Ngai Lik Electronics BSX100A BLUETOOTH SPEAKER SYSTEM User Manual Instruction Manual
Ngai Lik Electronics Enterprises Limited BLUETOOTH SPEAKER SYSTEM Instruction Manual
Instruction Manual
0 1
INSTRUCTION MANUAL
BLUETOOTH SPEAKER SYSTEM
MODEL: BSX100A
Please read following instructions prior to operating your unit.
Manufacturer of this unit follows a principle of continuous improvement and has no responsibility for any
changes that are made to the unit nor any liability for these changes. Thanks for your choice of our
products.
WARNING
- CAUTION: USE OF ANY CONTROLS, ADJUSTMENTS, OR PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
- CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR
EQUIVALENT TYPE.
- TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR
OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
- WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
- WARNING: THE BATTERIES SHALL NOT BE EXPOSED TO EXCESSIVE HEAT SUCH AS SUNSHINE, FIRE OR THE LIKE.
IMPORTANT SAFETY INSTRUCTIONS
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
WARNING: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR
BACK). NO USER-
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead
symbol, within an equilateral
triangle, is intended to alert the user
to the presence of uninsulated
"dangerous voltage" within the
product's enclosure that may be of
sufficient magnitude to constitute
a risk of electric shock to persons.
S3125A
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked on or pinch particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart
is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightening storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15) This appliance shall not be exposed to dripping or splashing water and that no object filled with liquid such as vases shall be
placed on the apparatus.
17) Rating label is located at the back of enclosure.
18) "CAUTION" mark is also located at the back of enclosure.
16) CAUTION: Visible and Invisible Laser Radiation when open and interlock defeated.
DO NOT STARE INTO BEAM.
2 3
1245678101
11 12 13
3 9
LOCATION OF CONTROLS
1. SPEAKERS
2. BLUETOOTH BUTTON
3. BLUETOOTH INDICATOR
STATUS INDICATOR
Power on lights up, yellow
Pairing mode flashes, blue
Connecting mode lights up, blue
4. PREV BUTTON
5. NEXT BUTTON
6. PLAY/PAUSE BUTTON
7. VOL- BUTTON
8. VOL+ BUTTON
9. AUX IN LED INDICATOR
10. AUX IN BUTTON
11. POWER
12. AUX IN JACK
13. DC IN JACK
POWER SUPPLY
Connect the AC/DC adapter to the unit and the main power.
VOLUME LEVEL
Press VOL+/- button to adjust the volume level accordingly. Beep tones will be heard when Volume
Maximum is reached.
BLUETOOTH CONNECTION
This unit can receive stereo audio signal from a BLUETOOTH stereo audio source device.
1. Press and hold POWER button to turn the unit on.
2. Press BT button to turn on the BLUETOOTH feature (LED indicator rapid blinking).
3. Pair and connect to F-3088 on the BLUETOOTH audio source device. If prompted for passcode,
enter “0000”.
4. Pairing successful (LED indicator blue), ready to stream music.
Note:
Pairing mode is canceled (LED indicator yellow) about 1.5 minutes
The above are generic steps to pair a BLUETOOTH device, for more specific instructions on
BLUETOOTH connectivity for your device, please consult your manufacturer’s manual.
AUX IN
Follow below steps to connect the unit to another audio device like MP3 player and the like:
1. Connect the Audio Out of the device to AUX IN jack with audio cable.
2. Press and hold POWER button to turn the unit on.
3. Press AUX IN button to switch the unit to AUX mode.
4. Power on the device and begin playback.
IMPORTANT SAFETY INSTRUCTIONS
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.
When the mains plug or an appliance coupler is used as the disconnect device, the disconnect device
shall remain readily operable. To be completely disconnected the power input, the mains plug of the
apparatus or the appliance coupler shall be disconnected from the mains completely.
No naked flame sources, such as lighted candles, should be placed on the apparatus.
Minimum distances 2.0cm around the apparatus for sufficient ventilation. The ventilation should not
be impeded by covering the ventilation openings with items, such as newspapers, table-cloths,
curtains, etc.
The use of apparatus is in tropical and/or moderate climates.
The marking plate is located at the back of the apparatus.
FCC Warnings
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
