Nexqo Technology NEX-530 DESKTOP READER User Manual UHF Desktop reader RS232
Shenzhen Nexqo Technology Co., Ltd DESKTOP READER UHF Desktop reader RS232
User Manual
nexqo Novelty•Experience•Quality•PrOfessional
NexqoTechnology Co.,Ltd.www.nexqo.comEmail:sales@nexqo.com
ADD:Rm16E/F,West Coast Building, Nanhai Blvd,Nanshan District, Shenzhen, China
TEL:+86‐755‐26490032 FAX:+86‐755‐26490070
NEX-530 HF RFID READER
Applications:
Identification
Access control
Off line ticketing
Customizing card
payment
Productive lines management: production process fixed identify.
Product counterfeit‐proof inspection: using memory’s write‐protect functions inside tags
and identifying with true‐false of products.
Other fields: used widely in club management, libraries, students schools, consumption
management, time management, dinner management and pool management.
Reader Characteristics:
nexqo Novelty•Experience•Quality•PrOfessional
NexqoTechnology Co.,Ltd.www.nexqo.comEmail:sales@nexqo.com
ADD:Rm16E/F,West Coast Building, Nanhai Blvd,Nanshan District, Shenzhen, China
TEL:+86‐755‐26490032 FAX:+86‐755‐26490070
The Nex-530 desktop reader is a Mifare ISO14443A, B or ISO15693 read/ write device with a
typical operating distance of50‐100mm. The desktop reader combines all basic functions to
access the ISO14443A, Bor ISO15693 card. Including MF Smart Card. Its versatility allows a
flexible and efficient application in different configurations and system devices. Using a serial
interface the device can be easily connected to a PC or other controller.
Specifications:
Protocol
ISO/IEC14443A,ISO/IEC14443B,ISO/IEC15693
Frequency range
13.56MHZ
Baud Rate
9600‐115200bit/s
Communication interface
RS232,USB,PS2
Reading range
50~100MM
Material
ABS
Support Card
MF1k/ 4K/ Ultralight/ DES fire/ Mini S20 (NXP), FM 11 RF 08,
SRI 512, I CODE SLI, Tag‐it Ti 2048, and another chips
available on request
Reading clue buzzer
Yes
Power consumption
DC 5V(±5%)
Working temperature
‐30~+80℃
Humidity
20% ~ 95%
Size
100mm×100mm×30mm
Weight
0.5Kg
Accessories
USB(RS232)Cable、disk（SDK, Demo、User’s manual）
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
