (WEP)
Encryption
•WiFi Protected Access Pre-shared Key
(WPA-PSK, WPA2-PSK)
•MAC Address filtering
•1 BSSID
MAC ACL
Wireless Client Mode
VPN Pass-through
802.11e WMM
•(Wireless multimedia mode) for QoS
Simultaneous Bridge/Client Association
Technical Specifications
Smartphone
Laptop PC
Surveillance Camera
VoIP phone
Tablet
Internet Gateway
2.4GHz frequency
5GHz frequency
Dual Band 802.11ac Wireless Access Point Data Sheet
WAC120
Page 3 of 3
Technical Specifications
Package Contents
•802.11ac Wireless AP (WAC120)
•Ethernet cable
•Installation guide
•Power adapter, localized to country of sale
•Warranty/support information card
Warranty and Support
Warranty
•NETGEAR 3-year Warranty
Safety Certification
•UL/cUL, CE (EN60950-1)
Optional Support
•PMB0351: 5 years OnCall 24x7
•PMB0331: 3 years OnCall 24x7
•PMB0311: 1 year OnCall 24x7
•PRR0351: 5 years XPressHW
•PRR0331: 3 years XPressHW
Product Ordering Information
•WAC120-100AUS
•WAC120 -100NA S
•WAC120 -100PES
•WAC120-100PRS
•WAC120 -100UK S
NETGEAR, the NETGEAR Logo, and ProSAFE are trademarks of NETGEAR, Inc. in the United States and/or other countries. Other brand names mentioned herein are for identification purposes only
and may be trademarks of their respective holder(s). Information is subject to change without notice. All rights reserved. © 2014 NETGEAR, Inc.
NETGEAR, Inc. 350 E. Plumeria Drive, San Jose, CA 95134-1911 USA, 1-888-NETGEAR (638-4327), E-mail: info@NETGEAR.com, www.NETGEAR.com D-WAC120-0
