PS15EMZ5-1 PLUG-IN MODULE
The GoControl™ family of Z-Wave® certifi ed wireless lighting products (smart
LED fi xtures, bulbs, switches, dimmers, outlets, plug-in modules) Control Products
(thermostats, irrigation controller and garage door controller)and Sensors (fl ood, leak,
alert sounder, motion sensor and door/window sensor) bring a new level of intelligent
wireless Home Automation capability to commercial and residential environments.
The Z-Wave wireless protocol is an international wireless standard for remote home
automation, security and other applications. This product can be included and operated
in any Z-Wave network with other Z-Wave certifi ed devices from other manufacturers
and/or other applications. All non-battery operated nodes within the network will act as
repeaters regardless of vendor to increase reliability of the network.
GoControl Z-Wave products are easy to install, are Z-Wave certifi ed, and allow
dealers to create an integrated wireless network with nearly limitless expansion and
interoperability with security, energy management, home entertainment, appliances,
and more.
The PS15EMZ5-1 is a simple Plug & Play Home Automation device that lets you
control any lighting or small appliance while monitoring the amount of energy being
used. Bright multi-colored LEDs provide an instant indicatioon of the energy being used
while simultaneously reporting this information to your Z-Wave hub that may be used for
energy monitoring and analysis.
Z-WAVE PLUS FEATURES
The PS15EMZ5-1 contains a Z-Wave 500 Series Module that supports Z-Wave Plus®
features. A Z-Wave certifi ed portable or stationary Controller can communicate with the
Z-Wave 500 Series Module.
Depending on the capability of the Controller or gateway software, the following
operations can be performed with the PS15EMZ5-1. Refer to the Controller or gateway
manual for details.
• Turn the load ON and OFF.
• Add or Remove the PS15EMZ5-1.
• Assign the PS15EMZ5-1 to a specific Group/Scene and/or to include the load as part
of ALL ON or ALL OFF system commands.
• Over-the-air firmware update by the gateway or static Controller.
• Lifeline function which automatically notifies the associated modules and the network
that a manually reset device is no longer in the network, thus, the corresponding
association becomes invalid.
• Monitors the amount of energy being used and reports the current usage to the
Z-Wave controller
INSTALLATION
Adding to a network:
Refer to your Controller operating instructions to add this switch under the command of
the Wireless Controller.
1. With your Controller in Discovery or Add Mode, tap the button on the face of the
outlet. The LED will blink slowly when in ADD Mode.
2. You should see an indication on your Controller that the “device was added” to the
network and the LED will stop blinking.
3. The device will appear in the list of Switches. It should display as a switch.
If the Controller/Gateway shows the addition failed, repeat Steps 1-3.
✓NOTE: If you have trouble adding the PS15EMZ5-1 to a group it may be that the
Home ID and Node ID were not cleared from it after testing. You must fi rst “RESET
UNIT” to remove it from the network. Although adding it to a group includes it in the
network, removing it from a group does not remove it from the network. If removed
from a group, it functions as a repeater (only). “RESET UNIT” removes it completely
from the network.
To Reset Unit (If Required):
In the event that your primary Controller is lost or otherwise inoperable, to reset the
PS15EMZ5-1 and clear all network information, follow these steps:
1. Tap the button on the face of the outlet fi ve (5) times.
2. Press and hold the button for 15 seconds. The LED will increasingly blink faster to
indicate that a Reset is taking place.
3. LED will turn off when reset is complete.
Removing from a network:
The PS15EMZ5-1 can be removed from the network by the Controller/Gateway. Refer to
the Controller operating instructions for details.
1. Set the Controller into Removal Mode and follow its instruction to delete the
PS15EMZ5-1 from the Controller.
2. Remove the switch by tapping the button on the face of the outlet 2 times. The LED
will begin blinking slowly for 10 seconds indicating that it has been removed.
3. You should see an indication on your Controller that the “device was removed” from
the network.
BASIC OPERATION
Local Control
The button on the PS15EMZ5-1 allows the user to:
• Turn the attached load on or off.
• Tapping the button on the face of the outlet turns the load attached ON or OFF.
Night Light
To act as a night light, the LED on the PS15EMZ5-1 will turn ON when the load attached
is OFF. However, the LED can be user confi gured to turn ON, when the load attached is
ON, if so desired. See “CONFIGURATION” section.
Energy Monitoring
PS15EMZ5-1 reports the total accumulated Kilowatt Hours (kWh) and the instantaneous Watts
being consumed by the load.
Parameter Length Valid Values Confi guration Option
13 1 Byte
0Automatic reporting OFF
1-255 Number of minutes between automatic reporting
(Default = 6)
Confi guration Parameter 13 confi gures the rate at which the energy readings are reported. If
the maximum kWh value that can be reported is reached (21,474 kWh), then it will remain at the
maximum level until reset to 0 using the Controller software.
To reset, the total accumulated kWh used by the PS15EMZ5-1 the Z-Wave controller needs
to send a reset command at the request of the user. It will also be reset if the PS15EMZ5-1 is
excluded from the Z-Wave network.
