1. Users Manual
2. User Manual

User Manual

QUICK GUIDE

13.3.

12.

11.

10.

15.

14.

16.

20.

17.

18.

19.

1. EARPHONE

2. DISPLAY

• Colour display with touch

screen

• Select, open or drag-and-

drop GUI objects

• Use as a virtual keyboard to

input text

3. GREEN KEY

• By default OK or Enter

4. SCAN KEY

5. TAB / ALT KEY

6. TELEPHONE KEYPAD /

FUNCTION KEYS

7. BACKSPACE

8. MICROPHONE

9. CHARGING INDICATOR

10. POWER KEY

• If needed, press and hold

for 5 seconds to perform

hardware reset

11. MODE / FUNCTION selection key

Press the Mode/Function key

repeatedly to select one of the

following keypad modes:

• Function: Numeric keys act as

• Function keys F1 to F10

• abc: Numeric keys act as

lower case letters

• ABC: Numeric keys act as

UPPER CASE letters

NORDIC ID MORPHIC

KEY PARTS

Nordic ID Morphic Quick Guide

• 123: Numeric keys act as

numbers

12. ARROW KEYS

• Move cursor within an input

ﬁeld or to navigate menus.

13. RED key

• By default Cancel or Esc

14. DOCKING CRADLE

15. CHARGER CONNECTOR

16. OPTICAL READER

• 1D laser scanner or 2D image

17. LOUDSPEAKER

• Audible alarms and signals

18. HANDSTRAP

19. BATTERY COVER

20. RFID ANTENNA (OPTIONAL)

INSTALLING BATTERY

BATTERY

ATTACHING THE BATTERY

ATTACHING THE BATTERY COVER

Nordic ID Morphic Quick Guide

INSTALLING SIM AND MICRO SD CARDS

INSTALLING A SIM CARD

INSTALLING A MICRO SD CARD

The SIM card holder is inside the battery compartment. First remove the battery to access the SIM card holder.

The microSD card holder is inside the battery compartment. First remove the battery to access the microSD card

The AC adapter is shipped with three

exchangeable adapter plugs for EU,

UK, US and China .

Suitable adapter plug has to be

attached onto the AC adapter before

ﬁrst use:

1. Place the exchangeable adapter

plug to the open end of its

attachment slot on the power

switching unit.

2. Slide the adapter plug along the

grooves of the slot.

3. Press the adapter plug until it is

ﬁrmly locked to its place by the

locking clip.

RECHARGING BATTERY

HANDSTRAP

ATTACHING THE HANDSTRAP

AC ADAPTER SCANNING DIRECTION

Nordic ID Morphic Quick Guide

NOTE

Do not touch the antenna with your ngers. Touching the antenna reduces the reading distance!

READING RFID TAGS

NORDIC ID MORPHIC UHF RFID

NORDIC ID MORPHIC UHF RFID CROSS DIPOLE

The optimal reading direction with Nordic ID Morphic UHF RFID is forward along the device axis from the top of

the device. The antenna is horizontally linear polarized and provides best performance when the tag polarization is

aligned with the device.

Before using Nordic ID Morphic Cross UHF RFID Dipole for reading TAGs: (1) Turn the foldable antenna as in the

picture below. The optimal reading direction with Nordic ID Morphic UHF RFID Cross Dipole antenna is directly

forward from the antenna along the device axis. The antenna polarization can be software controlled between vertical,

horizontal or cross polarization (default). The chosen polarization, as well as other settings, effect the practical reading

distance.

CHARGING THE NORDIC ID

MORPHIC DIRECT WITH THE

POWER SUPPLY

ORANGE: Battery is more than 80 %

charged but still being charged at low

current

RED: Battery is being charged

GREEN: Battery is fully charged

CHARGING

CHARGING THE SPARE

BATTERY AND DOCKED

NORDIC ID MORPHIC

DOCKING THE NORDIC ID

MORPHIC

PLACING THE BATTERY IN

THE CHARGING SLOT

CONNECTING THE POWER

SUPPLY TO THE CRADLE

RED: Spare battery is being charged

GREEN: Spare battery is fully charged

Your Nordic ID Morphic contains delicate

electronic parts. Therefore it is vulnerable to

environmental factors such as dirt, extreme

temperatures, humidity and mechanical

stress. Treat your Nordic ID Morphic

with care. The following hints help you to

preserve your device’s functionality and

longevity.

