INSTRUCTION MANUAL
PA-1200
INDEX
OPERATION.....................................................................................................1
GENERAL USE INSTRUCTIONS....................................................................2
SPECIFICATIONS............................................................................................3
CONTROLS AND SONNECTIONS..................................................................3
OPERATION
1. Prior to switching on,turn volume down to minimum.
2. Connect the audio source to the appropriate input socket.
3. Connect to the mains suppy.
4. Switch on the audio source,followed by the active speaker.
5. Set the volume with the applicable control.
6. Adjust the bass + treble.
7. Bluetooth connection instruction
Select “BT” mode of the mp3
Open Bluetooth function on your pairing device and find PA15.
Select PA15 to complet pairing.
Input passwort“0000”if ask for
Select the song and play through your mobile
INSTRUCTIONS
Do not overload the box to avoid damage to the speaker.
Do not place an open fire (candles etc) on top or next to the box - FIRE HAZARD
Only connect to an earthed mains outlet of 115V/230V 60~50Hz.
For indoor use only. If the box is used outdoors,you need to make sure that no humidity
can enter the box.
When not in use,unplug the unit from the mains.
Unplug the unit from the mains prior to checking or replacing fuse.
Make sure that the box is placed on a stable,strong surface.
The boxes can be hung. Use only strong and approved mounting material.During the
mounting, make sure that nobody is standing below the mounting area.
Do not place liquids on the box and protect it against humidity. Humidity can shorten
the life time considerably.
Only use suitable means of transportation if you want to move the box - BEWARE OF
YOUR BACK!!
Always unplug the unit during a thunderstorm or when it is not use.
If the unit has not been used for a long period of time, condensation can occur inside
the housing. Please let the unit reach room temperature prior to use.
Never try to repair the unit yourself. It does not contain any user serviceable parts.
Run the mains lead in such a way that nobody can fall over it and nothing canbe put in it.
Set the unit to the lowest volume prior to switching it on.
Keep the unit out of the reach of children.
![](/img.php?id=3356801&img=bg3.png)
SPECIFICATIONS
3*6.5”Speaker box
System Active 2-way fullrange
Woofer 3*6.5”
Tweeter 1”
Power RMS 1500W
Impedance 4 ohm
Frequency Range 78Hz-18KHz
Sensitivity 90dB(+/-2dB)V
Connector XLR/6.35mm/RCA
Mic Input Level ≤15mV
Line input/output level ≥250m
CONTROLS LOCATION
![](/img.php?id=3356801&img=bg4.png)
1.LCD screen
2.Mp3 control
MODE:USB/SD/BT convertor
:Play / Pause
:Repeat one / Repeat all / Random
Long hold to search lower/ higher station manually
:Previous Song
Long press for fast rewind
:Next Song
Long press for fast forward
3.SD card input
4.USB input
5.MIC level control
6.Line input level control
7.Volume control
8.Clip LED indicator
9.Power LED indicator
10.XLR microphone1 input
11.6.35mm microphone2 input
12.XLR line input
13.RCA phone(R+L) line input
14.3.5mm line input
15.XLR line output
16.LED Light Switch(ON/OFF)
17.115/230V Switch
18.Main power switch
19.Fused IEC mains inlet
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
RSS-Gen Issue 3 December 2010"&"CNR-Gen 3e édition Décembre 2010:
- English:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause in
terference, and (2) This device must accept any interference, including interference t
hat may cause undesired operation of the device.
- French:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux apparei
ls radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
