Aer the satellite is powered on, the
satellite’s ring LED lights white while the
satellite attempts to sync with the router,
lights one of the following colors for about
three minutes, and then turns o:
Quick Start Guide
Blue
The connection between the router
and satellite is good.
Amber
The connection between the router
and satellite is fair. Consider moving
the satellite closer to the router.
Magenta
The satellite was unable to connect
to the router. Move the satellite
closer to the router.
Note: If the ring LED still lights
magenta aer about one minute,
press the Sync button on the router
and on the satellite. If the satellite
successfully syncs with the router,
the satellite’s ring LED lights white
then lights blue to indicate a good
connection, and then turns o.
Use the NETGEAR Orbi app to set up your
Orbi network.
To find the app, scan a QR code or search
for NETGEAR Orbi in the Apple App Store
or Google Play Store. Launch the NETGEAR
Orbi app on your mobile device and follow
the onscreen instructions.
Note: If you don’t own a mobile device,
launch a web browser and visit
orbilogin.com to set up your Orbi network.
NETGEAR Orbi App Orbi Satellite LED Colors Support
Thank you for purchasing this NETGEAR
product. You can visit
www.netgear.com/support to register
your product, get help, access the latest
downloads and user manuals, and join our
community. We recommend that you use
only ocial NETGEAR support resources.
For the current EU Declaration of
Conformity, visit
http://support.netgear.com/app/answers/
detail/a_id/11621/.
For regulatory compliance information,
visit http://www.netgear.com/about/
regulatory/.
See the regulatory compliance document
before connecting the power supply.
NETGEAR INTL LTD
Building 3, University Technology Centre
Curraheen Road, Cork, Ireland
NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134, USA
© NETGEAR, Inc., NETGEAR and the NETGEAR Logo
are trademarks of NETGEAR, Inc. Any non‑NETGEAR
trademarks are used for reference purposes only.
January 2017
Ring LED (not shown in image)
Sync button (also used for WPS connection)
Internet port (the Orbi Mini Satellite does
not include an Internet port)
Ethernet ports
All Set Up!
Orbi Mini Router Overview
Orbi Mini Router
(Model RBR40)
Orbi Mini Satellite
(Model RBS40)
Ethernet cable
Power adapters (2) (vary by region)
Orbi Mini Satellite
Overview
Package Contents
2
1
3
4
1
2
345
6
7
5
6
7
Power On/O button and Power LED
DC power connector
Reset button
1
2
45
6
7