CLEANING

The device can be wiped clean with a damp,

non-abrasive, clean, lint-free cloth.

Do not use harsh chemicals, strong

detergents, or abrasive cleaners to clean

the device.

HANDLING

• Avoid dropping the Nordic ID Morphic,

or bumping it against other objects. Hard

impacts can damage the device. Note that

damages caused by careless handling

are not covered by the warranty.

• The touch sensitive colour display, i.e. the

touch screen, is vulnerable to mechanical

stress. Do not use sharp objects or

excess force on the touch screen.

• Avoid storing the Nordic ID Morphic in

dusty and dirty or extremely humid, cold

or hot conditions. Harsh environmental

factors can shorten the life of electronic

components, damage batteries and warp

or fracture plastics or other mechanical

parts.

• When the Nordic ID Morphic is moved

from a cold environment to a warm

environment, condensation may lead

to a short circuit inside the device.

It is advisable to allow the device to

acclimatise for several hours, after being

brought in from the cold, before powering

up.

• Try to keep your Nordic ID Morphic dry.

Wipe spilled liquids immediately with a

dry, non-abrasive, clean, lint-free cloth.

If moisture gets inside your Nordic ID

Morphic because of condensation or

spillage, open the battery cover and

remove the battery. You may power up

the device again once it has dried. Do not

open the device case. Opening the case

voids the warranty.

• Before using the device, the batteries

must be fully charged. Charging takes

approx. 8 hours.

• The surface of the touch screen is

vulnerable to damage. Do not use a sharp

object or press hard on the surface with

the stylus

CRADLE

The Nordic ID Morphic docking cradle

includes electronics for charging battery,

and for emitting and picking up USB and

Ethernet signals. Therefore the cradle

is vulnerable especially to high and low

temperatures, splashed liquids, and

rough treatment. The following hints help

preserving the docking cradle’s health and

longevity.

Do not use the power supply for any other

purposes than for charging the rechargeable

batteries on the Nordic ID Morphic device or

on the battery charger slot of the cradle.

CARE AND

MAINTENANCE

LAN AND USB

CONNECTIVITY

1. Mini-B (Mini USB)

2. RJ-45 (LAN)

3. Power supply

USB INTERFACE

• Full-speed (12Mbit/s)

• Low-speed (1.5Mbit/s)

• USB socket for Mini-B (Mini USB)

plug

The cradle can be connected e.g. to

PC by means of the USB cable with the

Mini-B connector at the other end.

LAN INTERFACE

• Ethernet 10/100BASE-TX

• LAN socket for RJ-45 plug

The LAN and USB connections can be

used simultaneously. Both connections

are plug-and-play. Your Nordic ID

Morphic LAN interface is set on factory

default settings, and the LAN into

which you have plugged the cradle

provides DHCP service.

LASER BATTTERY AC ADAPTER

MEDICAL DEVICES

POTENTIALLY EXPLOSIVE

ENVIRONMENTS

SAFETY PRECAUTIONS

Nordic ID Morphic mobile computers,

equipped with 1D laser scanner, are

classied as Class 2 Laser products having

1mW power and 650nm wavelength. The

laser scanner uses a low power, visible

laser diode. As with any very bright light

source, such as the sun, the user should

avoid staring directly into the light beam.

Momentary exposure to a Class 2 laser is

not known to be harmful.

The NORDIC ID Morphic fulls the

regulatory requirements as follows:

Complies with 21CFR1040.10 and 1040.11

except for deviations pursuant to Laser

Notice No. 50, dated June 24, 2007.

IEC/EN 60825-1:2007

用错误型号电池更换, 会有爆炸的危险, 务必

按照说明处置用完的电池

Use only the following Varta EasyPack

Recahargeable Li-Polymer 3,7V battery

models being intended for your Nordic ID

Morphic:

• EZPack XL (2260 mAh / 8,4Wh)

• EZPack L (1130 mAh / 4,2 Wh)

Note! Using some other battery type or

model for powering your Nordic ID Morphic

than those mentioned above may cause a

battery explosion.

Do not disassemble the battery.

Do not short circuit the battery’s electrical

contacts.

