Network operations systems

TOPS

Voice service node

Log and alarm messages

Release: VSN04 Status: Standard Version: 03.01

© Northern Telecom

All rights reserved.

TOPS is a trademark of Northern Telecom.

TOPS VSN log and alarm messages

Publication number: 450-1301-511

Document status: Standard

Document version: 03.01

Document release: VSN04

Date: August 1995

Network operations systems

TOPS

Voice service node

Log and alarm messages

iii

TOPS VSN Log and alarm messages

Contents

1. Introduction 1

Collection and printing log and alarm messages 1

TOPS VSN log message format 1

Change history 4

BCS30 4

BCS31 4

BCS32 4

VSN03 4

VSN04 4

2. TOPS VSN log messages 5

3. Common TOPS VSN log messages - 0200 7

4. Common TOPS VSN log messages -0201 13

5. Common TOPS VSN log messages - 0202 19

6. Common TOPS VSN log messages - 0203 39

7. Common TOPS VSN log messages - 020A 41

8. Common TOPS VSN log messages - 0020 47

9. Voice interface resource manager log messages -

0220 49

10. Alarm Subsystem - 8722 51

11. ACPE resource manager log messages - 9440 53

12. Control link log messages - 9441 57

13. Application call processing engine log messages

- 9442 59

14. T1 resource manager log messages - 9443 65

15. Locality database log messages - 944E 69

16. ACPE Maintenance Position log messages -

9445 73

17. Prompt manager log messages - 9451 75

18. Suppressed and Thresholded Logs 77

Suppressed Logs 77

Thresholding Logs 79

19. DMS notices 81

20. Abbreviations 83

1

TOPS VSN Log and alarm messages

1. Introduction

Collection and printing log and alarm messages

Logs and Alarms are collected for TOPS Voice Service Node (VSN) using the

log and alarm subsystem installed in base TOPS VSN software. The same

subsystem is responsible for creating log and alarm reports. These are stored

temporarily on the TOPS VSN and can be sent to a printer or to a terminal for

continuous display. TOPS VSN uses a dedicated printer to report its log

messages.

Predefined log and alarm configuration datafill is delivered to the operating

company as part of the TOPS VSN installation tapes.

TOPS VSN log message format

A typical TOPS VSN log or alarm message is shown below in figure 1-1. Its

identifying information is printed on one or two lines, and is followed by the

message.

Figure 1-1

Sample TOPS VSN log/alarm message

88 03 22 13:36Subsystem=8720, Report no=0003, Error no=0002,*Minor

Severity of

Occurrance Subsystem

Number Log Message

Number Date and Time of

Generation Locally

Report

Number

dwg 1301-511-1

PRU state Change: Cabinet 1 Slot 14 Unit#85BC Configuration #0000 FAULTY

Reporting PRU is Logger

Other PRU is Unspecified RU.

LAN_NAME

2 Introduction

TOPS VSN Log and alarm messages

Header Information For TOPS VSN Log Messages.

Identifying information, also known as header information, uniquely identifies

each log and alarm message. The header of every log or alarm message

generated by TOPS VSN contains the following:

(a) Date and Time. The date and time are displayed in the upper left of the

message. The format of the date is yymmdd, and the format of the time is

hh:mm.

(b) Severity. Each log message specifies the severity of the event it is

reporting. The following terms or values are used to indicate severity:

*C Critical Severity 1 Logs with this severity generate critical

alarms. These logs and alarms are the result

of catastrophic failures such as power

failures.

** Major Severity 2 Logs with this severity generate major

alarms. These logs and alarms are the result

serious failures such as PRUs being unable

to initialize.

* Minor Severity 3 Logs with this severity generate minor

alarms. These alarms are used to flag

problems that need either a visual or

audible display at the TOPS VSN site. An

example of a problem that would cause a

minor alarm is an incorrect table entry.

GEvent

GError

LEvent

LError

Severity 4

Severity 5

Severity 6

Severity 7

These are intermediate severity ratings. An

event is a happening that does not effect

service. The event is simply logged for the

record. An error is also considered non-

service affecting. It is an isolated error

condition caused by the system, for

example, a single lost call.

Warning/

Trouble Severity 8 This log severity indicates a warning.

Status Severity 9 This log severity reports the status of a

particular software or hardware unit. The

percentage of disk space used is an

example of a log with status severity.

Progress Severity 10 Log reports the progress of an event.

Severity 11-13 These severity ratings are not defined for

TOPS VSN.

Introduction 3

TOPS VSN Log and alarm messages

Status 14 Status 14 Used for login/logout security related

events. This status is now used by all logs

generated from two DVS subsystems

(8029 System Administration (Report #1

only, and 8039 Security Agent Sub-PRU).

The logs produced from these two

subsystems identify logins, logouts,

changes to USERIDs and Admin objects.

Information Status 15 This log severity is used for informational

purposes only.

(c) Subsystem Number. The subsystem number is a four-digit hexadecimal

number that identifies a message subsystem. For example, the subsystem

number for TOPS VSN common logs is 0200 to 020A. Each program

resource unit (PRU) that generates logs has its own subsystem; the common

logs are shared by all TOPS VSN PRUs.

The following list identifies the number associated with each PRU:

0200 - Common Logs - Run Errors

0201 - Common Logs - Tasking Errors

0202 - Common Logs - I/O Errors

0203 - Common Logs - VTP Errors

020A - TOPS VSN Common Logs

0220 - VI Resource Manager Logs

8722 - Alarms PRU

9440 - ACPE Resource Manager Logs

9441 - Control Link Logs

9442 - ACPE Logs + ACPE Executor

9443 - T1 Resource Manager Logs

9445 - ACPE Maintenance Position

(d) Report Number. Report numbers are hexadecimal numbers. They identify

the group or category within the subsystem file the message belongs to. For

TOPS VSN common log messages, the following numbering convention

applies:

Number Type

0000 Nonspecified error types

0001 Run errors

0002 Tasking errors

0003 IO errors

(e) Error Number. Error numbers are hexadecimal numbers. They identify the

specific error condition within each report number grouping.

4 Introduction

TOPS VSN Log and alarm messages

Change history

This section summarizes the important changes that affect this publication.

They are arranged under the heading of the appropriate Batch Change

Supplement (BCS) release.

BCS30

The presentation of this publication has been changed.

The following changes to the TOPS VSN application were made by BCS30:

•introduction of log messages for the locality database

•introduction of log messages for the prompt manager

•addition of an abbreviations list

•introduction of log messages for the support of locality call processing

BCS31

This Document has been reissued as part of the BCS31 release.

BCS32

This document has been revised to include several new alarms in the 8722

subsystem and to include a list of suppressed and thresholded logs.

VSN03 - Version 02.01

This document has been revised to include several new alarm and log messages.

VSN04 - Version 03.01

This document has been revised to include a new log message.

5

TOPS VSN Log and alarm messages

2. TOPS VSN log messages

TOPS VSN log messages are separated into two groups: common logs, and

PRU-specific logs. Each group generates logs from a single subsystem (in most

cases a subsystem is defined by a PRU). This Publication uses separate tables for

each subsystem that generates logs.

