Newcont Electronic NTP-6451XX 2.4 GHz digital Cordless Telephone User Manual
Newcont Electronic Co., Ltd. 2.4 GHz digital Cordless Telephone Users Manual
Users Manual
OWNER'S MANUAL
INSTALLATION AND
OPERATING
INSTRUCTIONS
PLEASE READ THIS
MANUAL CAREFULLY
BEFORE USE.
KEEP FOR
YOUR REFERENCE.
Digital 2.4GHz
Expandable Cordless Telephone System
NTP-6451
NEWCONTNEWCONT
1.This equipment has been tested and found to comply
with the limits for a class B digital device, pursuant
to part 15 of FCC Rules. These limits are designed to
provide reasonable protection against harmful inter
-ference in a residential installation. This equipment
generates, uses and can radiate radio frequency ener
-gy and, if not installed and used in accordance with
the instructions, may cause harmful interference to
radio communications. However, there is no guar
-antee that interference will not occur in a particular
installation. If this equipment dose cause harmful in
-terference to radio or television reception, which
-can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment
and receiver.
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV
technician for help.
2.Changes or modifications not expressly approved
by the party responsible for compliance could void
the user's authority to operate the equipment.
3.Privacy of communications may not be ensured
when using this phone.
NOTE
Contents
Getting Started.........................................................................................1
Connecting your phone....................................................................1
Preparing for use .............................................. ..............................4
Using the Handset Display
Using the soft keys
................................. .... .... .....................5
..........................................................................5
Using the Navigation Keys....................................... .......................5
Setting up your Handset...........................................................................6
Registering a handset......................................................................6
Setting the Ring Tone and Ring Volume .........................................6
Naming a Handset............................................................................6
Entering Text on the Handset..........................................................7
Setting the language........................................................................7
Setting Tone/Pulse Dialing...............................................................7
Setting the Date and Time...............................................................7
Setting the Area Code for caller ID................................ .................8
Using the Handset............................................................ ... .... .................9
Placing calls.................... .........9
Making a call using the speakerphone
........................................................
.............................................9
Switching Between the Handset and speakerphone......................9
Muting a call.....................................................................................9
Redialing a Number............................................................. .............9
Using the handset finder..................................................................9
Storing number in the phonebook..................................................10
Storing a caller ID number in the phonebook................................10
Calling a Numberfrom the phonebook........................... ...............10
Editting a phonebook Entry...........................................................11
Deleting a phonebook Entry..........................................................11
Using Caller ID...............................................................................11
Reviewing the List of Calls............................................................11
Deleting Caller ID Calls..................................................................12
Multihandset Functions............................................................................13
Conference Calling ....................13
Using the Intercom
......................................................
.........................................................................13
Transfering a call from one Handset to Another............................13
Unanounced Transfer.............................................................13
Announced Transfer...............................................................13
Using the Intercom
1.Press Intercom.
2.From the list of handsets, press until points to the handset you want to page,
or to Select All to page all handsets.
Note: If there are only 2 handsets registered to the base, pressing the Intercom
button will automatically page the other handset.
3.Press ( ).
4.To answer the page, press TALK ( ).The first handset to respond is connected.
If no one answers the page after 2 minutes, or if the person you are paging presses
EXIT ( ), No Answer displays on your handset and paging stops.
5.When someone answers the page, talk into the handset.
6.To end the intercom session, press EXIT( ).
Transferring a Call from One Handset to Another
Unannounced Transfer
1.Press ( ).
2.Press Intercom.
3.Scroll to the handset you want to transfer the call to and press ( ).
Note: If there are only 2 handsets registered to the base, pressing the Intercom
button will automatically page the other handset.
3.Press to hang up. The call is transferred to the other handset.
Announced Transfer
1.Follow steps 1 through 3 above.
2.To answer the page on the other handset, press ( ).
3.Tell the person on the other handset that you are transferring a call, then press
( ) button again.The call is transferred to the other handset and all three
individuals are on the call.
4.Press ( )to hang up the second handset.
Volume
OK
C
OK
OK
C
C
C
OK
OK
13
Multihandset Functions
C
Multihandset Functions
You can have up to 4 handsets registered to a base station. Expansion handsets do
not require connection to a phone line. You can place the handset and its
charging base anywhere a standard electrical outlet is available.
With multiple handsets, you can:
Conference call
Handset to handset intercom
Set up handsets to automatically answer intercom calls
Transfer calls from one handset to another
Conference Calling
If one handset is already on a call, the display on other handsets registered to the
same base station shows Line in use
Once a second handset is added to the call, the displays on all handsets shows
On conference. A maximum of 2 handsets can be on a conference call at the same time.
