UMTS Modems

Supported AT Command Reference

Includes:

AC875 / AC875U

AC880 / AC880E / AC880U

AC881 / AC881U

C885

C888

MC8775 / MC8775V

MC8780 / MC8781

MC8785V

MC8790 / MC8790V

MC8791V

MC8792V

Preface

Rev 2.8.1 Feb.11 3

Important Notice Duetothenatureofwirelesscommunications,transmission

andreceptionofdatacanneverbeguaranteed.Datamaybe

delayed,corrupted(i.e.,haveerrors)orbetotallylost.

Althoughsignificantdelaysorlossesofdataarerarewhen

wirelessdevicessuchastheSierraWirelessmodemareusedin

anormalmannerwithawell‐constructednetwork,theSierra

Wirelessmodemshouldnotbeusedinsituationswherefailure

totransmitorreceivedatacouldresultindamageofanykind

totheuseroranyotherparty,includingbutnotlimitedto

personalinjury,death,orlossofproperty.SierraWireless

acceptsnoresponsibilityfordamagesofanykindresulting

fromdelaysorerrorsindatatransmittedorreceivedusingthe

SierraWirelessmodem,orforfailureoftheSierraWireless

modemtotransmitorreceivesuchdata.

Safety and Hazards DonotoperatetheSierraWirelessmodeminareaswhere

blastingisinprogress,whereexplosiveatmospheresmaybe

present,nearmedicalequipment,nearlifesupportequipment,

oranyequipmentwhichmaybesusceptibletoanyformof

radiointerference.Insuchareas,theSierraWirelessmodem

MUSTBEPOWEREDOFF.TheSierraWirelessmodemcan

transmitsignalsthatcouldinterferewiththisequipment.

DonotoperatetheSierraWirelessmodeminanyaircraft,

whethertheaircraftisonthegroundorinflight.Inaircraft,the

SierraWirelessmodemMUSTBEPOWEREDOFF.When

operating,theSierraWirelessmodemcantransmitsignalsthat

couldinterferewithvariousonboardsystems.

Note: Some airlines may permit the use of cellular phones while the

aircraft is on the ground and the door is open. Sierra Wireless

modems may be used at this time.

Thedriveroroperatorofanyvehicleshouldnotoperatethe

SierraWirelessmodemwhileincontrolofavehicle.Doingso

willdetractfromthedriveroroperatorʹscontrolandoperation

ofthatvehicle.Insomestatesandprovinces,operatingsuch

communicationsdeviceswhileincontrolofavehicleisan

offence.

Limitation of

Liability

Theinformationinthismanualissubjecttochangewithout

noticeanddoesnotrepresentacommitmentonthepartof

SierraWireless.SIERRAWIRELESSANDITSAFFILIATES

SPECIFICALLYDISCLAIMLIABILITYFORANYANDALL

DIRECT,INDIRECT,SPECIAL,GENERAL,INCIDENTAL,

CONSEQUENTIAL,PUNITIVEOREXEMPLARYDAMAGES

INCLUDING,BUTNOTLIMITEDTO,LOSSOFPROFITSOR

Supported AT Command Reference

42130617

REVENUEORANTICIPATEDPROFITSORREVENUE

ARISINGOUTOFTHEUSEORINABILITYTOUSEANY

SIERRAWIRELESSPRODUCT,EVENIFSIERRAWIRELESS

AND/ORITSAFFILIATESHASBEENADVISEDOFTHE

POSSIBILITYOFSUCHDAMAGESORTHEYARE

FORESEEABLEORFORCLAIMSBYANYTHIRDPARTY.

Notwithstandingtheforegoing,innoeventshallSierra

Wirelessand/oritsaffiliatesaggregateliabilityarisingunderor

inconnectionwiththeSierraWirelessproduct,regardlessof

thenumberofevents,occurrences,orclaimsgivingriseto

liability,beinexcessofthepricepaidbythepurchaserforthe

SierraWirelessproduct.

Patents Thisproductmaycontaintechnologydevelopedbyorfor

SierraWirelessInc.Thisproductincludestechnologylicensed

fromQUALCOMM®3G.Thisproductismanufacturedorsold

bySierraWirelessInc.oritsaffiliatesunderoneormore

patentslicensedfromInterDigitalGroup.

Copyright ©2011SierraWireless.Allrightsreserved.

Trademarks AirCard®and“HeartoftheWirelessMachine®”areregistered

trademarksofSierraWireless.Watcher®isatrademarkof

SierraWireless,registeredintheEuropeanCommunity.

SierraWireless,theSierraWirelesslogo,theredwavedesign,

andthered‐tippedantennaaretrademarksofSierraWireless.

Windows®isaregisteredtrademarkofMicrosoftCorporation.

QUALCOMM®isaregisteredtrademarkofQUALCOMM

Incorporated.Usedunderlicense.

Othertrademarksarethepropertyoftherespectiveowners.

Contact

Information Sales Desk: Phone: 1-604-232-1488

Hours: 8:00 AM to 5:00 PM Pacific Time

E-mail: sales@sierrawireless.com

Post: Sierra Wireless

13811 Wireless Way

Richmond, BC

Canada V6V 3A4

Fax: 1-604-231-1109

Web: www.sierrawireless.com

Preface

Rev 2.8.1 Feb.11 5

Consultourwebsiteforup‐to‐dateproductdescriptions,

documentation,applicationnotes,firmwareupgrades,trouble‐

shootingtips,andpressreleases:

www.sierrawireless.com

Revision History

Revision

number Release

date Changes

2.3 Jul 2007 •Fixed !TIME (page 53) syntax

•Added +ECIO (page 33), !GSMINFO (page 36), !NVPORTSET

(page 39), !SMSSTSEN (page 48) commands

•Added detail for !SMSRETRY (page 47)

2.4 Jan 2008 •Updated !TIME (page 53) syntax

2.5 Mar 2008 •Added band indexes (0C,0D) and clarified query use for !BAND

(page 29)

•Clarified !NVBACKUP (page 63) options

•Clarified +ECIO (page 33) and +USET (page 55)

2.6 Jul 2008 •Added C885 / C888 / MC8790 / MC8790V to supported modems list

•Updated minimum firmware revisions

•Updated ‘supported modems’ lists for several commands

•Updated !GRELIMEI (page 35)

•Added !SCPROFDEL (page 44), !SDNOTINSTALLED (page 45),

!SIMNOTINSTALLED (page 46)!

•Changed ‘Support’ status to ‘Yes’ for supported AT commands described

in Chapter 2: +CMMS, +CPOL, +CPUC, +CTFR, +DS, &F, O, +VTD,

+VTS

2.7 Sep 2008 •Added MC8791V and MC8792V to supported modems list

•Added WCDMA900 content to !BAND (page 29) and

!GSTATUS (page 38)

2.8 Apr 2009 •Added +ETFCI

•Indicated support for +CIEV, +CIND, +CMER

•Moved !AUTH and !GCIPHER into different chapters

•Added general and AT command indexes

2.8.1 Feb 2011 •Updated Patents statement

Supported AT Command Reference

62130617

Rev 2.8.1 Feb.11 7

Table of Contents

About this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Result codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Terminology and acronyms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Current firmware versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Document structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Supported GSM / WCDMA AT Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Modem Status, Customization, and Reset Commands . . . . . . . . . . . . . . . . . .27

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Command summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Command reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Diagnostic Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Command summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Command reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Test commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Command summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Command reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Memory Management Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Command summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Supported AT Command Reference

82130617

Command reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

SIM Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Command summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Command reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Index (AT commands) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71

1

Rev 2.8.1 Feb.11 9

1: About this Guide

•Introduction

•Result codes

•Terminology and

acronyms

•Current firmware

versions

•Document structure

•Conventions Introduction

ThisdocumentdescribesstandardandproprietaryAT

commandsthatareavailableforusersofUMTSAirCard

modems,Compassmodems,andMiniCardembedded

modules.

Thestandard3GPPATcommandsforUMTSdevicesare

describedintwostandardsdocumentsavailablefromthe

3GPP(3rdGenerationPartnershipProject)website,

www.3gpp.org:

•TS27.007ATcommandsetforUserEquipment(UE)

•TS27.005UseofDataTerminalEquipment‐‐DataCircuit

terminatingEquipment(DTE‐DCE)interfaceforShortMessage

Service(SMS)andCellBroadcastService(BSE)

TheproprietaryATcommandsaresupplementaltothe

standardATcommands.

Fornormaloperationofthemodem,consulttheGSMAT

CommandReference(documentnumber2130213).Youmayalso

wanttoconsulttheotherdocumentsavailableintheAC8xx/

MC87xxDevelopmentKitoronourInternetsiteat

www.sierrawireless.com

Note: Some standard 3GPP commands are NOT supported, or are

partially supported. These commands are identified in Supported

GSM / WCDMA AT Commands, page 17.

Note: When designing applications that use these AT commands, use

Watcher® (and other Sierra Wireless applications) as functionality

templates to ensure proper use of command groups. For questions or

concerns relating to command implementation, please contact your

Sierra Wireless account representative.

Supported AT Command Reference

10 2130617

Result codes

Resultcodesarenotshowninthecommandtablesunless

specialconditionsapply.GenerallytheresultcodeOKis

returnedwhenthecommandhasbeenexecuted.ERRORmay

bereturnedifparametersareoutofrange,andwillbe

returnedifthecommandisnotrecognizedorisnotpermitted

inthecurrentstateorconditionofthemodem.

Terminology and acronyms

Thisdocumentmakesuseofacronymsthatareincommonuse

indatacommunicationsandcellulartechnology.OurInternet

siteprovidesaGlossaryofTermsandAcronyms(document

number2130891)thatmaybehelpfulinunderstandingsome

acronymsandterminologyusedinthisguide.

Current firmware versions

Versions

Note: Revision codes that

include letters, such as 2.1A, are

to be considered drafts and are

subject to change before final

release.

Document Thisdocumentisrevisedperiodicallyasnew

firmwareversionsarereleased.Thiseditionis:

Rev 2.8.1 Feb.11

Applicability of commands to different modules Each

commandlistedinthisguideincludesalistofsupporting

AC8xxandMC87xxmodules.Unlessotherwisenoted,the

followingminimumfirmwarerevisionsarerequiredto

supportthelistedcommands:

•AC875/MC8775/MC8775V–RevisionH1_0_0_0or

higher

•AC880/MC8780/MC8781–RevisionD1_0_3_0ap/

F1_0_0_0aporhigher

•AC881/AC881U–RevisionF1_0_0_4aporhigher

•C885/MC8785V—RevisionJ1_0_1_0aporhigher

•C888/MC8790/MC8790V—RevisionK1_0_1_2apor

higher

•MC8791V/MC8792V—RevisionK1_0_2_13aporhigher

Todetermineyourfirmwarerevision:

•EntertheidentificationcommandAT+GMR

Themodemrespondswithversioninformationfor

software,firmware,andhardware.

ThedetailsfollowingtherevisionnumberincludeSierra

Wirelessinformationonthespecificbuildfollowedbythe

dateandtimeofthebuild.

+GMR: … F/W VER: R1_0_0_…

About this Guide

Rev 2.8.1 Feb.11 11

Upgrading

Ifyourmodemfirmwareisanearlierversion,youcanacquire

updatedfirmwarebycontactingyouraccountmanager.

Document structure

Thisdocumentassumesyouhavethe3GPPTS27.007AT

commanddocumentation(seepage9).Thisreferenceincludes

achaptercoveringSupported 27.007 AT commands,aswellas

theproprietarycommandslistedinthetablesbelow.Each

tablecorrespondstoonechapterinthisguide.

Note: The ‘Supporting modems’ column indicates which modems

support each command — Mini Card (MC), Compass (C), and AirCard

(AC). If an entry is marked with an asterisk (‘*’), a firmware upgrade

may be required. See the detailed command entry for details.

Modem Status, Customization, and Reset Commands This

chapterdescribescommandsusedtodeterminemodemstatus,

adjustcustomizationsettings,andresetthemodem.

