ACCESS Controller

TheAccesscontrollercomesassembledwithabaseandalid.Thebaseofthecontrollercontainsthe

controlboardwithtwo13‐pinterminals.Thelidhasastickerthatshowsthefunctionforeachpost

ontheterminals.

AccessBase AccessLid

ACCESS-Mini Controller

TheAccess‐Minicontrollercomesassembledwithaboxandacover.Theboxofthecontroller

containsthecontrolboardwitha26‐pinJSTconnector.

AccessBase AccessLid

PB‐CBL‐1

Pin Assignments

PinAssignmentsforAccess

Access&Access– MiniPin# Function Pos/Neg

16V‐ 24VInput +

26V‐ 24VInput ‐

39VEmergencyPowerInput +

49VEmergencyPowerInput ‐

5 SolenoidOutput +/‐

6 SolenoidOutput +/‐

7DCMotorOutput +/‐

8DCMotorOutput +/‐

9ServoMotorSignalOutput Signaling

10 ServoMotorOutput ‐

11 ServoMotorOutput +

12 TFBLEDRED ‐

13 TFBLEDGREEN ‐

14 TFBLEDBLUE ‐

15 TFBLEDCOMMON +

16 LEDBLUE(NOTUSED) ‐

17 LEDBLUE(NOTUSED) +

18 TFBWake/Quick‐ClickButton ‐

19 TFBWake/Quick‐ClickButton +

20 ManualUnlockButton ‐

21 ManualUnlockButton +

22 SensorInput ‐

23 SensorInput +

24 GPIO(NOTUSED) +

25 GPIO(NOTUSED) ‐

26 Ground(NOTUSED) GND

Installing Access

Step1:Determinewhichendpointyouareusing.

Accessiscompatiblewithanyelectro‐mechanicallockpullingupto3Aof

power.

•Pins5&6shouldbeusedforsolenoids,dropbolts,electricstrikes,or

electromagneticlocks.

•Pins7&8shouldbeusedforDCMotors.

•Pins9,10,&11shouldbeusedforServomotors.

Step2: Attachwiresfromendpointtothecorrectpinsfortheendpoint

typeontheAccessboard.

Step3: AttachtheTFBwirestopins12‐15and18‐19accordingtothe

PinAssignmentsonthepreviouspageorthestickerontheAccesslid.

TheTFBbuttonwill“wakeup”theboardwhentheAccesshaspower

runningtoit.TheTFBalsohascolorlightindicatorsandwillbeusedto

activatethe“QuickClick”sequence.

Step4: Attachthemanualunlockbuttonwirestopins20&21.The

manualunlockbuttonwillautomaticallyunlocktheAccessunitwhen

triggered.(Ifnecessary)

Step5: AttachanysensorwirestoPins22&23.(Ifnecessary)

Step6: Attachmainpowerwirestopins1&2.

Step7: Attachsecondarypowerwirestopins3&4.

Note: SecondarypowerwiresrunfromtheTFB,ifusing,andare

attachedto9VbackupterminalsontheTFB.

Functions

MainPower: Themainpowerpowerstheboardwheninuse.TheAccesscan

acceptfrom6Vto24VDC.Thepolarityofthewiresonthepowerinputisvery

importantandmustbeinthecorrectpositions.Ifthewiresareswitched,the

boardwillnotfunctionproperly.

SecondaryPower: Thesecondarypowerisusedasback‐uppowerwhenthemain

powerisnotworking.Secondarypowercanacceptfrom6Vto24VDC.The

polarityofthewiresonthepowerinputisveryimportantandmustbeinthe

correctpositions.Ifthewiresareswitched,theboardwillnotfunctionproperly.

Note:Boththemainpowerandsecondarypowercanhavecurrentrunningtothe

atthesametime.ItwillnotaffecttheAccess.TheAccesswillonlyrunonone

powerinputatatime.

