Nikko Co RP7304H Remote Control Toy Receiver User Manual street
Nikko Co Ltd Remote Control Toy Receiver street
Nikko Co >
User Manual
![](/img.php?id=372651&img=bg1.png)
© NIKKO
Please read carefully before starting to operate.
1/16 STREET CAR
FEATURES
Full function
Runs forward backward, turns
left & right, stop.
BATTERY REQUIREMENTS
(Not included)
Vehicle: 6 x AA alkaline(1.5V)
or Ni-Cd(1.2V)batteries
Transmitter:1 x 9V(006P)battery
PRINTED IN CHINA
"Warning! use under the direct supervi-
sion of an adult.
Keep the operation manual and display
box for future reference.
Use 6 x "AA" size alkaline (1.5V) or Ni-
Cd (1.2V)batteries.(NOT INCLUDED)
and 006P(9V)battery.(NOT INCLUDED)
ATTENTION PARENTS
It is recommended that this toy and all
accessories be periodically examined
for potential hazards and that any po-
tentially hazardous parts be repaired
or replaced.
Repair and Parts Department
Monday to Friday 8:30AM-
5:30PM Central Time
Repair:(800)736-4556
Parts:(800)776-4556
Fax:(972)578-7059
e-mail:help@nikkoamerica.com
Please read the instructions before starting to
operate. Without any precautions, the vehicle
may move without your command or there
may be overheating or batteries or power mo-
tor. Additionally, the vehicle should be kept out
of the reach of very young children.
For ages 8 and up.
1 BATTERY INSTALLATION
TRANSMITTER
9V(006P)
Install batteries making sure that the + and - poles of the
batteries are positioned accurately.
Make sure vehicle's on-off switch is turned OFF when in-
stalling batteries.
Avoid combined use of new dry batterries and old ones.
Avoid combined use of Ni-Cd batteries and dry batteries.
Avoid combined use of charged Ni-Cd batteries and dis-
charged Ni-Cd batteries.
Remove all the batteries from the vehicle and the trans-
mitter after playing.
CAUTION WHEN USING BATTERIES
Battery lid
![](/img.php?id=372651&img=bg2.png)
2
2 HOW TO OPERATE
Turn ON the vehicle.
Operate the vehicle with transmitter.
Turn OFF the vehicle after operating.
Remove all the batteries both from the
vehicle and the transmitter.
Please follow the above sequence of
operation.
*
TRANSMITTER Antenna
Speed control stick
Steering control stick
LEFT/STRAIGHT/RIGHT
FORWARD
NEUTRAL
REVERSE
ANTI-POWER LOSS TRANSMITTER
(To prevent unnecessary power loss)
The transmitter power is automatically turned ON when the speed control stick is oper-
ated either to the forward running or reverse running positions, When the stick is returned
to the neutral position, the transmitter power is turned OFF. When the transmitter power is
turned OFF, the vehicle can be jammed by other transceiver radio waves and start to
move abnormally.
2
3
4
VEHICLE
TO OPEN THE BATTERY COMPARTMENT LID
Let the battery compartment lid
slide forward a littlee with a pres-
sure on to the latch.
Then, the battery compartment lid
can be pulled and open.
6 AA alkaline(1.5V)
or Ni-Cd(1.2V)batteries.
Steering alignment lever
3 MAJOR CAUSES OF VEHICLE MALFUNCTION
*WEAK BATTERIES
*INCORRECT BATTERY INSTALLATION
*INTERFERENCE
CAUTION
Install batteries making sure that the (+) and (-) poles of the batteries are positioned
accurately.
Avoid combined use of charged Ni-Cd batteries and discharged Ni-Cd batteries and
discharged Ni-Cd batteries.
Do not mix old batteries with new batteries.
Avoid using alkaline batteries and Ni-Cd batteries together.
Battery stopper
Use coin to turn the battery stopper to
the “OPEN” position.
ON/OFF switch
ON OFF
•©•¨
1
*Do not mix old and new batteries.
*Install batteries accurately in the battery compartment.
*Do not mix alkaline, standard [carbon-zinc], or rechargeable [nickel-cadmium] batter-
ies.
![](/img.php?id=372651&img=bg3.png)
3
Check to see that the batteries have been IN-
STALLED in the CORRECT position.
STOP
*
NOTE:
You can control the vehicle at a longer
distance by holding the transmitter
higher with the antenna straight up.
When the vehicle slows down or starts
moving erratically, replace all the
vehicle's batteries with fresh or fully
charged ones.
TO ADJUST STEERING ALIGNMENT
Adjust the steering alignment lever on
the underside of the vehicle when the
vehicle doesn't run straight forward.
Steering alignment lever
RADIO INTERFERENCE:Sometimes erratic behavior or loss of control of vehicle
is the result of interference caused by high tension wires, high voltage transformers, certain
types of building, concreate walls or narrow places where RADIO SIGNALS sent from your
transmitter MAY BE SCATTERED thus making it DIFFICULT for your vehicle to receive a
GOOD RADIO SIGNAL. If you encounter this type of behavior or loss of control, CHANGE
TO A DIFFERENT LOCATION.
You will encounter INTERFERENCE if ANOTHER radio controlled vehicle or CB radio is
operating in the vicinity on your SAME FREQUENCY.
3 OPERATING SAFETY RULES
Select a SAFE place to operate your vehicle.Do not drive in the street. Avoid driving on
SAND or through puddles of WATER. These hazards can impair performance. Check
the surface ahead of you and watch for obstacles.
The radio receiver in your vehicle and transmitter are sensitive instruments.Do not leave
Vehicle or Transmitter near sources of HEAT or under DIRECT SUNLIGHT for long
periods of time.
Avoid leaving Vehicle or Transmitter OUTSIDE OVERNIGHT. NIGHT DAMPNESS IS
HARMFUL TO INTERIOR MECHANISM.
VEHICLE
![](/img.php?id=372651&img=bg4.png)
4
English/Français
THE FCC WANTS YOU KNOW
This device complies with part 15 of the FCC Rules, Operation is subject to the
following two conditions:
(1)This device may not cause harmful interference.
(2)This device must accept any interference received,including interference that
may cause undesired operation.
Your R/C car might cause TV or radio interference even when it is operating prop-
erly.
To determine whether your R/C car is causing the interference, turn off your R/C
car.
If the interference goes away,your R/C car is causing the interference.
Try to eliminate the interference by:
Moving your R/C car away from the receiver.
Contacting your local store for help.
If you cannot eliminate the interference, the FCC requires that you stop using your
R/C car.
This toy vehicle needs periodic maintenance and cleaning.
Keep out of reach of small children under 36 months old as there is danger of getting
hurt.
Cleaning and maintenance:
Caution
