CONTENTS

  

 

  

  

  

  

  

  

  

  

 

  

 

  

CHAPTER 1: INTRODUCTION

The ME102 802.11b wireless Access Point is the basic building block of a wireless LAN infrastructure.

It provides wireless connectivity to multiple wireless network devices within a fixed range or area of

coverage, interacting with a wireless network interface card (NIC) via an antenna. Typically, individual

in-building access point provides a maximum connectivity range of about 300 feet. The ME102

wireless Access Point can support a small group of users in a range of several hundred feet; most access

points are rated between 30-70 users simultaneously.

The ME102 wireless Access Point converts airwave data into wired Ethernet data, acting as a bridge

between the wired LAN and wireless clients. Connecting multiple ME102 Access Points via a wired

Ethernet backbone can further lengthen the wireless network coverage. As a mobile computing device

moves out of the range of one access point, it moves into the range of another. As a result, wireless

clients can freely roam from one Access Point domain to another and still maintain seamless connection

to the network.

The auto-sensing capability of the ME102 wireless Access Point allows packet transmission in 11Mbps

for maximum throughput, or speed reduction to lower 1Mbps speed for distance or for operating in a

noisy environment.

Features

The features supported by the ME102 Wireless Access Point are outlined below:

y Interfaces directly to 10Mbps IEEE 802.3 Ethernet networks

y Supports IEEE 802.11 HR WLAN functions.

y Firmware is stored in a flash memory and can be upgraded remotely.

y Configurable through USB and Ethernet ports.

y Power and wireless activity LED indicators.

y Dual External antennas supporting diversity.

Related NETGEAR products

y MA401 – 802.11b Wireless PC Card

y MA301 – 802.11b Wireless PCI Adapter (requires the MA401 wireless PC Card)

y MA101 – 802.11b Wireless USB Adapter

y MR314 – 802.11b Wireless Cable/DSL Router

CHAPTER 2: WIRELESS NETWORK FUNDAMENTALS

Wireless Network Configuration

Ad-hoc Mode (Peer-to-Peer Workgroup)

The Institute of Electrical and Electronics Engineers (IEEE) standard for wireless LANs (WLANs),

802.11, offers two methods for configuring a wireless network — ad hoc and infrastructure. In an ad

hoc network, computers are brought together as needed; thus, there is no structure or fixed points to the

network — each node can generally communicate with any other node. There is no access point involved

in this configuration. It enables you to quickly set up a small wireless workgroup and allows workgroup

members to exchange data or share printers as supported by Microsoft Networking in the various

Windows operating systems. Some vendors also refer to ad hoc networking as Peer-to-Peer group

networking.

In this configuration, network packets are directly sent and received by the intended transmitting and

receiving stations. As long as the stations are within range of one another, this is the easiest and least

expansive way to set up a wireless network.

To set up an ad hoc workgroup operating with standard protocols, do the following:

• Set all stations to connect in Ad-hoc mode (or Peer-to-Peer workgroup mode).

• Set all stations to use the same network name (or SS ID).

• Set all stations to use no WEP encryption key or an identical WEP encryption key.

• Set all stations to use the same wireless channel for communication.



Infrastructure Mode

With a wireless access point, you can put the wireless LAN into the infrastructure mode. It provides

wireless connectivity to multiple wireless network devices within a fixed range or area of coverage,

interacting with wireless nodes via an antenna.

In the infrastructure mode, the wireless access point converts airwave data into wired Ethernet data,

acting as a bridge between the wired LAN and wireless clients. Connecting multiple ME102 Access

Points via a wired Ethernet backbone can further extend the wireless network coverage. As a mobile

computing device moves out of the range of one access point, it moves into the range of another. As a

result, wireless clients can freely roam from one Access Point domain to another and still maintain

seamless network connection.

To set up an infrastructure network operating with standard protocols, do the following:

• Set all wireless stations to connect in infrastructure mode

• Set all stations to use the same network name (or SS ID).

• Set all wireless access point to use the same network name ( or ESS ID).

• Set all stations to use no WEP encryption key or an identical WEP encryption key.

