User Manual
Installation Instructions
1) Provide 5V DC on pad 1 (4.75V-5.25V)
2) Provide DC ground onto PAD2
3) Connect PAD 3 (IF) to the µPC for signal processing
PAD1
PAD3
PAD2
NOTICE:
This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry
Canada.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
NOTICE:
Changes or modifications made to the equipment not expressly approved by PDLUX
may void the FCC / IC authorization to operate this equipment.
The use of the transceiver is authorized into mobile or fixed devices taking into
account the conditions listed below :
•OEM Integrator may be sure that the end user manual may not contain any
information about the way to install or remove the module from the final
product.
PD-V4
PD-V4-UFL
30mm
15mm
•Depends on final host configuration additional authorization requirements for
the non-transmitter functions on the transmitter module may be required (i.e.,
Verification, or Declaration of Conformity) OEM integrator is responsible for
ensuring that after the module is installed and operational into the host, it
continues to be compliant with the Part 15B unintentional radiator
requirements.
•The information on label and user manual is required to be incorporated in the
user manual of the final system. see 47 CFR15 requirements for more details
(e.g. 15.19 / 15.21 / 15.101 / 15.105 / RSS-GEN / ICES)
•Additional label with the words ‘Contains FCC ID:2AIWW-PD-V4’ and 2AIWW
-PD-V4-UFL shall be applied and visible from the outside of the end product.
•The module must be installed and used in strict accordance with the
manufacturer’s instructions as described in the user documentation that
comes with the product.
Microwave Sensor
FCC ID:2AIWW-PD-V4
MODEL:PD-V4
Microwave Sensor
FCC ID:2AIWW-PD-V4
MODEL:PD-V4
PD-V4
PD-V4-UFL
Microwave Sensor
FCC ID:2AIWW-PD-V4
MODEL:PD-V4-UFL
Microwave Sensor
FCC ID:2AIWW-PD-V4
MODEL:PD-V4-UFL
Approved hosts: sensor switch,sensor lighting
Note: These hosts provide power supply regulator to integrate with limited
compliance testing.