The first six tables list logs that are common to TOPS VSN as a whole. These

logs are generated from base software but have specific application to TOPS

VSN. With these logs there is no one-to-one correspondence between subsystem

and PRU. The remaining tables list logs by software (PRU) subsystem. A

complete list of logs generated from base software is given in Publication

450-1301-511.

Accompanying each log entry is a definition and a description of the action the

user must take to respond to the log. This Publication contains the following log

sections:

•3. lists messages for base run errors.

•4. lists messages for base tasking errors.

•5. lists messages for base IO errors.

•6. lists messages for base VTP errors.

•7. lists messages for TOPS VSN common logs.

•8. lists base maintenance notices.

•9. lists messages for VI resource manager errors.

•10. lists messages for the Alars PRU.

•11. lists messages for ACPE resource manager errors.

•12. lists messages for datalink errors.

•13. lists messages for ACPE errors.

•14. lists messages for T1 resource manager errors.

•15. lists messages for the Locality Database.

•16. lists messages for the Prompt Manager.

6 DNC Logs TOPS VSN Log Messages

TOPS VSN Log and alarm messages

The following messages are the complete, or raw messages. The log service may

select only certain items from the lists shown for each message, depending on

the nature of the event.

7

TOPS VSN Log and alarm messages

3. Common TOPS VSN log

messages - 0200

0001/0000

Message:

[PRU_name] has encountered a bus error. This is an

unrecoverable error and the SRU where this PRU resides should be rebooted.

Description:

The software task failed because of a hardware error. If the

PRU declares itself faulty then the log subsystem detects the faulty condition

and raises an alarm.

Action:

Reboot the SRU. If the error occurs more than once a week replace

the SRU. Record all action taken.

0001/0001

Message:

[PRU_name] has encountered a divided by zero run error. This is

an unrecoverable error and the PRU should be rebooted.

Description:

The software task failed because it encountered a divide by

zero operation. The PRU may declare itself faulty or recreate the task.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

0001/0002

Message:

[PRU_name] has encountered a dereferencing of an odd address

run error. This is an unrecoverable error and the PRU should be rebooted.

Description:

The software task failed due to a software error. The PRU may

declare itself faulty or recreate the task. If the PRU declares itself faulty then the

log subsystem detects the faulty condition and raises an alarm.

Action:

If the PRU is in the working state, no action is required. If the PRU is in

a faulty state, document the problem, restart the PRU, and then contact NT.

0001/0003

Message:

[PRU_name] has encountered an illegal user instruction run error.

This is an unrecoverable error and the PRU should be rebooted.

Description:

The software task failed due to a software error. The PRU may

declare itself faulty or recreate the task. If the PRU declares itself faulty then the

log subsystem detects the faulty condition and raises an alarm.

Action:

If the PRU is in the working state, no action is required. If the PRU is in

the faulty state, document the problem, restart the PRU, and then contact NT.

0001/0004

Message:

[PRU_name] has encountered a value range error. This is an

unrecoverable error and the PRU should be rebooted.

8 Common TOPS VSN log messages (0200)

TOPS VSN Log and alarm messages

Description:

The software task failed due to a software error. The PRU may

declare itself faulty or recreate the task. If the PRU declares itself faulty then the

log subsystem detects the faulty condition and raises an alarm.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

0001/0005

Message:

[PRU_name] has encountered a stack overflow condition. This is

an unrecoverable error and the PRU should be rebooted.

Description:

The software task failed due to a software error. The PRU may

declare itself faulty or recreate the task. If the PRU declares itself faulty then the

log subsystem detects the faulty condition and raises an alarm.

Action:

If the PRU is in the working state, no action is required. If the PRU is in

the faulty state, document the problem, restart the PRU, and then contact NT.

0001/0006

Message:

[PRU_name] has encountered a privilege violation error. This is an

unrecoverable error and the PRU should be rebooted.

Description:

The software task failed due to a software error. The PRU may

declare itself faulty or recreate the task. If the PRU declares itself faulty then the

log subsystem detects the faulty condition and raises an alarm.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

0001/0007

Message:

[PRU_name], Filler log. This log should not occur as defined in

Errordefs.

Description:

The software task failed due to a software error.

Action: Retain all information regarding the problem, and then contact NT.

0001/0008

Message:

[PRU_name] has no buffer pools associated with the task. This is

an unrecoverable error and the PRU should be rebooted.

Description:

The software task failed due to a software error. The PRU may

declare itself faulty or recreate the task. If the PRU declares itself faulty then the

log subsystem detects the faulty condition and raises an alarm.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

0001/0009

Message:

[PRU_name] can not allocate control blocks. This is an

unrecoverable error and the PRU should be rebooted. If rebooting the PRU

does not solve the problem, reboot the SRU.

Description:

The software task failed because it could not allocate control

blocks. Control blocks are required for communication between PRUs. The

PRU may declare itself faulty or recreate the task. If the PRU declares itself

faulty then the log subsystem detects the faulty condition and raises an alarm.

Action:

Reboot the PRU. If this action does not correct the problem, then

reboot the SRU. If the error occurs more than once a week replace the SRU.

Document the problem and record all action taken.

Common Tops log messages (0200) DNC Logs 9

TOPS VSN Log and alarm messages

0001/000A

Message:

[PRU_name] encountered a segment or mapper error. This is an

unrecoverable error and the PRU should be rebooted. If rebooting the PRU

does not solve the problem, reboot the SRU.

Description:

The software task failed because it encountered a segment or

mapping error. The PRU may declare itself faulty or recreate the task. If the

PRU declares itself faulty then the log subsystem detects the faulty condition

and raises an alarm.

Action:

Reboot the PRU. If this action does not correct the problem, then

reboot the SRU. If the error occurs more than once a week replace the SRU.

Document the problem and record all action taken.

0001/000B

Message:

[PRU_name] has been in a critical region too long. This is an

unrecoverable error and the PRU should be rebooted.

Description:

The software task failed due to a software error. The PRU may

declare itself faulty or recreate the task. If the PRU declares itself faulty then the

log subsystem detects the faulty condition and raises an alarm.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

0001/000C

Message:

[PRU_name] has encountered a parity error. This is an

unrecoverable error and the SRU should have diagnostics run.

Description:

The software task failed because of a parity error. The PRU may

declare itself faulty or recreate the task. If the PRU declares itself faulty then the

log subsystem detects the faulty condition and raises an alarm.

Action:

Run diagnostics on the SRU containing the PRU. To do this take all

other PRUs out of service first. If diagnostics fail, replace the SRU. If

diagnostics do not detect an error but the problem persists, replace the SRU.

Document the problem and record all action taken.

0001/000D

Message:

[PRU_name] encountered a kernel error. This is an unrecoverable

error and the SRU should be rebooted.

Description:

The software task failed because the kernel of the SRU in which

the PRU is operating has encountered an unexpected state. The PRU may

declare itself faulty or recreate the task. If the PRU declares itself faulty then the

log subsystem detects the faulty condition and raises an alarm.

Action:

Reboot the SRU. If the error occurs more than once a week replace

the SRU. Document the problem and record all action taken.

0001/000E

Message:

[PRU_name] has encountered a floating point math error. This is

an unrecoverable error and the PRU should be rebooted.