1.To connect a second handset to a call, press or on the second handset.
2.To disconnect from the conference call, press on either or both handsets.
Connecting Your Phone
This section is a reference guide to the basic functions and operations of your
cordless telephone. For more detailed descriptions of the operations and features
of this telephone, refer to the Content on page 1.
1.Carefully remove your cordless telephone from its shipping carton. If there is
any visible damage, do not attempt to operate this equipment. Return it to the
place of purchase.
2.Check to be sure you have all items that come with this cordless telephone
system. You should have a HANDSET, BASE UNIT,AC ADAPTOR,TELEP
HONE LINE CORD, SHORT TELEPHONE LINE CORD,BATTERY PACK,
BELT CLIP and Owner's Manual.
Getting Started
3.Insert the small plug on end of the AC ADAPTOR into the POWER IN CONNEC
-TION JACK at the back of the BASE UNIT.
4.Plug the AC ADAPTOR into a 120V AC wall outlet.
USE ONLY WITH CLASS 2 POWER SOURCE 9V DC, 500 mA.
5.Insert one plug of the TELEPHONE LINE CORD into the house TELEPHONE
JACK and the other end into the TELEPHONE LINE CONNECTION JACK
on the back of the BASE UNIT.
6.We recommend not placing this unit next to appliances. Doing so may cause
interference.
7.Install the HANDSET BATTERY PACK by plugging it into the BATTERY
1
PAGEPAGE
Deleting Caller ID Calls
1. Press CID( ) to enter into caller ID list.Press to select the number/name
which you want to delete.
2.Press Delete( ),the display shows DELETED? .PRress Delete( )again
to delete the number/name.
3.If deleting all calls,Press and hold( ).the display shows DELETE ALL?
Press DELETE( )to delete all calls.
4.Press EXIT( )to return to standby mode.
""
""
C
12
Using the Handset
CONNECTOR inside the BATTERY COMPART
-MENT.
8.Place the BATTERY PACK inside the
BATTERY COMPARTMENT.
9.Slide the HANDSET BATTERY COMPART
-MENT COVER firmly into place in its clos
-ed position.
10.IMPORTANT: Before initial use,
charge the HANDSET for 12 hours.
120VWALL
OUTLET
AC ADAPTOR
TELEPHONE
JACK
TELEPHONE LINE
CONNECTION
JACK
Getting Started
2
BATTERY
CONNECTOR
B ATTERY
COMPARTMENT
COVER
BATTERY PACK
Editting a Phonebook Entry
1.Press PHONEBK( ).
2.Press until points to the entry you want to edit.
3.Press SELECT( ).
4.Scroll to Edit and press SELECT ( ).
5.To modify the name, press DELETE ( ) to backspace and erase characters to
the left of the blinking cursor. See page 7 for information on entering text.
6.Scroll down ( )to move to the phone number field.
7.Modify the number.
8.Press SAVE ( ).
Deleting a Phonebook Entry
1.Press PHONEBK ( ).
2.Press until points to the entry you want to delete.
3.Press DELETE ( ).The Display shows
5.Press EXIT ( ).
Using Caller ID
Note: You must subscribe to caller ID service from your local telephone company
to use the caller ID features of your phone.
If you subscribe to caller ID service, the caller's name and number are displayed
when you receive an incoming call. If no caller ID information was sent from the
phone company, or you do not subscribe to caller ID service, the display shows
Incoming Call.
Reviewing the List of Caller ID Calls
The handset can hold up to 80 caller ID records.
1.Press to enter the recent call list. The most recent call is listed first.
2.Press to review more calls.
3.To call the number, press TALK( ) or Handsfree .
"DELETED?".
4.Press DELETE( )again.
Volume
OK
OK
Volume
Volume
C
11
Using the Handset
Getting Started
3
Handsfree/FlashHandsfree/Flash
DeleteDelete
TalkTalk
MuteMute
MicrophoneMicrophone
CIDCID
SaveSave
MenuMenu
ExitExit
PhonebookPhonebook
FormatFormat
IntercomIntercom
Redial/pauseRedial/pause
10
Using the Handset
4.Scroll down ( ).
5.Enter the phone number ( up to 24 digits).Press Cancel( )to backspace and
erase characters to the left of the blinking cursor.
6.Press SAVE ( ).
To store a recently called number in the phonebook:
1.Press Redial. The display shows the most recent number at the top.
2.Press SAVE ( ).
3.Enter the name (up to 11 characters). Press Cancel( ) to backspace and erase
characters to the left of the blinking cursor. See page 7 for information on
entering text.
4.Scroll down( ).
5.The phone number displays in the number field. To modify the number, press
DELETE ( )to backspace and erase characters to the left of the blinking cursor.
