M-2500
INSTRUCTION MANUAL
![](/img.php?id=2980280&img=bg2.png)
![](/img.php?id=2980280&img=bg3.png)
1
2500 W
8
15
15
![](/img.php?id=2980280&img=bg4.png)
LEV EL
MAX
MIN
LEV EL
MAXMIN
LEV EL
MAXMIN
MP3 L EVEL
MAXMIN
TREBLE
-12 dB +12 dB
BAS S
-12 dB + 12 dB
MIC 1 MIC 2 LI NE I NP UT
CH1 CH2 CH 3
R L
POWER
CLI P
POWER
ON
OFF
OFF O N
LED
SPE AKER OU T
8Ω
LIN E OUTPUT
SCA N
AC 115/230V 60/50Hz
115V 23 0V
3
4
1
2
5
6
7
18
17
8
11
15 16
12
14
910
13
19 20 21
24
23
22
1.LCD screen
2.MODE:USB/SD/BT/FM convertor
:Play / Pause
SCAN:Long press to auto search under FM radio
:Repeat one / Repeat all / Random
:PRE/NEXT under FM mode
Long hold to search lower/
higher station manually
:Short press to tune to saved station
:Previous Song
Long press for fast rewind
:Next Song
Long press for fast forward
3.SD card input
4.USB input
5.MP3 level control
6.Treble control for high frequencies
7.Bass control for low frequencies
8.MIC1 input level control
9.MIC2 input level control
10.Line input level control
11.XLR microphone1 input
12.XLR microphone2 input
13.XLR line input
14.6.35 microphone1 channel line input
15.6.35 microphone2 channel line input
16.RCA phone(R+L) line input
17.Power LED indicator
18.Clip LED indicator
19.XLR line output
20.Speaker out 8 Ohm
21.LED Light Switch(ON/OFF)
22.115/230V Switch
23.Main power switch
24.Fused IEC mains inlet
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