Do not expose the battery to direct sunlight

or other heat sources.

Dispose the battery in ecologically sound

manner and according to local laws and

regulations.

• Use only AC adapters approved by

Nordic ID. This device is intended for use

with Nordic Power S024EM0520300 AC

adapter.

• Do not use the AC adapter for any other

purposes than for charging the Nordic ID

Morphic rechargeable batteries.

• Check the mains voltage against those

specied in the AC adapter before

plugging to mains socket.

• Use the AC adapter indoors at normal

room temperatures.

To avoid potential interference from Nordic

ID Morphic it shall be operated (, and kept) a

minimum of 20 centimetres (8 inches) from

a medical device such as a pacemaker,

hearing aid, or cardioverter-debrillator, in

every situation.

Switch o your device when in area with

potentially explosive atmosphere. Sparks in such

areas could cause re or an explosion. Potentially

explosive environment include areas where the

air contains chemicals or particles such as dust

or other powders. Potentially explosive areas are

often, but not necessarily always, clearly marked.

Obey all signs and instructions.

DANSK LASERLYF! SE IKKE IND I STRÅLEN! KLASSE 2 LASER!

DEUTSCH LASERSTRAHLEN! NICHT DIRECT IN DEN LASERSTRAHL SCHAUEN!

LASER PRODUKT DER KLASSE 2!

ENGLISH LASER LIGHT! DO NOT STARE INTO BEAM! CLASS 2 LASER!

ESPAÑOL LUZ LASER! NO MIRE FIJAMENTE EL HAZ! PRODUCTO LASER DE

LA CLASE 2!

FRANCAIS LUMIERE LASER! NE PAS REGARDER LE RAYON FIXEMENT!

PRODUIT LASER DE CLASSE 2!

ITALIANO LUCE LASER! NON FISSARE IL RAGGIO PRODOTTO!

NEDERLANDS LASERLICHT! NIET IN STRAAL STAREN! KLASSE-2 LASER!

NORSK LASERLYS! IKKE STIRRINN I LYSSTRÅLEN! LASER, KLASSE 2!

PORTUGUÊS LUZ DE LASER! NÃO FIXAR O RAIO LUMINOSO! PRODUTO LASER

DA CLASSE 2!

SUOMI VARO LASERSÄDETTÄ! ÄLÄ SUUNTAA SÄDETTÄ SILMIIN! LASER,

LUOKKA 2!

SVENSKA VARNING LASERSTÅLNING! STIRRA EJ IN I STRÅLEN! KLASS 2

LASER!

Les ordinateurs mobiles Nordic ID Morphic,

équipés avec un scanner laser 1D, sont

classiés comme produit de classe 2 Laser

ayant 1mW de puissance et 650nm de

longueur d´ondes. Le scanner laser utilise

une faible puissance, une diode laser

visible. Comme toute source lumineuse,

comme le soleil, l´utilisateur doit éviter de

regarder directement le rayon laser. Une

exposition momentanée à un produit laser

de Classe 2 n´est pas reconnue comme

dangereuse.

Le NORDIC ID Morphic répond aux

exigences réglementaires suivantes :

Est conforme avec 21CFR1040.10 et

1040.11 excepté pour les déviations

conformément à la notice Laser No 50,

datant du 24 Juin 2007,

IEC/EN 60825-1 :2007

PRECAUTIONS D´UTILISATION

LASER

BATTERIE

Veuillez utiliser la batterie Varta EasyPack

rechargeable Li-Polymer 3,7V, étant le

modèle destiné pour votre Morphic.

EZPack XL (2260 mAh / 8,4Wh).

EZPack L (1130 mAh / 4,2 Wh).

Note: Utiliser d´autres type/modèle de

batteries pour la mise sous tension du

Morphic que ceux mentionnés ci-dessus

peut provoquer l´explosion de la batterie.

Ne pas démonter la batterie.

Ne pas court-circuiter les connecteurs

électriques de la batterie.

Ne pas exposer la batterie directement

au soleil, ou à toutes autres sources de

chaleur.

Veuillez jeter la batterie selon les normes

écologiques en accord avec les autorités

locales et les lois et régulations en vigueur.

ADAPTATEUR AC

• Veuillez utiliser l´adaptateur AC approuvé

par Nordic ID. Cet appareil est destiné

pour l´utilisation avec le Nordic ID Power

S024EM0520300 adaptateur AC.