Table 1-1: Modem status and reset commands

Cmnd Pg Description Supporting

modems

!BAND 29 Selects a set of frequency bands / queries current

selection All

!BCINF 30 Returns the bootloader version All

!BOOTHOLD 30 Resets modem and waits in bootloader for firmware

download All

^CARDMODE 30 Returns SIM card mode (card type) All

+CLVL 31 Sets / returns internal loudspeaker volume All

+CMUT 31 Enables / disables uplink voice muting All voice-

enabled

!CNTI 31 Returns current, available, and supported network

technologies Alla

+CQI 32 Returns or enables / disables return of averaged CQI

(Channel Quality Indicator) value (WCDMA only) All

!CSDONSIO2 32 Configures secondary SIO port for circuit-switched data All

+ECIO 33 Returns total Energy per chip per power density value

(WCDMA only) All

Supported AT Command Reference

12 2130617

+ETFCI 33 Enable / disable / query E-TFCI average value All

!GCIPHER 34 Enables / disables ciphering and integrity settings All

!GETBAND 34 Returns the current active band All

!GETRAT 34 Returns the current active radio access technology

(RAT) All

!GRELIMEI 35 Returns the modem’s production TAC All

!GRESET 35 Resets the modem All

!GSMINFO 36 Displays 2G network information Alla

!GSTATUS 38 Returns operational status All

!GVER 39 Returns the firmware version All

^HVER 39 Returns the modem hardware version All

!NVPORTSET 39 Assigns appropriate USB endpoint AT port AC880 / 881

MC8780 / 81

!PCTEMP 39 Returns current temperature information MC (all)

C885

C888

!PCVOLT 40 Returns current power supply voltage information MC (all)

C885

C888

!POWERDOWN 40 Powers down the system All

!REL 41 Queries the active protocol / revision All

!RESET 41 Resets the modem All

+RSCP 41 Returns Received Signal Code Power (RSCP)

(WCDMA only) All

!SCACT 42 Activates / deactivates PDP context for FIFO interface All

!SCDFTPROF 42 Queries / sets the default profile ID All

!SCDNS 43 Queries / sets profile ID DNS address All

!SCPADDR 43 Displays IP address for specified PDP context All

!SCPROF 44 Queries / sets SWI-specific profile information All

!SCPROFDEL 44 Erase profile information Alla

!SELMODE 45 Queries / sets current service domain All

!SELRAT 45 Queries / sets current radio access technology (RAT) All

Table 1-1: Modem status and reset commands (Continued)

Cmnd Pg Description Supporting

modems

About this Guide

Rev 2.8.1 Feb.11 13

Diagnostic Commands Thischapterdescribescommands

usedtoselectfrequencybandsanddiagnoseproblems.

Test commands Thischapterdescribescommandsrequired

toplacethemodeminparticularmodesofoperation,testhost

connectivity,andconfigurethetransmittersandreceiversfor

testmeasurements.

!SDNOTINSTALLED 45 Returns SD installation status C885

!SIMNOTINSTALLED 46 Returns SIM installation status AC885

C885

C888

MC8785V

MC8790 / 90V

MC8791V

MC8792V

!SMSRETRY 47 Queries / sets SMS retry period and interval AC880 / 881

C885

MC8780 / 81

MC8785V

MC8790 / 90V

MC8791V

MC8792V

!SMSSTSEN 48 Enables / disables SMS status reports Alla

!SWICALLPROG 49 Enables / disables Call Progress Notification All

^SYSCONFIG 51 Queries / sets system configuration information All

^SYSINFO 52 Returns service status information All

!TIME 53 Queries / sets current time of day All

!UDINFO 54 Queries / sets current time of day All

+UPSC 54 Displays Primary Scrambling Code (WCDMA only) All

+USET 55 Displays WCDMA set information All

&V 57 Return operating mode AT configuration parameters All

a. A firmware upgrade may be required, as noted in the detailed listing for this command.

Table 1-1: Modem status and reset commands (Continued)

Cmnd Pg Description Supporting

modems

Table 1-2: Diagnostic commands

Cmnd Pg Description Supporting

modems

!MXSTATS 60 Displays / clears 27.010 statistics All

Supported AT Command Reference

14 2130617

Memory Management Commands Thischapterdescribes

commandsthatcontrolthedatastoredinnon‐volatilememory

ofthemodem.

SIM Commands Thischapterdescribescommandsthat

communicatewithaninstalled(U)SIM.

Conventions

Thefollowingformatconventionsareusedinthisreference:

Charactercodesorkeystrokesthataredescribedwithwordsor

standardabbreviationsareshownwithinanglebracketsusing

adifferentfont,suchas<CR>forCarriageReturnand<space>

forablankspacecharacter.

Numericvaluesaredecimalunlessprefixedasnotedbelow.

Hexadecimalvaluesareshownwithaprefixof0x,i.e.inthe

form0x3D.

Binaryvaluesareshownwithaprefixof0b,i.e.intheform

0b00111101.

Table 1-3: Test commands

Cmnd Pg Description Supporting

modems

!ERR 61 Displays diagnostic information All

!GCCLR 61 Clears crash dump data All

!GCDUMP 61 Displays the crash dump data All

Table 1-4: Memory management commands

Cmnd Pg Description Supporting

modems

!NVBACKUP 63 Backs up items stored in non-volatile memory All

Table 1-5: SIM commands

Cmnd Pg Description Supporting

modems

!AUTH 65 !AUTH = <randNumber> All

!ICCID 66 Returns (U)SIM card’s ICCID All

About this Guide

Rev 2.8.1 Feb.11 15

Commandandregistersyntaxisnotedusinganalternatefont:

!CHAN=<c>[,b].The“AT”charactersarenotshownbutmustbe

includedbeforeallcommandsexceptasnotedinthereference

tables.

Charactersthatarerequiredareshowninuppercase;param‐

etersarenotedinlowercase.Requiredparametersare

enclosedinanglebrackets(<n>)whileoptionalparametersare

enclosedwithinsquarebrackets([x]).Thebracketsarenotto

beincludedinthecommandstring.

Commandsarepresentedintableformat.Eachchaptercovers

thecommandsrelatedtothatsubjectandpresentsasummary

tabletohelpyoulocateaneededcommand.Commandsarein

ASCIIalphabeticalorderinthebodyofeachchapter.

Anydefaultsettingsarenotedinthecommandtables.Note

thatthesearethefactorydefaultsettingsandnotthedefault

parametervalueassumedifnoparameterisspecified.

Result Code Thisisanumericortextcodethatisreturned

afterallcommands(exceptresets).Onlyoneresultcodeis

returnedforacommandlineregardlessofthenumberof

individualcommandscontainedontheline.

Response Thistermindicatesaresponsefromthemodem

thatisissuedpriortoaresultcode.Readingregistersor

issuingcommandsthatreportinformationwillprovidea

responsefollowedbyaresultcodeunlessthecommand

generatesanerror.

Responsesandresultcodesfromthemodem,orhostsystem

softwareprompts,areshowninthisfont:

CONNECT 14400

Supported AT Command Reference

16 2130617

2

Rev 2.8.1 Feb.11 17

2: Supported GSM / WCDMA AT

Commands

ThischapteridentifiestheITU‐TRecommendationV.250,

3GPPTS27.005,and3GPPTS27.007ATcommandsthatare

supportedonregularandvoice‐enabledSierraWireless

modems(AirCard,Compass,andMiniCard).These

commandsareusedto:

•Controlserialcommunicationsoveranasynchronous

interface(ITU‐TRecommendationV. 2 5 0 )

•ControlSMSfunctionsfordevicesonGSM/WCDMA

networks(3GPPTS27.005)

•ControldevicesoperatingonGSM/WCDMAnetworks

(3GPPTS27.007)

TheITU‐Tspecification,SerialAsynchronousDiallingand

Control(RecommendationV.250),isavailableontheInternational

TelecommunicationUnionwebsite,www.itu.int,andthe

3GPPspecificationdocuments,3GPPTS27.007V3.13.0(2003‐

03)and3GPPTS27.007V3.13.0(2003‐03),areavailableonthe

3GPPwebsite,www.3gpp.org.

Thetablesbelowidentifywhethereachcommandissupported

onAirCardmodems,Compassmodems,andMiniCard

embeddedmodules.An“N/A”intheSupportedcolumnofthe

tableindicatesthatthecommandisrelatedtoafeature(such

asvoice)thatisnotavailableonthemodems.

Somecommandsarepartiallysupported—thedescriptionsfor

thesecommandsidentifyanylimitationsoncommandusage.

Also,somecommandsaredescribedinmoredetailinlater

chapters—thedescriptionsforthesecommandslinktothose

detailedentries(forexample,&VinTable2‐1).

Table 2-1: Supported ITU-T Recommendation V.250 AT commands

Command Description Supported

&C Set Data Carrier Detected (Received line signal detector) function

mode No

&D Set Data Terminal Ready function mode No

&F Set all current parameters to manufacturer’s defaults Yes

&S Set DSR signal No

&T Auto tests No

&V Return operating mode AT configuration parameters Yes

Supported AT Command Reference

18 2130617

&W Store current parameter to user-defined profile No

+DR V42bis data compression report Yes

+DS V42bis data compression Yes

+GCAP Request complete TA capabilities list Yes

+GMI Request manufacturer identification Yes

+GMM Request TA model identification Yes

+GMR Request TA revision identification Yes

+GOI Request global object identification No

+GSN Request TA serial number identification Yes

+ICF Set TE-TA control character framing Yes

+IFC Set TE-TA local data flow control Yes

+ILRR Set TE-TA local rate reporting mode No

+IPR Set fixed local rate Yes

AAnswer incoming call Yes

A/ Re-issues last AT command given No

DDial Yes

D><MEM><N> Originate call to phone number in memory <MEM> No

D><N> Originate call to phone number in current memory Yes

D><STR> Originate call to phone number in memory which corresponds to

alphanumeric field <STR> No

DL Redial last telephone number used No

ESet command echo mode Yes

HDisconnect existing connections Yes

IDisplay product identification information Yes

LSet monitor speaker loudness No

MSet monitor speaker mode No

OSwitch from command mode to data mode Yes

PSelect pulse dialing No

QSet Result code presentation mode No

S0 Set number of rings before automatically answering the call Yes

Table 2-1: Supported ITU-T Recommendation V.250 AT commands (Continued)

Command Description Supported

Supported GSM / WCDMA AT Commands

Rev 2.8.1 Feb.11 19

S10 Set disconnect delay after indicating the absence of data carrier Yes

S3 Set command line termination character Yes

S4 Set response formatting character Yes

S5 Set command line editing character Yes

S6 Set pause before blind dialing Yes

S7 Set number of seconds to wait for connection completion Yes

S8 Set number of seconds to wait when comma dial modifier used Yes

TSelect tone dialing Yes

VSet result code format mode Yes

XSet connect result code format and call monitoring Yes

ZSet all current parameters to user-defined profile Yes

Table 2-2: Supported 27.005 AT commands

Command Description Supported

+CBM Cell broadcast message directly displayed Yes

+CBMI Cell broadcast message stored in memory at specified <index>

location No

+CDS SMS status report after sending a SMS Yes

+CDSI Incoming SMS status report Yes

+CMGC Send command Yes

+CMGD Delete message Yes

+CMGF Message format Yes

+CMGL List messages Yes

+CMGR Read message Yes

+CMGS Send message Yes

+CMGW Write message to memory Yes

+CMMS More messages to send Yes

+CMNA New message acknowledgement to ME/TA Yes

+CMS ERROR:

<err> SMS error (mobile or network error) Yes

+CMSS Send message from storage Yes

Table 2-1: Supported ITU-T Recommendation V.250 AT commands (Continued)

Command Description Supported

Supported AT Command Reference

20 2130617

+CMT Incoming message directly displayed Yes

+CMTI Incoming message stored in <mem> (“SM” - (U)SIM message

storage) at location <index> Yes

+CNMA New message acknowledgement to mobile equipment Yes

+CNMI New message indications to TE Yes

+CPMS Preferred message storage Yes

+CRES Restore settings No

+CSAS Save settings No

+CSCA Service centre address Yes

+CSCB Select cell broadcast message types Yes

+CSDH Show text mode parameters Yes

+CSMP Set text mode parameters Yes

+CSMS Select message service Yes

Table 2-3: Supported 27.007 AT commands

Command Description Support

CITU T V.24 circuit 109 carrier detect signal behavior command

Format

•C<value>

Limitations

•Default <value> = 2

•<value> = 2 causes the AT/Data carrier detect pin to ‘wink’

(briefly switch off and on) when data calls end.

