Nortek Security and Control 00155 Keychain Remote User Manual
Nortek Security & Control LLC Keychain Remote Users Manual
Users Manual
Welcome to your
ADT Keychain Remote
Make sure the ADT Keychain Remote is within 15 feet
of your SmartThings ADT Security Hub during setup.
1.
• Once you've set up your remote, you'll be able
to use it anywhere within 350 feet from the
ADT Security Hub. (Exact range depends on your
home’s construction, environment, position of the
ADT Security Hub, and the position and number
of other connected devices.)
2.
3. Press and hold the "Disarm" and "Away" buttons on
the remote for 5 seconds, and then release.
Use the SmartThings app on your smartphone
to select the “My Home” tab. Select "Things", and
then “Add a Thing".
Setup
1
LED Light Ring
Setup
• Make sure that your ADT Security Hub is disarmed
before connecting a new device.
Testing
2
If you have an ADT professional monitoring service
activated, make sure that your ADT Security Hub is in
Test Mode to avoid triggering a false alarm. See the
ADT Security Hub User Guide for more details.
Press the Disarm button on your remote for
2 seconds to disarm the ADT Security Hub. Door,
window, and motion detectors will be disarmed.
Press the Away button on your remote for 2 seconds
to arm the ADT Security Hub. Door, window, and
motion detectors will be armed.
Press the Stay button on your remote for 2 seconds
to arm the ADT Security Hub in Stay Mode. Door and
window detectors will be armed.
Press the * and Stay buttons on your remote for
3 seconds to send a panic alert (requires optional
ADT professional monitoring service).
1.
2.
3.
4.
Keychain Remote (Back)
Setup
Use the SmartThings app to scan the QR code on the
back of the remote and then follow the on-screen
instructions to complete setup.
4.
5.
QR Code
Remove the QR code from the back of the remote
and attach it to this guide for future reference.
Troubleshooting
3
To reset the ADT Keychain Remote to factory settings:
Press and hold all four buttons for 5 seconds. The
red LED will blink fast.
Once the reset is complete, the green LED will turn
on for 5 seconds.
Release the button. If the button is released before
the reset is complete, the reset will not be successful.
Follow the Setup instructions above to setup your ADT
Keychain Remote.
If you’re still having trouble connecting the ADT Keychain
Remote please visit SmartThings.com/Support-ADT for
assistance.
1.
2.
3.
4.
4Replacing Batteries
Coin
Keychain Remote
Remove the cover by by inserting a coin into the end
of the remote and twisting.
1.
Remove the old battery and insert a new CR2450
battery. Be sure to install the battery correctly.
Replace the cover.
2.
3.
Using your
ADT Keychain Remote
There are many ways you can use an ADT Keychain
Remote:
The ADT Keychain Remote allows you to arm or disarm
your SmartThings ADT home security system at the press
of a button, or to send a panic alert to ADT professional
monitoring services (additional fees apply).
7Suggestions
• Use one to arm your system and set it to initiate
optional ADT professional monitoring services if
an intrusion is detected in your home (additional
fees apply).
• Use one to disarm your system and set it to turn
on connected lights when you arrive home in the
evening.
Look for the Works with SmartThings label next time
you’re buying a connected device for your home, or visit
SmartThings.com to see the full list of compatible
devices.
Works With SmartThings
8
Visit SmartThings.com/Welcome for more ideas, tips,
and special offers.
• Use one to disarm your system and set it to turn on
connected speakers when you come home.
Suggestions
• Use one to arm your system and set it to turn down a
connected thermostat when you leave.
SmartThings works with a wide range of connected
devices, including lights, cameras, locks, thermostats,
and sensors. It also works with the Google Assistant
and Amazon Alexa so you can control your smart home
with voice commands.
SmartThings, Inc., 665 Clyde Ave, Mountain View, CA 94043, USA. Information in this document
is subject to change without notice. Revised 05/17. Copyright 2017 SmartThings, Inc. All rights
reserved. ADT and the ADT logo are marks and/or registered marks of ADT. Unauthorized use
is strictly prohibited. CA ACO7155, 974443, PPO17232; FL EF0001121; LA F1639, F1640, F1643,
F1654; MA 172C; NC Licensed by the Alarm Systems Licensing Board of the State of North
Carolina, 7535P2, 7561P2, 7562P10, 7563P7, 7565P1, 7566P9, 7564P4; NY 12000305615; PA
090797; MS 15019511. P/N 10015710.
Health, Safety and Regulatory Guide
Safety Instructions
• Read, keep, and follow these instructions. Heed all warnings.