• Ne pas utiliser l´adaptateur AC pour

tout autre usage que pour rechargé les

batteries rechargeable du Nordic ID

Morphic.

• Vérier toujours le voltage avec celui

spécié sur l´adaptateur AC avant de

brancher ce dernier.

• Veuillez utiliser l´adaptateur AC en

intérieur à température ambiante.

ENVIRONEMENTS POTEN-

TIELLEMENT EXPLOSIFS

Eteignez votre appareil lorsque vous vous

trouvez dans une zone potentiellement

sujette à des explosions. Des étincelles

dans de telles zones peuvent provoquer

un incendie ou une explosion. Les zones

considérées comme potentiellement

explosive inclus les zones ou l´air

contient des produits chimiques ou des

particules, poussières ou tout autres types

de poudres. Les zones potentiellement

sujettes à explosion sont souvent, mais

pas nécessairement toujours, clairement

indiquées. Veuillez obéir strictement aux

signes et instructions.

Pour éviter toutes interférences du Nordic

ID Morphic, celui-ci doit être utilisé (et

conservé) à un minimum de 20 centimètres

(8 pouces) d´un appareil médical tel qu´un

pacemaker, un appareil d´aide auditif

ou d´un débrillateur à synchronisation

automatique en toutes situations.

APAREIL MEDICAU

COMPLIANCE STATEMENTS

Depending on the markings in the device

label the product is compliant for the

following statements.

CE COMPLIANCE

STATEMENT

Hereby, Nordic ID Oy declares that this

Nordic ID Morphic product is in compliance

with the essential requirements and other

relevant provisions of Directive 1999/5/EC

Dansk Undertegnede Nordic ID Oy erklærer

herved, at følgende udstyr Nordic ID

Morphic overholder de væsentlige krav og

øvrige relevante krav i direktiv 1999/5/EF.

Deutsch Hiermit erklärt Nordic ID Oy,

dass sich das Gerät Nordic ID Morphic in

Übereinstimmung mit den grundlegenden

Anforderungen und den übrigen

einschlägigen Bestimmungen der Richtlinie

1999/5/EG bendet.

Español Por medio de la presente Nordic ID

Oy declara que el Nordic ID Morphic cumple

con los requisitos esenciales y cualesquiera

otras disposiciones aplicables o exigibles de

la Directiva 1999/5/CE.

Ελληνική ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Nordic

ID Oy ΔΗΛΩΝΕΙ ΟΤΙ Nordic ID Morphic

ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ

ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ

ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.

Français Par la présente Nordic ID Oy

déclare que l’appareil Nordic ID Morphic

est conforme aux exigences essentielles

et aux autres dispositions pertinentes de la

directive 1999/5/CE.

Italiano Con la presente Nordic ID Oy

dichiara che questo Nordic ID Morphic è

conforme ai requisiti essenziali ed alle altre

disposizioni pertinenti stabilite dalla direttiva

1999/5/CE.

Nederlands Hierbij verklaart Nordic ID

Oy dat het toestel Nordic ID Morphic in

overeenstemming is met de essentiële

eisen en de andere relevante bepalingen

van richtlijn 1999/5/EG.

Norsk Nordic ID Morphic er i samsvar med

de grunnleggende krav og andre relevante

bestemmelser i EU-direktiv 1999/5/EF.

Português Nordic ID Oy declara que este

Nordic ID Morphic está conforme com os

requisitos essenciais e outras disposições

da Directiva 1999/5/CE.

Suomi Nordic ID Oy vakuuttaa täten että

Nordic ID Morphic tyypin laite on direktiivin

1999/5/EY oleellisten vaatimusten ja

sitä koskevien direktiivin muiden ehtojen

mukainen.

Svenska Härmed intygar Nordic ID

Oy att denna Nordic ID Morphic står I

överensstämmelse med de väsentliga

egenskapskrav och övriga relevanta

bestämmelser som framgår av direktiv

1999/5/EG.