•<value> = 0 or 1 performs as defined in the standard

Partial

+CACM Accumulated call meter No

+CACSP Voice Group or Voice Broadcast Call State Attribute Presentation N/A

+CAEMLPP eMLPP Priority Registration and Interrogation No

+CAHLD Leave an ongoing Voice Group or Voice Broadcast Call N/A

+CAJOIN Accept an incoming Voice Group or Voice Broadcast Call N/A

+CALA Alarm N/A

+CALCC List current Voice Group and Voice Broadcast Calls N/A

+CALD Delete alarm N/A

Table 2-2: Supported 27.005 AT commands (Continued)

Command Description Supported

Supported GSM / WCDMA AT Commands

Rev 2.8.1 Feb.11 21

+CALM Alert sound mode No

+CAMM Accumulated call meter maximum No

+CANCHEV NCH Support Indication No

+CAOC Advice of Charge No

+CAPD Postpone or dismiss an alarm N/A

+CAPTT Talker Access for Voice Group Call N/A

+CAREJ Reject an incoming Voice Group or Voice Broadcast Call N/A

+CAULEV Voice Group Call Uplink Status Presentation N/A

+CBC Battery charge Yes

+CBST Select bearer service type Yes

+CCCM Current call meter value No

+CCFC Call forwarding number and conditions Yes

+CCLK Clock N/A

+CCUG Closed user group Yes

+CCWA Call waiting Yes

+CCWE Call Meter maximum event No

+CDIP Called line identification presentation No

+CDIS Display control No

+CEER Extended error report No

+CFUN Set phone functionality

Format

•+CFUN = [ <fun> [, <rst>] ]

Limitations

•Valid <fun> values:

·0 (minimum functionality, low power draw)

·1 (full functionality, high power draw)

Partial

+CGACT PDP context activate or deactivate Yes

+CGANS Manual response to a network request for PDP context activation No

+CGATT PS attach or detach Yes

+CGAUTO Automatic response to a network request for PDP context

activation No

Table 2-3: Supported 27.007 AT commands (Continued)

Command Description Support

Supported AT Command Reference

22 2130617

+CGCLASS GPRS mobile station class Yes

+CGCLOSP Configure local octet stream PAD parameters No

+CGCMOD PDP Context Modify No

+CGDATA Enter data state Yes

+CGDCONT Define PDP Context Yes

+CGDSCONT Define Secondary PDP Context Yes

+CGEQMIN 3G Quality of Service Profile (Minimum acceptable) Yes

+CGEQNEG 3G Quality of Service Profile (Negotiated) Yes

+CGEQREQ 3G Quality of Service Profile (Requested) Yes

+CGEREP Packet Domain event reporting Yes

+CGEV GPRS network event indication Yes

+CGMI Request manufacturer identification Yes

+CGMM Request model identification Yes

+CGMR Request revision identification Yes

+CGPADDR Show PDP address Yes

+CGQMIN Quality of Service Profile (Minimum acceptable) Yes

+CGQREQ Quality of Service Profile (Requested) Yes

+CGREG GPRS network registration status Yes

+CGSMS Select service for MO SMS messages Yes

+CGSN Request product serial number identification Yes

+CGTFT Traffic Flow Template Yes

+CHLD Call related supplementary services Yes

+CHSA HSCSD non-transparent asymmetry configuration N/A

+CHSC HSCSD current call parameters N/A

+CHSD HSCSD device parameters N/A

+CHSR HSCSD parameters report N/A

+CHST HSCSD transparent call configuration N/A

+CHSU HSCSD automatic user initiated upgrading N/A

+CHUP Hangup call Yes

Table 2-3: Supported 27.007 AT commands (Continued)

Command Description Support

Supported GSM / WCDMA AT Commands

Rev 2.8.1 Feb.11 23

+CIEV Indicator event Yes

+CIMI Request international mobile subscriber identity Yes

+CIND Indicator control Yes

+CKEV Key press or release event No

+CKPD Keypad control No

+CLAC List all available AT commands No

+CLAE Language Event No

+CLAN Set Language No

+CLCC List current calls Yes (MC8790V /

MC8791V /

MC8792V)

Partial (other

voice-enabled

modules)

+CLCK Facility lock Yes

+CLIP Calling line identification presentation Yes

+CLIR Calling line identification restriction Yes

+CLVL Sets / returns internal loudspeaker volume Yes

+CMAR Master Reset No

+CME ERROR:

<err> Mobile Termination error result code Yes

+CMEC Mobile Termination control mode No

+CMEE Report Mobile Termination error Yes

+CMER Mobile Termination event reporting Yes

+CMOD Call mode Yes

+CMUT Enables / disables uplink voice muting Yes

+CMUX Multiplexing mode Yes

+CNUM Subscriber number Yes

+COLP Connected line identification presentation Yes

+COPN Read operator names Yes

+COPS Operator selection Yes

+CPAS Phone activity status Yes

Table 2-3: Supported 27.007 AT commands (Continued)

Command Description Support

Supported AT Command Reference

24 2130617

+CPBF Find phonebook entries Yes

+CPBR Read phonebook entries Yes

+CPBS Select phonebook memory storage Yes

+CPBW Write phonebook entry Yes

+CPIN Enter PIN Yes

+CPOL Preferred operator list Yes

+CPROT Enter protocol mode No

+CPUC Price per unit and currency table Yes

+CPWC Power class No

+CPWD Change password Yes

+CR Service reporting control Yes

+CRC Cellular result codes Yes

+CREG Network registration Yes

+CRING Incoming call type Yes

+CRLP Radio link protocol Yes

+CRMP Ring Melody Playback N/A

+CRSL Ringer sound level N/A

+CRSM Restricted SIM access Yes

+CSCC Secure control command No

+CSCS Select TE character set Yes

+CSDF Settings date format N/A

+CSGT Set Greeting Text N/A

+CSIL Silence Command N/A

+CSIM Generic SIM access Yes

+CSNS Single numbering scheme No

+CSQ Signal quality Yes

+CSSN Supplementary service notifications Yes

+CSTA Select type of address Yes

+CSTF Settings time format Yes

Table 2-3: Supported 27.007 AT commands (Continued)

Command Description Support

Supported GSM / WCDMA AT Commands

Rev 2.8.1 Feb.11 25

+CSVM Set Voice Mail Number No

+CTFR Call deflection Yes

+CTZR Time Zone Reporting N/A

+CTZU Automatic Time Zone Update No

+CUSD Unstructured supplementary service data Yes

+CV120 V.120 rate adaption protocol No

+CVHU Voice Hangup Control No

+CVIB Vibrator mode N/A

DITU T V.25ter [14] dial command Yes

D*99# Sets up a packet data call (PDP context) based on profile ID #1 Yes

D*99***<n># Sets up a packet data call (PDP context) based on profile ID #<n>

(<n> is the <cid> in the +CGDCONT command) Yes

+VTD Tone duration Yes

+VTS DTMF and arbitrary tone generation Yes

+WS46 PCCA STD 101 [17] select wireless network No

Table 2-3: Supported 27.007 AT commands (Continued)

Command Description Support

Supported AT Command Reference

26 2130617

3

Rev 2.8.1 Feb.11 27

3: Modem Status, Customization,

and Reset Commands

•Introduction

•Command summary

•Command reference Introduction

Thischapterdescribescommandsusedtoresetthemodem,

adjustcustomizationsettings,retrievethefirmwareversion,

andmonitorthetemperature,voltage,andmodemstatus.

Command summary

Thetablebelowliststhecommandsdescribedinthischapter.

Table 3-1: Modem status commands

Command Description Page

!BAND Selects a set of frequency bands / queries current selection 29

!BCINF Returns the bootloader version 30

!BOOTHOLD Resets modem and waits in bootloader for firmware download 30

^CARDMODE Returns SIM card mode (card type) 30

+CLVL Sets / returns internal loudspeaker volume 31

+CMUT Enables / disables uplink voice muting 31

!CNTI Returns current, available, and supported network technologies 31

+CQI Returns or enables / disables return of averaged CQI (Channel

Quality Indicator) value (WCDMA only) 32

+CSDONSIO2 Configures secondary SIO port for circuit-switched data 32

+ECIO Returns total Energy per chip per power density value

(WCDMA only) 33

+ETFCI Enable / disable / query E-TFCI average value 33

!GCIPHER Returns operational status 38

!GETBAND Returns the current active band 34

!GETRAT Returns the current active radio access technology (RAT) 34

!GRELIMEI Returns the modem’s production TAC 35

!GRESET Resets the modem 35

!GSMINFO Displays 2G network information 36

!GSTATUS Returns operational status 38

Supported AT Command Reference

28 2130617

!GVER Returns the firmware version 39

^HVER Returns the modem hardware version 39

!NVPORTSET Assigns appropriate USB endpoint AT port 39

!PCTEMP Returns current temperature information 39

!PCVOLT Returns current power supply voltage information 40

!POWERDOWN Powers down the system 40

!REL Queries the active protocol / revision 41

!RESET Resets the modem 41

+RSCP Returns Received Signal Code Power (RSCP) (WCDMA only) 41

!SCACT Activates / deactivates PDP context for FIFO interface 42

!SCDFTPROF Queries / sets the default profile ID 42

!SCDNS Queries / sets profile ID DNS address 43

!SCPADDR Displays IP address for specified PDP context 43

!SCPROF Queries / sets SWI-specific profile information 44

!SCPROFDEL Erase profile information 44

!SDNOTINSTALLED Returns SD installation status 45

!SELMODE Queries / sets current service domain 45

!SELRAT Queries / sets current radio access technology (RAT) 45

!SIMNOTINSTALLED Returns SIM installation status 46

!SMSRETRY Queries / sets SMS retry period and interval 47

!SMSSTSEN Enables / disables SMS status reports 48

!SWICALLPROG Enables / disables Call Progress Notification 49

^SYSCONFIG Queries / sets system configuration information 51

^SYSINFO Returns service status information 52

!TIME Queries / sets current time of day 53

!UDINFO Returns information from active USB descriptor 54

+UPSC Displays Primary Scrambling Code (WCDMA only) 54

+USET Displays WCDMA set information 55

&V Return operating mode AT configuration parameters 57

Table 3-1: Modem status commands (Continued)

Command Description Page

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 29

Command reference

Table 3-2: Modem status, customization, and reset commands

Command Description

!BAND=<bandsetInd>

!BAND=?

!BAND?

Supporting modems:

•All

Note: These band sets are

preconfigured by your device’s

manufacturer. The bands

displayed by the query

command (AT!BAND=?)

depend on this configuration,

as shown in this example.

Selects a set of frequency bands / queries current selection

This command is used to configure the modem to operate on a set of

frequency bands, look up the sets available, and query the current selection.

Usage:

•AT!BAND=? reports allowed values for <bandsetInd> and the corre-

sponding frequency bands.

•AT!BAND=<bandsetInd> is used to select a set of bands.

•AT!BAND? reports the current band selection.

Parameters:

<bandsetInd> (band index value — When configured for ‘all regions’, all of the

bands supported by the modem will appear):

•00 = All bands

•01 = WCDMA 2100

•02 = WCDMA 850/1900

•03 = GSM 900/1800

•04 = GSM 850/1900

•05 = GSM ALL

•06 = WCDMA 2100 GSM 900/1800

•07 = WCDMA 850/1900 GSM 850/1900

•08 = WCDMA ALL

•09 = WCDMA 850/2100

•0A = WCDMA 800/2100

•0B = WCDMA 850/2100 GSM 900/1800

•0C = WCDMA 850 GSM 900/1800

•0D = WCDMA 850

•0E = WCDMA 900

•0F = WCDMA 900 / 2100

Example:

When configured for a specific region, AT!BAND=? could return:

00, All bands

01, WCDMA 2100

02, N/A (Defaults to All)

03, GSM 900/1800

04, N/A (Defaults to ALL)

05, GSM ALL

06, N/A (Defaults to ALL)

07, N/A (Defaults to ALL)

08, WCDMA ALL

09, N/A (Defaults to ALL)

0A, N/A (Defaults to ALL)

0B, N/A (Defaults to ALL)

0C, N/A (Defaults to ALL)

0D, N/A (Defaults to ALL)

0D, N/A (Defaults to ALL)

0E, N/A (Defaults to ALL)

Supported AT Command Reference

30 2130617

!BCINF

Supporting modems:

•All

Returns the bootloader version

This command is used to return the module’s bootloader version.

Usage:

•AT!BCINF returns several values—the bootloader version is the second

parameter returned.

Example:

AT!BCINF returns:

BOOT

Address: <...>

Version: <version>

...

