User Manual

2GIG-RPTR1-345

WIRELESS INDOOR REPEATER

INSTALLATION INSTRUCTIONS

The2GIGWirelessIndoorRepeater(2GIG‐RPTR1‐345)isaremotely

poweredwirelessindoorrepeater.Therepeaterisaperipheraldevice

thatcommunicateswiththe2GIGPanelusingaproprietary345MHz

transmissionprotocol.Therepeaterreceivesandrecognizesmessages

fromother345MHzdevicesthatareunabletodirectlycommunicate

withthesystem,and“repeats”thosemessagestoextendtherangeof

thesedevices.

Therepeaterwilltypicallybeinstalledatthemid‐pointbetweenthe

panelandthewirelessdevicesbeingrepeated.Whenatransmission

fromadeviceisrepeated,therepeateraddsabittothemessageto

indicatetothesystemthatthemessageisnotcomingdirectlyfrom

thedevice.Therepeaterwillnotrepeatalreadyrepeatedmessages.

TherepeaterispoweredbyanACadapterandisequippedwitha

rechargeablebatterywhichsupports24hoursofbatterybackup

underconditionsoflocalpowerfailure.Whenthepowersourcefor

therepeaterchangesfromACpowertobatterybackup,orfrom

batterybackuptoACpower,therepeaterwillautomaticallysenda

messagetothesystemwithintwo(2)minutes.Inaddition,

supervisorymessagesaresentapproximatelyevery70minutesthat

indicatetherepeaterstatus.

TherepeaterisequippedwithastatusindicatorLEDvisiblefromthe

frontoftheunit,andalearnbuttonislocatedonthesideoftheunit.

Figure 1 WirelessIndoorRepeaterPackageContents

Installing the Battery

Therechargeablebatterycanbeinstalledbyopeningtheenclosure

whilethepowerisdisconnected(seeFigure2).

WARNING: Polarityofthebatterymustbeobserved.Alignthe

batterytomatchthepolarityindicatorsonthecircuitboard.

Improperinstallationofthebatterymayresultinheat

generation,explosion,orfirewhichmayleadtopersonal

injury.

Installing the Repeater

Figure 2 Wireless Indoor Repeater Component and Feature Locations

Mounting Guidelines

Usetheseguidelineswheninstallingthewirelessindoorrepeater:

•MountRepeaterswithin100ft(30m)oftheControlPanel.

Althoughthetransmittermayhavearangeof350ft(106.7m)in

openair,therepeaterlocationcanhaveasignificanteffecton

range.Inopen/unobstructedsituations,thetransmitterrangemay

begreater.Inadversewirelessconditions,changingtherepeater

orientationmayleadtoimprovedrange.

•MountRepeatersashighaspossible.Mountingtherepeaterhigh

offthegroundhelpsreceiversensitivity.

•DoNotExposeRepeaterstoMoistureorExtremeTemperature.It

isbesttomountrepeatersinadrylocationwheretheoperating

temperaturedoesnotexceed32°to120°F(0°to49°C).

•KeepRepeatersAwayfromMetal/MetalicSurfaces.Tokeepthe

repeaterawayfrommetalormetallicsurfaces(forexample,foil

wallpaper),itisrecommendedthatyouusespacers(notincluded).

Youshouldalsoavoidmountingsensorsinareaswherethereisa

largequantityofmetalorelectricalwiring(forexample,neara

furnaceorinautilityroom).

Toinstallthewirelessrepeater:

1Opentherepeatercase.

2Attachthebasetothedesiredwalllocationwiththefour(4)

Phillipsheadscrewsandanchorssupplied(seeFigure2).

3Installthetamperscrew(seeFigure2).Withthetamperscrew

installed,removingthecasefromthewalltriggerstamper.

NOTE: Forthetampertoworkcorrectly,thetamperscrewmust

beinstalledintoawallstud.Donotuseawallanchor.

4Installthebattery.Observebatterypolarity.

5Connectthe2‐conductorwiretothepowersupplyandtothe

terminalconnectoronthecircuitboard.Makesurethewire

passesthroughthegrommetandholeontherepeaterbasebefore

connectingtotheterminal.

6Attachtherepeatercovertothebaseandsecuretheassembly

withthePhillipsheadcaselockingscrew.

ARechargeableLithium‐IonBattery

BACAdapter

CTamperScrew

DMountingScrewsandAnchors(4)

ELearnButton

FStatusIndicator

GPowerInput

HCaseLockingScrew

1RechargeableLithium‐IonBattery 6RepeaterBase

2TamperSwitch 7TamperScrew

3Repeater 8MountingScrews(4)

4PowerInputConnector 9MountingAnchors(4)

5LearnButton

OBSERVE

BATTERY

POLARITY 12

PRINTER’S INSTRUCTIONS

10012437A-2GIG-RPTR1-345-INSTALL-INSTR-en-PRT, 09/16/2016, BLACK, 20LB MEAD BOND, 8.5X11”, TOL. +/- 0.125, SCALE: 1:1, FRONT & BACK, FOLD TO FIT BOX

Wireless Indoor Repeater Installation Instructions

7PlugtheACadapterintoanACoutlet.Thestatusindicatorwill

emitasteadygreenlight.