• Set up wireless channels used by individual access point. (It is not necessary to set channels on

the stations as the stations will automatically scan through all channels for the nearest access

point.)

Service Set Identification (SS ID)

The Service Set Identification (SS ID) is a thirty-two alphanumeric character (maximum) string

identifying the wireless local area network. Some vendors refer to the SS ID as network name. For

stations to communicate with each other, all stations must be configured with the same SS ID.

A wireless LAN consisting of nodes operating in ad hoc configuration without an access point is called a

Basic Service Set (BSS). All nodes in a BSS must use the same Basic Service Set ID (BSS ID).

In an infrastructure configuration with access points, multiple BSS can be configured to form an

Extended Service Set (ESS). In this configuration, the access points are configured with the same

Extended Service Set ID (ESS ID). Wireless clients configured with the same ESS ID can freely roam

from one Access Point domain to another and still maintain seamless connection to the network

Authentication and WEP Encryption

The absence of a physical connection between nodes makes the wireless links vulnerable to information

theft. To provide certain level of security, IEEE 802.11 standard has defined two types of

authentication methods, Open System and Shared Key. Open System authentication is a null algorithm.

Shared Key authentication is an algorithm where both the transmitting node and the receiving node

share an authentication key to perform a checksum on the original message. By default, IEEE 802.11

wireless devices operate in an open system network.

Wired Equivalent Privacy (WEP) data encryption is utilized when the wireless nodes or access points

are configured to operate in Shared Key authentication mode. There are two shared key methods

implemented in most commercially available products, forty-bit WEP data encryption and 128-bit WEP

data encryption.



The forty-bit WEP data encryption method, allows for a five-character (forty-bit) input. Additionally,

24 factory-set bits are added to the forty-bit input to generate a 64-bit encryption key. (The 24 factory-

set bits are not user configurable.) This encryption key will be used to encrypt/decrypt all data

transmitted via the wireless interface. Some vendors may refer to the forty-bit WEP data encryption as

64-bit WEP data encryption since the actual encryption key used in the encryption process is 64 bits

wide.



The 128-bit WEP data encryption method consists of 104 configurable bits. Similar to the forty-bit

WEP data encryption method, the remaining 24 bits are factory set and not user configurable. Some

vendors allow passphrases to be entered instead of the cryptic hexadecimal characters to ease

encryption key entry.

Wireless Channel Selection

IEEE 802.11 wireless nodes communicate with each other using radio frequency signals in the ISM

(Industrial, Scientific, and Medical) band between 2.4Ghz and 2.5Ghz. Neighboring channels are 5Mhz

apart. However, due to spread spectrum effect of the signals, a node sending signals using a particular

channel will utilize frequency spectrum12.5Mhz above and below the center channel frequency. As a

result, two separate wireless networks using neighboring channels (for example, channel 1 and channel

2) in the same general vicinity will interfere with each other. Applying two channels that allow the

maximum channel separation will decrease the amount of channel cross-talk, and provide a noticeable

performance increase over networks with minimal channel separation

Channel Center Frequency Frequency Spread

1 2412Mhz 2399.5Mhz – 2424.5Mhz

2 2417Mhz 2404.5Mhz – 2429.5Mhz

3 2422Mhz 2409.5Mhz –2434.5Mhz

4 2427Mhz 2414.5Mhz –2439.5Mhz

5 2432Mhz 2419.5Mhz – 2444.5Mhz

6 2437Mhz 2424.5Mhz –2449.5Mhz

7 2442Mhz 2429.5Mhz –2454.5Mhz

8 2447Mhz 2434.5Mhz – 2459.5Mhz

9 2452Mhz 2439.5Mhz –2464.5Mhz

10 2457Mhz 2444.5Mhz –2469.5Mhz

11 2462Mhz 2449.5Mhz – 2474.5Mhz

12 2467Mhz 2454.5Mhz – 2479.5Mhz

13 2472Mhz 2459.5Mhz – 2484.5Mhz

Note: The available channels supported by the wireless products in various countries are

different.

The preferred channel separation between the channels in neighboring wireless networks is 25 MHz (5

channels). This means that you can apply up to three different channels within your wireless network.