SolenoidOutput: Thesolenoidoutputisforusewithsolenoids,dropbolts,electric

strikes,andotherelectromechanicallocks.Thetypeofendpointusedinthis

positionmaynotexceed3A.Theendpointisconfiguredusingthe“LockSettings”

inthePAC‐BLUapp.Thefunctionsthatareconfigurableintheappare:

•Re‐LockTrigger:Relockbasedonatimerorsensor.

•Re‐LockTimer:Theamountoftimetheendpointwilllockorunlockfor.

•Sensor1TriggerOn:LoworHigh.

•SolenoidDefaultState:OnorOff.The“off”optionisforendpointthatarefail

securelocksmeaningthatthelockislockedwhenpowerisnotrunningtoit.

The“on”optionisforlockswhicharefailsafelocksandarelockedwithpower

runningtoit.

•ManualUnlock:Whenselectedtheboardwillallowamanualunlockbuttonor

switchtobeusedinsideofthedoor.

•Sleep:Whenselectedtheboardwillgotosleepwhennotinusetoconserve

power.Itmustbewokenupusingabuttonorswitchtofunction.Whennot

selected,theboardwillnevergotosleepwhenpowerisrunningtoitandwill

alwaysbebluetoothing.

•WakeUpAction:NoneorLock.When“None”ischosen,theboardwilldo

nothingwhenwokenup.When“Lock”ischosen,theboardwillperformthe

lockfunctioneachtimeitiswokenup.

ElectromagneticOption: Thesolenoidoutputisalsousedwithelectromagneticlocks.

Thetypeofendpointusedinthispositionmaynotexceed3A.Theendpointis

configuredusingthe“LockSettings”inthePAC‐BLUapp.Thefunctionsthatare

configurableintheappare:

•Re‐LockTrigger:Relockbasedonatimerorsensor.

•Re‐LockTimer:Theamountoftimetheendpointwilllockorunlockfor.

•Sensor1TriggerOn:LoworHigh.

•ManualUnlock:Whenselectedtheboardwillallowamanualunlockbuttonor

switchtobeusedinsideofthedoor.

•Sleep:Whenselectedtheboardwillgotosleepwhennotinusetoconservepower.

Itmustbewokenupusingabuttonorswitchtofunction.Whennotselected,the

boardwillnevergotosleepwhenpowerisrunningtoitandwillalwaysbe

bluetoothing.

•WakeUpAction:NoneorLock.When“None”ischosen,theboardwilldonothing

whenwokenup.When“Lock”ischosen,theboardwillperformthelockfunction

eachtimeitiswokenup.

DCMotorOutput: TheDCoutputisforusewithDCmotors.TheDCmotorusedinthis

positionmaynotexceed3A.TheDCmotorisconfiguredusingthe“LockSettings”inthe

PAC‐BLUapp.Thefunctionsthatareconfigurableintheappare:

•Re‐LockTrigger:Relockbasedonatimerorsensor.

•Re‐LockTimer:Theamountoftimetheendpointwilllockorunlockfor.

•Sensor1TriggerOn:LoworHigh.

•Motorruntime:Theamountoftimethemotorwillrunforbeforerunninginthe

oppositedirectiontore‐lock.

•MotorUnlockDirection:Configurabletorunclockwiseorcounterclockwise.

•MotorVoltage:3.3Vor5.0V.AhighvoltagemotormaybeusedwiththeAccess.

Themotorwillonlyrunatthespecifiedvoltageof3.3Vor5.0Vandwillnotrunat

thefullcapacity.

•ManualUnlock:Whenselectedtheboardwillallowamanualunlockbuttonor

switchtobeusedinsideofthedoor.

•Sleep:Whenselectedtheboardwillgotosleepwhennotinusetoconservepower.

Itmustbewokenupusingabuttonorswitchtofunction.Whennotselected,the

boardwillnevergotosleepwhenpowerisrunningtoitandwillalwaysbe

bluetoothing.

•WakeUpAction:NoneorLock.When“None”ischosen,theboardwilldonothing

whenwokenup.When“Lock”ischosen,theboardwillperformthelockfunction

eachtimeitiswokenup.