Parameters:

<version> (bootloader version):

•ASCII string

•Maximum length: 84 characters

•Example: H1_0_0_0ACBT G:/WS/FW/H1_0_0_0ACBT/MSM6280/SRC

2006/09/01 16:33:30

!BOOTHOLD

Supporting modems:

•All

Resets modem and waits in bootloader for firmware

download

This command is used to prepare for a firmware download by resetting the

modem and waiting in ‘boot and hold’ mode.

Usage:

•AT!BOOTHOLD forces the modem to backup user NV options, reset, and

then wait in boot and hold mode for a firmware download.

^CARDMODE

Supporting modems:

•All

Returns SIM card mode (card type)

This command is used to identify the type of SIM card being used.

Returned parameters:

<sim_type> (the type of sim card)

•0 = unknown

•1 = SIM

•2 = USIM

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 31

+CLVL=<level>

+CLVL=?

+CLVL?

Supporting modems:

•All

Sets / returns internal loudspeaker volume

This command is used to set or report the modem’s internal loudspeaker

volume.

Usage:

•AT+CLVL=<level> sets the volume within a specified range

•AT+CLVL=? reports allowed values for <level>

•AT+CLVL? reports the current volume

Parameters:

<level> (Sound level):

•Manufacturer-specific volume levels

•Valid range: 0(lowest)–7(highest)

+CMUT=<enableFlag>

+CMUT=?

Supporting modems:

•All voice-enabled modems

Enables / disables uplink voice muting

This command is used to enable or disable uplink voice muting during a voice

call.

Usage:

•AT+CMUT=<enableFlag> turns muting on or off

•AT+CMUT=? returns valid <enableFlag> values

Parameters:

<enableFlag> (Enable / disable muting):

•0 = Mute off

•1 = Mute on

*CNTI=<n>

Supporting modems:

•All, with following excep-

tions:

·AC875 / 875U (min.

FW: H1_1_4_1)

Returns current, available, and supported network

technologies

This command is used to report the network technology currently being used,

the technologies available for use, or the technologies supported by the

modem.

Usage:

•AT*CNTI=<n> returns

*CNTI: <n>,<tech>[,<tech>[...]]

Parameters:

<n> (reporting option):

•0 = Network technology currently in use

•1 = Available technologies on current network

•2 = All technologies supported by the modem

<tech> (technology type):

•ASCII string

•Valid values: “GSM”, “GPRS”, “EDGE”, “UMTS”, “HSDPA”, “HSUPA”

(only when <n> = 1)

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

32 2130617

+CQI?

+CQI=<enableFlag>

Supporting modems:

•All

Returns or enables / disables return of averaged CQI

(Channel Quality Indicator) value (WCDMA only)

This command returns the averaged CQI from the modem.

Usage:

•AT!CQI? returns the average CQI and the number of samples used to

determine the average. For example:

+CQI:

total valid samples 1600, average cqi 26

•AT!CQI=<enableFlag> enables or disables the query version of the

command (+CQI?)

Parameters:

<enableFlag> (enable / disable CQI value retrieval):

•0 = Disable retrieval

•1 = Enable retrieval

CSDONSIO2?

!CSDONSIO2=<port#>

Supporting modems:

•All

Configures secondary SIO port for circuit-switched data

This command configures the secondary serial I/O (SIO) port for circuit-

switched data over the main AT port or MUX1 / MUX2 / MUX3.

Note: The modem must be reset before any change takes effect.

Usage:

•AT!CSDONSIO2? returns the current port number currently used for the

SIO port. For example:

+CSDONSIO2:

<port#>

•AT!CSDONSIO2=<port#> sets the port number to use for the SIO port.

Parameters:

<port#> (Port used for circuit-switched data):

•0 = CSD on main AT port (Default)

•1 = CSD on MUX1

•2 = CSD on MUX2

•3 = CSD on MUX3

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 33

+ECIO?

Supporting modems:

•All

Returns total Energy per chip per power density value

(WCDMA only)

This command returns the total energy per chip per power density (Ec/Io)

value of the active set’s three strongest cells.

Usage:

•AT+ECIO? returns the signed dB values of the three strongest cells in the

active set. The values are listed from strongest to weakest, based on

RSCP, and separated by tabs. If there are less than three cells, only

those values appear. For example:

+ECIO:

Ec/Io: -3.5 dB -14.0 dB -24.5 dB

---or---



+ECIO:

Ec/Io: -7.5 dB

•Valid range = -31.5 dB to 0 dB

•The command +USET also displays Tot Ec/Io as one of its outputs.

+ETFCI?

+ETFCI=<status>

Supporting modems:

•MC879x(V) (min.

FW: K1_1_1_1ap)

Enable / disable / query E-TFCI average value

This command enables/disables checking of average E-TFCI values during

an HSUPA call.

The average value is based on 64 sets of log values extracted from the

E-DPCCH packet:

•every 200 ms (for 10 ms TTI) — each set includes 20 samples. A total of

1280 samples are taken (200 ms/set, 20 samples per set, 64 sets over

12.8 second period).

•every 80 ms (for 2 ms TTI) — each set includes 40 samples. A total of

2560 samples are taken (80 ms/set, 40 samples per set, 64 sets over

5.12 second period).

Note: An HSUPA call must be in progress to obtain the E-TFCI.

Usage:

•AT+ETFCI? indicates if E-TFCI checking is enabled, and reports the total

number of samples and average E-TFCI value. For example:

+ETFCI:

Status: <status>

total samples 1280, average etfci <etfci>

•AT+ETFCI=<status> enables or disables the ability to check the average

E-TFCI value.

Parameters:

<status> (E-TFCI reporting status):

•0 — Disabled

•1 — Enabled

<etfci> (Average E-TFCI value over sampling period):

•Valid range = 0–127

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

34 2130617

!GCIPHER = <setting>

!GCIPHER?

Supporting modems:

•All

Enables / disables ciphering and integrity settings

To register onto a network with WCDMA service, the modem’s ciphering and

integrity settings must be enabled or disabled to match the network settings.

Most carriers enable both ciphering and integrity.

When testing the modem, you may be using a SIM that has different codes

for ciphering and integrity than those used by the test system. In this case,

you may need to disable ciphering and integrity checking to use the test

system.

Usage:

•AT!GCIPHER=<setting> sets the ciphering and integrity settings.

•AT!GCIPHER? reports the current ciphering and integrity settings

(0=disabled, 1=enabled).

Parameters:

<setting> (enable / disable ciphering and integrity):

•0 = ciphering disabled; integrity disabled

•1 = ciphering enabled; integrity disabled

•2 = ciphering enabled; integrity enabled

•3 = ciphering disabled; integrity enabled

!GETBAND?

Supporting modems:

•All

Returns the current active band

This command returns the active band currently being used by the modem.

Usage:

•AT!GETBAND? returns a description of the current active band, or returns

an error message.

Note: Due to stack implementation requirements, !GETBAND reports W800

for both W800 and W850.

!GETRAT?

Supporting modems:

•All

Returns the current active radio access technology (RAT)

This command returns the RAT currently being used by the modem.

Usage:

•AT!GETRAT? returns a description of the current RAT, or returns an error

message.

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 35

!GRELIMEI?

Supporting modems:

•All

Returns the modem’s production TAC

This command returns the modem’s production TAC (Type Allocation Code).

(TAC is first 8 chars, then padded with Zeros). EG: if IMEI is

289258158732085, returns 289258150000000.

Usage:

•AT!GRELIMEI? returns the <TAC> assigned to the modem.

Parameters:

<TAC>

•15-character string. First 8 characters are the TAC, remainder of string is

zero-padded.

Example:

If the modem’s IMEI is 289258158732085, !GRELIMEI returns

289258150000000.

!GRESET

Supporting modems:

•All

Resets the modem

This command performs a modem reset.

Note: This command is identical in function to !RESET.

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

36 2130617

!GSMINFO?

Supporting modems:

•All, with following excep-

tions:

·MC8775 (min.

FW: H1_1_8_13mcap)

·AC875 (min.

FW: H1_1_8_13acap)

Displays 2G network information

This command returns 2G network information for the ‘serving’ cell and up to

6 ‘neighbor’ cells.

Parameters: (referenced in example below)

<mccmnc>: Mobile Country Code and Mobile Network Code (combine to

form the PLMN)

•16-bit decimal

<lac>: Location Area Code

•16-bit decimal

<cellid>: Cell ID

•16-bit decimal

<bsic>: Base Station Identity Code

•8-bit decimal

<ncc>: Network Color Code

•8-bit decimal

<bscc>: Base Station Color Code

•8-bit decimal

<rac>: Routing Area Code

•8-bit decimal

<minrx>: Minimum Rx level (dBm) needed to register

•16-bit decimal

<maxrach>: Reserved for future use

•16-bit decimal

<band>: Indicates the 2G network band

•Valid values: “E900”, “P900”, “1900”, “1800”, “850”, “Unknown”

<arfcn>: Absolute Radio Frequency Channel Number

•16-bit decimal

<rxlvl>: Received BCCH frequency level (dBm)

•16-bit decimal

<c1>: C1 cell selection criteria

•16-bit decimal

<c2>: C2 cell selection criteria

•16-bit decimal

<c31>: C31 cell selection criteria

•16-bit decimal

<c32>: C32 cell selection criteria

•16-bit decimalf

(Continued on next page)

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 37

!GSMINFO

(Continued) Displays 2G network information

Example

AT!GSMINFO?

returns:

!gsminfo:

Serving Cell:

PLMN: <mccmnc>

LAC: <lac>

Cell ID: <cellid>

BSIC: <bsic>

NCC: <ncc>

BSCC: <bscc>

RAC: <rac>

Min Rx Lvl Rqd: <minrx>

Max Rach: <maxrach>

Band: <band>

ARFCN: <arfcn>

RX level (dBm): <rxlvl>

C1: <c1>

C2: <c2>

C31: <c31>

C32: <c32>

Neighbour Cells:

Band: <band> <band> <band>

ARFCN: <arfcn> <arfcn> <arfcn>

RAC: <rac> <rac> <rac>

RX level (dBm): <rxlvl> <rxlvl> <rxlvl>

C1: <c1> <c1> <c1>

C2: <c2> <c2> <c2>

C31: <c31> <c31> <c31>

C32: <c32> <c32> <c32>

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

38 2130617

!GSTATUS?

Supporting modems:

•All

Returns operational status

This command returns specific details about the current operational status of

the modem.

Parameters:

<ctime>: Current time (Seconds from bootup)

<temperature>: Approximate temperature (5C)

<btime>: Bootup Time (Seconds from reset)

<mode>: Current modem mode

•(“POWERING OFF”, “FACTORY TEST”, “OFFLINE”, “ONLINE”,

“LOW POWER MODE”, “RESETTING”, “NETWORK TEST”, “OFFLINE

REQUEST”, “PSEUDO ONLINE”, “Unknown”)

<smode>: System mode acquired by modem

•(“No service”, “AMPS”, “CDMA”, “GSM”, “HDR”, “WCDMA”, “GPS”,

“WCDMA+GSM”, “Unknown”)

<PSstate>: Current PS state

•(“Attached”, “Not attached”)

<wband>: Current WCDMA band being accessed

•(“CDMA cell”, “CDMA PCS”, “IMT2000”, “WCDMA1900”,

“WCDMA1800”, “WCDMA800”, “GSM EGSM900”, “GSM DCS1800”,

“GSM 850”, “GSM1900”, “GPS”, “No band”, “WCDMA900”)

<gband>: Current GSM band, either TCH or BCCH

•(“GSM850”, “GSM900”, “DCS1800”, “PCS1900”, “Unknown”)

<wchan>: WCDMA channel number

<gchan>: GSM channel number

<gmmstate>: Current GMM state

•(“IDLE”, “DEREGISTERED”, “Registering”, “REGISTERED”,

“Deregistering”, “RA updating”, “Requesting srvc”)

<gmmsubstate>: Current GMM sub-state

•(“NORMAL SERVICE”, “LIMITED SERVICE”, “ATT NEEDED”,

“ATTEMPTING ATT”, “NO IMSI”, “NO SERVICE”, “PLMN SEARCH”,

“SUSPENDED”, “UPDATE NEEDED”, “UPDATING”, “DEATACHING”,

“---”)

Note: “---” indicates ‘undefined sub-state’

<mmstate>: Current MM state

•(“NULL”, “IDLE”, “LA Rejected”, “LA Start”, “CONNECTED”,

Network Command”, “---”)

Note: “---” indicates ‘undefined state’

<mmsubstate>: Current MM sub-state

•(“NORMAL SERVICE”, “LIMITED SERVICE”, “NO IMSI”,

“NO SERVICE”, “PLMN SEARCH”, “UPDATE NEEDED”,

“UPDATING”, “---”)

Note: “---” indicates ‘undefined sub-state’

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 39

!GVER?