• Clean only with a dry cloth.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including ampliers) that produce heat.
•Only use attachments and accessories specied by the Manufacturer.
• Read our Product Usage Guidelines at: www.SmartThings.com/Guidelines.
Safety Instructions: ADT Security Hub
Limitations of Alarm Products: This product should be tested periodically to make sure it is working
properly. The product, if used properly, may reduce the risk of burglary, robbery, and other adverse
events that have the potential to result in injury or loss of life; however, the manufacturer is not an
insurer. This product is neither insurance nor a guarantee that such an event will be prevented, and
users should protect themselves with proper insurance. The manufacturer makes no representation
that this product cannot be compromised or circumvented, that it will provide an adequate warning,
or that it will prevent any personal injuries, property damage, or other losses. Like any alarm
product, it may be bypassed, it is subject to compromise, and it may fail to warn for a variety
of reasons, including, but not limited to:
• improper installation or positioning; improper maintenance; tampering; dead or improperly
installed batteries; sensing limitations; component failures; receivers;
•intrusions may be outside of a product’s designated range and certain environmental
conditions may impact performance, and audible alarm signals may be outside of hearing
range, muted by doors, walls, and oors, unheard by deep sleepers or the hearing-impaired,
or overwhelmed by other sounds.
Risk of Noise Induced Hearing Loss: The ADT Security Hub is equipped with a warning siren.
Exposure to high sound levels or prolonged exposure to the warning siren can result in Noise
Induced Hearing Loss (NIHL).
Disclaimer
Some content and services accessible through this device belong to third parties and are protected
by copyright, patent, trademark and/or other intellectual property laws. Such content and services
are provided solely for your personal non-commercial use.
You may not use any content or services in a manner that has not been authorised by the content
owner or service provider. Without limiting the foregoing, unless expressly authorised by the
applicable content owner or service provider, you may not modify, copy, republish, upload, post,
transmit, translate, sell, create derivative works, exploit, or distribute in any manner or medium any
content or services displayed through this device.
US Certications
Certied under FCC Part 15.
ADT Security Hub
Manufacturer Model : F-ADT-HUB-1
FCC ID : EF400150
Battery Type: Shenzhen Grepow Battery CO
LTD, MFG P/N: GLP823990
ADT Door and Window Detector
Manufacturer Model : F-ADT-DW-1
FCC ID : EF400151
Battery Type: 1 x CR2450 (Panasonic)
ADT Motion Detector
Manufacturer Model : F-ADT-PIR-1
FCC ID : EF400152
Battery Type: 1 x CR123A (Panasonic)
ADT Smoke Alarm
Manufacturer Model : F-ADT-SMK-1
FCC ID : EF400153
Battery Type: 2 x CR123A (Panasonic)
ADT Carbon Monoxide Alarm
Manufacturer Model : F-ADT-CO-1
FCC ID : EF400154
Battery Type: 2 x AAA (Duracell)
ADT Keychain Remote
Manufacturer Model : F-ADT-KEY-1
FCC ID : EF400155
Battery Type: 1 x CR2450 (Panasonic)
ADT Water Leak Detector
Manufacturer Model : F-ADT-WTR-1
FCC ID : EF400156
Battery Type: CR17345 (Panasonic)
Safety Instructions: ADT Detectors
• Do not expose products to moisture or extreme temperature.
•Make sure that products are used in a dry location and within the recommended operating
temperature:
⸰ ADT Security Hub: 32° to 120° F (0° to 49° C)
⸰ ADT Door and Window Detector: 32° to 120° F (0° to 49° C)
⸰ ADT Motion Detector: 32° to 120° F (0° to 49° C).
⸰ ADT Water Leak Detector: 32° to 104° F (0° to 40° C)
⸰ ADT Smoke Alarm: 32° to 104° F (0° to 40° C)
⸰ ADT Carbon Monoxide Alarm: 32° to 120° F (0° to 49° C)
⸰ ADT Keychain Remote: 32° to 120° F (0° to 49° C)
•Make sure that the ADT Door and Window Detector is not positioned near metal or metallic
surfaces. Example: foil wallpaper.
•The ADT Water Leak Detector is water resistant but not waterproof; avoid submerging it in water
or liquid to keep interior dry and to protect batteries. All other detectors should not be used
near water or exposed to dripping or splashing of any water or liquid.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS.
Avoid installing the SmartThings Hub
near or inside sources of metal, radio
or electromagnetic interference.
WARNING: No user-serviceable parts inside. Refer all
servicing to qualied service personnel.