Description:

The software task failed due to a reference error. The PRU may

declare itself faulty or recreate the task.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

10 Common TOPS VSN log messages (0200)

TOPS VSN Log and alarm messages

0001/000F

Message:

[PRU_name] has encountered a nil pointer reference run error.

This is an unrecoverable error and the PRU should be rebooted.

Description:

The software task failed due to a reference error. The PRU may

declare itself faulty or recreate the task.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

0001/0010

Message:

[PRU_name] has encountered a run error when performing a set

operation. This is an unrecoverable error and the PRU should be rebooted.

Description:

The software task failed during a set operation. The PRU may

declare itself faulty or recreate the task.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

0001/0011

Message:

[PRU_name] has encountered a run error while performing a math

operation. Specifically, the error occurred when performing a conversion of a

long integer to a short integer. This is an unrecoverable error and the PRU

should be rebooted.

Description:

The software task failed because the integer was to large to be

converted to a short integer. The PRU may declare itself faulty or recreate the

task. If the PRU declares itself faulty then the log subsystem detects the faulty

condition and raises an alarm.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

0001/0012

Message:

[PRU_name] has encountered a divide by zero run error. This is an

unrecoverable error.

Description:

The software task failed because of a long divide by zero

operation. The PRU may declare itself faulty or recreate the task.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

0001/0013

Message:

[PRU_name] has encountered an overflow run error when

performing multiplication. This is an unrecoverable error and the PRU should

be rebooted.

Description:

The software task failed because a multiplication operation was

too large and overflowed. The PRU may declare itself faulty or recreate the

task.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

0001/0014

Message:

[PRU_name] has attempted to exit a procedure not directly called.

This is an unrecoverable error and the PRU should be rebooted.

Common Tops log messages (0200) DNC Logs 11

TOPS VSN Log and alarm messages

Description:

The software task failed because it tried to perform an exit

command from a procedure it was not currently executing. The PRU may

declare itself faulty or recreate the task.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

0001/0015

Message:

[PRU_name] encountered a mini-task error. This is an

unrecoverable error and the PRU should be rebooted.

Description:

The software task failed due to a software error. The PRU may

declare itself faulty or recreate the task.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

0001/0016

Message:

[PRU_name] was passed input to a transcendental function that

was negative. This is an unrecoverable error and the PRU should be rebooted.

Description:

The software task failed because a negative value was used for

a transcendental function. Transcendental function values must be positive.

The PRU may declare itself faulty or recreate the task.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

0001/0017

Message:

[PRU_name] encountered an error associated with IEEE real

numbers. This is an unrecoverable error and the PRU should be rebooted.

Description:

The software task failed because of an illegal IEEE real number

operation. The PRU may declare itself faulty or recreate the task.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart the PRU, and then contact

NT.

13

TOPS VSN Log and alarm messages

4. Common TOPS VSN log

messages -0201

0002/0000

Message:

[PRU_name] has successfully communicated with [Other

PRU_name]. (No error detected.)

Description:

The named PRUs are communicating.

Action:

No action is required.

0002/0001

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. This means the message was not accepted after a

timeout value.

Description:

The sending PRU could not communicate with the receiving

PRU. The latter did not accept the message after a specified time interval. It is

the responsibility of the sending PRU to recover from the error by resending

the message, or to declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart both sending and receiving

PRUs, and then contact NT.

0002/0002

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. This means the message was not accepted after a

timeout value.

Description:

The sending PRU could not communicate with the receiving

PRU. The latter did not accept the message after a specified time interval. It is

the responsibility of the sending PRU to recover from the error by resending

the message or to declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart both sending and receiving

PRUs, and then contact NT.

0002/0003

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. This means the message was not accepted after a

timeout value.

Description:

The sending PRU could not communicate with the receiving

PRU. The latter did not accept the message after a specified time interval. It is

the responsibility of the sending PRU to recover from the error by resending

the message or to declare itself faulty.

14 Common TOPS VSN log messages (0201)

TOPS VSN Log and alarm messages

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart both sending and receiving

PRUs, and then contact NT.

0002/0004

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. Either a bad control block handler or a bad taskID

could cause such an error.

Description:

The sending PRU could not communicate with the receiving

PRU. The latter did not accept the message. It is the responsibility of the

sending PRU to recover from the error by resending the message or to declare

itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart both sending and receiving

PRUs, and then contact NT.

0002/0005

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. The receiver of the message [Receiving_PRU_

name] is probable cause of error.

Description:

The sending PRU could not communicate with the receiving

PRU. The latter did not accept the message. It is the responsibility of the

sending PRU to recover from the error by resending the message or to declare

itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart both sending and receiving

PRUs, and then contact NT.

0002/0006

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. This means the message was not accepted after a

timeout value.

Description:

The sending PRU could not communicate with the receiving

PRU. The latter did not accept the message after a specified time interval. It is

the responsibility of the sending PRU to recover from the error by resending

the message or to declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart both sending and receiving

PRUs, and then contact NT.

0002/0007

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. The sender encountered an invalid wait time.

Description:

The sending PRU could not communicate with the receiving

PRU. The latter did not accept the message after a specified time interval. It is

the responsibility of the sending PRU to recover from the error by resending

the message or to declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart both sending and receiving

PRUs, and then contact NT.

Common Tops log messages (0201) DNC Logs 15

TOPS VSN Log and alarm messages

0002/0008

Message:

[PRU_NAME] was trying to communicate with [PRU_NAME] but

could not.

->TaskResult=<task_result_num>

"Diagnostic String1"

"Diagnostic String2"

Description:

This log indicates that a communication error has occurred.

Action may be required, depending on the state of the PRU(s). If the PRU(s) are

in a "working" state, it can be assumed that the software recovered from the

error and no further action is required. If one or both of the PRUs are "faulty" or if

the problem persists, reboot the "faulty" PRU(s).

Action:

If the problem persists, retain all of the information regarding the

problem and contact your NT representative.

0002/0009

Message:

[Sending_PRU_name] was trying to initiate a task but could not.

Description:

The sending PRU could not initiate a task. It is the responsibility

of this PRU to recover from the error by resending the message or to declare

itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem and reboot the PRU. If the problem

persists reboot the SRU in which the PRU resides. Document the problem,

record all action taken , and then call NT.

0002/000F

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. The sender [Sending_PRU_name] did not have a

communication pool available OR there was an invalid "MakePool".

Description:

The sending PRU could not communicate with the receiving

PRU. It is the responsibility of the sending PRU to recover from the error by

resending the message or to declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart both sending and receiving

PRUs, and then contact NT.

0002/0011

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. The sender [Sending_PRU_name] encountered

an illegal operation in its mini task.

Description:

The sending PRU could not communicate with the receiving

PRU. It is the responsibility of the sending PRU to recover from the error by

resending the message or to declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart both sending and receiving

PRUs, and then contact NT.

0002/0015

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. Depending on the type of communication method

used either [Receiving_PRU_ name] or [Sending_PRU_name] does not have

enough communication buffers available.