Supporting modems:

•All

Returns the firmware version

This command returns the firmware version as a string in the format

version yyyy/mm/dd hh:mm:ss.

^HVER

Supporting modems:

•All

Returns the modem hardware version

This command returns the modem’s hardware version number based on the

FSN.

The version number is returned as a short string representing the actual

version.

Examples:

•“E2” – Eng2 device

•“1.0” – Production v1.0

•“1.1” – Production v1.1

•etc.

!NVPORTSET?

!NVPORTSET=

<mapping>

Supporting modems:

•MC8780 / 81

•AC880 / 881

Assigns appropriate USB endpoint AT port

This command maps the AT port to either endpoint 5 or endpoint 2 in non-

MUX mode, or reports the current mapping.

Usage:

•AT!NVPORTSET? returns the current endpoint <mapping>

•AT!NVPORTSET=<mapping> maps the AT port to the appropriate USB

endpoint

Parameters:

<mapping> (mapping type):

•0 = endpoint 5 (Default value)

•1 = endpoint 2

!PCTEMP?

Supporting modems:

•All MC modems

•C885

•C888

Returns current temperature information

This command returns the module’s temperature state and actual

temperature.

Usage:

•AT!PCTEMP? returns the <state> and <temperature>.

Parameters:

<state> (temperature state):

•“Normal”

•“High Warning”

•“High Critical”

•“Low Critical”

<temperature> (current temperature):

•Current temperature in degrees Celsius – this is the highest temperature

reported by the two thermistors (one measures the PA (Power Amplifier)

used by the WCDMA transceiver, the other measures the temperature of

the PA used by the GSM transceiver).

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

40 2130617

!PCVOLT?

Supporting modems:

•All MC modems

•C885

•C888

Returns current power supply voltage information

This command returns the module’s power supply state and actual voltage.

Usage:

•AT!PCVOLT? returns the <state>, <voltage>, and <raw> (Analog/Digital

Convertor reading).

Parameters:

<state> (power supply state):

•“Normal”

•“High Critical”

•“Low Warning”

•“Low Critical”

<voltage>:

•Current voltage reading in mV.

<raw>:

•Analog/Digital Convertor reading

!POWERDOWN

Supporting modems:

•All

Powers down the system

This command powers down the system. After using this command, the

modem will not communicate with the host until it has been power cycled.

Usage:

•AT!POWERDOWN returns “OK” and powers the system down.

Note: This command should only be used when testing using an appropriate

testing jig—do not use it when the modem is installed in a computer.

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 41

!REL?

Supporting modems:

•All

Queries the active protocol / revision

This command is used to indicate the modem’s current protocol, SGSN, and

MSC revision settings.

Usage:

•AT!REL? reports the current operating protocol, SGSN revision, and MSC

revision in the format <wcdmarrc> <sgsnr> <mscr> (each value appears

on a separate line).

Parameters:

<wcdmarrc>: WCDMA RRC Revision (Protocol)

•00 = Release 99

•01 = Release 5 (Default)

<sgsnr>: SGSN Revision

•00 = Release 97

•01 = Release 99

•02 = Release 5

•03 = Dynamic (Default)—uses whichever protocol is broadcast by the

network

<mscr>: MSC Revision

•00 = Release 97

•01 = Release 99

•02 = Release 5

•03 = Dynamic (Default)—uses whichever protocol is broadcast by the

network

!RESET

Supporting modems:

•All

Resets the modem

This command performs a modem reset.

Note: This command is identical in function to !GRESET.

+RSCP?

Supporting modems:

•All

Returns Received Signal Code Power (RSCP) (WCDMA

only)

This command returns the RSCP of the active set’s three strongest cells.

Usage:

•AT!RSCP? returns the signed dBm value, from weakest to strongest cell.

For example:

+RSCP:

RSCP: -73 dBm -84 dBm

•Valid return values: -120 dBm to -20 dBm

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

42 2130617

!SCACT? [<pid>]

!SCACT=<state>[, <pid>]

Supporting modems:

•All

Activates / deactivates PDP context for FIFO interface

This command is used to activate or deactivate the specified PDP context for

FIFO interface.

Usage:

•AT!SCACT?[<pid>] reports the status of the identified profile (<pid>). If no

<pid> is specified, the status of all profiles is returned.

•AT!SCACT=<state>[,<pid>] is used to set the state of the identified profile

(<pid>). If no <pid> is specified, profile 1 is updated.

Parameters:

<state> (PDP context activation state):

•0 = Deactivated

•1 = Activated

•During assignment, any <state> other than 1 or 2 will return an ERROR

response.

<pid> (PDP context definition):

•Valid range: 1–16

!SCDFTPROF?

!SCDFTPROF=<pid>

Supporting modems:

•All

Queries / sets the default profile ID

This command is used to query / set the default profile ID.

Usage:

•AT!SCDFTPROF? returns the default profile ID (<pid>).

•AT!SCDFTPROF=<pid> sets the default profile ID to <pid>.

Parameters:

<pid> (Profile ID):

•Valid range: 1–16 — a valid profile ID that will be used as the default

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 43

!SCDNS?<pid>

!SCDNS=<pid>,

<pri_dns>,<sec_dns>

Supporting modems:

•All

Queries / sets profile ID DNS address

This command is used to query / set the primary and secondary DNS

addresses of a profile.

Usage:

•AT!SCDNS?<pid> returns the primary (<pri_dns>) and secondary

(<sec_dns>) DNS addresses for the specified profile (<pid>).

•AT!SCDNS=<pid>,<pri_dns>,<sec_dns> sets the default primary and

secondary IP addresses for domain name services.

Parameters:

<pid> (PDP context definition)

•Valid range: 1–16 — a valid profile ID that will be used as the default

<pri_dns> (Default primary IP address for DNS lookup):

•‘Dot format’ IP address. For example, 10.10.10.1

•Used by modem when no DNS server address is received over the air

during PDP context activation

<sec_dns>: Default secondary IP address for DNS lookup

•‘Dot format’ IP address. For example, 10.10.10.1

•Used by modem when no DNS server address is received over the air

during PDP context activation

!SCPADDR=<pid>

Supporting modems:

•All

Displays IP address for specified PDP context

This command is used to display the IP address of the specified PDP context

(profile), or for all profiles.

Usage:

•AT!SCPADDR=<pid> returns the IP address for the specified <pid> in the

format <pid>, <addr>.

•AT!SCPADDR= returns the IP addresses for all defined profiles.

Parameters:

<pid> (profile ID (PDP context))

•Valid range: 1–16

<addr> (IP address of <pid>)

•‘Dot’ format IP address (for exampel, 255.255.255.0)

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

44 2130617

!SCPROF?<pid>

!SCPROF=<pid>,<label>,

<autoconnect>,

<promptforpassword>,

<autolaunchapp>,

<rffu>

Supporting modems:

•All

Queries / sets SWI-specific profile information

This command is used to query / set the SWI specific information for a profile.

Usage:

•!SCPROF?<pid> reports current SWI-specific information for the

specified profile (<pid>) in the format <pid> <label> <autoconnect>

<promptforpassword> <autolaunchapp> <pdplingertimer>.

•!SCPROF=<pid>...<pdplingertimer> sets the SWI-specific information for

the specified profile (<pid>).

Parameters:

<pid>: PDP context definition

•Valid range: 1–16 — a valid profile ID that will be used as the default

<label>: Configuration buffer label

•30-character string surrounded by quotation marks

<autoconnect>: Automatic context activation mode

•0 = manual activation

•1 = auto activation

<promptforpassword>: Flag value (prompt for password)

•0 = do not prompt for password

•1 = prompt for password

<autolaunchapp>: Flag value (auto launch application)

•0 = do not auto launch the application

•1 = auto launch the application

<rffu>: Reserved for future use

•0–32767 = Reserved

!SCPROFDEL=?

!SCPROFDEL=<pid>

!SCPROFDEL

Supporting modems:

•AC875 (min.

FW: H2_0_8_8ap)

•AC880 / 881 (min.

FW: F1_2_3_14ap)

•C888

•MC8775 (min.

FW: H2_0_8_8mcap)

•MC8780 / 81 (min.

FW: F1_2_3_14ap)

•MC8785V

•MC8790 / 90V

•MC8791V

•MC8792V

Erase profile information

This command is used to erase the information for one or all profiles.

Usage:

•!SCPROFDEL=? returns valid formats for the assignment command

(!SCPROFDEL=).

•!SCPROFDEL=<pid>deletes the identified profile.

•!SCPROFDEL deletes all profiles

Parameters:

<pid>: PDP context definition

•Valid range: 1–16

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 45

!SDNOTINSTALLED?

Supporting modems:

•C885

Returns SD installation status

This command is used to indicate if an SD card is in the modem.

Usage:

•AT!SDNOTINSTALLED? returns:

·‘OK’ if an SD card is not currently installed

·‘ERROR’ if there is an SD card currently installed

!SELMODE?

!SELMODE=?

!SELMODE=<sdInd>

Supporting modems:

•All

Queries / sets current service domain

This command is used to configure the modem to use a specific service

domain.

Usage:

•AT!SELMODE? returns the current service domain index (<sdInd>) and

description. If the <sdInd> is undefined, an error message is returned.

•AT!SELMODE=? returns a list of supported service domain indexes in the

format <sdInd>, <description>.

•AT!SELMODE=<sdInd> sets the desired service domain.

Parameters:

<sdInd> (service domain index):

•00 = CS only

•01 = PS only

•02 = CS and PS

!SELRAT?

!SELRAT=?

!SELRAT=<ratInd>

Supporting modems:

•All

Queries / sets current radio access technology (RAT)

This command is used to configure the modem to use a specific (or

preferred) RAT.

Usage:

•AT!SELRAT? returns the current RAT configuration index (<ratInd>) and

description. If the <ratInd> is undefined, an error message is returned.

•AT!SELRAT=? returns a list of supported RAT configurations in the format

<ratInd>, <description>.

•AT!SELRAT=<ratInd> sets the desired RAT configuration.

Parameters:

<ratInd> (RAT configuration index):

•00 = Automatic

•01 = UMTS 3G only

•02 = GSM 2G only

•03 = UMTS 3G preferred

•04 = GSM 2G preferred

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

46 2130617

!SIMNOTINSTALLED?

Supporting modems:

•AC885

•C885

•C888

•MC8785V

•MC8790 / 90V

•MC8791V

•MC8792V

Returns SIM installation status

This command is used to indicate if a SIM is installed for the modem.

Usage:

•AT!SIMNOTINSTALLED? returns:

·‘OK’ if a SIM is not currently installed

·‘ERROR’ if there is a SIM currently installedf

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 47

!SMSRETRY?

!SMSRETRY=?

!SMSRETRY=<period>,

<interval>

Supporting modems:

•AC880 / 881

•C885

•C888

•MC8780 / 81

•MC8785V

•MC8790 / MC8790V

•MC8791V

•MC8792V

Queries / sets SMS retry period and interval

This command is used to configure the SMS retry period and interval for MO-

SMS.

Usage:

•AT!SMSRETRY? returns the current <period> and <interval> settings.

•AT!SMSRETRY=? reports the format used for AT!SMSRETRY.

•AT!SMSRETRY=<period>, <interval> sets the retry period and retry

interval

Parameters:

<period> (Number of seconds allowed for MO-SMS retry attempts):

•0–255

<interval> (Number of seconds to wait between MO-SMS retry attempts):

•0–255

Note: If <interval> is greater than <period>, a single retry attempt is made.

Note: <interval> ignores the time spent actually performing a retry attempt. If

<interval> = 5, attempts are made at elapsedTime = 0, 5, 10, etc. until an

attempt is successful or <period> - elapsedTime < <interval>.

Example 1:

Assume a retry attempt takes 2 seconds.

If <period> = 1 and <interval> = 8, and no attempts are successful:

•time = 0: Retry attempt fails at time = 2. No more attempts are made

because <period> has expired.

Example 2:

Assume a retry attempt takes 2 seconds.

If <period> = 3 and <interval> = 5, and no attempts are successful:

•time = 0: Retry attempt fails at time = 2. No more attempts are made

because <period> will expire before the <interval> passes.

Example 3:

Assume a retry attempt takes 2 seconds.