NOTE: DonotconnecttheACadaptertoanACoutletthatis

controlledbyaswitch.

8Oncetherepeaterispoweredup,itbeginsrepeatingall

unrepeated345MHz2GIGtransmissions.

Status Indications

Thestatusindicatorshowstherepeaterstatusasfollows:

•SteadyGreen:TherepeaterisACpowered,andthebackup

batteryisgood.

•SolidRed:TamperorACpowerfailure.

•SlowFlashingRed:Lowbattery.

•FastFlashingRed:Jammed.

•Blinkoff:Transmissionreceived.

SPECIFICATIONS

OverallSize 102X76X46mm(4.0”X3.0”X1.8”)

Material High‐impactABSplastic

Color White

Weight(withoutbattery) 125g(4.4oz.)

InstallationType Wallmounted

OperatingFrequency 345MHz

OperatingTemperatureLimits ‐10°Cto55°C(14°Fto131°F)

RelativeHumidity 5to85%non‐condensing

PowerType RemotelypoweredbyACadapter,with

internalbatterybackup

ACAdapterNominalInputVoltage 100–240VAC50/60Hz

ACAdapterNominalOutputVoltage 14VDC

MaximumPowerConsumption 3W

IdleCurrent 40mA

OperatingCurrent(repeating) 75mA

StorageDeviceCapacity 800mAh(1)3.7V800mAh14500TypeLi‐

ionbattery(nottobereplaced)

REPEATER OPERATION

AND MESSAGE DESCRIPTIONS

SupervisoryMessage:

•Therepeatergeneratesasupervisorymessageevery70min

±10min.Themessagecontainsthecurrentbatterystatusand

tamperstate.

PowerUp:

•Whentherepeaterisfirstpoweredup,amessageisgenerated

containingthecurrentbatterylevelandtamperstate.

TamperMessage:

•Whentherepeaterdetectstamper,amessageissentcontaining

therepeaterstate,tamperstate,andbatterylevel.

EventMessage:

•Whentherepeaterreceivesamessage,themessageis

regeneratedwithanindicationthemessagehasbeenrepeated.

REGULATORY INFORMATION

2GIG

1950CaminoVidaRoble,Suite150

Carlsbad,CA92008USA

FortechnicalsupportintheUSAandCanada:

855‐2GIG‐TECH(855‐244‐4832)

Email:2gigtechsupport@linearcorp.com

Visitwebsitefortechnicalsupporthoursofoperation

FortechnicalsupportoutsideoftheUSAandCanada:

Contactyourregionaldistributor

Visit2gig.com/dealers/foralistofdistributorsinyourregion

ANortekCompany

10012437A

WARNING: Thisdeviceisnotdesignedtorepeatsignals

fromlifesafetydevicessuchasSmokeorCOdetectors.

This equipment has been tested and found to comply with the limits for Class B Digital

Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protec on against harmful interference in a residen al installa on. This equipment generates

and can radiate radio frequency energy and, if not installed and used in accordance with the

instruc ons, may cause harmful interference to radio communica ons. However, there is

no guarantee that interference will not occur in a par cular installa on. If this equipment

does cause harmful interference to radio or television recep on, which can be determined by

turning the equipment oﬀ and on, the user is encouraged to try to correct the interference by

one or more of the following measures.

Reorient or relocate the receiving antenna

Increase the separa on between the equipment and receiver

Connect the equipment into an outlet on a circuit diﬀ erent from that to which the receiver

is connected

Consult the dealer or an experienced radio/TV technician for help.

Any changes or modiﬁ ca ons not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils

radio exempts de licence. Ľexploita on est autorisée aux deux condi ons suivantes: (1)

ľappareil ne doit pas produire de brouillage, et (2) ľu lisateur de ľappareil doit accepter tout

brouillage radioélectrique subi, même si le brouillage est suscep ble ďen comprome re le

fonc onnement.

FCC COMPLIANCE STATEMENT

This device complies with FCC Rules and Regula ons as Part 15 devices as well as Industry

Canada license exempt RSS Rules and Regula ons. Opera on is subject to the following two

(2) condi ons: This device may not cause harmful interference. This device must accept any

interference received, including interference that may cause undesired opera on.

LIMITED WARRANTY

This Nortek Security & Control LLC product is warranted against defects in material and

workmanship for two (2) years. This warranty extends only to wholesale customers who

buy direct from Nortek Security & Control LLC or through Nortek Security & Control normal

distribu on channels. Nortek Security & Control does not warrant this product to consumers.

Consumers should inquire from their selling dealer as to the nature of the dealer’s warranty,

if any.

There are no obliga ons or liabili es on the part of Nortek Security & Control for consequen al

damages arising out of or in connec on with use or performance of this product or other

indirect damages with respect to loss of property, revenue, or proﬁ t, or cost of removal,

installa on, or reinstalla on. All implied warran es for func onality, are valid only un l the

warranty expires. This Nortek Security &Control Warranty is in lieu of all other warran es

expressed or implied.
