Users Manual
1/12 Radio Control Car
NIKKO
PRINTED IN MALAYSIA
IMPRIME EN MALAISIE
IMPRESO EN MALASIA
English / Français / Español
Owner's Manual
Manuel du lutilisateur
Manual del Propietario
• Recharge the Battery
Before You Start to Operate
• Recargue la bateria antes de
empezar a jugar
• Recharger la batterie avant d'allumer
ATTENTTION: JOUET ELECTRIQUE
Non recommandé pour les enfants de moins de 8 ans. Comme aves tous les appareils électriques, des précaut
ons doivent être observées pendant la manipulation et l'emploi pour éviter toute décharge électrique.
Entrée: secteur 120 VAC, 60 Hz seulement
Sortie: 12VDC 200mA
PARENTS ATTENTION
Il est recommandé de vérifier périodiquement l'absence de risque potentiel sur ce jouet et tous les
accessoires et de réparer o remplacer les pieces potentieliement dangereuses.
FEATURES
PRECAUCÓN: JUGETE ELÉCTRICO
No recomendado para niños de menos de 8 años de edad. AL igual que con todos los productos eléctricos,
para evitar un shock eléctrico, se deben observar precauciones especiales al manipular y usar este juguete.
Entrada: Solamente 120 VAC, 60 Hz.
Salida: 12 VDC, 200mA
ATENCIÓN PADRES
Se recomienca que este juguete y todos sus accesorios sean examinados periódicamente para tratar
de encontrar peligros potenciales provocados por piezas que necesiten ser reparadas o cambiadas.
CARACTERISTIQUES
CARACTERÍSTICAS
9.6 V
KMNA-120125
NMO-300505
NECESIDADES DE PILAS
PILE/BATTERIE
BATTERY REQUIREMENTS:
Vehicle : Ni-Cd battery energy pack
(9.6V, 600-650mAh)
Transmitter : 1 x 9V(006P)battery
Véhicule : Batterie autonome Ni-Cd
(9,6V, 600-650mAh)rechargeable
Emetteur : 1 pile 006p(9V)
Vehiculo : Bateria de pilas do Ni-Cd
"energy pack" de
(9,6V, 600-650mAh)
Transmisor : 1 pila de 9 V (006P)
2-channel full function: Forward, reverse, left/ right turn and stop.
Transform action.
Rear wheel differential gear.
Front & rear suspension.
Working headlight.
Please read carefully before starting to operate.
Keep the display box and the manual for future reference.
Warning! Use under the direct supervision of an adult
Actual product may vary from illustration of this manual.
Lea estas instrucciones detenidamente antes de la utilización.
Guardar la caja y el manual para su consulta en el futuro.
Precautión! Úselo bajo la supervisión diercta de un adulto.
El producto real puede diferir ligeramente de las ilustraciones.
Lisez attentivement ce manuel avant de commencer à utiliser le véhicule.
Conservez la boîte d'exposition et le manuel pour toute référence ultérieure.
Attention! A utiliser sous la supervision directe d’un adulte.
La moto contenue dans l'emballage peut ne pas correspondre exactement aux illustrations.
!
Toutes fonctions, 2 canaux: marche avant, arrière, virage à gauche/droite et arrèt
Transformation.
Fonctionnement des phares avant
Funciones completas mediante dos canales: Avance, retroceso, giros a la izquierda o derecha y detención
Acción de transformación.
Faros que se iluminan.
120125 Morph nator
ST-39672
English
2
Do not charge Battery Pack immediately after use. Wait until it has cooled before charging.
Avoid short circuits. Short circuits will cause overheating, burning of the cords and other damages to the
battery Pack and Charger.
The Ni-Cd Battery Charger should be used for charging one Battery Pack. Do not use the Charger for
charging other type of batteries and battery packs
Do not use the Charger as a direct current outlet for other electrical appliances or machines.
Make sure that the Battery Pack and Charger are kept out of the hands of infants and small children while
charging.
Do not charge near fires, where the temperature is extremely high, or where it is wet or damp.
The charger will become slightly heated while charging. Allow sufficient free space around the Charger.
If the power of the battery pack is weak in spite of proper charging, the batteries may be worn out from
repeated use. Replace it with a new Ni-Cd battery pack.
Dispose of use Ni-Cd battery packs correctly.