There are only 11 usable wireless channels in the United States. It is recommended that you start using

channel 1 and grow to use channel 6, and 11 when necessary.

CHAPTER 3: Hardware Installation

Package Contents

The product package should contain:

• Model ME102 802.11b Wireless Access Point

• Power adapter and cord (5Vdc, 1.0A)

• 10-ft Category 5 Ethernet Cable

• 5-ft USB cable

• MA401/MA301 Wireless Access Point Resource CD

• Installation Guide

• Support Information Card

Call your reseller or customer support in your area if there are any wrong, missing, or damaged parts.

Refer to the Support Information Card for the telephone number of customer support in your area.

Keep the Support Information Card, along with the original packing materials. Use the packing

materials to repack the Model MA401 Wireless PC Card if you need to return it for repair.

To qualify for product updates and product warranty registrations, register online on the NETGEAR

Web page at: http://www.NETGEAR.com.

Hardware Description

The ME102 802.11b Wireless Access Point provides a bridge between Ethernet wired LANs and

802.11b compatible wireless LAN networks. It provides connectivity between Ethernet wired networks

and radio-equipped wireless notebook systems, desktop systems, print servers, and other devices. The

ME102 access point provides an 11Mbps data transfer rate on the radio network.

The ME102 access point supports the following hardware functions:

y Built-in dual antenna assembly to support antenna diversity on both transmit and receive

y Wired Equivalent Privacy (WEP) data encryption accomplished on the fly

y Access Point configuration through USB port or using the SNMP manager through Ethernet or

wireless interface.

y Firmware stored in flash to allow easy firmware upgrade.

Additionally, the ME102 access point supports the following wireless features:

y Distributed coordinated function (CSMA/CA, Back off procedure, ACK procedure, retransmission

of unacknowledged frames

y RTS/CTS handshake

y Duplicate detection and Recovery

y Beacon generation

y Fragmentation and reassembly

y Authentication Algorithm (Open System, Shared Key)

y Short or long preamble

y Roaming among access points on the same subnet

CHAPTER 4: Access Point Configuration

The ME102 Wireless Access Point is configurable through its USB interface or using the SNMP utility

through the Ethernet or wireless interface. .

Using USB Port

The installation example below illustrates the wireless access point configuration through its USB

interface from a connected PC. This PC must be running Windows 98, Windows 2000, or Windows

Millennium.

Connecting the USB Cable

Plug in the power adapter for the ME102 access point to provide power to the unit. Using the provided

USB cable, connect the access point to a PC. The USB interface of the ME102 Access point can be

connected to the PC either powered on or shut down. The following procedure illustrates connecting the

access point to a PC running Microsoft Windows while powered on.

Installing the Access Point USB driver

This section explains how to install the Windows 98 Network Driver. Microsoft Windows 2000 or

Windows Millennium may respond with different dialog boxes, or the dialog boxes may open in a

different sequence than those shown in this guide, but should prompt you for the same information.

Â Note: You also need to have the Windows 98 CD and the ME102 Wireless Access Point

Resource CD ready to use in the installation process.

Â Note: If the “Insert Disk” dialog box opens and the “Please insert the disk labeled Windows

98…” message appears at any time during the installation process, insert the Windows

98 CD in drive F (or whichever letter represents the CD-ROM drive on you PC) and

click “OK.” Then follow the next step in the instructions.

1. Upon connecting the USB cable, Windows indicates that new hardware is found, and looks for

the driver to load. Click “Next.”

2. In the next Add New Hardware Wizard window, select “Search for the best driver for your

device (Recommended),” and then click “Next.”

3. Click on “Specify a location” and enter the drive letter for the CD-ROM drive. Insert the

MA102 Wireless Access Point Resource CD. Click on “Browse”.

4. Double-click on the CD-ROM drive letter to show the content of the CD. Click to select the

USBDRV

folder in the CD-ROM. Click on “OK” to continue.

5. When Windows returns back to the original Add New Hardware Wizard window, the Specify a

location entry field should show “

D:\USBDRV

” assuming that D: is the drive letter for the CD-

ROM drive. Click on “Next”.

