Nortek Security and Control GTO Access 318MK DIGITAL KEYPAD TRANSMITTER User Manual
GTO Access Systems, LLC DIGITAL KEYPAD TRANSMITTER
User Manual
PRINTER’S INSTRUCTIONS:
INSTR,INSTL,WLKP - GTO P/N: 10014459 - INK: BLACK - MATERIAL: 20 LB. MEAD BOND - SIZE: 11.000” X 8.500” - SCALE: 1-1 - SIDE 1 OF 2
SCREW ANCHORS MOUNTING SCREWS
KEYPAD
This digital keypad is a MegaCode series of wireless radio controls designed for use with automatic garage
door and gate operators. The MegaCode radio format provides unparalleled security with more than a million
different codes.
In operation, the user enters their unique code on the unit’s keypad (1 to 6 digits long) and presses
the button to activate the door operator. For up to 30 seconds after the last activation, the keypad can
be re-triggered by simply pressing the button again. This allows the user to stop or reverse the opener
quickly, without having to re-enter their code.
The keypad has built-in keypad lighting for use at night or in dark areas. The clear silicone keys are backlit
with a pleasing blue glow. By pressing the button rst, before entering their code, the user can light up the
keypad. Pressing the button twice at any time will light up the keypad.
The keypad lockout timer will disable the keypad after 10 activations. The keypad must remain idle for 30
seconds before new attempts.
MegaCode receivers are programmed by sending a signal from the user’s transmitters. This stores the
transmitter’s code into the receiver’s memory. The receiver will retain its memory even without power and
will only activate from these “memorized” transmitters. Each keypad code can be considered a different
transmitter. Each MegaCode receiver can remember a maximum of 10 transmitter codes. Any combination of
portable transmitters and keypad codes up to the maximum number can be entered.
COMPONENTS
KEYPAD FEATURES PROGRAMMING OPERATORS WALL MOUNTING
KEYPAD OPERATION CHANGING BATTERIES LIMITED WARRANTY
This product is warranted to the consumer against defects in material and workmanship for
one year from the date of purchase. This warranty applies to rst retail buyers of new devices.
Warrantor will repair, or at its option, replace, any device it nds that requires service under this
warranty, and will return the repaired or replaced device to the consumer at the warrantor’s cost.
For warranty service and shipping instructions contact warrantor at the address shown below.
Devices must be sent to warrantor for service at owner’s expense. The remedies provided by
this warranty are exclusive. Implied warranties under state law are to the one year period of this
written warranty. Some states do not allow limitations on how long an implied warranty lasts, so
the above limitation may not apply to you. In order to be protected by this warranty, save your
proof of purchase and send copy with equipment should repair be required. This warranty gives
you specic legal rights, and you may also have other rights which vary from state to state.
All products returned for warranty service require a Return Product Authorization Number (RPA#).
Contact Linear Technical Service at 1-800-543-1236 for an RPA# and other important details.
WARNING: Changes, modications or adjustments not expressly approved by GTO Access
Systems, LLC could void the user’s authority to operate this equipment. There Are No User
Serviceable Parts.
NOTICE: This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to
the following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouil-
lage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
DESCRIPTION
Digital Keypad
Operation Instructions
WLKP
MOUNT THE KEYPAD IN CLEAR VIEW OF THE
DOOR WITH THE TWO SCREWS SUPPLIED
Use screw
anchors if
required.
Slide battery cover open and remove batteries to
access mounting hole. Replace batteries and slide
battery cover closed after mounting.
DAYTIME OPERATION
1
2
PRESS (LIGHTS KEYPAD)
1
2
3
NIGHTTIME OPERATION
LIGHT OPERATION
1-6 DIGIT KEYPAD CODE THAT
WAS ENTERED INTO OPENER
ENTER THE KEYPAD CODE
PRESS
ENTER THE KEYPAD CODE
PRESS
1-6 DIGIT KEYPAD CODE THAT
WAS ENTERED INTO OPENER
Press the LIGHT ( )
button to turn backlight
on and off.
NOTE:
TO STOP OR REVERSE THE OPENER, THE BUTTON CAN BE PRESSED AGAIN FOR UP TO 30 SECONDS WITHOUT
RE-ENTERING THE CODE.
Refer to the instructions provided with the garage door opener
to set it into “learn” mode.
Press the opener’s LEARN BUTTON for 1 second and release.
The opener should BEEP and the LIGHT should BLINK once.
The RED LED will remain lit in Learn Mode for 15 seconds.
While the RED LED is lit, enter a 1-6 digit code into the
keypad. Then PRESS and HOLD the keypad’s key until
the opener BEEPS and the light BLINKS once.
1
2
Repeat Steps 1 & 2 for any additional keypad codes.
Printed in China for GTO Access Systems, LLC. Copyright© 2016 GTO Access Systems, LLC
Document Number: 10014459 REV A (12-02-16)
To delete a keypad code that you no longer want follow the
same steps above. The opener will recognize the code and
delete it from memory. The RED LED and LIGHT will blink 4
times to show the code was successfully deleted.
DELETING A KEYPAD CODE
HINGED COVER
PROTECTS THE KEYPAD
SOFT BLUE LIGHTS ILLUMINATE
THE KEYS FOR NIGHTTIME USE
LIGHT BUTTON TURNS THE
BACKLIGHT ON AND OFF
BUTTON STAYS ACTIVE FOR 30
SECONDS AFTER A CODE IS USED SO THE
OPENER CAN BE STOPPED OR REVERSED
TEN KEYS ENTERING 1-6 KEYPAD CODES
USING NUMBERS OR LETTERS
PRESS THE
LEARN BUTTON
THE RED LED WILL
GLOW FOR 15 SECONDS
1
ENTER A 1-6 DIGIT CODE
WHILE RED LED IS ON
2
1 2
3
SLIDE BATTERY
COVER OPEN
REMOVE THE OLD
BATTERIES AND
DISPOSE OF THEM
PROPERLY
INSTALL 3 FRESH
AAA BATERIES
4
SLIDE BATTERY
COVER CLOSED
GTO Access Systems, LLC
(850) 575-0176
USA & Canada (800) 543-4283
www.gtoaccess.com
Follow the steps in the diagram and use caution to keep batteries away from
children.
Replace old batteries with fresh AAA Alkaline batteries.
Properly dispose of old batteries.
Many electronic stores and supermarkets have battery recycling bins.
Alkaline batteries can be safely disposed of with normal household waste.
Never dispose of batteries in re because they could explode.
