Nextlink to A S BLUESPOON1 Bluetooth Wireless Headset User Manual bluespoon 5G user s guide
Nextlink.to A/S Bluetooth Wireless Headset bluespoon 5G user s guide
Users guide
User’s Guide is divided into sections, with each feature of the Bluespoon™ 5G described in steps :
CONDITIONS (what state the headset is in)
WHAT TO DO (what you do)
The 5G will do what (the result of your action)
And then (further actions)
_____________________________________________________________________________________
PAIRING the headset with another Bluetooth® enabled device (e.g. mobile phone) :
Conditions:
The 5G is turned off and not connected to a Bluetooth® mobile phone.
What to do?
Press and hold down the volume up button for 7 seconds.
The 5G will do what?
The 5G will shift between the red and blue light. The 5G will now be in the pairing mode for 2 minutes.
And then…..
Start to search for the 5G with your mobile phone. The name of the 5G on your mobile phone’s screen, will be “Bluespoon 5G”. When
the phone ask for a passkey : enter : 0000.
NOTE:
For phones that are using the Hands-Free profile:
Some of the phones that are using the Bluetooth® Hands-Free profile might need to connect to the Bluespoon™ 5G after pairing, in
order to work with the headset. This can be done in two ways. Either you connect to the phone by pressing one of the buttons on the
headset, or you connect to the Bluespoon™ 5G using the phone’s menu. Also remember to set the Bluespoon™ 5G as “authorised” in
the mobile phone’s Bluetooth® menu. (Consult the mobile phone’s manual in order to do so).
Pairing with more than one device:
The Bluespoon™ 5G is capable of pairing with up to 8 devices.
E.g. a mobile phone, the Bluespoon Home and the Bluespoon USB dongle.
This will enable you to use the Bluespoon 5G when you are out of the house by using the mobile phone. Use the Bluespoon 5G with
your line phone when you are in the house and also when you want to use Voice over IP (VoIP) with your computer.
If the Bluespoon™ 5G is paired with more than one device it will connect to the last connected device. To connect to another paired
device, turn off the first device’s Bluetooth®, and connect afterwards to the other device.
___________________________________________________________________________________________________________
BASIC FUNCTIONS :
Turn on:
Conditions:
The Bluespoon™ 5G is turned off.
What to do?
Press and hold down the volume up button for 2 seconds.
The 5G will do what?
The Bluespoon™ 5G will play an audio sequence in the form of a low tone followed by a high tone in the loudspeaker, and flash with the
blue light 5 times.
Turn off:
Conditions:
The Bluespoon™ 5G is turned on and perhaps connected.
What to do?
Press and hold down the volume up button for 2 seconds.
The 5G will do what?
The Bluespoon™ 5G will play an audio sequence in the form of a high tone followed by a low tone in the loudspeaker, and flash with the
red light 5 times. If the Bluespoon™ 5G is connected it will disconnect before it turns off.
______________________________________________________________________________________
Bluespoon™ AX overview and features.
FIG 1-Front view FIG 2-Rear view FIG 3-Side view
Charging port for
Battery drawer with
Mini-USB cable and neck carrying strap finger grip Charging port for
Mini-USB cable and
Center button neck carrying strap
TALK
(blue and red
light)
Earpiece with
Soft spring
Button Button
VOLUME DOWN VOLUME UP Loudspeaker Microphone
FIG 4-Charging the battery FIG 5-Changing the battery
ONLY USE ORIGINAL BLUESPOON™
Mini-USB plug connected AX BATTERIES! Coin Cell type battery
to headset (Widest side downwards)
Charge headset
for 8 hours
before “first
time use”
Battery drawer out
Normal USB plug (drawer can be pulled all
Connected to computer the way out)
FIG 6-Preparing the earpieces FIG 7-
Left or right ear usage
Two earpieces with soft springs are supplied.
Put one of the earpieces with softspring on the
Soft springs are made extra long, and can be cut by headset, and turn it to the approx. angles shown
you to fit your ear. below.
Soft spring part We reco
mmend that you You may adjust earpieces further for a more comfortable fit.
cut a little piece of the
soft spring at a time.
Approx. 0.3 cm.