If <period> = 14 and <interval> = 5, and no attempts are successful:

•time = 0: Retry attempt fails at time = 2; next attempt will begin at time=5

(the <interval> counts from the beginning of the previous attempt)

•time = 5: Retry attempt fails at time = 7; next attempt will begin at time=10

•time = 10: retry attempt fails at time = 12; No more attempts will be made

because the <period> will expire before another <interval> of 5 seconds

can pass.

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

48 2130617

!SMSSTSEN?

!SMSSTSEN=?

!SMSSTSEN=<enable>,

<mode>

Supporting modems:

•All, with following excep-

tions:

·AC875 (min. FW:

H1_1_8_14Acap)

·MC8775 / 75V (min.

FW: H1_1_8_14mcap)

Enables / disables SMS status reports

This command is used to enable / disable SMS status reports for MO-SMS

messages, and to indicate if the user should be able to enable / disable the

reports.

The status report indicates when a message is delivered to its intended

recipient (in addition to the report that is sent when the network first receives

the message).

Usage:

•AT!SMSSTSEN? returns the current <enable> and <mode> settings.

•AT!SMSSTSEN=? reports the format used for AT!SMSSTSEN.

•AT!SMSSTSEN=<enable>, <mode> enables / disables status reports,

and indicates if the user can enable / disable the feature.

Parameters:

<enable> (Enable / Disable SMS status reports):

•0 = Disable

•1 = Enable

<mode> (User access to reporting feature):

•0 = Read / Write (User can enable / disable the feature)

•1 = Read only (User cannot enable / disable the feature—the feature

status is preset by the device provider)

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 49

!SWICALLPROG?

!SWICALLPROG

=<cpnStatus>

Supporting modems:

•All

Enables / disables Call Progress Notification

This command is used to enable or disable call progress notification. This

allows the host to receive call status updates such as type of call, answered,

on hold, etc.

Usage:

•AT!SWICALLPROG? returns the current <cpnStatus>.

•AT!SWICALLPROG=<cpnStatus> Information on current calls is returned,

when the call status changes, in the format:

!SWICALLPROG:<idx1>,<dir>,<stat>,<mode>,<mpty>,<number>,<type>,

<alpha>

!SWICALLPROG:<idx2>,<dir>,<stat>,<mode>,<mpty>,<number>,<type>,

<alpha>

...

Note: When call progress notification is enabled, the standard AT command

+CLCC (List Current Calls) is disabled.

Parameters:

<cpnStatus> (Call progress notification status):

•0 = Disabled

•1 = Output on AT channel if AT is not blocked

•2 = Output on AT channel even if AT is blocked

•Any other value will return an ERROR response

<idx> (Call identification number):

•Integer value as described in GSM 02.30 Section 4.5.5.1

•Can be used in +CHLD command

<dir> (Call direction):

•0 = Mobile-originated (MO)

•1 = Mobile-terminated (MT)

<state> (Call state):

•0 = Active

•1 = Held

•2 = Dialing (MO calls)

•3 = Alerting (MO calls)

•4 = Incoming (MT calls)

•5 = Waiting (MT calls)

•6 = Disconnected

<mode> (Bearer / teleservice):

•0 = Voice

•1 = Data

•2 = Fax

(Continued on next page)

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

50 2130617

!SWICALLPROG

(Continued) Enables / disables Call Progress Notification (Continued)

<mpty> (Multiparty status):

•0 = Not part of a multiparty (conference) call

•1 = Part of a multiparty (conference) call

<number> (Telephone number of other end of connection):

•format specified by next parameter (<type>)

<type> (Address octet type):

•Two bitfields identifying the type of telephone number and numbering

plan type (national / international).

•Format specified in 3GPP TS 24.008 Section 10.5.4.7

<alpha> (Tag associated with <number> in the phonebook):

•Example: “John Doe”

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 51

^SYSCONFIG?

^SYSCONFIG=<mode>,

<acqorder>, <roam>,

<srvDomain>

Supporting modems:

•All

Queries / sets system configuration information

This command is used to set and retrieve the modem’s configuration.

Usage:

•AT^SYSCONFIG= sets the various configuration parameters. You must

specify all of the parameters.

•AT^SYSCONFIG? returns the current modem configuration information in

the format <mode> <netAccessOrder> <roaming> <srvDomain>.

Parameters:

<mode> (Supported system mode):

•2 = Auto-select

•13 = GSM only

•14 = WCDMA only

•16 = No change—use this value with AT^SYSCONFIG= if you do not

want to change the current setting.

<acqOrder> (Network acquisition order)

•0 = Automatic

•1 = GSM, then WCDMA

•2 = WCDMA, then GSM

•3 = No change—use this value with AT^SYSCONFIG= if you do not want

to change the current setting.

<roam> (Roaming support)

•0 = Not supported

•1 = Supported

•2 = No change—use this value with AT^SYSCONFIG= if you do not want

to change the current setting.

<srvDomain> (Service domain support)

•0 = Circuit-switched only

•1 = Packet-switched only

•2 = Circuit- and packet-switched

•3 = Any

•4 = No change—use this value with AT^SYSCONFIG= if you do not want

to change the current setting.

<simStatus> (SIM status)

•0 = SIM is not available

•1 = SIM is available

•255 = No SIM, or the SIM has been PIN-locked (invalid PIN was entered

and must be reset)

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

52 2130617

^SYSINFO

Supporting modems:

•All

Returns service status information

This command returns current service type and availability information, and

the current status of the module’s SIM in the format <srvStatus>

<srvDomain> <roamStatus> <sysMode> <simState>.

Parameters:

<srvStatus> – Service availability

•0 = No service

•1 = Limited service

•2 = Service

•3 = Limited regional service

•4 = Power save mode or deep sleep mode

<srvDomain> – Service domain

•0 = No service

•1 = Circuit-switched service only

•2 = Packet-switched service only

•3 = Circuit- and packet-switched service

<roamStatus> – Roaming status indicator

•0 = Not roaming

•1 = Roaming

<sysMode> – System mode

•0 = No service

•3 = GSM / GPRS mode

•5 = WCDMA mode

<simStatus> – SIM status

•0 = SIM is not available

•1 = SIM is available

•255 = No SIM, or the SIM has been PIN-locked (invalid PIN was entered

and must be reset)

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 53

!TIME=<YYYY>, <MM>,

<DD>, <hh>, <mm>, <ss>

[, <TZ>, <DST>]

!TIME?

!TIME=?

Supporting modems:

•All

Queries / sets current time of day

This command is used to set and retrieve the current time of day—the time of

day can be set using this command, or could be set by the network. If the

time has not been set, the command returns ERROR.

Usage:

•AT!TIME= <YYYY>,<MM>,<DD>,<hh>,<mm>,<ss> [, <TZ>, <DST>] sets

the current time.

•AT!TIME? returns four lines of data. Lines 1-2 show local date and time,

lines 3-4 show UTC date and time. Date format is YYYY/MM/DD; time

format is hh:mm:ss.

Example response:

!TIME:

2007/10/21

10:23:38 (local)

2007/10/21

17:23:38 (UTC)

OK

Note: In this example, <tz> is -32 (-8 hours) and DST is 1 (+1 hour).

•AT!TIME=? reports the format used for AT!TIME

Parameters:

<YYYY> – year

•4 digits required

<MM> – month

•Valid values: 01–12

<DD> – day

•Valid values: 01–31

<hh> – hour

•Valid values: 00-23

<mm> – minute

•Valid values: 00–59

<ss> – second

•Valid values: 00–59

<TZ> – time zone offset from UTC in 15-minute increments

•Valid values: -48 to 48

•<DST> must also be set if <TZ> is used

<DST> – Daylight Saving Time offset in 1-hour increments

•Valid values: 0 to 2

•<TZ> must also be set if <DST> is used

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

54 2130617

!UDINFO?

Supporting modems:

•All

Returns information from active USB descriptor

This command returns information from the active USB descriptor in the

format <vid> <pid> <manuf string> <product string> (each parameter on a

separate line).

Parameters:

<vid> – Vendor ID

•Valid range: 0000–FFFF

<pid> – Product ID

•Valid range: 0000–FFFF

<manuf string> – Manufacturer string

•ASCII string (29 characters maximum)

•Example: “Sierra Wireless, Incorporated”

<product string> – Product string

•ASCII string (64 characters maximum)

•Example: “Mini Card”

+UPSC

Supporting modems:

•All

Displays Primary Scrambling Code (WCDMA only)

This command displays the Primary Scrambling Code (PSC) of the reference

WCDMA cell.

Example:

AT!UPSC returns:

+UPSC: <psc>

Parameters:

<psc> – Primary Scrambling Code of reference WCDMA cell

•Valid range: 0-255

•255 = No valid cell

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 55

+USET?<set>

+USET=?

Supporting modems:

•All

Displays WCDMA set information

This command displays WCDMA set information (Active Set, Candidate Set,

etc.).

Usage:

•AT+USET?<set> returns detailed information about each item in the

<set>.

•AT+USET=? returns the list of valid <set> values

Example:

AT+USET?<set> returns:

+USET: <setName>

Count: <count>

PSC: <psc> <ref>

SSC: <ssc>

STTD: <sttd>

Tot Ec/Io: <totEcIo>

Ec/Io: <EcIo>

RSCP: <rscp>

Window Size: <winSize>



... (repeats for <count> items)

Parameters:

<set> – Set for which details are requested

•Valid range: 0–11 (see <setName> for descriptions)

<setName> – Description of <set> value

•ASCII string

•Valid values:

0-Active Set

1-Sync Neighbour Set

2-Async Neighbour Set

3-Unlisted Set

4-Add-Candidate Set

5-Drop-Candidate Set

6-After failed W2G Set

7-DCH-Only Set

8-HHO Active Set

9-HHO Active No PN Set

10-Candidate to Unlisted Set

11-Saved Set

<count> – Number of items in <set>

•Valid range: 0-255

<psc> – Primary Scrambling Code

•Valid range: 0–FFFF

(Continued on next page)

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

56 2130617

+USET Displays WCDMA set information (Continued)

<ref> – Reference PSC designator string

•Displays “(REF)” if this is the reference PSC

<ssc> – Secondary Scrambling Code

•Valid range: 0–FFFF

<sttd> – Common Pilot Channel (CPICH) supports Space Time Transit

Diversity

•0 = Not supported

•1 = Supported

<totEcIo> – Total Ec/Io

•Valid range: 00–FF

•To convert to a dB value, convert to decimal and divide by -2.

Example: 0x0B / -2 = 11 / -2 = -5.5 dB

•Note: The command AT+ECIO? also reports Total Ec/Io as a dB value.

<EcIo> – Best path Ec/Io

•Valid range: 00–FF

•To convert to a dB value, convert to decimal and divide by -2.

Example: 0x0B / -2 = 11 / -2 = -5.5 dB

<rscp> – Received Signal Code Power

•Valid range: 0-FFFF

<winSize> – Search window size

•Valid range: 0000–FFFFFFFF

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Modem Status, Customization, and Reset Commands

Rev 2.8.1 Feb.11 57

&V

Supporting modems:

•All

Return operating mode AT configuration parameters

This command returns the status of all AT command parameters that apply to

the current operating mode.

Example:

“AT&V <Enter>

&C: 2; &D: 2; &F: 0; E: 1; L: 0; M: 0; Q: 0; V: 1; X: 0; Z: 0; S0: 0; S2: 43;

S3: 13; S4: 10; S5: 8; S6: 2; S7: 50; S8: 2; S9: 6; S10: 14; S11: 95;

+FCLASS: 0; +ICF: 3,3; +IFC: 2,2; +IPR: 115200; +DR: 0; +DS:

0,0,2048,6;+WS46: 12; +CBST: 0,0,1;+CRLP:

(61,61,48,6,0),(61,61,48,6,1),(240,240,52,6,2);+CV120: 1,1,1,0,0,0; +CHSN:

0,0,0,0; +CSSN: 0,0; +CREG: 0; +CGREG: 0;+CFUN:; +CSCS: "IRA";

+CSTA: 129; +CR: 0; +CRC: 0; +CMEE: 2; +CGDCONT: (1,"IP","","",0,0);

+CGDSCONT: ; +CGTFT: ; +CGEQREQ: ; +CGEQMIN: ; +CGQREQ: ;

+CGQMIN: ;+CGEREP: 0,0; +CGDATA: "PPP"; +CGCLASS: "A"; +CGSMS:

3; +CSMS: 0;+CMGF: 0; +CSCA: "",; +CSMP: ,,0,0; +CSDH: 0; +CSCB:

0,"",""; +FDD: 0;+FAR: 0; +FCL: 0; +FIT: 0,0; +ES: ,,; +ESA: 0,,,,0,0,255,;

+CMOD: 0;+CVHU: 0; +CPIN: ,; +CMEC: 0,0,0; +CKPD: 1,1; +CGATT: 0;

+CGACT: 0;+CPBS: "SM"; +CPMS: "SM","SM","SM"; +CNMI: 0,0,0,0,0;

+CMMS: 0; +FTS: 0;+FRS: 0; +FTH: 3; +FRH: 3; +FTM: 96; +FRM: 96;

+CCUG: 0,0,0;+COPS: 0,0,""; +CUSD: 0; +CAOC: 1; +CCWA: 0; +CPOL:

0,2,""; +CTZR: 0;+CLIP: 0; +COLP: 0; +CMUX:

0,0,5,31,10,3,30,10,2;!CMUX: 0,0,5,31,10,3,30,10,2



OK”

Table 3-2: Modem status, customization, and reset commands (Continued)

Command Description

Supported AT Command Reference

58 2130617

4

Rev 2.8.1 Feb.11 59

4: Diagnostic Commands

•Introduction

•Command summary

•Command reference Introduction

Thischapterdescribescommandsusedtodiagnosemodem

problems.

