Instruction Manual
Item no. EMW2600T
A. Functions
1. An ideal device to control you appliances automatically by using a programmable
remote timer
2. LCD displays the timing setting and current time.
3. Transmitter has 11 manual buttons: MY ON, MY OFF, ON, OFF, UP, DW ,
Morning, Evening, All night, Countdowm, BL and one reset button R
B. Diagram
LED indicate light
Button
Function
UP
1. In current time display, press to adjust (add 1 min or
continuously)
2. In countdown mode, press to adjust
3. Time adjusting from minute to hour, hold to adjust
continuously
DW
1. In current time display, press to adjust (reduce 1 min or
continuously)
2. In countdown mode, press to adjust
3. Time adjusting from minute to hour, hold to adjust
continuously
ON
1. If no program set, press ON to switch on the receiver outlet
2. If timing program is set, press ON to switch on the receiver
outlet until it reaches the programmed OFF time. LED light on
indicates the receiver is on
OFF
1. If no program set, press OFF to switch off the receiver outlet
2. If timing program is set, press OFF to switch off the receiver
outlet until it reaches the programmed ON time. LED light on
indicates the receiver is off
MY ON
Press to select MY ON time function (LED light on), you can set
MY ON time meanwhile, press again to cancel
MY OFF
Press to select MY OFF time function (LED light on), you can set
MY OFF time meanwhile, press again to cancel
evening
Press to select Evening function (receiver stay on from 5pm to
12am, other time stay off), press again to cancel
morning
Press to select Morning function (receiver stay on from 5am to
8am, other time stay off), press again to cancel
All night
Press to select All Night function (receiver stay on from 6pm to
6am, other time stay off), press again to cancel
Countdown
Press to select Countdown function, press again to cancel
(adjustable from 1 minute to 24 hours, default time is 1 hour)
BL
Press to show the program status with LCD light on, press again
to cancel. If there is no action within 5 seconds, the device goes
into sleep mode
R
Reset button, press to clear all the programs, wait for several
seconds, the LCD turns into initial display
C. Instruction Procedures
- For safety use, please switch off your appliance before plugging in the receiver.
- Plug the receiver in a socket.
- Please ensure the receiver is switched off (LED power indicator off), then plug the
appliance in the receiver.
1. Current time setting
Current time display is a basic working status, other program settings are based on
current time. LCD displays hour, minute, AM or PM, and an arrow points at “clock”.
In current time mode, press DW or UP to adjust the time. Press once, the time
adjusts for 1 minute, hold the button for 2 seconds, the time adjusts quickly, keep
holding over 5 seconds, the time adjusts for 5 minutes continuously.
2. Program Setting
a. Press ON to switch on the receiver outlet (the LED indicator on)
b. Press OFF to switch off the receiver outlet (the LED indicator on)
c. Press EVENING to select Evening function (the LED indicator on), the receiver
stays on from 5pm to 12am, other time stays off, press again to cancel (the LED
indicator off)
d. Press MORNING to select Morning function (the LED indicator on), the receiver
stays on from 5am to 8am, other time stays off, press again to cancel (the LED
indicator off)
e. Press ALL NIGHT to select All Night function (the LED indicator on), the receiver
stays on from 6pm to 6am, other time stays off, press again to cancel (the LED
indicator off)
f. Press Countdown to select Countdown function (the LED indicator on), the LCD
displays the time left and an arrow points at “countdown”, press DW or UP to
set the countdown time, press again to cancel (the LED indicator off)
During countdown mode, you can still press DW or UP to adjust the time to
switch off. The countdown time is adjustable from 1 minute to 24 hours, default
time is 1 hour.
While under countdown mode, the receiver outlet stays on until it reaches the
countdown time or the countdown mode can be cancelled manually.
g. Press MY ON to select MY ON function (the LED indicator on), the time on LCD
blinks, press DW or UP to set a time for the receiver to switch on. After 5
seconds, the program is saved and activated, the LCD goes back to current time.
Press the button again to deactivate the function (LED indicator off)
h. Press MY OFF to select MY OFF function (the LED indicator on), the time on LCD
blinks, press DW or UP to set a time for the receiver to switch off. After 5
seconds, the program is saved and activated, the LCD goes back to current time.
Press the button again to deactivate the function (LED indicator off)
i. Press BL to show the program status with LCD light on, press again to cancel. If
there is no action within 5 seconds, the device goes into sleep mode
j. Press Reset to reset all the transmitter’s settings. LCD shows the time 12am; the
receiver is switched off; the countdown default time is 1 hour.
3. Program Connections
a. ON, OFF，Countdown,
press any of them will cancel other two functions
e.g. in countdown mode, press ON to change the receiver from countdown mode to
ON mode
in countdown mode, press OFF to change the receiver from countdown mode to
OFF mode
in ON mode, press OFF to change the receiver from ON mode to OFF mode
in ON mode, press Countdown to change the receiver from ON mode to
countdown mode
b. ON，OFF, MORING, ALL NIGHT, EVENING,
while MORING, ALL NIGHT, EVENING are activated, press ON or OFF to switch
the receiver’s power on/off until it reaches the next action of MORING, ALL
NIGHT, EVENING program
c. Countdown, MORING, ALL NIGHT, EVENING,
while MORING, ALL NIGHT, EVENING are activated, press Countdown to enter
countdown mode, the receiver outlet switches on and stays on until it reaches
the countdown time, then the MORING, ALL NIGHT, EVENING program takes
over the control
d. MORING, ALL NIGHT, EVENING, can be selected multiply
D.Caution:
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Prudence：
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Warning:
Under Industry Canada regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for the transmitter by
Industry Canada. To reduce potential radio interference to other users, the antenna
type and its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful communication.
Avertissement :
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio
peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé
pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de
brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type
d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente
(p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication
satisfaisante
E. Specification
If the LCD does no work, please change the battery
Power Rating: 3 x AAA battery
Working frequency: 433.92 MHz
Working range: Max. 30m
IP20
Manufacturer
Logo:
Factory:Everflourish Electrical Co., Ltd.
Address: Renjiu Village, Wuxiang Town, Yinzhou Ningbo 315111 P.R. China