(0.125 inches)
Put the earpiece with soft
spring on the headset, and
try headset on.
Additional cutting might be
needed. Use scissors or a
hobby knife for cutting.
NOTE: Remember to put
earpiece with soft spring on
headset when trying it on. Left ear Right ear
FIG.8-How earpiece/headset sits in your ear
A) B) A) Illustration shows how the earpiece with soft spring
should sit in your ear.
Do not place earpiece with soft spring in the ear, without
the headset attached (illustration is only to show position
of the earpiece)
HOW TO PLACE HEADSET:
Hold headset with three fingers, insert the headset in
your ear. Use your indexfinger to bend the soft spring.
Place soft spring in the upper bend of your ear
(see illustration A)
B) Illustration shows how the headset should sit in the right
ear.
Thank you for purchasing the Bluespoon™ AX headset.
To fully appreciate all the features of your new headset, please follow the easy steps in this User’s Guide.
Bluespoon™ AX is a wireless headset using Bluetooth® technology.
Bluetooth® devices are connected to each other by what is known as “PAIRING”. Each Bluetooth device has a Pairingcode/PASSKEY.
The PASSKEY for Bluespoon™ AX is 0000. This PASSKEY must be used each time the Bluespoon™ AX is paired with a new device.
Once devices are paired, they will recognize each other whenever they are reconnected.
The effective wireless range between Bluespoon™ AX and another paired device is 10 metres (33ft).
Bluetooth® devices use “profiles” to communicate. The two Audio profiles for speech are Bluetooth® HEA DSET and Bluetooth®
HANDS-FREE profile. Mobile devices support either one or both of them. Bluespoon™ AX has both these profiles, and can be used
with a wide range of devices. e.g. mobile phones, pda’s and computers.
The Bluespoon™ Collection consists also of a Bluespoon™ USB dongle for computers and a home/office telephone adapter.
Bluespoon™ AX can be used with the USB dongle for Voice over IP (speaking over the internet), and also with the Bluespoon™ HOME
telephone adapter, which gives your home or office phone wireless capability.
The Bluetooth® profiles HEADSET and HANDS-FREE mainly have the same features. Bluetooth® HANDS-FREE is the new profile,
and adds some extra features to your headset. These extra features are also explained in this user’s Guide.
________________________________________________________________________________________________________
Package content :
Bluespoon™ AX headset.
USB computer charging cable.
2 exchangeable earpieces/speakercasings with built-in soft springs (one large and one small).
Rechargeable/user exchangeable battery – Coin Cell type.
Neck carrying strap.
User’s guide.
________________________________________________________________________________________________________
Features and Facts of the Bluespoon™ AX :
· Battery-drawer/compartment slides out, for easy swapping of rechargeable battery.
· Headset sits IN the ear
· Headset can be used in left or right ear – turnable earpieces with built-in softsprings.
· Earpiece’s soft spring part can be cut by user, to give a perfect fit.
· 2 different size earpieces are supplied.
· 3 button interface. Large TALK button in center of headset (with indicator lights)
· Blue/red indicator lights and Audio sequences/signals.
· USB charger, for fast, easy and “on the go” charging via computer (desktop/laptop).
· Neck carrying strap plugs into/uses the Mini-USB port, for easy transportation.
________________________________________________________________________________________________________
BEFORE YOU START TO USE YOUR NEW HEADSET :
Charging your Bluespoon™ AX (FIG.4) :
· Connect the USB cable to your computers USB port.
· Connect the Mini-USB plug to the Bluespoon™ AX.
· Charge Bluespoon™ AX for 8 hours before using it for the first time.
Whilst Bluespoon™ AX is charging, the RED light will be lit in the TALK-button. Once battery is fully charged, the RED light will turn off.
Changing the battery (FIG.2 and 5) :
· Use your indexfinger to gently pull the battery drawer out of Bluespoon™ AX.
· Lift up the battery, and put the new battery in the drawer (wide side of battery downwards).
· Push the batter drawer back into Bluespoon™ AX.
· Connect the USB cable to your computer.
· Connect the Mini-USB plug to Bluespoon™ AX in order to activate the headset again.
