User Manual
Nikko MicroRadioControl System”iTruck”
RDC-700600
-2-
-3- -4-
-1-
For ages 6 and over
Manual of Instructions
*Thank you for choosing NIKKO iTruck!
*Read this Manual of Instructions care-
fully to the end before starting to play.
*Don’t throw away the box or this
manual, but keep them for future use.
*The actual product may differ slightly
from the illustrations.
Features
*The controller (transmitter) has a built-in battery recharger. Attach iTruck to the controller
for quick recharging and lasting power.
*A large volume, high-power nickel metal hydride battery is built into the chassis.
*The controller has only 1 control stick. Forward-backward running, left-right turns, and
stopping are all possible with single-hand operations.
Battery requirements:
Size "AA" "UM3" "R6" alkaline batteries x 2 (No other type of battery should be used)
Battery Characteristics and Recharging Tips
When playing for the first time after purchase, or after a long interval, the battery power
may be weak. Even after recharging, the running time can be relatively short. The
battery will gradually regain power after 2 or 3 repetitions of usage and recharging.
Also, if you keep the power switch turned ON for a long time, the battery power will be
discharged. Make sure to turn OFF the power switch immediately after use.
Names of the Parts
iTruck
Receiver
antenna
Top side
Steering
alignment
lever
Power switch
Bottom side
Recharging
terminal
(iTruck side)
Charger cover
CONTROLLER
Center marker holder
Recharging
terminal (control-
ler side)
release button
Power switch Recharging monitor
lamp (green LED)
Control stick
Top side
Transmitter antenna
Battery lid
Bottom side
safety hook
removal button
How to Install the Controller Batteries
Use a ballpoint pen to open
the battery lid. Install 2 alkaline
batteries
Battery installation:
*Install the batteries in the controller.
(This product operates only with size "AA" "UM3" "R6"alkaline batteries. If you use man-
ganese or other types of batteries, the nickel metal hydride battery built into the vehicle
may not be recharged fully. Be sure to use ONLY alkaline dry cell batteries.)
Make sure that the power switch of the controller is turned OFF.
Use a ballpoint pen, pencil or sharp tools to push the release button of the battery
lid. While pressing the button, slide the lid a little bit as shown in the diagram.
*Slide out the lid with your hand and detach.
*Be careful so that the pencil lead will not be broken.
Install 2 size "AA" "UM3" "R6" alkaline batteries, making sure that the (+) and (-)
ends are positioned properly.
Attach the battery lid again. Slide the lid back into position until the release button
clicks. (Lift up the rear end of the battery lid slightly to fit the lid into the groove as
shown in the diagram. Then, keep the lid flat and slide into the groove.)
There is a safety hook on the controller to prevent ve-
hicle from falling off while recharging. When vehicle is
fully recharged, the green LED lamp will turn off. When
this has been confirmed, keep pressing the recharg-
ing release button on the side of the controller, and
pull vehicle toward you to detach it from the controller.
removal
button
iTruck power
switch is turned
OFF
Controller
power switch
is turned ON
Open the charger
cover
Fit the claw of the con-
troller into the hollow
pit of the chassis.
Slide iTruck forward until
you hear a click.
The set-up is completed!
Check to see that iTruck does
not fall off.
The green LED
lamp lights up.
The ordinary recharging time is about
2 minutes. (The LED lamp will turn
off when recharging is completed.)
Contents of the Kit
iTruck x 1 Controller x 1
Manual of
Instructions x 1
close the lid.
If the product is used in low temperatures, the battery duration can be shorter than
normal. This is a characteristic feature of the battery and is not a defect. The situation
can be improved by recharging the battery immediately before playing. The battery
power tends to be weakened as time elapses.
When you have finished recharging, de-
tach iTruck from the controller and replace
the recharger cover.
Fit into the groove. To remove the bot-
tom battery more
easily, press the mi-
nus (-) end with
your finger and pull
out the plus (+) end.
Procedures for Recharging iTruck
(Remove dust or filth from the charger Recharging terminal.)
Follow the correct procedures when recharging.
When the battery starts to run out of power, the LED lamp will grow dim.
1 2
34
1 2
3 4
5 6
7
8
ATTENTION PARENTS
It is recommended that this toy and
all accessories be periodically ex-
amined for potential hazards and
that any potentially hazardous
parts be repaired or replaced.
IT IS A VIOLATION OF THE FCC REGULA-
TIONS TO REMODEL OR ALTER THIS DE-
VICE IN ANY WAY WITHOUT PERMISSION,
ANYONE WHO VIOLATES THE REGULA-
TIONS WILL LOSE THE RIGHT TO OPERATE
THE DEVICE.
Repair and Parts Department
Monday to Friday 8:30AM-5:30PM Central Time
Repair:(800)736-4556
Parts:(800)776-4556
Fax:(972)578-7059
e-mail:help@nikkoamerica.com
-6-
-7- -8-
P_No.R700600NC030530
If there is anything wrong with the vehicle movements, check the following:
What’s
wrong? Cause
1 The power switch on vehicle is in
the OFF position.
2 The vehicle is too far away from
the controller.
3 The (+) and (-) poles of the batter-
ies of the controller are positioned
in the wrong direction.
4 The metal tab touching the con-
troller battery is rusted.
5 The metal recharging terminals
of the controller or boat may be
rusted.
6 Either the controller batteries or
vehicle battery lack power.
7 There is another radio control ve-
hicle using the same band being
operated nearby.
8 The antenna of the controller or
vehicle is bent.
Check and see
1 Turn ON the power switch on ve-
hicle .
2 Shorten the distance between the
controller and vehicle .
3 Install the batteries in the right di-
rection.
