Netgear orporated 15200317 Nighthawk X4 AC2200 WiFi Range Extender User Manual rev 2
Netgear Incorporated Nighthawk X4 AC2200 WiFi Range Extender Users Manual rev 2
Contents
- 1. Users Manual (Statement)_rev 2.pdf
- 2. Users Manual_rev 2.pdf
- 3. Users Manual (Statement)_rev.pdf
Users Manual_rev 2.pdf
Boost your existing WiFi range
Overview
The Nighthawk® X4 WiFi Range Extender boosts your existing network range, delivering extreme AC dual band WiFi speeds of
up to 2200 Mbps over a range of up to 10,000 2. It works with any standard WiFi router and is ideal for HD video streaming
and gaming. MU-MIMO allows you to go faster by simultaneously streaming to multiple devices, while FastLane technology
improves performance using both WiFi bands. High-power amplifiers and internal antenna array increases range so you can get the
connectivity you need for iPads®, smartphones, laptops & more.
• Dual band WiFi up to 2200 Mbps
• Up to 10,000 ² range
• MU-MIMO for simultaneously streaming to multiple devices
• Works with any WiFi router
PAGE 1 OF 4
Nighthawk® X4 WiFi Range Extender Data Sheet
EX7300
EXTEND | EXTREME RANGE &
PERFORMANCE
STREAM | ULTIMATE
CONNECTIVITY
MOBILE | UP TO 100% FASTER
· Extreme dual band WiFi speed — Up to
2200 Mbps
· High-power amplifiers & internal
antenna array increases range
· Beamforming+ improves wireless range
& reliability
· Access Point mode creates a WiFi hotspot
using a wired Ethernet connection
· MU-MIMO allows you to go faster by
simultaneously streaming to multiple
devices
· FastLane™ technology improves
performance using both WiFi bands
· Gigabit port to connect to wired
devices like smart TVs and game
consoles to WiFi
· Custom Low-Noise Amplifier improves
incoming transmission quality from
mobile devices
· Access scheduling for parental controls
· Optimize your WiFi network with the
WiFi Analytics app for Android®
· Mobile browser support for installation
1733
1733
1733
Nighthawk® X4 WiFi Range Extender Data Sheet
EX7300
PAGE 2 OF 4
WiFi Range Extenders boost your existing WiFi & deliver greater wireless speed & coverage to where WiFi signals are weak.
Improve your home’s WiFi and get better connections for iPads®, smartphones, laptops & more.
Existing WiFi
Sometimes your router
does not provide the WiFi
coverage you need.
WiFi Range
Extender
Boosts the range of
your existing WiFi &
creates a stronger
signal in hard-to-
reach areas.
Extender or Access
Point mode switch
Power on/o
Secure Connection (WPS)
Gigabit Ethernet
port (bottom)
Nighthawk® X4 WiFi Range Extender Data Sheet
EX7300
PAGE 3 OF 4
WiFi Analytics App
How strong is your WiFi signal? Use the NETGEAR WiFi Analytics app & get advanced analytics to optimize your existing or newly
extended WiFi network. Check your network status, WiFi signal strength, identify crowded WiFi channels & much more!
Here’s what you can do with the WiFi Analytics App!
• Get a network status overview
• Check WiFi signal strength
• Measure WiFi channel interference
• Keep track of WiFi strength by location
• and more...
Scan to install app
This product comes with a limited warranty that is valid only if purchased from a NETGEAR authorized reseller.
*90-day complimentary technical support following purchase from a NETGEAR authorized reseller.
¹Works with devices supporting Wi-Fi Protected Setup® (WPS). Data throughput, signal range, and wireless coverage per sq. ft. are not guaranteed and may vary due to differences in
operating environments of wireless networks, including without limitation building materials and wireless interference. Specifications are subject to change without notice. The product
may not be compatible with routers or gateways with firmware that has been altered, is based on open source programs, or is non-standard or outdated.
NETGEAR, the NETGEAR Logo, Nighthawk and ReadySHARE are trademarks of NETGEAR, Inc. Mac and the Mac logo are trademarks of Apple Inc. Any other trademarks on this package
are for reference purposes only. © 2016 NETGEAR, Inc.
NETGEAR, Inc. 350 E. Plumeria Drive, San Jose, CA 95134-1911 USA, www.NETGEAR.com/support D-EX7300-1
Nighthawk® X4 WiFi Range Extender Data Sheet
EX7300
PAGE 4 OF 4
P C
• AC2200 Nighthawk® X4 Range Extender
(EX7300)
• Quick start guide
P S
• Dimensions: 6.34 x 3.2 x 1.75 in
(161 x 81.4 x 44.5 mm)
• Weight: 0.66 lb (0.3 kg)
W
• www.netgear.com/about/warranty
S
• Wi-Fi Protected Access® (WPA/WPA2–PSK)
and WEP
S
• IEEE® 802.11 b/g/n 2.4GHz
• IEEE® 802.11 a/n/ac 5GHz
• One (1) 10/100/1000 Mbps Gigabit Ethernet
port with auto-sensing technology
S
• 24/7 90-day complimentary technical support*
E U
• CD-less setup—Great for mobile devices
• Push ‘N’ Connect using Wi-Fi Protected Setup®
(WPS)1
• Power on/off button
S R
• 2.4 and/or 5GHz 802.11 a/b/g/n/ac wireless
router or gateway
• Microsoft® Internet Explorer 8.0, Firefox® 20,
Safari® 5.1, Google Chrome™ 25.0 browsers
or higher