Functions

ServoMotorOutput: TheServooutputisforusewithServomotors.TheServomotor

usedinthispositionmaynotexceed3A.TheServomotorisconfiguredusingthe“Lock

Settings”inthePAC‐BLUapp.Thefunctionsthatareconfigurableintheappare:

•Re‐LockTrigger:Relockbasedonatimerorsensor.

•Re‐LockTimer:Theamountoftimetheendpointwilllockorunlockfor.

•Sensor1TriggerOn:LoworHigh.

•ServoUnlockPosition:Thepositionthattheservoservo isinwhenunlocked.

•ServoLockPosition:Thepositionthattheservomotorisinwhenlocked.

•Motorruntime:Theamountoftimethemotorwillrunforbeforerunninginthe

oppositedirectiontore‐lock.

•MotorUnlockDirection:Configurabletorunclockwiseorcounterclockwise.

•MotorVoltage:3.3Vor5.0V.AhighvoltagemotormaybeusedwiththeAccess.

Themotorwillonlyrunatthespecifiedvoltageof3.3Vor5.0Vandwillnotrunat

thefullcapacity.

•ManualUnlock:Whenselectedtheboardwillallowamanualunlockbuttonor

switchtobeusedinsideofthedoor.

•Sleep:Whenselectedtheboardwillgotosleepwhennotinusetoconservepower.

Itmustbewokenupusingabuttonorswitchtofunction.Whennotselected,the

boardwillnevergotosleepwhenpowerisrunningtoitandwillalwaysbe

bluetoothing.

•WakeUpAction:NoneorLock.When“None”ischosen,theboardwilldonothing

whenwokenup.When“Lock”ischosen,theboardwillperformthelockfunction

eachtimeitiswokenup.

TFBLEDLightColorInputs: ThethreeTFBcolorinputsarefortheindicatorlightsonthe

TFB.Thelightsindicatethecurrentstatusoftheboard.

•Red:Theboardhaspowerandisawake.

•Green:Thecurrentfunctionisrunning.

•Blue:Theboardisupdatingtothenewsettingsindicatedintheapp.

TFBWake/QuickClickButton: Thesetwoinputsservetwofunctions.

•Wake:ThebuttonwillwaketheAccessuptobeginbluetoothing whenpushed.

•QuickClick:ThepatentedQuickClickopensthelockusingMorseCodetype

sequenceswithbuttonclicks.

ManualUnlockButton: Themanualunlockbuttoninputisforamanualunlockswitch,

button,orsensor.Themanualunlockisusedtounlocktheendpointfrominsideofthe

roomorenclosure.Whenusingthemanualunlock,thelockwillopenwithouttheuseof

eKeys.

SensorInput: Thesensorinputallowsforasensorthatfunctionsasarelocktrigger

whenselected.

Functions

Caution: Theuseriscautionedthatchangesormodificationsnotexpresslyapprovedby

thepartyresponsibleforcompliancecouldvoidtheuser'sauthoritytooperatethe

equipment.

ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowing

twoconditions:(1)thisdevicemaynotcauseharmfulinterference,and(2)thisdevice

mustacceptanyinterferencereceived,includinginterferencethatmaycauseundesired

operation.

NOTE:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassB

digitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovide

reasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.This

equipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalled

andusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradio

communications.However,thereisnoguaranteethatinterferencewillnotoccurina

particularinstallation.

Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,which

canbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotryto

correcttheinterferencebyoneormoreofthefollowingmeasures:

‐‐ Reorientorrelocatethereceivingantenna.

‐‐ Increasetheseparationbetweentheequipmentandreceiver.

‐‐ Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe

receiverisconnected.

‐‐ Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

FCCRadiationExposureStatement:

ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforanuncontrolled

environment.Thisequipmentshouldbeinstalledandoperatedwithaminimumdistance

of20cmbetweentheradiatorandyourbody.

Thistransmittermustnotbeco‐locatedoroperatinginconjunctionwithanyother

antennaortransmitter.
