DESCRIPTION
This Digital Keypad is designed for use with automatic garage door
operators. The radio format provides unparalleled security with more than
a million different codes.
To activate the door operator, the user enters their unique 1 to 6 digit long
code on the unit’s keypad and presses the START/STOP button. For up to 30
seconds after the last activation, the keypad can be re-triggered by simply
pressing the START/STOP button again. This allows the user to stop or
reverse the opener quickly, without having to re-enter their code.
The keypad has built-in lighting for use at night or in dark areas. The clear
silicone keys are backlit with a pleasing blue glow. By pressing the START/
STOP button rst, before entering their code, the user can light up the
keypad. Pressing the START/STOP button twice at any time will light up
the keypad.
The keypad lockout timer will disable the keypad after 10 activations. The
keypad must remain idle for 30 seconds before new attempts.
The garage door operator contains a built-in receiver that is programmed by
sending a signal from the user’s transmitters. This stores the transmitter’s
code into the receiver’s memory. The receiver will retain its memory even
without power and will only activate from these “memorized” transmitters.
Each keypad code can be considered a different transmitter.
KEYPAD COMPONENTS KEYPAD FEATURES
KEYPAD OPERATION CHANGING BATTERIES LIMITED WARRANTY FCC STATEMENT
PROGRAMMING OPERATOR WALL MOUNTING
PRINTER’S INSTRUCTIONS:
INSTR,INSTL,MDTK,PVT LBL - GTO P/N: 10007727 - INK: BLACK - MATERIAL: 20 LB. MEAD BOND - SIZE: 11.000” X 8.500” - SCALE: 1-1
www.mightymule.com
ADDING A KEYPAD CODE
1PRESS THE OPERATOR'S LEARN
BUTTON FOR 1 SECOND AND RELEASE.
THE OPERATOR SHOULD BEEP AND THE
LIGHT SHOULD BLINK ONCE.
THE RED LED WILL REMAIN LIT (LEARN
REMOTE MODE).
2WHILE THE RED LED IS ON,
ENTER A 1-6 DIGIT KEYPAD CODE
THEN PRESS AND HOLD THE KEYPAD'S
START/STOP KEY UNTIL THE OPERATOR
BEEPS AND THE LIGHT BLINKS ONCE.
3REPEAT STEPS 1 & 2 FOR ANY
ADDITIONAL KEYPAD CODES
WXY
GH
I
D
E
F
ABC
JK
L
M
NO
PRS
T
U
V
SCREW
PLUGS
SCREW
ANCHORS MOUNTING
SCREWS
KEYPAD
HINGED COVER
PROTECTS THE
KEYPAD
SOFT BLUE LIGHTS
ILLUMINATE THE KEYS
FOR NIGHTTIME USE
START/STOP BUTTON STAYS ACTIVE FOR
30 SECONDS AFTER A CODE IS USED SO THE
OPENER CAN BE STOPPED OR REVERSED
NOTE: FOR SECURITY, THE KEYPAD WILL SHUTDOWN
AFTER 10 CODE ENTRIES UNTIL IT IS IDLE FOR 30 SECONDS
TEN KEYS ENTERING
1-6 KEYPAD CODES
USING NUMBERS OR LETTERS
MOUNT THE KEYPAD IN
CLEAR VIEW OF THE DOOR
WITH THE TWO SCREWS SUPPLIED USE THE SCREWS
ANCHORS SUPPLIED
IF REQUIRED
SCREWS
ANCHORS
PUSH IN THE
TWO SCREW
COVER TO HIDE
THE SCREWS
DAYTIME OPERATION
START
STOP
START
STOP
START
STOP
1
2
PRESS START/STOP (LIGHTS KEYPAD)
1
2
3
NIGHTTIME OPERATION
PRESS THE LIGHT ( ) BUTTON TO TURN THE OPERATOR’S LIGHT ON/OFF
(KEYPAD MUST HAVE AT LEAST ONE CODE PROGRAMMED INTO THE OPERATOR)
1
LIGHT OPERATION
1-6 DIGIT KEYPAD CODE THAT
WAS ENTERED INTO OPENER
ENTER THE KEYPAD CODE
PRESS START/STOP
ENTER THE KEYPAD CODE
PRESS START/STOP
1-6 DIGIT KEYPAD CODE THAT
WAS ENTERED INTO OPENER
NOTE: TO STOP OR REVERSE THE OPERATOR, THE START/STOP BUTTON CAN BE
PRESSED AGAIN FOR UP TO 30 SECONDS WITHOUT RE-ENTERING THE CODE.
1
34
2
REMOVE THE TWO
SCREWS AND SLIDE
THE BATTERY COVER OFF
REMOVE THE
LOW VOLTAGE
BATTERIES AND
DISPOSE OF THEM
PROPERLY
INSTALL 3 FRESH
AAA BATERIES
BE SURE THE
SILICONE GASKET
IS IN PLACE
REPLACE THE
BATTERY COVER
AND RE-INSTALL
THE TWO SCREWS