IMPORTANT CONSUMER INFORMATION: Please read
before activating or using the device.
WARNING: This product contains chemicals known to the State of
California to cause cancer and reproductive toxicity. For more information,
please call 1-800-SAMSUNG (726-7864).
For each of the devices listed in the previous table, the following FCC statements
and information apply:
FCC Statement
This device complies with Part 15 of the FCC rules. Operation is subject to the
following conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
FCC Caution
Any changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
Important Note: FCC Radiation Exposure Statement
To satisfy FCC radiation exposure safety requirements for the ADT
Securty Hub
,
a separation
distance of 20cm or more should be maintained between this device and a person’s body
(excluding extremities: hands, wrists, feet, and ankles.)
This ZigBee Certied Product works with
ZigBee networks supporting the Home
Automation Prole.
Global 2.4 GHz wireless use.
ZigBee® Certied is a registered trademark
of the ZigBee Alliance.
a copy of your purchase receipt and a description of the problem you are experiencing with the
Product. Any claim under this Limited Warranty must be submitted to SmartThings before the end
of the Warranty Period. Exclusions: This warranty does not apply to: a) damage caused by failure
to follow instructions relating to the Product’s use or the installation of components; b) damage
caused by accident, abuse, misuse, transport, neglect, re, oods, earthquake or other external
causes; c) damage caused by service performed by anyone who is not an authorized representative
of SmartThings; d) accessories used in conjunction with a covered Product; e) a Product or part that
has been modied to alter functionality or capability; f) items intended to be periodically replaced
by the purchaser during the normal life of the Product, including, without limitation, batteries,
bulbs or cables; g) a Product that is used commercially or for a commercial purpose, in each case as
determined by SmartThings. EXCEPT FOR BODILY INJURY, SMARTTHINGS SHALL NOT BE LIABLE FOR
(I) ANY LOST PROFITS, COST OF PROCUREMENT OF SUBSTITUTE PRODUCTS, OR ANY INCIDENTAL
OR CONSEQUENTIAL DAMAGES, OR (II) ANY AMOUNTS IN EXCESS OF THE PURCHASE PRICE FOR
THE PRODUCT, IN EACH CASE WHETHER RESULTING FROM THE USE OF OR INABILITY TO USE THIS
PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, EVEN IF COMPANY HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. SOME STATES DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION AND
EXCLUSIONS MAY NOT APPLY TO YOU. TO THE EXTENT PERMITTED BY APPLICABLE LAW,
SMARTTHINGS DISCLAIMS ANY AND ALL STATUTORY OR IMPLIED WARRANTIES, INCLUDING
WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE
AND WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS. IF SMARTTHINGS CANNOT LAWFULLY
DISCLAIM STATUTORY OR IMPLIED WARRANTIES, THEN TO THE EXTENT PERMITTED BY LAW, ALL
SUCH WARRANTIES SHALL BE LIMITED IN DURATION TO THE WARRANTY PERIOD. SOME STATES DO
NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
LIMITATIONS MAY NOT APPLY TO YOU.
This warranty gives you specic legal rights and you may also have other rights, which vary from
state to state. To exercise your rights under this warranty, please follow the instructions above
under the heading “Obtaining Service”, or contact SmartThings at SmartThings, Inc., 665 Clyde Ave,
Mountain View, CA 94043, USA. Samsung is a registered trademark of Samsung Electronics Co.,
Ltd. Android is a trademark of Google Inc. Other marks are the property of their respective owners.
Device purchase subject to additional SmartThings terms and conditions.
Samsung SmartThings Use of Free and Open-Source Software
This document contains licensing information relating to the use of free and open-source software
(FOSS) with or within the Samsung SmartThings software. Any terms, conditions, or restrictions on
FOSS included within the Samsung SmartThings software that are not included within the original
FOSS licenses are offered and imposed by Samsung SmartThings alone. The authors, licensors, and
distributors of the FOSS disclaim all express or implied conditions, representations, and warranties
relating to the FOSS and any liability arising from use and distribution of the FOSS. A document
containing the complete and current list of FOSS packages used in Samsung SmartThings software
and mobile applications can be found here: www.SmartThings.com/FOSS
The document at the URL above identies the FOSS packages used in the Samsung SmartThings
Hub software, the FOSS licenses that Samsung SmartThings believes govern those FOSS packages,
and copyright and license notices associated with Samsung SmartThings’ use of the FOSS. While
Samsung SmartThings has sought to provide complete and accurate licensing information for each
FOSS package, Samsung SmartThings does not represent or warrant that the licensing information
provided herein is correct or error-free. Recipients of the product have the option to investigate
the identied FOSS packages to conrm the accuracy of the licensing information provided herein.