NATIONAL RESTRICTIONS IN

THE EUROPEAN UNION

When the Nordic ID Morphic device

incorporates an optional 2.4 GHz wideband

transmission system (transceiver), it

imposes some restrictions on the use of its

2.4 GHz WLAN connectivity in France, Italy,

and Latvia where restrictive use applies to

2.4 GHz band.

In Italy the end-user should apply for a

license at the national spectrum authorities

in order to obtain authorization to use the

outdoor WLAN set-ups and/or for supplying

public WLAN access to telecommunications

and/or network services.

The outdoor WLAN set-ups may not be

used in France and in some areas the RF

output power may be limited to 10 mW EIRP

in the frequency range of 2454 – 2483.5

MHz. For detailed information the end-

user should contact the national spectrum

authority in France.

In Latvia the outdoor usage of the 2.4 GHz

band requires an authorization from the

Electronic Communications Oce.

France Pour la bande 2,4 GHz, la puissance

est limitée à 10 mW en p.i.r.e. pour les

équipements utilisés en extérieur dans

la bande 2454 - 2483,5 MHz. Il n’y a pas

de restrictions pour des utilisations dans

d’autres parties de la bande 2,4 GHz.

Consultez http://www.arcep.fr/ pour de plus

amples détails.

Italy Questo prodotto è conforme alla

speciche di Interfaccia Radio Nazionali

e rispetta il Piano Nazionale di ripartizione

delle frequenze in Italia. Se non viene

installato all ‘interno del proprio fondo,

l’utilizzo di prodotti Wireless LAN richiede

una “Autorizzazione Generale”. Consultare

http://www.comunicazioni.it/it/ per maggiori

dettagli.

Latvia 2,4 GHz frekveču joslas izmantošanai

ārpus telpām nepieciešama atļauja no

Elektronisko sakaru direkcijas. Vairāk

informācijas:

http://www.esd.lv.

FCC COMPLIANCE

STATEMENT

This hand-held device complies with part 15

of the FCC Rules. Operation is subject to

the following two conditions: (1) This device

may not cause harmful interference, and (2)

this device must accept any interference

received, including interference that may

cause undesired operation.

Changes or modications not expressly

approved by the party responsible for

compliance could void the user’s authority

to operate the hand-held equipment.

FCC COMPLIANCE NOTICE

NOTE: This equipment has been tested and

found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide

reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses, and can

radiate radio frequency energy and, if not

installed and used in accordance with the

instructions, may cause harmful interference

to radio communications. However, there

is no guarantee that interference will not

occur in a particular installation. If this

equipment does cause harmful interference

to radio or television reception, which can

be determined by turning the equipment

o and on, the user is encouraged to try to

correct the interference by one or more of

the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the

equipment and receiver.

Connect the equipment into an outlet on

a circuit dierent from that to which the

receiver is connected.

Consult the dealer or an experienced radio/

TV technician for help.

IC COMPLIANCE STATEMENT

This hand-held device complies with

Canadian radio regulation.

Operation is subject to the following two

conditions: (1) This device may not cause

harmful interference, and (2) this device

must accept any interference received,

including interference that may cause

undesired operation.

Changes or modications not expressly

approved by the party responsible for

compliance could void the user’s authority

to operate the hand-held equipment.

To prevent radio interference to the licensed

service, this device is intended to be

operated indoors and away from windows

to provide maximum shielding. Equipment

that is used outdoors is subject to licensing.

RF EXPOSURE STATEMENT

This equipment complies with EU, FCC and

IC’s RF radiation exposure limits set forth

for an uncontrolled environment under the

following conditions:

1. This equipment should be installed and

operated such that a minimum separation

distance of 20cm is maintained between the

antenna and user’s/nearby person’s body at

all times.

2. This equipment must not be co-located

or operating in conjunction with any other

antenna or transmitter.

THE PICTURE SHOWS THE SAFE WAY

TO HANDLE THE DEVICE.

ETL LISTED

CONFORMS TO UL STD 60950-1

CERTIFIED TO CAN/CSA STD C22.2 NO.

60950-1

В PОССЙИ

ГОСТ Р

СЕРТИФИКАТ СООТВЕТСТВИЯ В

СИСТЕМЕ ГОСТ Р

Устройство обработки информации:

компьютер портативный Nordic ID Morphic

удостоверен сертификатом соответствия

ГОСТ Р № POCC FI.AГ23.B04078, срок

действия с 27.12.2011 до 26.12.2012,

выдан органом по сертификации

продукции «ТЕСТМАКС» (ООО «Бизнес

аспект»), РОСС RU.0001.11AГ23.