4 Use sandpaper to remove the rust.
5 Use sandpaper to remove the rust.
6 Either change the controller batter-
ies with new ones or recharge ve-
hicle as necessary.
7 Play at a different time or in a dif-
ferent place.
8 Straighten the antenna.
The vehicle
doesn’t
move or it
malfunc-
tions.
How to Operate
Turn the power switch ON. Controller operations and iTruck movements.
First, turn ON the controller power switch, and then turn ON the iTruck power
switch.
Tilt the controller stick in the direction you wish to move iTruck, and it will start
moving.
If either the antenna on iTruck or the controller is bent, the radio waves will not
reach a long distance. Straighten them before playing. When you finish playing,
be sure to remove the batteries from the controller.
Steering Alignment
Steering alignment lever
If iTruck does not move straight forward or straight
backward, try adjusting the steering alignment le-
ver on the bottom side of iTruck. If the vehicle
tends to go to the right, move the alignment lever
toward L. If the vehicle tends to go to the left,
move the lever toward R.
Features of the Controller
This controller enables single-hand
operation for all movements.
Therefore, you can do something
else while operating iTruck.
iTruck is operated by use of radio waves. If you operate iTruck where it can be affected
by other radio waves, the vehicle may not respond correctly to your operations, or start
to move even though you are not operating it. In such cases, the vehicle is not broken.
Operate your vehicle in a different place or at a different time.
*The kit contains very small parts . They can be dangerous if swallowed by mistake, so
keep them away from reach of children under 3 years old.
*Use ONLY size-"AA" "UM3" "R6" alkaline batteries for the vehicle. DO NOT use Ni-Cd
or other rechargeable batteries or manganese batteries.
*Be careful not to let your fingers, hair or clothes get caught in the tire. (DO NOT turn
the power switch ON while the vehicle is still in your hands.)
<If the alkaline batteries are used improperly, they may become heated, explode, ignite,
leak, etc. Observe the following points and the warnings in the manual of instruc-
tions.>
CAUTION!
-5-
* Operation Techniques *
For smooth cornering, move the stick
slightly forward or reverse and then slide it
to the left or right.
This will enable
smooth left/right
turns. If you mas-
ter this basic tech-
nique, you will be
able to make a let-
ter ”8” slalom, etc.
This cornering technique will enable the
user to operate iTruck on the table or in
other small places.
The position of the stick and
the direction of the vehicle.
Extended Operating Time (follow-up recharging)
Recharge the battery once. Without using the
battery, recharge a second time. This ”follow-up
recharging” will lengthen the playing time.
Moreover, if you recharge the battery 3 times in a
row before use, the playing time will be extended
even more.
However, be careful NOT to recharge the battery
more than 3 times in a row.
Also, note that the battery duration differs depend-
ing on how you play.
If you keep the product on some furniture, floor, etc., compounding agents from the tires
can cause color change and other damage to the surface on which the product is placed.
To prevent this, observe the following:
* When storing the product, don’t place it directly on furniture or the floor. Protect the
surface of the furniture, floor, etc. by placing a thick mat under the product.
Please note the following points when storing the product:
Maintenance and Care
If the becomes dirty, use a slightly dampened cloth to wipe off the dirt and filth. Then use
a dry cloth to wipe of the moisture. You can also use a small brush to remove filth from
intricate parts.
To remove dust particles, tie a small bit of cloth to the tip of a toothpick, tweezers, etc. and
wipe off.
CAUTION!: BE SURE TO READ THE FOLLOWING PRECAUTIONS:
*DO NOT use chemicals. The body of the vehicle can melt and cause machine troubles.
*If you keep the vehicle in a place where the temperature is extremely hot or cold, or
where it is extremely humid (such as in a car or under direct sunlight), the vehicle can
be damaged and lead to machine troubles.
*Be sure to remove the batteries from the controller when storing the product away.
Keep this Manual of Instructions carefully for future use.
*Make sure that the + and - poles of the batteries are positioned properly.
*Avoid mixed use of old and new batteries, or mixed use of different types of batteries.
*When you finish playing, be sure to turn the power switch OFF and remove all the batteries.
*DO NOT let the batteries get wet and cause short-circuits. DO NOT take the batteries
apart, heat them, or throw them into a fire.
*The Manual of Instructions will be necessary if you forget the operation methods or the
caution points, so DO NOT throw it away. Keep it with you.
THE FCC WANTS YOU KNOW
This device complies with part 15 of the FCC Rules, Operation is sub-
ject to the following two conditions:
(1)This device may not cause harmful interference.
(2)This device must accept any interference received,including interfer-
ence that may cause undesired operation.
Your R/C vehicle might cause TV or radio interference even when it is
operating properly.
To determine whether your R/C vehicle is causing the interference, turn
off your R/C vehicle.
If the interference goes away,your R/C vehicle is causing the interfer-
ence. Try to eliminate the interference by:
Moving your R/C vehicle away from the receiver.
Contacting your local store for help.
If you cannot eliminate the interference, the FCC requires that you
stop using your R/C vehicle.
English/Français
THE RBRCTMSeal on the nickel cadmium battery
pack indicates that NikkoAmerica is voluntarily
participating in an industry program to collect and
recycle these batteries at the end of their useful life.
The RBRC program provides a convenient alternative
to disposing nickel-cadmium batteries into the trash
or municipal waste stream,which is illegal in some areas.
Nikko America's payments to RBRC makes it easy for you to drop
off the spent battery pack at local retailers who sell replacement
nickel-cadmium batteries.
You may also contact your local recycling center for information on
where to return the spent battery pack.RBRC is a trademark of the
Rechargeable Battery Recycling Corporation.