16 Common TOPS VSN log messages (0201)

TOPS VSN Log and alarm messages

Description:

The sending PRU could not communicate with the receiving

PRU. The latter did not accept the message. It is the responsibility of the

sending PRU to recover from the error by resending the message or to declare

itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart both sending and receiving

PRUs, and then contact NT.

0002/0016

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. The sender [Sending_PRU_ name] could not

transmit to the network.

Description:

The sending PRU could not communicate with the receiving

PRU. It is the responsibility of the sending PRU to recover from the error by

resending the message or to declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, restart the sending PRU. If the problem persists, then

reboot the entire machine. Document the problem, record all action taken, and

then contact NT.

0002/0017

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. The sender [Sending_PRU_ name] encountered a

stack overflow.

Description:

The sending PRU could not communicate with the receiving

PRU. It is the responsibility of the sending PRU to recover from the error by

resending the message or to declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then restart the sending PRU. If the problem persists, then

reboot the SRU in which the PRU resides. Document the problem, record all

action taken, and then contact NT.

0002/0018

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. The information being passed within the

communication packet is invalid.

Description:

The sending PRU could not communicate with the receiving

PRU. It is the responsibility of the sending PRU to recover from the error by

resending the message or to declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart both sending and receiving

PRUs, and then contact NT.

0002/0019

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. The entry definition in [Receiving_PRU_name]

does not match what [Sending_PRU_ name] expects. User action is required.

Description:

The sending PRU could not communicate with the receiving

PRU because the software version in each were not the same.

Action:

The user must reinstall both PRUs from the load tape. If the problem

persists, then contact NT.

Common Tops log messages (0201) DNC Logs 17

TOPS VSN Log and alarm messages

0002/001A

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. The entry definition in [Sending_PRU_name] was

not found, OR push/pull was invoked when not in entry. User action is

required.

Description:

The sending PRU could not communicate with the receiving

PRU because the software version in each were not the same.

Action:

The user must reinstall both PRUs from the load tape. If the problem

persists, then contact NT.

0002/001B

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. The result was a communication failure.

Description:

The sending PRU can not communicate with the receiving PRU

because the receiving PRU is not there. It is the responsibility of the sending

PRU to recover from the error or to declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, document the problem, restart both sending and receiving

PRUs, and then contact NT.

0002/001C

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. The result was that the location address of the

receiver was invalid.

Description:

The sending PRU could not communicate with the receiving

PRU. It is the responsibility of the sending PRU to recover from the error by

resending the message or to declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then document the problem, and restart both sending and

receiving PRUs. If necessary, restart the SRUs in which both PRUs reside.

Record all action taken, and then contact NT.

0002/001D

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. The result was an interval timer error.

Description:

The sending PRU could not communicate with the receiving

PRU. It is the responsibility of the sending PRU to recover from the error by

resending the message or to declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then document the problem, and restart both sending and

receiving PRUs. If necessary, restart the SRUs in which both PRUs reside.

Record all action taken, and then contact NT.

0002/001E

Message:

[Sending_PRU_name] was trying to communicate with [Receiving_

PRU_name] but could not. The problem is the sender [Sending_PRU_name]

could not obtain control blocks. User action is required.

Description:

The sending PRU could not communicate with the receiving

PRU. It is the responsibility of the sending PRU to recover from the error by

resending the message or to declare itself faulty.

18 Common TOPS VSN log messages (0201)

TOPS VSN Log and alarm messages

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then document the problem, and restart both sending and

receiving PRUs. If necessary, restart the SRUs in which both PRUs reside.

Record all action taken, and then contact NT.

19

TOPS VSN Log and alarm messages

5. Common TOPS VSN log

messages - 0202

0003/0000

Message:

[PRU_name] successfully performed an IO operation on pathname

[file/directory_pathname].

Description:

The PRU successfully completed an IO operation.

Action:

No action required.

0003/0001

Message:

[PRU_name] received an IO error (Mixed_Access) on path

[file/directory_path name]. The "localized SRU" error was the result of mixing IO

types, for example (Readln and blockreads).

Description:

The PRU encountered an error during an IO operation on the

file or directory. It is the responsibility of the PRU performing the operation to

recover from the error and to retry the operation. If it is unable to do so, then it

can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, the

corrective action taken, and then contact NT.

0003/0002

Message:

[PRU_name] received an IO error on path [file/directory_path

name]. The error was the result of reaching a resource limit.

Description:

The PRU encountered an error during an IO operation on the

file or directory. It is the responsibility of the PRU performing the operation to

recover from the error and to retry the operation. If it is unable to do so, then it

can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If the PRU is still faulty, then reboot

the SRU in which the PRU resides. If all reboot operations are unsuccessful,

then reboot the whole system. Document the problem, the corrective action

taken, and then contact NT.

0003/0014

Message:

[PRU_name] received an IO error on path [file/directory_path

name]. The error was the result of trying to write an illegal character.

20 Common TOPS VSN log messages (0202)

TOPS VSN Log and alarm messages

Description:

The PRU encountered an error during an IO operation on the

file or directory. It is the responsibility of the PRU performing the operation to

recover from the error and to retry the operation. If it is unable to do so, then it

can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, the

corrective action taken, and then contact NT.

0003/001E

Message:

[PRU_name] received an IO error on path [file/directory_path

name]. The error was the result of an out of bounds operation.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, the

corrective action taken, and then contact NT.

0003/0028

Message:

[PRU_name] received an IO error on path [file/directory_path

name]. The error was the result of performing an I/O operation on a file that was

not opened.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed because it did not make its

way to the server. This error is in the SRU where the PRU resides. It is the

responsibility of the PRU performing the operation to recover from the error and

to retry the operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, or if the problem persists, then reboot the PRU. If this action

doesn't correct the problem, reboot the SRU. If the PRU is still faulty, then

reboot the entire system. Document the problem, record all action taken, and

then contact NT.

0003/0029

Message:

[PRU_name] received an IO error on path [file/directory_path

name]. The error was the result of performing an open operation on a file that

was already opened.

Description:

The PRU encountered an error during an IO (open) operation

on the file or directory. The operation was not performed because it did not

make its way to the server. The error is in the SRU where the PRU resides. It is

the responsibility of the PRU performing the operation to recover from the error

and to retry the operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, the

corrective action taken, and then contact NT.

Common Tops log messages (0202) DNC Logs 21

TOPS VSN Log and alarm messages

0003/002A

Message:

[PRU_name] received an IO error on path [file/directory_path

name]. The error was the result of trying to save the file to disk, but the file was

not opened for "writable" access.

Description:

The PRU encountered an error during an IO operation such as,

open, read, or write, on the file or directory. The operation was not performed

because it did not make its way to the server. The error is in the SRU where the

PRU resides. It is the responsibility of the PRU performing the operation to

recover from the error and to retry the operation. If it is unable to do so, then it

can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, the

corrective action taken, and then contact NT.

0003/002B

Message:

[PRU_name] received an IO error on path [file/directory_path

name]. The error was the result of performing an illegal seek operation.