Command summary

Thetablebelowliststhecommandsdescribedinthischapter.

Table 4-1: Diagnostic commands

Cmnd Description Page

!MXSTATS Displays / clears 27.010 statistics 60

Supported AT Command Reference

60 2130617

Command reference

Table 4-2: Diagnostic command details

Command Description

!MXSTATS=0

!MXSTATS?

Supporting modems:

•All

Displays / clears 27.010 statistics

TS 27.010 is a standard that defines a multiplexing protocol between a

mobile station and a terminal. This standard is supported on the modem

and AT!MXSTATS is used to display statistics related to that protocol for

debugging purposes.

Usage:

•AT!MXSTATS=0 clears the statistics.

•AT!MXSTATS? reports the statistics.

The command AT!MXSTATS? returns these statistics:

•Sessions Started

•Sessions Ended

•SABM (Tx/Rx)

•DISC (Tx/Rx)

•UA (Tx/Rx)

•DM (Tx/Rx)

•UIH (Tx/Rx)

•T1 expiry

•T2 expiry

•T3 expiry

•N1 count

•N2 count

•Bad Frame (addr)

•Bad Frame (ctl)

•Bad Frame (len)

•Bad Frame (F9)

•Bad Frame (fcs)

•Bad Frame (mem)

Values are accumulated until cleared (by issuing the command

AT!MXSTATS=0).

5

Rev 2.8.1 Feb.11 61

5: Test commands

•Introduction

•Command summary

•Command reference Introduction

Thischapterdescribescommandsusedtodisplayandclear

datathatisstoredifthemodemcrashes.

Command summary

Thetablebelowliststhecommandsdescribedinthischapter.

Command reference

Table 5-1: Test commands

Cmnd Description Page

!ERR Displays diagnostic information 61

!GCCLR Clears crash dump data 61

!GCDUMP Displays the crash dump data 61

Table 5-2: Test command details

Command Description

!ERR

Supporting modems:

•All

Displays diagnostic information

This command is used to display diagnostic information that Sierra Wireless

uses to assist in resolving technical issues.

!GCCLR

Supporting modems:

•All

Clears crash dump data

This command clears the crash dump and assert data.

!GCDUMP

Supporting modems:

•All

Displays the crash dump data

This command displays crash dump data. If there is no crash dump data, it

displays the string “No crash data available”.

Supported AT Command Reference

62 2130617

6

Rev 2.8.1 Feb.11 63

6: Memory Management

Commands

Introduction

Themodemhas2MBofnon‐volatilememorythatisusedto

store:

•Factorycalibrationdata

•SettingsmadeinahostapplicationsuchasWatcher

Thecommandsinthischapterallowyoutobackupand

restorethedatainnon‐volatilememory.

Command summary

Thetablebelowliststhecommandsdescribedinthischapter:

Command reference

Table 6-1: Memory management command passwords

Command Description Page

!NVBACKUP Backs up items stored in non-volatile memory 63

Table 6-2: Memory management command details

Command Description

!NVBACKUP

=<category>

Supporting modems:

•All

Backs up items stored in non-volatile memory

This command creates a backup that is stored in the modem’s flash memory.

Parameters:

<category> (specify items to back up):

•0 = Factory items (RF calibration data) — Used only at the factory (only

needs to be done once for the lifetime of the device)

•1 = OEM items (PRI customizations) — Used only by the OEM when loading

a new PRI configuration (only needs to be done once for the lifetime of the

device)

•2 = User items (customizations, including those made by Watcher or other

host applications) — This is the only backup option that should be employed

by users. Use this command before doing a firmware update. If the

modem’s file system is reinitialized for some reason during the update, the

customizations would then be automatically restored using from the backed-

up information.

The command returns:

•NV Items saved

•NV Items skipped

The ‘items skipped’ represent memory to which nothing has been written.

Supported AT Command Reference

64 2130617

7

Rev 2.8.1 Feb.11 65

7: SIM Commands

•Introduction

•Command summary

•Command reference Introduction

Thischapterdescribescommandsusedtocommunicatewith

aninstalled(U)SIM.

Command summary

Thetablebelowliststhecommandsdescribedinthischapter:

Command reference

Table 7-1: SIM command passwords

Command Description Page

!AUTH Runs GSM algorithm on SIM 65

!ICCID Returns (U)SIM card’s ICCID 66

Table 7-2: SIM command details

Command Description

!AUTH = <randNumber>

Supporting modems:

•All

Runs GSM algorithm on SIM

This command is used to authenticate the SIM using a random number.

The command returns the SIM’s response and a 64–bit ciphering key in the

format: <key>, <SRES>

Parameters:

<randNumber>

•32 hexadecimal digit random number.

Example: 123A567B9012C4567D90123E56789012

<SRES> - SIM response

•Example: 500e2879

<key> - Ciphering key

•Example: ec793ac5662e7000

Supported AT Command Reference

66 2130617

!ICCID

Supporting modems:

•All

Returns (U)SIM card’s ICCID

This command returns a (U)SIM’s ICCID (Integrated Circuit Card ID).

Usage:

•AT!ICCID?

returns !ICCID: <iccid>

Parameters:

<iccid> (ICCID of the (U)SIM currently being tested):

•20 digit decimal number — This number is often printed on the (U)SIM

card.

Table 7-2: SIM command details (Continued)

Command Description

Rev 2.8.1 Feb.11 67

A

A,answerincomingcall,18

A/,re‐issuelastATcommand,18

!AUTH,runGSMalgorithmonSIM,65

B

!BAND,set/queryfrequencybands,29

!BCINF,returnbootloaderversion,30

!BOOTHOLD,resetmodemandwaitforf/wdownload,

30

C

&C,setdatacarrierdetected,17

C,ITUTv.24circuit109carrierdetectsignalbehavior

command,20

+CACM,accumulatedcallmeter,20

+CACSP,voicegrouporvoicebroadcastcallstateat‐

tributepresentation,20

+CAEMLPP,eMLPPpriorityregistrationandinterroga‐

tion,20

+CAHLD,leaveanongoingvoicegrouporvoicebroad‐

castcall,20

+CAJOIN,acceptincomingvoicegrouporvoicebroad‐

castcall,20

+CALA,alarm,20

+CALCC,listcurrentvoicegroupandvoicebroadcast

call,20

+CALD,deletealarm,20

+CALM,alertsoundmode,21

+CAMM,accumulatedcallmetermaximum,21

+CANCHEV,NCHsupportindication,21

+CAOC,adviceofcharge,21

+CAPD,postponeordismissanalarm,21

+CAPTT,talkeraccessforvoicegroupcall,21

^CARDMODE,returnSIMcardtype,30

+CAREJ,rejectincomingvoicegrouporvoicebroadcast

call,21

+CAULEV,voicegroupcalluplinkstatuspresentation,

21

+CBC,batterycharge,21

+CBM,cellbroadcastmessagedirectlydisplayed,19

+CBMI,cellbroadcastmessagestoredinmemoryat

specifiedlocation,19

+CBST,selectbearerservicetype,21

+CCCM,currentcallmetervalue,21

+CCFC,callforwardingnumberandconditions,21

+CCLK,clock,21

+CCUG,closedusergroup,21

+CCWA,callwaiting,21

+CCWE,callmetermaximumevent,21

+CDIP,calledlineidentificationpresentation,21

+CDIS,displaycontrol,21

+CDS,SMSstatusreportaftersendingaSMS,19

+CDSI,incomingSMSstatusreport,19

+CEER,extendederrorreport,21

+CFUN,setphonefunctionality,21

+CGACT,PDPcontextactivateordeactivate,21

+CGANS,manualreponsetonetworkrequestforPDP

contextactivation,21

+CGATT,PSattachordetach,21

+CGAUTO,automaticresponsetonetworkrequestfor

PDPcontextactivation,21

+CGCLASS,GPRSmobilestationclass,22

+CGCLOSP,configurelocaloctetstreamPADparame‐

ters,22

+CGCMOD,PDPcontextmodify,22

+CGDATA,enterdatastate,22

+CGDCONT,definePDPcontext,22

+CGDSCONT,definesecondaryPDPcontext,22

+CGEQMIN,3GQoSprofile(minimumacceptable),22

+CGEQNEG,3GQoSprofile(negotiated),22

+CGEQREQ,3GQoSprofile(requested),22

+CGEREP,packetdomaineventreporting,22

+CGEV,GPRSnetworkeventindication,22

+CGIEV,indicatorevent,23

+CGMI,requestmanufactureridentification,22

+CGMM,requestmodelidentification,22

+CGMR,requestrevisionidentification,22

+CGPADDR,showPDPaddress,22

+CGQMIN,QoSprofile(minimumacceptable),22

+CGQREQ,QoSprofile(requested),22

+CGREG,GPRSnetworkregistrationstatus,22

+CGSMS,selectserviceforMOSMSmessages,22

+CGSN,requestproductserialnumberidentification,22

+CGTFT,trafficflowtemplate,22

+CHLD,call‐relatedsupplementaryservices,22

+CHSA,HSCSDnon‐transparentasymmetryconfigura‐

tion,22

+CHSC,HSCSDcurrentcallparameters,22

+CHSD,HSCSDdeviceparameters,22

+CHSR,HSCSDparametersreport,22

+CHST,HSCSDtransparentcallconfiguration,22

+CHSU,HSCSDautomaticuserinitiatedupgrading,22

+CHUP,hangupcall,22

+CIMI,requestinternationalmobilesubscriberidentity,

23

+CIND,indicatorcontrol,23

+CKEV,keypressorreleaseevent,23

+CKPD,keypadcontrol,23

+CLAC,listallavailableATcommands,23

+CLAE,languageevent,23

+CLAN,setlanguage,23

+CLCC,listcurrentcalls,23

+CLCK,facilitylock,23

Index (AT commands)