Battery indications (with headset turned on) :
When the battery is charged, Bluespoon™ AX will flash every 10th second with the BLUE light. If the battery level is low, the RED light
will flash every 10th second, indicating that it needs to be recharged.
WARNING : Only use original Bluespoon™ AX rechargeable batteries. If unoriginal batteries are
used, Nextlink.to A/S cannot be held responsible in any way, if the headset fails to work.
_________________________________________________________________________________________________________
User’s Guide is divided into sections with each feature of Bluespoon™ AX being described in steps :
Before starting out on a section with a feature, please read all the steps within that specific feature.
_________________________________________________________________________________
PAIRING the headset with another Bluetooth® enabled device (e.g. mobile phone) :
Current mode:
Bluespoon™ AX is turned off and not connected to a Bluetooth® mobile phone.
What to do?
Press and hold down the TALK button. BLUE light will flash 4 times after a short period. Keep holding button down, until RED and BLUE
indicator lights flash repeatedly.
Bluespoon™ AX will do what?
Bluespoon™ AX will now be in the pairing mode for 2 minutes. Both the RED and BLUE indicator lights in the TALK button will flash
repeatedly at this time.
And then…..
By using your mobile phone’s Bluetooth® menu, start to search for Bluespoon™ AX. When the search is complete, the name of
Bluespoon™ AX will appear as “Bluespoon AX”, on your mobile phone’s screen. When the mobile phone requests a passkey : enter :
0000.
NOTE:
For mobile phones supporting Bluetooth® Hands-Free profile:
Some of the phones that use Bluetooth® Hands-Free profile might need to connect to Bluespoon™ AX after pairing in order to work with
the headset. This can be done in two w ays. Either you connect to the phone by pressing the TALK button on the headset, or you
connect to Bluespoon™ AX using the phone’s menu. Remember also to set Bluespoon™ AX as “authorised” in the mobile phone’s
Bluetooth® menu. (consult the mobile phone’s manual in order to do so).
Pairing with more than one device:
Bluespoon™ AX is capable of pairing with up to 8 devices.
E.g. a mobile phone, the Bluespoon™ Home and the Bluespoon™ USB dongle.
If Bluespoon™ AX is paired with more than one device it will connect to the last connected device This means that if you want to
connect with another device then initiate the bluetooth connection from that device. Now this device will be the last connected device.
If you pair with more than 8 devices, one on the list will be deleted (the one that has not been used recently).
See FAQ for further explanation.
___________________________________________________________________________________________________________
FUNCTIONS :
Turn the headset off:
Current mode:
Bluespoon™ AX is turned on and/or connected.
What to do?
Press and hold down the TALK button for approximately 4 seconds.
Bluespoon™ AX will do what?
The RED indicator light will flash 5 times, and Bluespoon™ AX will play an audio sequence in the form of a high tone followed by a low
tone in the loudspeaker. Bluespoon™ AX will automatically disconnect before it turns off.
Turn the headset on:
Current mode:
Bluespoon™ AX is turned off.
What to do?
Press and hold down the TALK button for approximately 4 seconds.
Bluespoon™ AX will do what?
The BLUE indicator light will flash 5 times and Bluespoon™ AX will play an audio sequence in the form of a low tone followed by a high
tone in the loudspeaker.
NOTE: Audio tones can only be heard if you wear the headset.
______________________________________________________________________________________
To answer a call:
Current mode:
You have an incoming call. Bluespoon™ AX and the mobile phone are paired and within range of each other.
Bluespoon™ AX will do what?
Bluespoon™ AX will alert you with a ringing signal.
What to do?
Press the TALK button in order to take the call.
To hang up:
Current mode:
You have an ongoing call in Bluespoon™ AX.
What to do?
Press the TALK button in order to end the call.
Bluespoon™ AX will do what?
Call will be ended.
_____________________________________________________________________________________
Volume control:
Current mode:
You have an active call in the headset.
What to do?
In order to increase/decreas e the volume on the loudspeaker, press the VOLUME UP or DOWN button repeatedly until the desired
volume level has been reached. Volume adjustment is followed by audio tones. Once maximum is reached, audiotones stop.
Bluespoon™ AX will do what?
Bluespoon™ AX will save and store volume setting when headset is turned off.