6.When the phone number is correct as you want to store it, press SAVE ( ).
Storing a Caller ID Number in the Phonebook
1.Press CID( ) to enter into caller ID list.
2.Scroll up and down to select the call you want to store.
3.Press FORMAT( ) to change the dialing format of the number(7-digit,
10-digit or 11-digit).
4.Press SAVE( ).The caller s name displays in the name field.You can
modify the name before storing it.
5.When the name is correct as you want to store it,press to scroll down.
6.the caller s phone number displays in the number field.You can modify the nu
-mber before storing it.
7.When number is correct as you want to store it,press SAVE( ).
8.Press EXIT( )return to standby Mode.
Calling a Number from the Phonebook
1.Press Directory( ).
2.Press until points to the entry you want to call.
3.Press TALK or Handsfree.
Volume
Volume
C
OK
Storing numbers in the phonebook
Storing numbers in the phonebook makes it easy to dial numbers you can frequently.
You can enter numbers directly into the phonebook or add them from the caller
ID . The phonebook can hold 64 names and numbers.
1 Press Directory( )
2.Scroll to (New Entry) and press SELECT ( ).
3.Enter the name (up to 11 characters). Press Cancel( ) to backspace and
erase characters to the left of the blinking cursor. See page 6 for information on
entering text.
Preparing for Use
Before you can use your cordless telephone, you must charge the HANDSET for
12 hours. Failure to do so will require recharging of the BATTERY PACK more
often.
1.Place the HANDSET in the BASE Cradle for 12 hours.
2.After 12 hours, remove the HANDSET from the BASE UNIT.
NOTE:
Depending on the frequency of use, once the HANDSET is fully charged, it
remains functional for approximately 4 hours of continuous use and approxim
-ately 5 days when the HANDSET is off the BASE UNIT in STANDBY mode.
Using the Handset Display
When the handset is not in use, the display shows the standby screen.
4
Getting Started
Switching Between the Handset and Speakerphone
Press Handsfree( ).
Muting a Call
Press MUTE( ). To unmute the call, press MUTE again.
Redialing a Number
To redial the most recently dialed number:
1.Press TALK( ).
2.Press Redial.
If a number in the redial list matches a number in your phonebook, the phonebook
name and number display in the redial list instead of just the phone number.
Using the handset finder(PAGE)
1.Press PAGE on the base station. The charge LED will light if the handset is
within range. A series of beeps will sound for approximately 15 seconds.
2.Place the handset back into the base or press the TALK button to stop the
page/find feature.
Out of Range Warning
If you venture too far from the base the handset will beep. Reverse your direction
to re-establish connection with the base or the call will be dropped. When the base
detects that the handset has been out of range for 20 continuous seconds it will
release the engaged line.
OK
9
Using the Handset
C
C
Using the Handset
Placing Calls( )
Press the Talk button. When you hear the dial tone, dial the number. Or enter the
phone number, then press TALK( ). The phone number is displayed on the
screen before the number is dialed.
During a call, a timer on the display shows the amount of time on the call.
When you are finished talking, press ( )to hang up.
Press Handsfree to answer using the speakerphone.
If you have call waiting service, press TALK to answer the second call.
Making a Call Using the Speakerphone
Press Handsfree and dial the number. When the speakerphone on the handset is
on, appears on the display.
When you are finished talking, press ( ) to hang up and turn the speakerphone off.
When pressing Handsfree in the caller ID list, redial list, or phonebook turns
the speakerphone on and ( )dials the number.
Press Handsfree( ).
If you have call waiting service, press TALK ( )to answer the second call.
Volume
Note: Caller ID information is supplied only if you subscribe to caller ID service
from your local phone company.
When the handset speakerphone is on, appears on the display.
Using the Soft Keys
-Directory button,Press to enter into PHONEBK.
-CID button.Press to enter into caller ID list.
-SAVE & Volume(+)button.
-DELETE & Volume (-)button.
-MENU& SELECT button,Press to enter into MENU.Then press again
to select.
-Handsfree.
-EXIT/OFF button.
-TALK & Flash button.
Using the Navigation Key
is used to scroll up and down through menu items, a list of settings, caller ID
and redial lists, and the phonebook. Points to the currently selected item, and
indicates there are more items above and below the currently selected item.
Press to scroll up or down on the display.
Volume
C
OK OK
5
OK
Getting Started
For example, if you store212in 10-digit format, when you receive a call from
that area code, the phone number is stored in your call list with all 10 digits. The
number will then be in the correct format for you to dial directly from the call list
without any reformatting.
1.Press MENU( )
2.Scroll to Loc area codes and press SELECT( ).
3.Enter the first area code.
4.Press SAVE( ).