The Watts reading provides the immediate reading of the power being consumed by the load.
The Watts reading takes several seconds to settle so wait a few seconds before reading the
energy value when the state of the switch (on / off) has changed.
✓NOTE: If Power Monitoring, see Confi guration Section below, is turned OFF the PS15EMZ5-1
will not report any energy use.
Remote Control
The PS15EMZ5-1 will respond to BASIC and BINARY commands that are part of the
Z-Wave system. Refer to your Controller’s instructions as to whether your Controller can
transmit those commands.
Protection Mode
The PS15EMZ5-1 supports Protection Mode that is used to disable the button on
the front of the device. This eliminates inadvertent activation of the switch. To enable
Protection Mode, press the button on the PS15EMZ-1 three times quickly. The LED
will blink Purple twice showing that Protection Mode has been enabled. When Enabled
the only way to turn ON or OFF the PS15EMZ5-1 is through the Z-Wave controller or
Mobile app. If the button on the PS15EMZ5-1 is pressed, the LED will blink Purple twice
and have no impact on the attached device. To exit Protection Mode, press the button
three times.
Associations
The PS15EMZ5-1 supports one Group with fi ve Nodes for lifeline communication. Group
1 must be assigned the Node ID of the Controller to which unsolicited notifi cations from
the PS15EMZ5-1 will be sent. The Z-Wave Controller should set this Association
automatically after inclusion. You can associate up to fi ve Z-Wave devices to Group 1.
For instructions on how to “set Lifeline Association” please refer to your Controller
instructions.
PRINTER’S INSTRUCTIONS:
INSTR,INSTL,PS15EMZ5-1 P/N 10008371 X9,GO CONTROL ; INK: BLACK; MATERIAL: 20# MEAD BOND; SIZE: 8.500” x 11.000”; TOLERANCE ± .125”; SCALE: 1-1; PAGE 1 OF 2
PS15EMZ5-1
Z-Wave Radio Frequency (RF) Controlled, 120 VAC
15 Amp, Plug-In Switch Series 500
NOTE: This unit must be added to the Network only where it will be permanently installed. The proper operation of this node in the mesh
network is dependent on it knowing its location with respect to other nodes. You cannot “test bench” confi gure this unit, then install.
Bottom of Appliance Module
showing 3 prong plug-in
Copyright © 2016 Nortek Security & Control LLC
2
Removing Associations
To remove the Associations, if the Controller has recognized the Associations, refer to the
Z-Wave Controller’s instructions on how to remove Associations. If the Controller has not
recognized the Associations, removing the PS15EMZ5-1 from the Z-Wave network will
eliminate the Associations.
ADVANCED OPERATION
All On/All Off
The PS15EMZ5-1 supports the ALL ON / ALL OFF commands. The PS15EMZ5-1 can be set
to respond to ALL ON and ALL OFF commands four different ways.
Refer to your Controller for information on how to set the PS15EMZ5-1 to operate in the manner
you desire. Some Controllers may be only able to set certain settings of ALL ON/ALL OFF
response.
The four different ways the PS15EMZ5-1 can be setup to respond to ALL ON and ALL OFF
commands are:
1. Responds to ALL ON or the ALL OFF command.
2. Responds to ALL OFF command but will not respond to ALL ON command.
3. Responds to ALL ON command but will not respond to ALL OFF command.
4. Responds to ALL ON and the ALL OFF command.
CONFIGURATION
The PS15EMZ5-1 supports the Confi guration command. Each unit can be confi gured to
operate slightly differently than how it works when you fi rst install it.
Using the Confi guration command you can confi gure the following:
LED Intensity
You can set the intensity of the LED to fi t the environment the PS15EMZ5-1 is being
used in from off to full brightness. This is done by changing Parameter 2
Parameter Length Valid Values Confi guration Option
21 Byte 0 - 99
0 = OFF
1 = Very dim
99 = Full Brightness (default)
Power Monitoring
The PS15EMZ5-1 provides a visual display of the amount of energy being consumed
when the switch is turned on by illuminating the LEDs in one of 5 different colors.
Energy Use LED Color
0 to 0.02 Amps White
0.02 to 2 Amps Green
2 to 5 Amps Blue
5 to 10 Amps Yellow
Over 10 Amps Red
The Power monitoring can be turned off utilizing Parameter 11. When turned off, the
PS15EMZ5-1 will no longer illuminate the LED to indicate any energy use and periodic
reports to the hub on energy use will also be turned off.
Parameter Length Valid Values Confi guration Option
11 1 Byte 0 Power monitoring OFF
1 Power monitoring ON (Default)
The duration the LED will change color to indicate the amount of energy being used can be set
using Parameter 12. After displaying the “energy used” color, the LED will revert to OFF or ON
(white) as determinded by confi guration parameter #3
Parameter Length Valid Values Confi guration Option
12 1 Byte 1 - 254 Number of seconds LED displays
power level usage. Default = 30
255 Power level usage continuous ON
Night Light
By default, the LED on the PS15EMZ5-1 will turn OFF when the load attached is turned ON. To
make the LED turn ON when the load attached is turned ON, set Parameter 3 to a value of 1.