___________________________________________________________________________________________________________
Mute/Un-mute the microphone:
Current mode:
You have an active call in the headset and the microphone is not muted.
What to do?
Hold the VOLUME UP or DOWN button for approximately 4 seconds.
Bluespoon™ AX will do what?
Bluespoon™ AX will mute the microphone. While the microphone is muted, two beeps will be heard every 2 seconds on the speaker.
How to un-mute the microphone?
Hold the VOLUME UP or DOWN button for approximately 4 seconds.
Bluespoon™ AX will do what?
Bluespoon™ AX will un-mute the microphone.
_____________________________________________________________________________________
Voice dialling: (Please read your mobile phone’s user manual for setting up and activating Voice dial)
Current mode:
Bluespoon™ AX is paired with the mobile phone, and they are both turned on and within range of each other.
What to do?
Place Bluespoon™ AX in your ear and press the TALK button.
Bluespoon™ AX will do what?
Bluespoon™ AX will request a voice dial.
Cancel a voice dial:
Current mode:
Bluespoon™ AX is in the Voice dial proces.
What to do?
Press the TALK button.
Bluespoon™ AX will do what?
Bluespoon™ AX will cancel the voice dial.
__________________________________________________________________________________________________________
Transfer a call to Bluespoon™ AX:
Current mode:
Bluespoon™ AX is paired with the mobile phone and turned on. There is an ongoing/incoming call in the phone.
What to do?
Press the TALK button.
Bluespoon™ AX will do what?
Bluespoon™ AX will connect to the mobile phone and transfer the call to the headset.
_____________________________________________________________________________________
Handle a Call waiting:
Current mode:
Call waiting feature is supported by the mobile phone and operator. There is an active call in the headset, and there is a waiting call.
What to do?
Press the TALK button to answer the call.
Bluespoon™ AX will do what?
The mobile phone will activate the waiting call, and put the active call on hold. In order to switch back to the held call, push the TALK
button.
______________________________________________________________________________________
Handle a call waiting (HANDS-FREE PROFILE):
Current mode:
Call waiting feature is supported by the mobile phone and operator. There is an active call in the headset, and there is a waiting call.
What to do?
Press the TALK button to hang up the active call, press the TALK button again to answer the waiting call.
Bluespoon™ AX will do what?
The mobile phone will hang up on the first call. Bluespoon™ AX will answer the call on the second button press. In order to hang up the
second call, push the TALK button.
___________________________________________________________________________________________________________
Transfer a call to the mobile phone (HANDS-FREE PROFILE):
Current mode:
Bluespoon™ AX has an ongoing call.
What to do?
Press and hold the TALK button for two seconds.
Bluespoon™ AX will do what?
Bluespoon™ AX will close the audio connection. The call continues in the mobile phone.
_____________________________________________________________________________________
Reject a call (HANDS-FREE PROFILE) :
Current mode:
You have an incoming call. Bluespoon™ AX and mobile phone are paired and within range of each other.
What to do?
Press and hold down the TALK button for 2 seconds in order to reject the call.
Bluespoon™ AX will do what?
Bluespoon™ AX will close the audio connection. The mobile phone will send a busy signal to the caller.
_____________________________________________________________________________________
Re -dial last number (HANDS-FREE PROFILE):
Current mode:
Bluespoon™ AX is paired with the mobile phone.
What to do?
Hold the VOLUME UP or DOWN button for approximately 4 seconds.
Bluespoon™ AX will do what?
Bluespoon™ AX will connect to the mobile phone and request a re-dial.
_____________________________________________________________________________________
FAQ: Problem: Solution:
Bluespoon™ AX disconnect after 90 seconds, when it is
connected with phone that is using the Hands -Free
profile
The Bluespoon™ AX or the mobile phone disconnects,
and Bluespoon™ AX turns off.
When the Bluespoon™ AX is connected with a Siemens
S55 and you want to make a phone call, it doesn’t
transfer the sound to the headset.
If the SE T610 is supporting the Hands-Free function, it is
not possible to transfer the call to the headset, when
there is an ongoing call in the phone.
You do not get a ring tone in the Bluespoon™ AX or in
the phone.
You need to pair device number 9, but which of the
already paired device will then be deleted ?
