DOCSIS 3.0 AC1900 Voice and Data Cable Gateway, C7000B
The NETGEAR Difference
AC1900 WiFi speeds plus
Beamforming+ for the ultimate in
speed, ease of use and reliability
The new NETGEAR DOCSIS® 3.0 AC1900 Voice and
Data Cable Gateway (C7000B), gives service providers
the ultimate experience for their end-users.
The NETGEAR C7000B raises the bar with its incredibly
fast WiFi giving service provider’s subscribers the
power to connect to all of their smartphones, tablets
and mobile devices faster than ever before. Enhancing
end-user’s ultra-fast WiFi connection is the addition
of explicit and implicit Beamforming+ creating better
range and a stronger connection that is ideal for large
homes.
Built-in NETGEAR genie® offers end-users complete
access and management of their home network,
resulting in fewer technical support calls. NETGEAR
Enhanced Support Tools offer easy troubleshooting for
cable operators providing unprecedented visibility and
diagnostic tools to ensure carrier-grade voice services.
• 11ac ultra-fast cable Internet speeds up to 1 Gbps with NETGEAR Beamforming+
for expanded coverage and a better WiFi connection
• NETEGAR genie® application for simplified home network management
• Enhanced support tools with TR-069, SNMP and genie app
• Hotspot/WiFi offload support using GRE soft tunnel
• ReadyShare USB hard drive access through local network
• Live parental controls
Benefits
• 11ac AC1900 WiFi – 600+1300 Mbps† speeds
• Up to 1 Gig DOCSIS download speed with 24 bonded channels
• Explicit and implicit Beamforming+ for improved WiFi range and performance
• High powered amplifiers and antennas to extend WiFi coverage
• Upstream and downstream advanced Quality of Service (QoS) for best gaming and
video streaming experience
• Integrated 4-port Gigabit Ethernet switch
• Next generation of HD voice with PacketCable 2.0
Ease of Use
• Installation and management is simple and easy with Push ‘N’ Connect and
NETGEAR genie app
• NETGEAR genie has a host a features to give end-users ultimate access and control
of their network:
– Home network management
– MyMedia: Find and play media files from network
– Turbo Transfer: Share files within home network between PC, MAC or Android
– Guest Network and EZ Mobile Connect: Separate and secure access for guests;
scan QR code to connect guests to the network
C7000B
Data Sheet - Preliminary
C7000B Data Sheet
Self-Install
No-Click Training
FW Upgrade
DOCSIS, SNMP & TR-069
Remote Care
TR-069 ACS
(multiple vendors)
TR-069/
DOCSIS/
SNMP
Installation Post-Installation
TR-069/
DOCSIS
Self-Care
Integrated
Gateway Tools
genie
Assisted Care
Optional:
NETGEAR Support
Center
DUAL BAND
1900
ReadyShare USB Beamforming+ DLNAWPS
Data Sheet
DOCSIS 3.0 AC1900 Voice and Data Cable Gateway, C7000B
C7000B
Technical Specifications
System Requirements
• Cable broadband Internet
service
• Microsoft® Windows® 7, 8,
Vista®, XP, 2000, Mac OS®,
or other operating systems
running a TCP/IP network
• Microsoft® Internet Explorer®
5.0, Firefox® 2.0, Safari® 1.4,
or Google Chrome™ 11.0
browsers or higher
• Use laptop with 3x3 450
Mbps adapter like Centrino®
6300/5300 for maximum
performance
• Use with an 802.11ac
adapter like NETGEAR A6200
for maximum performance
Physical Interfaces
• 1: USB 2.0 port
• 1: Coaxial port for cable
Internet
• 2: Voice ports
• 4: Gigabit Ethernet ports with
auto-sensing technology
Security
• WPA/WPA2 – PSK
• SPI and NAT firewall
• Denial-of-Service (DoS)
attack prevention
• WPS
Power
• 12V/3.5A
Environmental Specifications
• Operating Temperature:
5–40 ºC
• RoHS/REACH/WEEE
Compliant
Warranty
• Standard 2-year
Network Management
• Remote GUI Management
• Genie® GUI Management
• uPnP
• DLNA
• Port forwarding/Port
Triggering
• DHCP Server
LEDs
• Power
• DS/US
• ONLINE
• Telephony
• 2.4GHz
• 5GHz
• WPS
• WiFi
Ease-of-use
• NETGEAR genie for PCs, iPad,
tablets, MacBook Air, and
smartphones
• Push ‘N’ Connect using WiFi
Protected Setup® (WPS)1
Advanced Features
• 24x8 3.0 Modem
• Download and upload speeds
up to 1.2 Gbps
• IPv6
• Simultaneous dual-band WiFi
• WiFi Transmitters/Receivers
(Tx/Rx)- 3x3 (2.4GHz) +
3x3 (5GHz)
• WiFi Boost with high-powered
radio amplifiers
• Memory – 128 MB flash and
256 MB RAM
• Advanced QoS
• Four Gigabit Ethernet ports
NETGEAR Green Features
• Power On/Off button
• Wireless On/Off button
• 80% recycled packaging
• CEC (California Efficiency)
• RoHS
• WEEE
• REACH
Package Contents
• C7000B cable gateway
• Ethernet cable
• Quick install guide
• Power adapter
Data Sheet
DOCSIS 3.0 AC1900 Voice and Data Cable Gateway, C7000B
C7000B
Connection Diagram
NETGEAR and the NETGEAR logo are trademarks and/or registered trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States and/
or other countries. Other brand names mentioned herein are for identification purposes only and may be trademarks of their respective holder(s).
Information is subject to change without notice.
© 2014 NETGEAR, Inc. All rights reserved. D-C7000B-1
Push ‘N’ Connect
with WPS
WiFi On/Off Voice ports
USB 2.0 port
Gigabit Ethernet
Coaxial Cable
Internet
† Maximum wireless signal rate derived from IEEE standard 802.11 specifications. Actual data throughput and wireless coverage will vary. Network conditions and environmental factors,
including volume of network trac, building materials and construction, and network overhead, lower actual data throughput rate and wireless coverage. NETGEAR makes no express or
implied representations or warranties about this product’s compatibility with any future standards. 802.11ac 1300 Mbps is approximately 3x faster than 802.11n 450 Mbps. 2.4GHz
Performance Mode requires 256 QAM support on WiFi client. Up to 1300 Mbps wireless speeds achieved when connecting to other 802.11ac 1300 Mbps devices.
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this
equipment.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 30cm between the radiator & your body.
Note: The country code selection is for non-US model only and is not
available to all US model. Per FCC regulation, all WiFi product marketed in
US must fixed to US operation channels only.