Disconnect the supply before making or breaking connections to the battery.
Only use batteries or accumulators of the recommended type or a similar type.
WARNING AGAINST RECHARGING NON-RECHARGEABLE BATTERIES.
Please use this battery charger only for the charge of the rechargeable battery pack.
The Ni-Cd battery pack should be charged under the supervision of an adult.
CAUTION
RECHARGING "WARNING! USE UNDER THE DIRECT SUPERVISION OF AN ADULT."
* The newly purchased Ni-Cd pack is not charged. Charge before operating. Household
outlet
Ni-Cd battery pack
OR
Charger
Household
outlet
Charger
Ni-Cd battery pack
1. Join the connector of the charger to the connector of
the Ni-Cd battery pack.
2. Plug the charger into an electrical outlet.
3. Recharge for about 4-5 hours.
4. When the recharging is over, plug out the charger
from the electrical outlet and detach the connectors.
When playing for the first time after purchase, or after a long
interval, the battery power may be weak. Even after recharging,
the playing time can be relatively short. The battery will gradually
regain power after 2 or 3 repetitions of usage and recharging.
TOP VIEW BOTTOM VIEW
NAMES OF PARTS
120125 Morph nator
Transmitter
antenna
3
English
Pass the antenna wire through the antenna tube, then
insert the tube into the antenna tube holder.
If the antenna tube cannot be successfully inserted into the
antenna tube holder, try holding the root of the antenna
wire with fingers of one hand and extending the wire with
fingers of the other hand.
1. HOW TO ATTACH ANTENNA TUBE
* Note: Be careful not to pull antenna wire too strong.
PREPARATION FOR STARTING OPERATION
2. HOW TO INSTALL TRANSMITTER ANTENNA
Place the transmitter antenna into the antenna holder
to screw it in clock-wise.
Do not extend the antenna when installing. It’s
dangerous.
If the antenna is not screwed in securely, the vehicle
may move erratically. Screw the antenna securely.
Antenna wire
Antenna tube
Antenna tube
holder
3. HOW TO INSTALL THE BATTERIES
Transmitter
To remove the battery lid, press the
point marked “OPEN” and pull the lid
downward. * Dispose the used batteries separately from
other trash.
One 9 volt (006P) battery
Steering control stick
Forward / Reverse
control stick
Red LED
power indicator
LEFT / STRAIGHT / RIGHT
FORWARD
STOP
(NEUTRAL)
REVERSE
R/C SYSTEM
TRANSMITTER
Transform button
120125 Morph nator
Install battery make sure that (+) and (-) poles
are positioned properly.
English
4
When installing a Ni-Cd battery pack, Make sure that the power switch of the vehicle is OFF.
*
Vehicle
Press the battery lid stopper
and slide it downward.
2Lift the battery stopper
3
Insert the Ni-Cd battery pack (9.6V)
into the battery compartment
and push in all the way.
4Join the connectors of the
Ni-Cd pack with the vehicle.
5Put the connector cable into
the connector holder.
6
Close the cover and snap
it shut.
7
(1) Extend the transmitter antenna.
You can control the vehicle at a longer dis-
tance by holding the transmitter higher with
the antenna straight up.
(2) Turn on the transmitter by
operating the control stick.
(The power indicator will light
up.)
*
4. HOW TO PLAY
(3) Switch ON the power
switch of the vehicle.
OFFON
120125 Morph nator
When you connect the connectors. Make
sure the vehicle switch is in the “OFF”
position.
Fixed connectors properly.(The
connectors are designed to be connected
in only one way so that the positive(+) and
the negative(-) terminals are connected
accurately.)
Disconnect the connectors immediately
after played.
When you disconnect the connectors, be
careful do not pull the wire too strongly.
Avoid short circuits because it is very
dangerous.
Remove all the batteries both from the
vehicle and the transmitter after played.
++
--
++
--
1
Vehicle's
connector
Battery’s
Connectors
Vehicle's
connector
Battery’s
Connectors
ON
OFF
5
English
(5) Switch OFF the
vehicle after playing.
OFF ON
To prevent damage from battery
leakage, remove all the batteries from
transmitter and vehicle after playing.
HOW TO ADJUST WORKING LIGHT FUNCTION
Adjust the steering alignment when the vehicle does not run straight forward.