This is a normal behaviour of the headset. The reason
why this happens is that the mobile phone does not
support a low power mode. Next time you receive a call,
press the TALK button and the headset will reconnect
and answer the call.
The Bluespoon™ AX turns off if something went wrong
with the connection. This is done in order to save the
battery power.
Turn on the Bluespoon™ AX by pressing the TALK
button for 3 seconds.
When you have dialled the number, press the TALK
button, and the call will be transferred to the Bluespoon™
AX.
In the phone menu choose:
Connectivity->Bluetooth->Handsfree->Car handsfree->
Power Save.
The phone is probably in silent mode and therefore you
don’t get at ring tone.
You have paired 8 devices in this order:
A, B, C, D, E, F, G, H
You then use used devices in the following order :
C, D, A, F, B, H, G, E,
When you pair the 9th device, the “E” device will be
deleted.
We constantly update FAQ’s at website: WWW.NEXTLINK.TO
Quick reference tables:
HOW TO USE: Left vertical column shows headset state/mode.
Horizontal columns show actions when specific buttons are pressed.
Headset profile
TALK BUTTON VOLUME BUTTONS
Press Long press Press Long press
Off - Power ON - -
Standby Voice dial Power OFF - -
Ringing Answer Power OFF - -
Call Active End Call Power OFF Adjust volume Mute
Hands-Free profile
TALK BUTTON VOLUME BUTTONS
Press Long press Press Long press
Off - Power ON - -
Standby Voice dial Power OFF Adjust volume Re-dial
Setting up Voice dial Cancel voice dial Power OFF - -
Ringing Answer Reject - -
Call Active End Call Transfer call to
phone Adjust volume Mute
Call Active in phone Transfer call to
the headset Turn off - -
Call Active (Audio in
headset, second call
coming into phone
End call Transfer call to
phone Adjust volume Mute
CAUTION :
· Do not expose headset or battery to direct sunlight for prolonged periods of time.
· Do not use the headset or battery at extreme high or low temperatures.
· Do not leave the headset or battery in a car in blazing heat.
· Do not expose the headset or battery to lit cigarettes, cigars, open flames, liquid or moisture etc.
· Do not drop, hit, throw or try to bend headset or battery, as rough treatment could damage the products.
· Do not try to eat/swallow headset or battery.
· Do not try to shortcircuit battery.
Important information on safe and efficient operation. Read this information before using device.
Users are not permitted to make changes or modify the device in any way. Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate the equipment. See 4 7 CFR See, 15.21. This device
complies with part 15 of the FCC rules. Operation is subjec t to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. See
47 CFR Sec.15.19(3).
Electromagnetic Interference/compatibility
Note: Nearly every electronic device is susceptible to electromagnetic interference (EMI) if inadequately shielded, designed, or
otherwise configured for electromagnetic compatibility.
Facilities
To avoid electromagnetic interference and/or compatibility conflicts, turn off your headset in any facility where posted notices instruct
you to do so. Hospitals or Health care facilities may be using equipment that is sensitive to external RF energy.
Aircraft
When instructed to do so, turn off your headset when on board an aircraft. Any use of the headset must be in accordance with
applicable regulations per airline crew instructions.
Medical devices
Pacemakers
The Health Industry manufacturers Association recommends that a minimum seperation of 15 centimeters (6 inches) be maintained
between a handheld wireless device and a pacemaker. These recommendations are consistent with the independent research by, and
recommendations of, Wireless Technology Research.
Persons with pacemakers should:
· ALWAYS keep the phone and Bluetooth® headset more than 15 centimeters (6 inches) from your pacemaker when the phone is
turned ON.
· NOT carry the phone and Bluetooth® headset in the breast pocket.
· Turn OFF the phone and headset immediately if you have any reason to suspect that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult with your
hearing aid manufacturer to discuss alternatives. Simultaneous use of a CIC-hearing aid and the Bluespoon™ headset is not possible
due to lack of space in the ear.
Other medical devices
If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from RF
energy. Your physician may be able to assist you in obtaining this information.
FCC notice to Users
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will occur in a particular installation. If
the equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
· Reorient or relocate the receiving antenna.