6. Windows indicates that the best driver for the device has been found. Click on “Next”.

Windows starts copying files into your system.

7. Windows indicates that it has finished installing the software. Click on “Finish”.

The USB driver for the access point is now installed into your PC. You can check into the Device

Manager to see if there is any error in activating the USB driver for the access point.

Installing USB Configuration Utility

The access point USB configuration utility enables you to modify the various configurable parameters of

the access point.

1. Insert the ME102 Wireless Access Point Resource CD into the CD-ROM drive. From the

Windows 98 desktop, double-click on

My Computer

. Double-click on the CD-ROM drive to look

into the content of the CD. Double-click on the

USBMANG

folder. Windows displays all of the

files in the

\USBMANG

directory of the CD.

2. Double-click on the

SETUP

application icon to start the installation procedure. The InstallShields

Wizard opens. Click on “Next” to continue.

3. Click on “Browse” to change the destination location where the Access Point USB utility is

installed. Otherwise, click on “Next” to continue.

4. Modify the “Program Folders” entry field if desired. Click on “Next” to continue. InstallShields

starts copying files into your system.

5. Click on “Finish” to complete the installation of the access point USB utility.

Configuring Access Point

From the Windows desktop, select

Start ⇒ Program ⇒ NETGEAR ME102 AP ⇒ Access Point USB

Manager

. The opening screen opens showing the firmware version of the access point and the access

point USB utility software version. Click on “Configure” to go into the main USB management window.

Click on the “Get Value” button to retrieve the current configurable settings from the access point.

To modify the access point parameters, first click on the intended parameter to select the parameter.

And click on “Modify”. A pop-up window appears inquiring for changes to the parameter. Enter any

desired changes and click “OK” to accept the changes.

After making modification to all of the parameters, click on “Set” to send the changes to the access

point. It is recommended to make all intended changes prior to clicking “Set” to configure the access

point all at once.

When configuration is done. Click on “Exit” on the device window and click on “Exit” at the main

window to quit the USB configuration utility.

Changing Wireless Parameters

The following table explains each of the configurable parameters of the ME102 Wireless Access Point.

General Specifications Model ME102 Wireless Access Point

Access Point Name Assign name to the access point.

IP Address Assign Internet Protocol (IP) address to the access point.

Subnet Mask Assign IP Subnet Mask to the access point.

MAC Address Displays the six-byte MAC address of the access point. This

parameter is not changeable by the user.

ESSID Enter a 32-character (maximum) extended service set ID in this

field. The characters are case sensitive. With an access point, the

wireless network always functions in infrastructure mode. The ESS

ID assigned to the wireless nodes in the same network is required to

match the access point ESS ID. The default ESS ID is “Wireless”.

Channel Only valid in ad-hoc mode, this field defines the wireless channel to

use. In infrastructure mode, the wireless node automatically

searches through all available wireless channels for an access point

to be associated with. It is not necessary to select the wireless

channel when operating in infrastructure mode. The default wireless

channel is 6.

WEP The ME102 Wireless access point supports 40-bit WEP data

encryption. (40-bit WEP data encryption is also called 64-bit WEP

data encryption by some vendors.) This parameter enables/disables

encryption and select the 40-bit WEP data encryption key to use. Up

to four keys can be defined in the access point. The possible values

for this parameter are Disable, Key1, Key2, Key3, and Key4. . For

more explanation on data encryption, please refer to the wireless

network fundamental chapter at the beginning of this reference

guide. The WEP data encryption method and the key used must be

the same for all wireless nodes and access points in the same

network.

Note: the present version of the USB Configuration Utility software

does not support WEP Passphrase.

Key1 One of the four data encryption keys defined in the access point.

Each data encryption key contains five hexadecimal numbers, making

it 40 bits wide. Together with the twenty-four factory-set bits to

make up a 64-bit encryption key.

Key2 One of the four data encryption keys defined in the access point.

Key3 One of the four data encryption keys defined in the access point.

Key4 One of the four data encryption keys defined in the access point.