Recipients are also encouraged to notify Samsung SmartThings of any inaccurate information or
errors found in these notices.
Certain FOSS licenses, such as the GNU General Public License, GNU Lesser (or Library) General
Public License, and Mozilla Public License, require Samsung SmartThings to make available to
recipients the source code corresponding to FOSS binaries distributed under those licenses. Users
who would like to download source code used by Samsung SmartThings under those licenses can do
so by logging in with their Samsung SmartThings account here: https://graph.api.smartthings.com/
foss_sources.
Users with questions or concerns regarding Samsung SmartThings use of Free or Open-Source
Software can contact us via email at: foss@smartthings.com
Deleting a Location (Home, Ofce, etc) in the SmartThings app will cause all Z-Wave devices to
be disconnected from the ADT Security Hub, requiring them to be excluded and re-included. Visit
Support.SmartThings.com for more information. P/N 10015713
SmartThings, Inc., 665 Clyde Ave, Mountain View, CA 94043, USA.
Revised 05/17. Copyright 2017 SmartThings, Inc. All rights reserved. P/N 10015713
ADT and the ADT logo are marks and/or registered marks of ADT. Unauthorized use is strictly
prohibited. CA ACO7155, 974443, PPO17232; FL EF0001121; LA F1639, F1640, F1643, F1654; MA 172C;
NC Licensed by the Alarm Systems Licensing Board of the State of North Carolina, 7535P2, 7561P2,
7562P10, 7563P7, 7565P1, 7566P9, 7564P4; NY 12000305615; PA 090797; MS 15019511.
Household users should contact either the retailer or installer from which they purchased this
product, or their local government ofce, for details of where and how they can take these items for
environmentally safe recycling. Business users should contact their supplier and check the terms
and conditions of the purchase contract. This product and its electronic accessories should not be
mixed with other commercial wastes for disposal.
WARNING: Failure to follow these warnings and instructions can lead to heat generation, rupture,
leakage, explosion, re, or other injury, or damage. Do not insert the battery into the compartment
in the wrong direction. Always replace the battery with the same or equivalent type. Never recharge
or disassemble the battery. Never place the battery in re or water. Always keep batteries away from
small children. If batteries are swallowed, promptly see a doctor.
Always dispose and/or recycle used batteries in accordance with the hazardous waste recovery and
recycling regulations for your location. Your city, state, or country may also require you to comply
with additional handling, recycling, and disposal requirements.
CONSTANT EXPOSURES TO HIGH OR LOW TEMPERATURES OR HIGH HUMIDITY MAY REDUCE
BATTERY LIFE.
One (1) Year Limited Warranty
SmartThings, Inc. warrants this product (the “Product”) against defects in materials and/or
workmanship under normal use for a period of ONE (1) YEAR from the date of purchase by the
original purchaser (“Warranty Period”). If a defect arises and a valid claim is received within the
Warranty Period, then as your sole remedy (and SmartThings’ sole liability), SmartThings will at its
option either 1) repair the defect at no charge, using new or refurbished replacement parts, or 2)
replace the Product with a new product that is functionally equivalent to the original, in each case
within 30 days following receipt of the returned Product. A replacement product or part, assumes
the remaining warranty of the original Product. When a Product or part is exchanged, any
replacement item becomes your property and the replaced Product or part becomes SmartThings’
property.
Obtaining Service: To obtain warranty service, visit Support.SmartThings.com to speak with a service
agent or open a service request. Please be prepared to describe the Product that needs service
and the nature of the problem. A purchase receipt is required. The Product must be insured, and
shipped freight prepaid and securely packaged. You must contact support for a Return Material
Authorization Number (“RMA Number”) before shipping any Product, and include the RMA Number,
Information to the User
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Covered by one or more claims of patents http://sipcollc.com/patent-list/ and
http://intusiq.com/patent-list/.
Correct disposal of batteries in this product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product, its electronic
accessories (e.g. charger, headset, USB cable), and batteries should not be disposed of with other
household waste.
To prevent possible harm to the environment or human health from uncontrolled waste disposal,
please separate these items from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources. Where marked, the chemical symbols Hg, Cd or Pb indicate
that the battery contains mercury, cadmium or lead above the reference levels in EC Directive
2006/66. If batteries are not properly disposed of, these substances can cause harm to human
health or the environment.