· Increase the seperation between equipment and the receiver.
· Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Nextlink.to is under license.
Other trademarks and trade names are those of their respective owners.
Please visit our website for further information on the Bluespoon™ Collection, and also additional materials like
video guides, FAQ’s and news.
www.nextlink.to info@nextlink.to
Copyright 2004 All rights reserved. Bluespoon is a registred trademark of Nextlink.to.
NEXTLINK.TO A/S · Sandtoften 10 · 2820 Gentofte · Denmark · Tel: +45 70 22 23 43
Answer a call:
Conditions:
You have an incoming call, and the phone is ringing. The Bluespoon™ 5G and the phone are paired and on.
The 5G will do what?
It will alert you with a ringing signal.
What to do?
Press one of the buttons in order to take the call.
And then …
The mobile phone will open an audio connection.
Hang up:
Conditions:
You have an ongoing call in the Bluespoon™ 5G.
What to do?
Press the volume down button for 2 seconds in order to end the call.
The 5G will do what?
The Bluespoon™ 5G will ask the mobile phone to end the call. The mobile phone will close the audio connection and hang up.
_____________________________________________________________________________________
Reject a call (HANDS-FREE PROFILE ONLY) :
Conditions:
You have an incoming call, and the phone is ringing. The Bluespoon™ 5G and the phone are paired.
The 5G will do what?
The Bluespoon™ 5G will alert you with a ringing signal.
What to do?
Press the volume up button for 2 seconds in order to reject the call.
And then …
The mobile phone will send a busy signal to the caller.
_____________________________________________________________________________________
Volume control:
Conditions:
You have an audio connection to the mobile phone.
What to do?
In order to increase/decrease the volume on the loudspeaker, press the buttons, volume up or volume down.
The 5G will do what?
Every time you press volume up or down, the Bluespoon™ 5G will increase/decrease the volume on the speaker.
___________________________________________________________________________________________________________
Voice dialling:
Conditions:
The Bluespoon™ 5G is paired with the mobile phone, and they are both turned on.
What to do?
Press one of the two buttons.
The 5G will do what?
The Bluespoon™ 5G will connect, if not connected, to the mobile phone and request a voice dial.
Cancel a voice dial:
Conditions:
The Bluespoon™ 5G is about to make a voice dial.
What to do?
Press one of the buttons.
The 5G will do what?
The Bluespoon™ 5G will cancel the voice dial.
__________________________________________________________________________________________________________
Re -dial last number (HANDS-FREE PROFILE ONLY):
Conditions:
The Bluespoon™ 5G is paired with the mobile phone.
What to do?
Press the button volume down for 2 seconds.
The 5G will do what?
The Bluespoon™ 5G will connect to the mobile phone, if not connected, and request a re-dial.
_____________________________________________________________________________________
Transfer a call to the 5G:
Conditions:
The Bluespoon™ 5G is paired with the mobile phone and turned on. There is an ongoing/incoming call in the phone.
What to do?
Press the one of the buttons.
The 5G will do what?
The Bluespoon™ 5G will connect to the mobile phone and pick up the call.
_____________________________________________________________________________________
Transfer a call to the mobile phone (HANDS-FREE PROFILE ONLY):
Conditions:
The Bluespoon™ 5G has an audio connection to the phone and there is an ongoing call.
What to do?
Press volume up button for two seconds.
The 5G will do what?
The Bluespoon™ 5G will close the audio connection. The call continues in the phone the phone.
_____________________________________________________________________________________
Handle a call waiting (HEADSET PROFILE):
Conditions:
Call waiting is supported by the mobile phone. There is an active call in the headset, and there is a waiting call.
What to do?
Press the volume up button to answer the call.
The 5G will do what?
The Bluespoon™ 5G will send an accept command to the phone. The phone will activate the waiting call, and put the active call on hold.
What’s next?
In order to switch back to the held call, push the volume up button for two seconds.
The 5G will do what?
The Bluespoon™ 5G will send a command to the phone. The phone will end the active call, and switch to the held call.
---------------------------------------------------------------------------
Handle a call waiting (HANDS-FREE PROFILE):
Conditions:
Call waiting is supported by the mobile phone. There is an active call in the headset, and there is a waiting call.