Description:

The PRU encountered an error during an IO operation such as,

open, read or write, on the file or directory. The operation was not performed

because it did not make its way to the server. The error is in the SRU where the

PRU resides. It is the responsibility of the PRU performing the operation to

recover from the error and to retry the operation. If it is unable to do so, then it

can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/002C

Message:

[PRU_name] received an IO error on path [file/directory_path

name]. The error was the result of performing an operation on a file set using a

bad identifier for the file set.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed because it did not make its

way to the server. This error is in the SRU where the PRU resides. It is the

responsibility of the PRU performing the operation to recover from the error and

to retry the operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/002D

Message:

[PRU_name] received an IO error on path [file/directory_path

name]. The error was the result of performing an I/O operation, but the server

that was referenced [first_component_of_pathname], was not found.

22 Common TOPS VSN log messages (0202)

TOPS VSN Log and alarm messages

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed because it did not make its

way to the server. This error is in the SRU where the PRU resides. It is the

responsibility of the PRU performing the operation to recover from the error and

to retry the operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/002E

Message:

[PRU_name] received an IO error (Across_File_System) on path

[file/directory_path name]. The error was the result of performing an I/O

operation across file systems. Some commands are not supported.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed because it did not make its

way to the server. This error is in the SRU where the PRU resides. It is the

responsibility of the PRU performing the operation to recover from the error and

to retry the operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/002F

Message:

[PRU_name] received an IO error (Already_Logged_On) on path

[file/directory_path name]. The error was the result of logging into a server that

is already logged into.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed because it did not make its

way to the server. This error is in the SRU where the PRU resides. It is the

responsibility of the PRU performing the operation to recover from the error and

to retry the operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0030

Message:

[PRU_name] received an IO error (Client_Resource_Limit) on path

[file/directory_path name]. The error was the result of reaching some limit local

to the SRU where the PRU [PRU_name] resides.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed because it did not make its

way to the server. Probable cause is one or more open files. This error is in the

SRU where the PRU resides. It is the responsibility of the PRU performing the

operation to recover from the error and to retry the operation. If it is unable to

do so, then it can declare itself faulty.

Common Tops log messages (0202) DNC Logs 23

TOPS VSN Log and alarm messages

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0031

Message:

[PRU_name] received an IO error (Value_Overflow) on path

[file/directory_path name]. The error was the result of overflowing a particular

field.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed because it did not make its

way to the server. This error is in the SRU where the PRU resides. It is the

responsibility of the PRU performing the operation to recover from the error and

to retry the operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0064

Message:

[PRU_name] received an IO error (Mismatch_In_Interface) on path

[file/directory_path name]. The "server" error was the result of having old and

new versions of kernel/file server code. User action is required.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed because it did not make its

way to the server. This error is in the SRU where the PRU resides. It is the

responsibility of the PRU performing the operation to recover from the error and

to retry the operation. If it is unable to do so, then it can declare itself faulty.

Action:

Load compatible software loads on each SRU and the file server(s).

Reboot the system. Document the problem, record all action taken, and then

contact NT.

0003/0065

Message:

[PRU_name] received an IO error (Bad_Pathname) on path

[file/directory_path name]. The "server" error was the result of specific illegal

characters, or bad length in the pathname.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0066

Message:

[PRU_name] received an IO error (File_Not_Found) on path

[file/directory_path name]. The "server" error was the result of not being able to

find the specified file (or path) on the requested server.

24 Common TOPS VSN log messages (0202)

TOPS VSN Log and alarm messages

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0067

Message:

[PRU_name] received an IO error (Cannot_Create) on path

[file/directory_path name]. The "server" error was the result of not being able to

create the specified file (or path).

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0068

Message:

[PRU_name] received an IO error (Duplicate_Name) on path

[file/directory_path name]. The "server" error was the result of attempting to

create a file (or directory) when the entity already exits.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0069

Message:

[PRU_name] received an IO error (Bad_Address) on path

[file/directory_path name]. The "server" error was the result of specifying a bad

address.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

Common Tops log messages (0202) DNC Logs 25

TOPS VSN Log and alarm messages

0003/006A

Message:

[PRU_name] received an IO error (Outside_File_Boundaries) on

path [file/directory_path name]. The "server" error was the result of attempting

an IO operation outside the boundaries of the file. (Accessing beyond the end

of file).

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/006B

Message:

[PRU_name] received an IO error (Mode_Conflict) on path

[file/directory_path name]. The "server" error was the result of a mode conflict

error. (i.e.. a file was opened for write mode and someone else already had the

file opened in the write mode.)

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/006C

Message:

[PRU_name] received an IO error (Bad_Obj_Type) on path

[file/directory_path name]. The "server" error was the result of specifying a bad

object type.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/006D

Message:

[PRU_name] received an IO error (Access_Denied) on path

[file/directory_path name]. The "server" error was the result of an access

denied operation. (i.e.. The user does not have access rights to the file.)

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

26 Common TOPS VSN log messages (0202)

TOPS VSN Log and alarm messages

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/006E

Message:

[PRU_name] received an IO error (Invalid_Password) on path

[file/directory_path name]. The "server" error was the result of an invalid

password specified.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/006F

Message:

[PRU_name] received an IO error (Command_Not_Supported) on

path [file/directory_path name]. The "server" error was the result of specifying a

command that is not supported.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0070

Message:

[PRU_name] received an IO error (Device_Offline) on path

[file/directory_path name]. The "server" error was the result of attempting to

access a device that is offline.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

Put the required device on line or specify an alternate online

device. If the PRU is in the working state, no action is required. If the PRU is in

the faulty state, then reboot the PRU. If the problem persists, then reboot the

server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0071

Message:

[PRU_name] received an IO error (Server_Resource_Limit) on

path [file/directory_path name]. The "server" error was the result of reaching a

server resource limit, probably too many files open.

Common Tops log messages (0202) DNC Logs 27

TOPS VSN Log and alarm messages

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

Close all files that do not need to be open. If the PRU is in the

working state, no action is required. If the PRU is in the faulty state, then reboot

the PRU. If the problem persists, then reboot the server which handles the IO

operation. If neither reboot operations are successful, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0072

Message:

[PRU_name] received an IO error (Parity_Error) on path

[file/directory_path name]. The "server" error was the result of a parity error in

reading data from the server.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU and the file server. If the problem

persists, replace the file server SRU and if necessary, the disk. Document the

problem, record all action taken, and then contact NT.

0003/0073

Message:

[PRU_name] received an IO error (Disk_Write_Protected) on path

[file/directory_path name]. The "server" error was the result of trying to write to

a disk that is write protected. Access SAS utilities and unprotect the server. If it

is the prime disk, use FSPATCH.

Description:

The PRU encountered an error during an IO (write) operation

on the file or directory. The operation was not performed. It is the responsibility

of the PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

Reset the write protect flag of the file server. If the PRU is in the

working state, no further action is required. If the PRU is in the faulty state, then

reboot the PRU and the file server. If the problem persists, replace the file

server SRU and if necessary, the disk. Document the problem, record all action

taken, and then contact NT.

0003/0074

Message:

[PRU_name] received an IO error (No_Directory) on path

[file/directory_path name]. The "server" error was the result of performing an

operation on a directory that does not exit.