Authentication Configurable between Open System (WEP disabled), Shared Key (40-

bit WEP data encryption), and both.

Preamble Mode A long transmit preamble allows the receiver to lock into the received

bit patterns more easily. A short transmit preamble provides better

performance. The default value is Long Tx Preamble.

Auto Rate Enables or disables automatic negotiation of wireless transmit data

rate.

Fragment Threshold This is the packet length used for fragmentation. Packets larger than

the size programmed in this field will be fragmented. The Fragment

Threshold value must be larger than RTS Threshold value. The

default value for Fragment Threshold is 2346.

RTS Threshold The packet size that the wireless node uses to determine if it should

use the CSMA/CD mechanism or the CSMA/CA mechanism for

packet transmission. With the CSMA/CD transmission mechanism,

the transmitting station sends out the actual packet as soon as it has

waited for the silence period. With the CSMA/CA transmission

mechanism, the transmitting station sends out a RTS packet to the

receiving station, waits for the receiving station to send back a CTS

packet before sending the actual packet data. The default value for

RTS Threshold is 2346.

Using Ethernet/Wireless Port

The installation below illustrates the wireless access point configuration through its Ethernet/Wireless

interface from a connected PC.

Installing SNMP Configuration Utility

The access point SNMP configuration utility enables you to modify the various configurable parameters

of the access point. This utility must be running Windows 98 or Windows Millennium. The following

steps illustrate the installation of the utility in Windows 98.

1. Insert the ME102 Wireless Access Point Resource CD into the CD-ROM drive. From the

Windows 98 desktop, double-click on

My Computer

. Double-click on the CD-ROM drive to look

into the content of the CD. Double-click on the

SNMPMANG

folder. Windows displays all of the

files in the

\SNMPMANG

directory of the CD.

2. Double-click on the

SETUP

application icon to start the installation procedure. The InstallShields

Wizard opens. Click on “Next” to continue.

3. Click on “Browse” to change the destination location where the Access Point SNMP utility is

installed. Otherwise, click on “Next” to continue.

4. Modify the “Program Folders” entry field if desired. Click on “Next” to continue. InstallShields

starts copying files into your system.

5. Click on “Finish” to complete the installation of the access point SNMP utility.

Assigning IP Address

In order to set the access point IP address you need to know the access point MAC address. Follow the

steps below to give the access point a temporary address at the beginning and save the IP address

permanently through the SNMP Configuration Utility.

Assigning temporary IP address

1. Connect an Ethernet station and the access point on the same subnet. The simplest way to

accomplish this is to connect the access point and the Ethernet station to the same hub. You need

to make sure that the station IP address and the Subnet Mask are configured properly. Also the

new IP address for the access point must correspond to the same Subnet Mask.

2. From the Ethernet station, open an MS-DOS prompt window and enter a static route in the ARP

table for the new IP address you want to assign. Use the “arp –s” command to do that:

¾arp –s “new-ip-address” “AP-MAC-address”

Â Note: The MAC address of the access point is indicated on the bottom label of the access

point.

3. Ping the access point, using the new IP address, to confirm the IP address assignment.

Saving the temporary IP address

Select an Ethernet/wireless station on the same subnet to install the access point SNMP utility. From

the windows desktop of the station, select

Start ⇒ Program ⇒ NETGEAR ME102 AP ⇒ Access Point

SNMP Manager

. You should be able to see the device that is configured with the new IP address.

Connect to the access point by selecting the access point and click on “Configure”. Click on the IP

Address folder tab. You might see a different IP address setting. Modify the IP address and Subnet

Mask. Click on “Upgrade” to permanently save the new setting into the access point.

Configuring Access Point

From the Windows desktop, select

Start ⇒ Program ⇒ NETGEAR ME102 AP ⇒ Access Point SNMP

Manager

. All accessible access points from this system are shown in a table. Select the access point,

and click on “Configure”. The configurable parameters are categorized into folders and are accessible

by clicking on the folder tabs. The definitions of the parameters are explained in the following table.

General MODEL ME102 WIRELESS ACCESS POINT

ESS ID Enter a 32-character (maximum) extended service set ID in this