5.Press EXIT ( )to return to the standby screen, or to scroll to a different menu
option.
OK
OK
C
10-digit format
You have to dial the 3-digit area code+7-digit phone number to call numbers in
this area.
11-digit format
You have to dial the 1+3-digit area code+7-digit phone number to call numbers
in this area code.
8
Volume
Volume
C
OK
6.Scroll down ( ) to move the next field.
7.Press SELECT( ) to select date format(MM/DD or DD/MM).
8.Scroll down ( ) to move the next field.
9. Enter the current date.
10.Press SAVE( ).
11.Press EXIT( ) to return to the standby screen, or to scroll to a different
menu option.
Setting Area Code for Caller ID
Note: This section applies only if you subscribe to caller ID service from your
local phone company.
You can store one area code to make it easy to dial numbers from your list
of caller ID calls. Each area code can be:
7-digit format
You do not have to dial the area code to call numbers in this area code.
Setting up your Handset
5.Scroll down ( ) to advance to the Ring Tone. This is the ring sound for
incoming calls.
6 Press SELECT ( )to scroll through the ring tones. Each tone plays as you
Press ( ). Stop at the ring tone you want to set.
7.Press SAVE ( ).
10.Press EXIT ( )to return to the standby screen, or to scroll to a different
menu option.
Volume
OK
Naming a Handset
When you register a handset, you can change the name to something more useful,
for example a location (Bedroom) or someone's name ( Mary). Naming a handset
makes it easy to select the handset from a list( for example, to intercom another
handset).
If you name a handset, the handset number remains part of the name, for example,
Bedroom(2)
1.Press MENU ( ).
2.Scroll to Name handset and press SELECT ( ).
3.Use the keypad to enter the handset name (up to 11 characters). The flashing
underline shows the input cursor position. Press DELETE ( )to backspace and
erase characters to the left of the input cursor.
4.Press SAVE ( ).
5.Press EXIT ( ) to return to the standby screen, or to scroll to a different menu
option.
OK
C
OK
C
6
Setting up your Handset
OK
OK
OK
C
OK
Telephone Setting
Registering a handset
You can have up to 4 handsets registered to a base station. To register a new
expansion handset that has never been registered to a base station before:
1.Press MENU( )
2.Scroll up and down to select REGIST-ER.
3.Press and hold PAGE on the base station for at least 6 seconds or until you
hear a long beep and see the handset name, for example, Handset(2).
4.Press EXIT ( )to return to the standby screen.
Setting the Ring Tone and Ring Volume
You can set ring Volume level and a ring tone for incoming calls.
1.Press MENU ( ).
2.Scroll to Ringer and press SELECT ( ).
3.The ringer Volume displays .Press SELECT ( ) to scroll through the settings
( off, low, medium, high ). Each volume level plays as you press Stop at the
volume level you want to set.
4. Press SAVE ( ).
7
Setting up your Handset
Setting the Language
1.Press MENU ( ).
2.Scroll to Language and press SELECT( ).
3.Press until points to the language you want to set.
4.Press SAVE( ).
5.Press EXIT ( ) to return to the standby screen, or to scroll to a different
menu option.
Setting Tone/Pulse Dialing
1.Press MENU ( ).
2.Scroll to Tone/Pulse and press SELECT( ).
3.Press until points to the dialing mode.
4.Press SAVE( ).
5.Press EXIT ( ) to return to the standby screen, or to scroll to a different
menu option.
Setting the Date and Time
1.Press MENU( )
2.Scroll to Date/Time and press SELECT( ).
3.Press to select the time format(12-or 24-hour clock).
4.Enter the time(2 digits are required for the hour and 2 digits for the minutes,
so use a leading 0 for 1-digit values).
5.Press to select AM/PM..
Note: This applies only if using a 12-hour clock.
OK
OK
OK
OK
C
OK
OK
C
Entering Text on the Handset
Press each button on the handset the indicated number of times to enter text
numbers, and other characters. For example, to enter E, press the 3 button
two times.
Press Key
1
2
3
4
5
6
7
8
9
0
*
#
1st
Space
A
D
G
J
M
P
T
W
0
*
#
2nd
1
B
E
H
K
N
Q
U
X
0
*
#
3rd
&
C
F
I
L
O
R
V
Y
0
*
#
4th
a
d
g
j
m
s
t
z
0
*
#
5th
b
e
h
k
n
p
u
w
0
*
#
6th
)
c
f
i
l
o
q
v
x
0
*
#
7th
.
2
3
4
5
6
r
8
y
0
*
#
8th
A
D
G
J
M
s
T
z
0
*
#
Space
(
9th
1
B
E
H
K
N
7
U
9
0
*
#