4004039

ETL LISTED

IMPORTANT – READ CAREFULLY

THIS END USER LICENSE

AGREEMENT (“Licence Terms”)

BEFORE INSTALLING OR USING

THE SOFTWARE.

By using the Device on which Software

is installed, You agree to be bound

by the terms of the Licence Terms,

including the warranty disclaimers and

limitations of liability provisions below.

If You do not agree to the Licence

Terms, You may not use the Device or

install the Software. Instead, promptly

contact the reseller You purchased the

Device from for instructions on return

of unused Device(s) for a refund. ANY

INSTALLATION OR USE OF THE

SOFTWARE OR THE DEVICE ON

WHICH SOFTWARE IS INSTALLED

INDICATES YOUR AGREEMENT TO

BE BOUND BY THE CONDICTIONS

OF THE LICENCE TERMS (OR

RATIFICATION OF ANY PREVIOUS

CONSENT).

DEFINITIONS

“Device” means the Nordic ID

equipment You acquired from Nordic

ID or one of its resellers and on which

the Software was pre-installed or onto

which it is to be installed.

“Software” means the computer

program(s) licensed and installed

on the Device and/or any Revisions

thereto. Software may include

computer programs made by Nordic

ID as well as operating systems and

application programs by third party

licensors or other software suppliers.

The Software includes any disks or

media on which it is recorded and any

Documentation.

“Documentation” means the materials

accompanying the Software which

describe its functions and how to install

and use the Software.

“Revision” means any correction,

modication, update, enhancement,

or new version of the Software or

Documentation whether printed or in

electronic format (including but not

limited to on-line documentation).

“You” or “Your” refers to the end user

licensed to use the Software under this

EULA.

“Nordic ID” means Nordic ID Oy, a

company incorporated in Salo, Finland

PROPRIETARY RIGHTS AND

LICENSE

You agree that the Software constitute

trade secrets and/or copyrighted

material of Nordic ID, its licensors, or

other software suppliers. All rights,

title and interest in and to the Software

(including, without limitation, any

images, photographs, animations,

video, audio, music, text, and applets

incorporated into the Software, the

accompanying media and printed

materials), and any copies of the

Software are owned by Nordic ID, its

licensors or other software suppliers.

You acknowledge and agree that

nothing in this EULA gives You any

right, title or interest in and to the

END USER LICENSE AGREEMENT

Software except the limited rights

expressly granted herein. You agree

to maintain and reproduce all copyright

and other proprietary notices of

Software.

Nordic ID hereby grants You a license

to use the Software subject to the

following terms and conditions:

Unless expressly provided in the

Documentation, You may use the

Software only as embedded in, for

execution on, or (where the applicable

Documentation permits installation

on non-Nordic ID equipment) for

communication with Device. You have

no right to use Revisions unless You,

at the time of acquiring such Revision

hold a valid license to the original

Software and have paid the applicable

license fees (if any)

The Software is licensed, not sold.

Nordic ID hereby grants You a non-

exclusive, terminable, limited license to

use the Software on the Device(s) for

Your own internal business purposes

subject to payment of applicable

license fees (if required). No other right

or license is granted or implied. You

agree not to modify copy, distribute

or otherwise disclose the Software

without the prior written consent of

Nordic ID. You further agree not to

reverse engineer, disassemble, or

de-compile the Software, except and

only to the extent that such activity is

expressly permitted by applicable law

notwithstanding this limitation. This

license shall terminate when You no

longer own or You cease to use the

Device(s) on which You are licensed

to use the Software. Your rights to the

Software do not include any license,

right, power or authority to subject the

Software in whole or in part to any of

the terms of an Excluded License.

“Excluded License” means any license

that requires as a condition of use,

modication and/or distribution of

Software subject to Excluded License,

that such Software of other software

combined or distributed with such

software be a) disclosed or distributed

in source code form; b) licensed for the

purpose of making derivative works; or

c) redistributable at no charge

You may not sell, lease, rent, assign,

sublicense or transfer the Software

except that You may transfer all of

Your rights under this EULA as part of

a sale or transfer of the Device(s). Such

a sale or transfer may only be made if

You retain no copies of the Software,

You transfer all of the Software

(including any media, archival copies,

Revisions and Documentation) and the

recipient agrees to abide by the terms

of this EULA. A Revision may not be

transferred unless You transfer all prior

versions of the Software. In the event

of any such transfer, You shall remain

liable and responsible to Nordic ID for

the performance of all of Your duties

and obligations under this EULA.