Description:

The PRU encountered an error during an IO operation trying to

access a directory. The operation was not performed. It is the responsibility of

the PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

28 Common TOPS VSN log messages (0202)

TOPS VSN Log and alarm messages

0003/0075

Message:

[PRU_name] received an IO error (Object_Not_Writable) on path

[file/directory_path name]. The "server" error was the result of performing a

write operation on an object (or file) that can not be written to.

Description:

The PRU encountered an error during an IO (write) operation

on the file or object. The operation was not performed. It is the responsibility of

the PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0076

Message:

[PRU_name] received an IO error (Bad_Access_Mode) on path

[file/directory_path name]. The "server" error was the result of an illegal access

specification in pathname.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0077

Message:

[PRU_name] received an IO error (Bad_Remote_Pointer) on path

[file/directory_path name]. The "server" error was the result of using a bad

remote pointer.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0078

Message:

[PRU_name] received an IO error (Transaction_Timeout) on path

[file/directory_path name]. The "server" error was the result of a timeout that

occurred on a close/commit of a transactional file set.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Common Tops log messages (0202) DNC Logs 29

TOPS VSN Log and alarm messages

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0079

Message:

[PRU_name] received an IO error (Date_Noset) on path

[file/directory_path name]. The error was the result of attempting a file commit

with no time server on node.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0082

Message:

[PRU_name] received an IO error (Bad_Directory) on path

[file/directory_path name]. The error was the result of not being able to

recognize the directory structure on the floppy.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0083

Message:

[PRU_name] received an IO error (Too_Many_Files_On_Dir) on

path [file/directory_path name]. The error was the result of an overrun on UCSD

limit of 77 files per floppy.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

Remove unwanted files from the floppy. If the PRU is in the working

state, no action is required. If the PRU is in the faulty state, then reboot the

PRU. If the problem persists, then reboot the server which handles the IO

operation. If neither reboot operations are successful, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0084

Message:

[PRU_name] received an IO error (No_Room_On_Vol) on path

[file/directory_path name]. The error was the result of the disk being full.

30 Common TOPS VSN log messages (0202)

TOPS VSN Log and alarm messages

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0085

Message:

[PRU_name] received an IO error (New_Volume_Mounted) on

path [file/directory_path name]. The error was the result of a new volume being

mounted.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0086

Message:

[PRU_name] received an IO error (Timeout_On_Vol) on path

[file/directory_path name]. The error was the result of a server communication

problem.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/008C

Message:

[PRU_name] received an IO error (Serious_Error_Level) on path

[file/directory_path name].

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

Common Tops log messages (0202) DNC Logs 31

TOPS VSN Log and alarm messages

0003/0094

Message:

[PRU_name] received an IO error (Bad_Comm_Addr) on path

[file/directory_path name]. The error was the result of specifying an invalid site

address.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If neither reboot operations are

successful, then reboot the whole system. Document the problem, record all

action taken, and then contact NT.

0003/0095

Message:

[PRU_name] received an IO error (Bad_Comm_Msg) on path

[file/directory_path name]. The error was the result of a protocol error between

communication servers.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0096

Message:

[PRU_name] received an IO error (Comm_Link_Failure) on path

[file/directory_path name]. The error was the result of failure in communications

between sites.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0097

Message:

[PRU_name] received an IO error (Remote_Site_Failure) on path

[file/directory_path name]. The error was the result of a failure of the server at

the remote site.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

32 Common TOPS VSN log messages (0202)

TOPS VSN Log and alarm messages

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0098

Message:

[PRU_name] received an IO error (Bad_File) on path

[file/directory_path name]. The error was the result of file identifier not

recognized by the server.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0099

Message:

[PRU_name] received an IO error (Consistency_Check) on path

[file/directory_path name]. The error was the result of data on the disk is not

what the file system thinks is on the disk.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

Reformat the disk. Document the problem, record all action taken,

and then contact NT.

0003/009A

Message:

[PRU_name] received an IO error (Bad_Transaction_ID) on path

[file/directory_path name]. The error was the result of an invalid file set

transaction identifier.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/009B

Message:

[PRU_name] received an IO error (Bad_Volume_ID) on path

[file/directory_path name]. The error was the result of the specified volume

identifier for the fid (file identifier) is for this server.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Common Tops log messages (0202) DNC Logs 33

TOPS VSN Log and alarm messages

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/009C

Message:

[PRU_name] received an IO error (Spares_Not_Zero) on path

[file/directory_path name]. The error was the result of the "spares" field input is

not zero.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/009D

Message:

[PRU_name] received an IO error (Bad_Uobj_Type) on path

[file/directory_path name]. The error was the result of an invalid Unix Object

type specified.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/009E

Message:

[PRU_name] received an IO error (File_Exists_Already) on path

[file/directory_path name]. The error was the result of specifying an exclusive

option set but the file already exists.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/009F

Message:

[PRU_name] received an IO error (Bad_SCR_Pathname) on path

[file/directory_path name]. The error was the result of invalid source pathname

specified.

34 Common TOPS VSN log messages (0202)

TOPS VSN Log and alarm messages

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0100

Message:

[PRU_name] received an IO error (Illegal_Parameter) on path

[file/directory_path name]. The error was the result of an illegal parameter

submitted to FileOperating System interface.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0101

Message:

[PRU_name] received an IO error (Bad_Dest_Pathname) on path

[file/directory_path name]. The error was the result of specifying a bad

destination pathname.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0102

Message:

[PRU_name] received an IO error (Bad_Dest_VolumeID) on path

[file/directory_path name]. The error was the result of specifying a volume ID of

the destination fid (file identifier) is not for this server.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

Common Tops log messages (0202) DNC Logs 35

TOPS VSN Log and alarm messages

0003/0103

Message:

[PRU_name] received an IO error (Bad_Parameter) on path

[file/directory_path name]. The error was the result of specifying an invalid input

parameter.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0096

Message:

[PRU_name] received an IO error (New_PSWD_Invalid) on path

[file/directory_path name]. The error was the result of specifying a bad

password.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0105

Message:

[PRU_name] received an IO error (Bad_Vol_Control_Param) on

path [file/directory_path name]. The error was the result of specifying a bad

volume control parameter.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0106

Message:

[PRU_name] received an IO error (Bad_Agent_ID) on path

[file/directory_path name]. The error was the result of an agent_ID on logout

being invalid.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

36 Common TOPS VSN log messages (0202)

TOPS VSN Log and alarm messages

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0107

Message:

[PRU_name] received an IO error (No_Dir_Blk_Delete) on path

[file/directory_path name]. The error was the result of no standard delete of

directory blocks.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0108

Message:

[PRU_name] received an IO error (Bad_Key) on path

[file/directory_path name]. The error was the result of the instance key handed

in is invalid.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0096

Message:

[PRU_name] received an IO error (FS_Read_Error) on path

[file/directory_path name]. The error was the result of a Read Error occurring in

user data.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/010A

Message:

[PRU_name] received an IO error (FS_Write_Error) on path

[file/directory_path name]. The error was the result of a Write Error occurring in

user data.