Parameter Length Valid Values Confi guration Option
31 Byte
0LED OFF when the load is on, and ON when the load
is off (default mode)
1LED ON when the load is on, and OFF when the
load is off
2 LED is always on
3 LED is always off
4LED blinks during RF transmissions from or to the
device
Over-The-Air (OTA) Update
A Quadruple tap of the switch enables the fi rmware update mode. Firmware update mode
must be entered before the system Controller sends the fi rmware update command to begin
downloading new fi rmware. Firmware update mode is enabled for 60 seconds after the
quadruple tap. If the Firmware update does not begin before the end of the 60 seconds then
fi rmware update mode is exited returns to normal operation. The LED “winks” twice per second
indicating it is in fi rmware update mode.
Resetting to Defaults
Each confi guration Parameter can be set back to its default setting by setting the default bit
in the Confi guration Set command. See your Controller’s instructions on how to do this
(and if it supports it). All confi guration commands will be reset to their default state when the
PS15EMZ5-1 is excluded from the Z-Wave network by using the Controller to reset the node.
SPECIFICATIONS
Power: 120 VAC, 60 Hz
Signal (Frequency): 908.42 MHz / 916 MHz
Maximum Load: Resistive: 15 amps (1800 watts) maximum, 120 VAC
Range: Up to 130 feet (line of sight)
NOTICES
Z-Wave® and Z-Wave Plus® are registered trademarks of Sigma Designs and its subsidiaries in the United States
and other countries.
Terms and Conditions pertaining to the sale of this Nortek Security & Control wireless mesh network product are
available at http://nortekcontrol.com/terms_conditions.php
REGULATORY INFORMATION
We, Nortek Security & Control, LLC of 1950 Camino Vida Roble STE 150, Carlsbad, CA
92008,declare under our sole responsibility that the device, PS15EMZ5-1 complies with Part
15 of FCC rules.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must accept
any interference received, including interference that may cause undesired operation.
FCC Notice
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected
• Consult the dealer or an experienced radio/TV technician to help.
Changes or modifi cations not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment
IC Notice
This Class B digital apparatus complies with Canadian ICES-003
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Le présent
appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts
de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas
produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
This device complies with the Industry Canada license exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation
of the device.
WARRANTY
What is Covered?
Nortek Security & Control (“NS&C”) warrants to consumers who purchase this product for
personal, family or household purposes new from NS&C directly or from an authorized NS&C
dealer, that the product will be free from defects in materials and workmanship for a period of (1)
year from the date of purchase. This warranty only applies if the product is installed at a residence
in the 50 United States or District of Columbia, and only at the site of the original installation. It is
not transferable. This warranty is not extended to resellers.
If a defect exists, NS&C will have you ship the defective part or product to us and we will, at our
option, either repair or replace it. This warranty does not cover the cost of labor to remove a
defective part or product or to reinstall any repaired or replacement part or product
This warranty does not cover defects or damages caused by improper handling, maintenance,
storage, installation, removal or re-installation, misuse, non-factory authorized modifi cation or
alteration, use of incompatible accessories, electrical power problems or surges, impact by
foreign objects, accident, fi re, acts of God, normal wear and tear or shipping damage other than
a shipment from NS&C. Note that all NS&C products are designed to be installed, removed and
serviced by trained individuals or professionals.
Keep your original sales receipt as it will be required to obtain warranty service.
This warranty shall not be extended or restarted upon receipt of any repaired or replacement
part or product under this warranty. No person is authorized to extend or otherwise modify this
warranty.
How do I Obtain Warranty Service?
To obtain warranty service, email our Returns Department at returns@nortek.com. Include your
name, address, telephone number, the model number of your product, a copy of your original
sales receipt, and a description of the problem. Unless we need to discuss the situation further
with you, you will be emailed a Return Authorization Number and shipping instructions. If we
need to discuss the situation further with you, we will call or email you. NS&C may require
troubleshooting on installed product before a Return Authorization Number is issued. Anything
shipped to us without a Return Authorization Number will be automatically returned unopened.
You are responsible for the charges for shipment to us, unless you are a California resident.
Limitations
THE DURATION OF ANY IMPLIED WARRANTY, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL NOT EXCEED THE
WARRANTY PERIOD PROVIDED HEREIN.
Some states do not allow limitations on how long an implied warranty lasts, so the above
limitation may not apply to you.
NS&C SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE BREACH OF ANY WRITTEN OR IMPLIED WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
This warranty gives you specifi c legal rights, and you may also have other legal rights which vary from State to State.
PRINTER’S INSTRUCTIONS:
INSTR,INSTL,PS15EMZ5-1 P/N 10008371 X8,GO CONTROL ; INK: BLACK; MATERIAL: 20# MEAD BOND; SIZE: 8.500” x 11.000”; TOLERANCE ± .125”; SCALE: 1-1; PAGE 2 OF 2
Copyright © 2016 Nortek Security & Control LLC 10008371 X9