Supported AT Command Reference

68 2130617

+CLIP,callinglineidentificationpresentation,23

+CLIR,callinglineidentificationrestriction,23

+CLVL,sets/returnsinternalloudspeakervolume,23,31

+CMAR,masterreset,23

+CMEERROR,mobileterminationerrorresultcode,23

+CMEC,mobileterminationcontrolmode,23

+CMEE,reportmobileterminationerror,23

+CMER,mobileterminationeventreporting,23

+CMGC,sendcommand,19

+CMGD,deletemessage,19

+CMGF,messageformat,19

+CMGL,listmessages,19

+CMGR,readmessage,19

+CMGS,sendmessage,19

+CMGW,writemessagetomemory,19

+CMMS,moremessagestosend,19

+CMNA,newmessageacknowledgementtoME/TA,19

+CMOD,callmode,23

+CMSERROR,SMSerror(mobileornetworkerror),19

+CMSS,sendmessagefromstorage,19

+CMT,incomingmessagedirectlydisplayed,20

+CMTI,incomingmessagestoredatspecificmemorylo‐

cation,20

+CMUT,enables/disablesuplinkvoicemuting,23,31

+CMUX,multiplexingmode,23

+CNMA,newmessageacknowledgementtoME,20

+CNMI,newmessageindicationstoTE,20

*CNTI,returncurrent,available,andsupportednetwork

technologies,31

+CNUM,subscribernumber,23

+COLP,connectedlineidentificationpresentation,23

+COPN,readoperatornames,23

+COPS,operatorselection,23

+CPAS,phoneactivitystatus,23

+CPBR,readphonebookentries,24

+CPBS,selectphonebookmemorystorage,24

+CPBW,writephonebookentry,24

+CPFB,findphonebookentries,24

+CPIN,enterPIN,24

+CPMS,preferredmessagestorage,20

+CPOL,preferredoperatorlist,24

+CPROT,enterprotocolmode,24

+CPUC,priceperunitandcurrencytable,24

+CPWC,powerclass,24

+CPWD,changepassword,24

+CQI,enable/disable/returnaveragedCQIvalue,32

+CR,servicereportingcontrol,24

+CRC,cellularresultcode,24

+CREG,networkregistration,24

+CRES,restoresettings,20

+CRING,incomingcalltype,24

+CRLP,radiolinkprotocol,24

+CRMP,ringmelodyplayback,24

+CRSL,ringersoundlevel,24

+CRSM,restrictedSIMaccess,24

+CSAS,savesettings,20

+CSCA,servicecentreaddress,20

+CSCB,selectcellbroadcastmessagetype,20

+CSCC,securecontrolcommand,24

+CSCS,selectTEcharacterset,24

+CSDF,settingsdateformat,24

+CSDH,showtextmodeparameters,20

!CSDONSIO2,configuresecondarySIOportforCSdata,

32

+CSGT,setgreetingtext,24

+CSIL,silencecommand,24

+CSIM,genericSIMaccess,24

+CSMP,settextmodeparameters,20

+CSMS,selectmessageservice,20

+CSNS,singlenumberingscheme,24

+CSQ,signalquality,24

+CSSN,supplementaryservicenotifications,24

+CSTA,selecttypeofaddress,24

+CSTF,settingstimeformat,24

+CSVM,setvoicemailnumber,25

+CTFR,calldeflection,25

+CTZR,timezonereporting,25

+CTZU,automatictimezoneupdate,25

+CUSD,unstructuredsupplementaryservicedata,25

+CV120,v.120rateadaptionprotocol,25

+CVHU,voicehangupcontrol,25

+CVIB,vibratormode,25

D

&D,setDTRfunctionmode,17

D,dial,18

D,ITUTV.25terdialcommand,25

D’99’’’<n>#,setuppacketdatacallbasedonprofileID

#<n>,25

D’99#,setuppacketcallbasedonprofileID#1,25

D><MEM><N>,originatecalltophonenumberinmem‐

ory,18

D><N>,originatecalltophonenumberincurrentmem‐

ory,18

D><STR>,originatecalltophonenumbercorresponding

toa/nfield,18

DL,rediallastphonenumberused,18

+DR,V42biscompressionreport,18

+DS,V42bisdatacompress,18

E

E,setcommandechomode,18

+ECIO,returntotalenergyperchipperpowerdensity

value,33

!ERR,displaydiagnosticinformation,61

+ETFCI,enable/disable/queryE‐TFCIaveragevalue,33

F

&F,setcurrentparameterstodefaults,17

G

+GCAP,RequestcompleteTAcapabilitieslist,18

Index

Rev 2.8.1 Feb.11 69

!GCCLR,clearcrashdumpdata,61

!GCDUMP,displaycrashdumpdata,61

!GCIPHER,enable/disablecipheringandintegrityset‐

tings,34

!GETBAND,returncurrentactiveband,34

!GETRAT,returncurrentactiveRAT,34

+GMI,requestmanufactureridentification,18

+GMM,requestTAmodelidentification,18

+GMR,requestTArevisionidentification,18

+GOI,requestglobalobjectidentification,18

!GRELIMEI,returnmodem’sproductionTAC,35

!GRESET,resetthemodem,35

!GSMINFO,display2Gnetworkinformation,36

+GSN,requestTAserialnumberidentification,18

!GSTATUS,returnoperationalstatus,38

!GVER,returnfirmwareversion,39

H

H,disconnectexistingconnections,18

^HVER,returnmodemhardwareversion,39

I

I,displayproductidentificationinformation,18

!ICCID,returnSIMcard’sICCID,66

+ICF,setTE‐TAcontrolcharacterframing,18

+IFC,setTE‐TAlocaldataflowcontrol,18

+ILRR,setTE‐TAlocalratereportingmode,18

+IPR,setfixedlocalrate,18

L

L,setmonitorspeakerloudness,18

M

M,setmonitorspeakermode,18

!MXSTATS,display/clear27.010statistics,60

N

!NVBACKUP,backupnon‐volatilememory,63

!NVPORTSET,assignUSBendpointATport,39

O

O,switchfromcommandmodetodatamode,18

P

P,selectpulsedialing,18

!PCTEMP,returncurrenttemperatureinformation,39

!PCVOLT,returncurrentpowersupplyvoltageinforma‐

tion,40

!POWERDOWN,powerdownthesystem,40

Q

Q,setresultcodepresentationmode,18

R

!REL,querytheactiveprotocol/revision,41

!RESET,resetthemodem,41

!RSCP,returnRSCP,41

S

&S,setDSRsignal,17

S0,setnumberofringsbeforeauto‐answer,18

S10,setdisconnectdelayafterindicatingabsenseofdata

carrier,19

S3,setcommandlineterminationcharacter,19

S4,setresponseformattingcharacter,19

S5,setcommandlineeditingcharacter,19

S6,setpausebeforeblinddialing,19

S7,setnumberofsecondstowaitforconnectioncomple‐

tion,19

S8,setnumberofsecondstowaitwhencommadial

modifierused,19

!SCACT,activate/deactivatePDPcontextforFIFOinter‐

face,42

!SCDFTPROF,query/setthedefaultprofileID,42

!SCDNS,query/setprofileIDDNSaddress,43

!SCPADDR,displayIPaddressforPDPcontext,43

!SCPROF,query/setSWI‐specificprofileinformation,44

!SCPROFDEL,eraseprofileinformation,44

!SDNOTINSTALLED,returnSDinstallationstatus,45

!SELMODE,query/setcurrentservicedomain,45

!SELRAT,query/setcurrentRAT,45

!SIMNOTINSTALLED,returnSIMinstallationstatus,46

!SMSRETRY,query/setSMSretryperiodandinterval,47

!SMSSTSEN,enable/disableSMSstatusreport,48

!SWICALLPROG,enable/disablecallprogressnotifica‐

tion,49

^SYSCONFIG,query/setsystemconfigurationinforma‐

tion,51

^SYSINFO,returnservicestatusinformation,52

T

&T,autotests,17

T,selecttonedialing,19

!TIME,query/setcurrenttimeofday,53

U

!UDINFO,returninformationfromactiveUSBdescrip‐

tor,54

!UPSC,displayprimaryscramblingcode,54

+USET,displayWCDMAsetinformation,55

Supported AT Command Reference

70 2130617

V

&V,returnATconfigurationparameters,17,57

V,setresultcodeformatmode,19

+VTD,toneduration,25

+VTS,DTMFandarbitrarytonegeneration,25

W

&W,Storeparametertouser‐definedprofile,18

+WS46,PCCASTD101selectwirelessnetwork,25

X

X,setconnectresultcodeformatandcallmonitoring,19

Z

Z,setallcurrentparameterstouser‐definedprofile,19

Rev 2.8.1 Feb.11 71

Numerics

27.010statistics,display/clear60

2Gnetworkinformation,return36

3GPP

27.005commands,list19

27.007commands,list20

ATcommands,references9

A

acronyms10

applicationauto‐launch,query/set44

ARFCN,2G,return36

ATcommandparameters,display57

ATcommands

3GPP27.005commands,list19

3GPP27.007commands,list20

3GPP,standard9

ITU‐TV.250commands,list17

ATport,USBendpointmapping39

B

badframestatistics,display/clear60

band

2Gnetwork,return36

currentactiveband,return34

currentGSM,return38

currentWCDMA,return38

bands

available29

current29

set29

basestation

colorcode,2G,return36

identitycode,2G,return36

BCCHfrequencylevel,2G,return36

bearer,callprogressnotification49

bootandhold.Seebootloader.

bootloader

version,return30

waitforfirmwareupdate30

bootuptime,return38

C

callidentificationnumber,callprogressnotification49

callprogressnotification,enable/disable49

callstate,callprogressnotification49

cellID,2G,return36

cellselectioncriteria,2G,return36

channelnumber

currentGSM,return38

currentWCDMA,return38

ChannelQualityIndicator.SeeCQI.

cipheringandintegritysettings,enable/disable34

commonpilotchannel,display55

configurationbufferlabel,query/set44

contextactivationmode,query/set44

CPICH,display55

CQI

averaged,display32

averaged,enable/displaydisplay32

crashdata

clear61

display61

D

diagnosticinformation,display61

DISC(Tx/Rx)statistics,display/clear60

DM(Tx/Rx)statistics,display/clear60

DNSaddress,query/set43

E

Ec/Io

display55

strongestcellvalues,return33

endpoint

ATportmapping39

eraseprofileinformation44

E‐TFCIaveragevalues,enable/disable/query33

F

FIFOinterface,activate/deactivatePDPcontext42

firmware

revision,minimumrequired10

update,waitinbootloadermode30

upgrading11

version,return39

frequencybands.Seebands.

G

glossary10

GMMstate,return38

H

hardwareversion,return39

Index

Supported AT Command Reference

72 2130617

I

ICCID,display66

IPaddressdisplay,profileID43

ITU‐TV.250commands,list17

L

LAC,2G,return36

loudspeakervolumequery/set,internal31

M

MCC,2G,return36

MM

state,return38

substate,return38

MNC,2G,return36

modeacquiredbymodem,return38

mode,query/set51

modem

configuration,query/set51

hardwareversion,return39

mode,query/set51

mode,return38

networkacquisitionorder,query/set51

networks,supported31

operationalstatus,return38

reset35,41

reset,waitforfirmwareupdate30

roamingsupport,query/set51

servicedomainsupport,query/set51

SIMstatus,query/set51

statuscommands,list27

MSCrevision,current41

multi‐partystatus,callprogressnotification49

mutingvoicecall,enable/disable31

MUX,secondarySIOport,configureforCS32

N

N1/N2counts,display/clear60

network

acquisitionorder,query/set51

availableforuse31

colorcode,2G,return36

currentlyinuse31

information,2G,return36

supportedbymodem31

P

password

profileIDprompt,query/set44

PDPcontext

activate/deactivateforFIFOinterface42

SeealsoprofileID

powerdownsystem40

primaryscramblingcode,display54,55

profileID

applicationauto‐launch,query/set44

default,query/set42

DNSaddress,query/set43

eraseinformation44

IPaddress,display43

passwordprompt,query/set44

SeealsoPDPcontext.

SWI‐specificinformation,query/set44

protocol,current41

PSstate,return38

PSC,display54

R

radioaccesstechnology.SeeRAT.

RAT

current,displaydescription34

current,query/set45

receivedsignalcodepower

display55

return41

reset

modem35,41

modem,waitforfirmwareupdate30

roamingsupport,query/set51

routingareacode,2G,return36

RSCP,return41

Rx,minimumleveltoregister,2G,return36

S

SABM(Tx/Rx)statistics,display/clear60

scramblingcodes,display55

SDcard

installationstatus45

searchwindowsize,display55

secondaryscramblingcode,display55

serialI/O.SeeSIO.

service

availability,display52

domain,display52

domain,query/set45

servicedomainsupport,query/set51

sessioncounters,display/clear60

SGSNrevision,current41

SIM

authentication65

cardtype,return30

ICCID,display66

installationstatus46

status,display52

status,query/set51

SIO,secondaryport,configureforCSoverATorMUX

32

SMS

Index

Rev 2.8.1 Feb.11 73

retryperiodandintervalforMO‐SMS,query/set47

statusreports,enable/disable48

system

powerdown40

systemmode,display52

T

T1/T2/T3expirystatistics,display/clear60

TAC,return35

temperature

current,return39

return38

state,return39

terminology10

timeofday,query/set53

typeallocationcode,return35

U

UA(Tx/Rx)statistics,display/clear60

UIH(Tx/Rx)statistics,display/clear60

USBdescriptorinformation,display54

V

version

bootloader,return30

firmware,return39

modemhardware,return39

voice

callmuting,enable/disable31

voltage

actual,return40

rawreading,return40

state,return40

volume

internalloudspeaker,query/set31

W

WCDMA

RRCrevision,current41

setinformation,display55

Supported AT Command Reference

74 2130617