Common Tops log messages (0202) DNC Logs 37

TOPS VSN Log and alarm messages

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/010B

Message:

[PRU_name] received an IO error (Bad_SFS_Task_ID) on path

[file/directory_path name]. The error was the result of the agent or object

identifier which does not exist.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/010C

Message:

[PRU_name] received an IO error (Bad_CMD_Length) on path

[file/directory_path name]. The error was the result of the length of the File

Operating System command being incorrect.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/010D

Message:

[PRU_name] received an IO error (Bad_SRC_Volume_ID) on path

[file/directory_path name]. The error was the result of specifying a volume_ID of

source fid (file identifier) not for this server.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

38 Common TOPS VSN log messages (0202)

TOPS VSN Log and alarm messages

0003/010E

Message:

[PRU_name] received an IO error (PERM_Denied) on path

[file/directory_path name]. The error was the result of permission denied.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

0003/0129

Message:

[PRU_name] received an IO error (Special_File) on path

[file/directory_path name]. The error was the result of a SFS special file for

UNIX.

Description:

The PRU encountered an error during an IO operation on the

file or directory. The operation was not performed. It is the responsibility of the

PRU performing the operation to recover from the error and to retry the

operation. If it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. If the problem persists, then reboot

the server which handles the IO operation. If this action doesn't correct the

problem, then reboot the SRU. If the PRU is still faulty, then reboot the whole

system. Document the problem, record all action taken, and then contact NT.

39

TOPS VSN Log and alarm messages

6. Common TOPS VSN log

messages - 0203

0001/0000

Message:

[PRU_name] encountered a VTP error [decimal]. [Two 80 character

lines of optional data.]

Description:

The PRU encountered an communication error. The

communication operation was not performed. It is the responsibility of the PRU

performing the operation to recover from the error and to retry the operation. If

it is unable to do so, then it can declare itself faulty.

Action:

If the PRU is in the working state, no action is required. If the PRU is

in the faulty state, then reboot the PRU. Document the problem, record all

action taken, and then contact NT.

41

TOPS VSN Log and alarm messages

7. Common TOPS VSN log

messages - 020A

0001/0000

Message:

[PRU_name] could not obtain sufficient memory to operate. User

action is required. [Two 80 character lines of optional data.]

Description:

The PRU could not find enough memory to perform a function

or to initialize.

Action:

The user should make sure that there are no PRUs defined in the

application processor that do not need to be there. Document the problem,

record all action taken, and then contact NT.

0001/0001

Message:

[PRU_name] could not obtained sufficient memory to obtain

communication buffer pools. The number of buffers required = [decimal]. The

size of buffers required = [decimal]. The buffer pool identifier = [name]. User

action is required. [Two 80 character lines of optional data.]

Description:

The PRU could not find found enough memory to obtain

communication buffers.

Action:

The user should make sure that there are no PRUs defined in the

application processor that do not need to be there. Document the problem,

record all action taken, and then contact NT.

0001/0002

Message:

[PRU_name] could not add buffer memory pools to task. [Two 80

character lines of optional data.]

Description:

The PRU had trouble interacting with the memory manager.

The PRU should declare itself faulty.

Action:

Document the problem, and then contact NT.

0001/0003

Message:

[PRU_name] tried to register [name] with the name server but

failed. [Two 80 character lines of optional data.]

Description:

The PRU could not register its name with the name server

facility. No other PRU will be able to find this PRU through the name server

facility. The PRU does not necessarily have to declare itself faulty; it can

communicate using other means. This log indicates trouble with the name

server.

Action:

Reboot the PRU. If this action is unsuccessful, then reboot the SRU

in which the name server resides. Document the problem, record all action

taken, and then contact NT.

42 Common TOPS VSN log messages (020A)

TOPS VSN Log and alarm messages

0001/0004

Message:

[PRU_name] tried to locate [name] with the name server but failed.

[Two 80 character lines of optional data.]

Description:

The PRU could not find the name of the PRU or task it was

trying to locate using the name server facility. The PRU does not necessarily

have to declare itself faulty; it can communicate using other means. This log

indicates one of two problems: trouble with the name server, or that the PRU or

task does not exist.

Action:

If the entity exists make sure that it's state is "working". If the PRU or

task does exist, reboot it. If this action is unsuccessful, then reboot the SRU in

which the PRU resides. If the problem persists reboot the entire machine.

Document the problem, record all action taken, and then contact NT.

0001/0005

Message:

[PRU_name] tried to register with the DVS Resource Manager and

failed. Return code = [defined_below]. [Two 80 character lines of optional

data.]

Description:

When the PRU tries to register its name with the DVS Resource

Manager, a return code indicates the nature of the failure. Return codes are:

invalid address or not present, or Reg-Operation parameter is out of range.

Action:

When the return code indicates failure to communicate with the DVS

Resource Manager, reboot the PRU. If this action is unsuccessful, then reboot

the entire machine. Document the problem, and record all action taken. If the

problem persists, then contact NT.

0001/0006

Message:

[PRU_name] tried to perform an "rm_Request" with the DVS

Resource Manager and failed. Return code = [DVS_code]. [Two 80 character

lines of optional data.]

Description:

The PRU tried to perform a request with the DVS Resource

Manager but failed. The return code indicates the reason.

Action:

When the return code indicates failure to communicate with the DVS

Resource Manager, then reboot the PRU. If this action is unsuccessful, then

reboot the entire machine. Document the problem, and record all action taken.

If the problem persists, then contact NT.

0001/0007

Message:

[PRU_name] could not free memory. User action is required. [Two

80 character lines of optional data.]

Description:

The PRU or task was unable to perform because it could not

free enough memory.

Action:

Courtesy down the PRU, then return it to service. If this action does

not solve the problem, then reboot the SRU. Document the problem, and

record all action taken. If the problem persists, then contact NT.

0001/0020

Message:

[PRU_name] was attempting to perform an SDM "Init" and failed.

Error Type = [Helix_IO_result], Error Class = [1,2,3]. [Two 80 character lines of

optional data.]

Description:

When the PRU tries to initialize the Service Data Manager it fails.

Class error codes are: 1) run error, 2) task error, and 3) IO error.

Action:

This log should never occur. If it does, contact NT immediately.

Common Tops log messages (020A) DNC Logs 43

TOPS VSN Log and alarm messages

0001/0021

Message:

[PRU_name] was attempting to perform an SDM "Set Atomic

Commit" and failed. Error Type = [Helix_IO_result], Error Class = [1,2,3]. [Two

80 character lines of optional data.]

Description:

The PRU tries to set the atomic commit for a Service Data

Manager operation and fails. Class error codes are: 1) run error, 2) task error,

and 3) IO error.

Action:

This log should never occur. If it does, contact NT immediately.

0001/0022

Message:

[PRU_name] was attempting to perform an SDM "Add table

TransID" and failed. table Name = [SDM_table] Access Mode = [read only/read-

write]. Error Type = [Helix_IO_result], Error Class = [1,2,3]. [Two 80 character

lines of optional data.]

Description:

When the PRU tries to add a table to the Service Data Manager,

it fails. Class error codes are: 1) run error, 2) task error, and 3) IO error. The

error may be caused by a full internal array or a duplication in table names.

Action:

Record all information for NT.

0001/0023

Message:

[PRU_name] was attempting to perform an SDM "Set TNUM

TransID" and failed. Error Type = [Helix_IO_result], Error Class = [1,2,3]. [Two

80 character lines of optional data.]

