Boost your exiting WiFi
Overview
NETGEAR AC750 WiFi Range Extender boosts your existing network range & speed, delivering AC dual band WiFi up to 750 Mbps.
It works with any standard WiFi router & is ideal for HD video streaming & gaming. Get the connectivity you need for iPads®,
smartphones, laptops & more.
Dual band WiFi up to 750Mbps
Supports new 802.11ac & b/g/n WiFi devices
External antennas for better performance
PAGE 1 OF 4
RANGE
DUAL BAND
AC750
AC750 WiFi Range Extender—802.11ac Dual Band Gigabit Data Sheet
EX6100
Simultaneous Dual Band WiFi
Extend 2.4 & 5GHz WiFi up to 750Mbps
& reduce interference.
FastLane™ Technology
Use both WiFi bands to establish one super
high-speed connection; ideal for HD
streaming & gaming.
More WiFi Standards
Create faster access for 802.11 b/g/n
& ac WiFi devices.
Gigabit Ethernet Port
Connect a wired device like Blu-ray® player,
game console, smart TV or streaming player
to your WiFi network.
External Antennas
For better WiFi coverage & more speed.
Two WiFi Modes
Extender mode to boost existing WiFi.
Access Point mode to create new AC
WiFi access.
EX3700
AC750 WiFi Range Extender—802.11ac Dual Band Gigabit Data Sheet
EX6100
PAGE 2 OF 4
Smart LED indicators help find the best extender
placement for optimal WiFi coverage while displaying
real-time, extender network status.
Easy, secured connection at the push of a
button for either WiFi Range Extender mode
or Access Point mode setup.
Existing WiFi
Sometimes your router
does not provide the
WiFi coverage you need.
WiFi Range
Extender
Boosts the range of your
existing WiFi & creates
a stronger signal in
hard-to-reach areas.
Network Connections
Secure Connection
(WPS)
Power on/o
Extender or Access
Point mode switch
Gigabit Ethernet port
Wall plug
Smart LED indicators
WiFi Range Extenders boost your existing WiFi & deliver greater wireless speed, range & connectivity you desire for iPad,
smartphones, laptops & more.
EX3700
AC750 WiFi Range Extender—802.11ac Dual Band Gigabit Data Sheet
EX6100
PAGE 3 OF 4
WiFi Analytics App
How strong is your WiFi signal? Use the NETGEAR WiFi Analytics app & get advanced analytics to optimize your existing or newly
extended WiFi network. Check your network status, WiFi signal strength, identify crowded WiFi channels & much more!
Here’s what you can do with the WiFi Analytics App!
Get a network status overview
Check WiFi signal strength
Measure WiFi channel interference
Keep track of WiFi strength by location
• and more...
Scan to install app
EX3700
© 2013 NETGEAR, Inc. NETGEAR, and the NETGEAR logo, are trademarks and/or registered trademarks of NETGEAR, Inc. and/or subsidiaries in the United States and/or other countries.
Mac and the Mac logo are trademarks of Apple Inc., registered in the U.S. and other countries. Other brand names mentioned herein are for identification purposes only and may be
trademarks of their respective holder(s). Information is subject to change without notice. All rights reserved.
This product is packaged with a limited warranty, the acceptance of which is a condition of sale. Warranty valid only when purchased from a NETGEAR authorized reseller.
*24/7 basic technical support provided for 90 days from date of purchase when purchased from a NETGEAR authorized reseller.
1
Works with devices supporting Wi-Fi Protected Setup™ (WPS).
Data throughput, signal range, and wireless coverage per sq. ft. are not guaranteed and may vary due to differences in operating environments of wireless networks, including without
limitation building materials and wireless interference. Specifications are subject to change without notice.
The product may not be compatible with routers or gateways with firmware that has been altered, is based on open source programs, or is non-standard or outdated.
NETGEAR, Inc. 350 E. Plumeria Drive, San Jose, CA 95134-1911 USA, 1-888-NETGEAR (638-4327), E-mail: info@NETGEAR.com, www.NETGEAR.com D-EX6100-0
AC750 WiFi Range Extender—802.11ac Dual Band Gigabit Data Sheet
EX6100
PAGE 4 OF 4
P C
AC750 WiFi Range Extender (EX6100)
• Installation guide
P S
Dimensions: 4.80 x 2.91 x 1.50 in
(122 x 74 x 38 mm)
Weight: 0.47 lb (0.213 kg)
W
NETGEAR 1-year limited warranty
S
WiFi Protected Access® (WPA/WPA2—PSK)
and WEP
S
IEEE® 802.11 b/g/n 2.4GHz
IEEE 802.11 a/n/ac 5GHz
One (1) 10/100/1000 Mbps Gigabit Ethernet
port with auto-sensing technology
S
24/7 basic technical support free for 90 days
E  U
CD-less setup—great for mobile devices
Push ‘N’ Connect using Wi-Fi Protected Setu
(WPS)1
S R
2.4 and/or 5GHz 802.11 a/b/g/n/ac WiFi
router or gateway
Microsoft® Internet Explorer® 5.0, Firefox® 2.0
or Safari® 1.4 or Google Chrome 11.0 browsers
or higher
EX3700
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
For operation within 5.15 ~ 5.25GHz frequency range, it is restricted to
indoor environment.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
Industry Canada statement:
This device complies with RSS-210 of the Industry Canada Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable
aux appareils radio exempts de licence. Son fonctionnement est sujet aux
deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage
préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y
compris un brouillage susceptible de provoquer un fonctionnement
indésirable.
Caution :
(i) the device for operation in the band 5150-5250 MHz is only for indoor use
to reduce the potential for harmful interference to co-channel mobile
satellite systems;
(ii) high-power radars are allocated as primary users (i.e. priority users) of
the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could
cause interference and/or damage to LE-LAN devices.
Avertissement:
les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés
uniquement pour une utilisation à l’intérieur afin de réduire les risques de
brouillage préjudiciable aux systèmes de satellites mobiles utilisant les
mêmes canaux;
(ii) De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de
radars de haute puissance sont désignés utilisateurs principaux (c.-à-d.,
qu’ils ont la priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et
que ces radars pourraient causer du brouillage et/ou des dommages aux
dispositifs LAN-EL.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC
établies pour un environnement non contrôlé. Cet équipement doit être
installé et utilisé avec un minimum de 20 cm de distance entre la source de
rayonnement et votre corps.