What to do?
Press the volume down button for 2 seconds in order to hang up the first call, press one of the buttons again to answer the second call.
The 5G will do what?
The Bluespoon™ 5G will send a hang up command to the phone on the first button press. The phone will hang up on the first call. The
Bluespoon™ 5G will send a accept call on the second button press.
What’s next?
In order to hang up on the second call, push the volume down button.
The 5G will do what?
The Bluespoon™ 5G will send a hang up command to the phone. The phone will end the second call.
____________________________________________________________________________________________________________
Quick reference tables:
Bluespoon™ 5G button interface when using the Hands-Free profile
Volume up Volume down
Bluespoon™ 5G state Press 2 seconds press Press 2 seconds press
Off
- Power ON - -
Waiting for a call Voice dial Power OFF Voice dial Re-dial
Setting up Voice dial Cancel voice dial Power OFF Cancel voice dial -
Ringing Answer Reject Answer Answer
Call Active Adjust volume Transfer call to
phone Adjust volume End Call
Call Active in phone Transfer call to
the headset Turn off Transfer call to
the headset Transfer call to the
headset
Call Active (Audio in
headset, second call
coming into phone
Adjust volume
Transfer call to
phone
Adjust volume
End Call
Bluespoon™ 5G button interface when using the Headset profile
Volume up Volume down
Bluespoon™ 5G state Press 2 seconds press Press 2 seconds press
Off
- Power ON - -
Waiting for a call Voice dial Power OFF Voice dial Voice dial
Ringing Answer Power OFF Answer Answer
Call Active in phone Transfer call to
headset Turn off Transfer call to
headset -
Call Active Adjust volume Power OFF Adjust volume End call
Call Active (Audio in
headset, second call
coming to phone
Adjust volume
Power OFF
Adjust volume
Switch to waiting call*
*) Depending on the phone
__________________________________________________________________________________________________________
Important information on safe and efficient operation. Read this information before using device.
Users are not permitted to make changes or modify the device in any way. Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate the equipment. See 4 7 CFR See, 15.21. This device
complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. See
47 CFR Sec.15.19(3).
Electromagnetic Interference/compatibility
Note: Nearly every electronic device is susceptible to electromagnetic interference (EMI) if inadequately shielded, designed, or
otherwise configured for electromagnetic compatibility.
Facilities
To avoid electromagnetic interference and/or compatibility conflicts, turn off your headset in any facility where posted notices instruct
you to do so. Hospitals or Health care facilities may be using equipment that is sensitive to ex ternal RF energy.
Aircraft
When instructed to do so, turn off your headset when on board an aircraft. Any use of the headset must be in accordance with
applicable regulations per airline crew instructions.
Medical devices
Pacemakers
The Health Industry manufacturers Association recommends that a minimum seperation of 15 centimeters (6 inches) be maintained
between a handheld wireless device and a pacemaker. These recommendations are consistent with the independent research by, and
recommendations of, Wireless Technology Research.
Persons with pacemakers should:
· ALWAYS keep the phone and Bluetooth® headset more than 15 centimeters (6 inches) from your pacemaker when the phone is
turned ON.
· NOT carry the phone and Bluetooth® headset in the breast poc ket.
· Turn OFF the phone and headset immediately if you have any reason to suspect that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult with your
hearing aid manufacturer to discuss alternatives. Simultaneous use of a CIC-hearing aid and the Bluespoon™ headset is not possible
due to lack of space in the ear.
Other medical devices
If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from RF
energy. Your physician may be able to assist you in obtaining this information.
FCC notice to Users
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will occur in a particular installation. If
the equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
· Reorient or relocate the receiving antenna.
· Increase the seperation between equipment and the receiver.
· Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Nextlink.to is under license.
Other trademarks and trade names are those of their respective owners.
Please visit our website for further information on the Bluespoon™ Collection, and also additional materials
like video guides, FAQ’s and news.
www.nextlink.to info@nextlink.to
Copyright 2004 All rights reserved. Bluespoon is a registred trademark of Nextlink.to.
NEXTLINK.TO A/S · Sandtoften 10 · 2820 Gentofte · Denmark · Tel: +45 70 22 23 43