TO ADJUST STEERING ALIGNMENT
Turn the steering alignment
lever towards “L” if the vehicle
runs towards right.
Turn the steering alignment
lever towards “R” if the vehicle
runs towards left.
L RL R
TRANSFORM ACTION
CAUTION
It is dangerous to have your finger caught in the
vehicle while it is performing the transform action.
When the transformation
ends, press the button again.
Push transformation button and watch vehicle transform from off-road truck to low riding rail racer.
120125 Morph nator
(4) Start operation.
(6)
R/C SYSTEM
R/C SYSTEM
R/C SYSTEM
3 2
MASH THE THROTTLE AND MORPH'NATOR POPS WHEELIES
WHEELIES FUNCTION
1
2
1
2
When transform from low riding rail racer to off-road truck, there will be a slight gap on the truck bed.
This is not a defect. Once the vehicle move forward or backward, the gap will close automatically.
NOTE:
English
6
DO NOT operate your vehicle on tick-piled carpets. It can be dangerous since the carpet fiber may twine
round a shaft and cause a motor overheated.
TM
THE RBRC Seal on the nickel cadmium battery pack indicates that Nikko America is voluntarily
participating in an industry program to collect and recycle these batteries at the end of their useful
life. The RBRC program provides a convenient alternative to disposing nickel-cadmium
batteries into the trash or municipal waste stream, which is illegal in some areas.
Nikko America's payments to RBRC makes it easy for you to drop off the spent battery pack at
local retailers who sell replacement nickel-cadmium batteries.
You may also contact your local recycling center for information on where to return the spent
battery pack. RBRC is a trademark of the Rechargeable Battery Recycling Corporation.
THE FCC WANTS YOU KNOW
This device complies with part 15 of the FCC Rules, Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
Your R/C car might cause TV or radio interference even when it is operating properly.
To determine whether your R/C car is causing the interference, turn off your R/C car.
If the interference goes away, your R/C car is causing the interference.
Try to eliminate the interference by:
• Moving your R/C car away from the receiver.
• Contacting your local store for help.
If you cannot eliminate the interference, the FCC requires that you stop using your R/C car.
Select a SAFE place to operate your vehicle, Do not drive in the street. Avoid driving on SAND or through puddles of WATER.
These hazards can impair performance. Check the surface ahead of you and watch for obstacles.
The radio receiver in your vehicle and transmitter are sensitive instruments. Do not leave Vehicle or Transmitter near sources of HEAT
or under DIRECT SUNLIGHT for long periods of time.
Avoid leaving Vehicle or Transmitter OUTSIDE OVERNIGHT. NIGHT DAMPNESS IS
HARMFUL TO INTERIOR MECHANISM.
Cleaning and maintenance:
This toy vehicle needs periodic maintenance and cleaning.
Warning to the parents:
The charger for the Ni-Cd battery pack needs periodic inspection
to see that the lead wires, plugs, outer case, and other parts are
not damaged in any way. If any of the parts are damaged,
do not use the charger until it is completely repaired.
Caution:
Keep out of reach of small children under 36 months old as there is danger of getting hurt.
CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE MANUFACTURER FOR COMPLIANCE COULD VOID
THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
RADIO INTERFERENCE:
Sometimes erratic behavior or loss of control of vehicle is the result of interference caused by high tension wires, high voltage
transformers, certain types of building, concrete walls or narrow places where RADIO SIGNALS sent from your transmitter MAY BE
SCATTERED thus making it DIFFICULT for your vehicle to receive a GOOD RADIO SIGNAL.
If you encounter this type of behavior or loss of control, CHANGE TO A DIFFERENT LOCATION.
You will encounter INTERFERENCE if ANOTHER radio controlled vehicle or
CB radio is operating in the vicinity on your SAME FREQUENCY.
120125 Morph nator
Check the batteries regularly for leakage.
Remove empty batteries from the toy.
Never try to charge non-rechargeable batteries.
Rechargeable batteries may only be charge under the supervision
of an adult.
When inserting the batteries take care not to reverse their polarity.
Never use batteries of different manufacturers, and do not mix old
and new batteries.
Use only the recommended batteries or batteries of equal quality.
Never short-circuit the terminals.
Rechargeable batteries which can be recharged must be removed
from the toy prior to charging.
CAUTION