You agree to grant Nordic ID and its

independent accountants the right to

examine Your books, accounts and

records to verify compliance with this

EULA. In the event such an audit

reveals non-compliance, You shall

promptly sustain compliance and pay

Nordic ID the applicable license fees

(if any)

DISCLAIMER OF WARRANTY

AND LIMITATION OF LI-

ABILITY

The software is not fault tolerant and

is not designed, manufactured or

intended for any use requiring fail-safe

performance in which the failure of

Software could lead to death, serious

personal injury, severe physical or

environmental damage (“High Risk

Activities”). This includes the operation

of aircraft, aircraft navigation or

communication systems, direct life

support machines or weapons systems

or nuclear facilities. Use of Device in

High Risk Activities is not licensed.

The Software is not warranted to be

compatible with all applications or

environments. Contact the reseller You

purchased the Device for information

about hardware and/or software

compatibility.

NO WARRANTIES FOR THE

SOFTWARE. THE SOFTWARE IS

PROVIDED AS IS AND WITH ALL

FAULTS. NORDIC ID, ITS LICENSORS

AND OTHER SOFTWARE

SUPPLIERS DISCLAIM ANY AND ALL

PROMISES, REPRESENTATIONS,

AND WARRANTIES WITH RESPECT

TO THE SOFTWARE, INCLUDING

ITS CONDITION, ITS CONFORMITY

TO ANY REPRESENTATION OR

DESCRIPTION, THE EXISTENCE

OF ANY LATENT OR PATENT

DEFECTS, ANY NEGLIGENCE

AND ITS MERCHANTABILITY OR

FITNESS FOR A PARTICULAR USE

OR NON-INFRINGEMENT. THE

ENTIRE RISK WITH RESPECT TO

THE SOFTWARE IS WITH YOU.

IF YOU HAVE RECEIVED ANY

WARRANTIES REGARDING THE

SOFTWARE, THOSE WARRANTIES

DO NOT ORIGINATE FROM, AND

ARE NOT BINDING ON, NORDIC ID,

ITS LICENSORS OR ITS SOFTWARE

SUPPLIERS.

EXCEPT AS PROHIBITED BY LAW,

NEITHER NORDIC ID NOR ANY

OF ITS SOFTWARE SUPPLIERS

SHALL HAVE ANY LIABILITY FOR

ANY DIRECT, INDIRECT, SPECIAL

CONSEQUENTIAL OR INCIDENTAL

DAMAGES ARISING FROM OR

IN CONNECTION WITH THE USE

OR PERFORMANCE OF THE

SOFTWARE. THIS LIMITATION

SHALL APPLY EVEN IF ANY REMEDY

FAILS OF ITS ESSENTIAL PURPOSE.

IN NO EVENT SHALL NORDIC

ID OR NORDIC ID’S SOFTWARE

SUPPLIERS BE LIABLE FOR ANY

AMOUNT IN EXCESS OF THE INITIAL

LICENSE FEE NORDIC ID RECEIVED

FROM YOU FOR THE NORDIC ID

DEVICE IN THE CASE OF NORDIC ID

OR U.S. TWO HUNDRED AND FIFTY

DOLLARS (U.S. $250.00) IN THE

CASE OF NORDIC ID’S LICENSORS

OR SOFTWARE SUPPLIERS.

TERMINATION

Nordic ID, its licensors and its software

suppliers reserve the right to terminate

this EULA if You violate any term or

condition of this EULA. If You assert

any claims against Nordic ID, its

licensors or software suppliers over

patents that You think might apply to

Software (including a cross-claim or

counterclaim in a lawsuit) Your license

to the Software ends automatically.

In the event of termination, You must

stop using the Software and You shall

immediately return to Nordic ID, all

Software and any copies thereof and

Nordic ID 811-4A Wireless Data Collection Terminal User Manual

Nordic ID Oy Wireless Data Collection Terminal

Contents

User Manual

Navigation menu

Namespaces

Views

Navigation