Description:

The PRU tries to set TNUM transID for a Service Data Manager

operation and fails. Class error codes are: 1) run error, 2) task error, and 3) IO

error.

Action:

This log should never occur. If it does, contact NT immediately.

0001/0024

Message:

[PRU_name] was attempting to perform an SDM "Get TNUM

TransID" and failed. Error Type = [Helix_IO_result], Error Class = [1,2,3]. [Two

80 character lines of optional data.]

Description:

The PRU tries to get a TNUM transID for a Service Data Manager

operation and fails. Class error codes are: 1) run error, 2) task error, and 3) IO

error.

Action:

This log should never occur. If it does, contact NT immediately.

0001/0025

Message:

[PRU_name] was attempting to perform an SDM "Init TransID" and

failed. table Name = [SDM_table] Access Mode = [read only/read-write]. Error

Type = [Helix_IO_result], Error Class = [1,2,3]. [Two 80 character lines of

optional data.]

Description:

The PRU tries to initialize transID for a Service Data Manager

operation and fails. Class error codes are: 1) run error, 2) task error, and 3) IO

error.

Action:

This log should never occur. If it does, contact NT immediately.

0001/0026

Message:

[PRU_name] was attempting to perform an SDM "Start Transaction"

and failed. Error Type = [Helix_IO_result], Error Class = [1,2,3]. [Two 80

character lines of optional data.]

44 Common TOPS VSN log messages (020A)

TOPS VSN Log and alarm messages

Description:

The PRU tries to start a transaction with the Service Data

Manager and fails. Class error codes are: 1) run error, 2) task error, and 3) IO

error. This log indicates that another user has already opened some of the

required files or tables.

Action:

Record all information for NT.

0001/0027

Message:

[PRU_name] was attempting to perform an SDM "End Transaction"

and failed. Error Type = [Helix_IO_result], Error Class = [1,2,3]. [Two 80

character lines of optional data.]

Description:

The PRU tries to end a transaction with the Service Data

Manager and fails. Class error codes are: 1) run error, 2) task error, and 3) IO

error. The files or tables could not be committed.

Action:

Record all information for NT.

0001/0028

Message:

[PRU_name] was attempting to perform an SDM "Open table" and

failed. table Name = [SDM_table] Access Mode = [read only/read-write]. Error

Type = [Helix_IO_result], Error Class = [1,2,3]. [Two 80 character lines of

optional data.]

Description:

The PRU tries to open a Service Data Manager table and fails.

Class error codes are: 1) run error, 2) task error, and 3) IO error. The error may

be caused by a full internal array or when the table does not exist.

Action:

Record all information for NT.

0001/0029

Message:

[PRU_name] was attempting to perform an SDM "Add table" and

failed. SD table Name = [SDM_table], DD table Name = [data_dictionary_table],

File Name = [Helix_filename]. Error Type = [Helix_IO_result], Error Class =

[1,2,3]. [Two 80 character lines of optional data.]

Description:

The PRU tries to add a Service Data Manager table and fails.

Class error codes are: 1) run error, 2) task error, and 3) IO error. The error may

be caused by a full internal array or when the table has already been added.

Action:

Record all information for NT.

0001/002A

Message:

[PRU_name] was attempting to perform an SDM "Change table"

and failed. table Name = [SDM_table]. table change Type = [new_attribute/

new name/new DD name]. Error Type = [Helix_IO_result], Error Class = [1,2,3].

[Two 80 character lines of optional data.]

Description:

The PRU tries to change a Service Data Manager table and fails.

Class error codes are: 1) run error, 2) task error, and 3) IO error. This log is

generated when the table does not exist.

Action:

Record all information for NT.

0001/002B

Message:

[PRU_name] was attempting to perform an SDM "Delete table" and

failed. table Name = [SDM_table]. Error Type = [Helix_IO_result], Error Class =

[1,2,3]. [Two 80 character lines of optional data.]

Description:

The PRU tries to end a transaction with the Service Data

Manager and fails. Class error codes are: 1) run error, 2) task error, and 3) IO

error. This log is generated when the table does not exist.

Action:

Record all information for NT.

Common Tops log messages (020A) DNC Logs 45

TOPS VSN Log and alarm messages

0001/002C

Message:

[PRU_name] was attempting to perform an SDM "Read table" and

failed. table Name = [SDM_table]. Error Type = [Helix_IO_result], Error Class =

[1,2,3]. [Two 80 character lines of optional data.]

Description:

The PRU tries to read a Service Data Manager table and fails.

Class error codes are: 1) run error, 2) task error, and 3) IO error. This log is

generated when the table does not exist.

Action:

Record all information for NT.

0001/002D

Message:

[PRU_name] was attempting to perform an SDM "Add Tuple" and

failed. table Name = [SDM_table]. Tuple ID = [tuple_name]. Error Type =

[Helix_IO_result], Error Class = [1,2,3]. [Two 80 character lines of optional data.]

Description:

The PRU tries to add a tuple to a Service Data Manager table

and fails. Class error codes are: 1) run error, 2) task error, and 3) IO error. The

log may be generated when the tuple already exists in the table, or when the

table does not exist.

Action:

Record all information for NT.

0001/002E

Message:

[PRU_name] was attempting to perform an SDM "Change Tuple"

and failed. table Name = [SDM_table]. Tuple ID = [tuple_name]. Error Type =

[Helix_IO_result], Error Class = [1,2,3]. [Two 80 character lines of optional data.]

Description:

The PRU tries to change a tuple in a Service Data Manager table

and fails. Class error codes are: 1) run error, 2) task error, and 3) IO error. The

log may be generated when the tuple can not be found, or when the table does

not exist.

Action:

Record all information for NT.

0001/002F

Message:

[PRU_name] was attempting to perform an SDM "Delete Tuple"

and failed. table Name = [SDM_table]. Tuple ID = [tuple_name]. Error Type =

[Helix_IO_result], Error Class = [1,2,3]. [Two 80 character lines of optional data.]

Description:

The PRU tries to delete a tuple in a Service Data Manager table

and fails. Class error codes are: 1) run error, 2) task error, and 3) IO error. The

log may be generated when the tuple can not be found, or when the table does

not exist.

Action:

Record all information for NT.

0001/0030

Message:

[PRU_name] was attempting to perform an SDM "Read Tuple" and

failed. table Name = [SDM_table]. Tuple ID = [tuple_name]. Error Type =

[Helix_IO_result], Error Class = [1,2,3]. [Two 80 character lines of optional data.]

Description:

The PRU tries to delete a tuple in a Service Data Manager table

and fails. Class error codes are: 1) run error, 2) task error, and 3) IO error. The

log may be generated when the tuple can not be found, because the table

does not exits or when the table has been modified since the last transaction.

Action:

Record all information for NT.

46 Common TOPS VSN log messages (020A)

TOPS VSN Log and alarm messages

0001/0031

Message:

[PRU_NAME] could not interpret a triple read from the SDM.

Table name = [table_name]

Tuple ID = [tuple_name]

"Diagnostic String1"

"Diagnostic String2"

Description:

This log indicates an error in interpreting a field within the

specified tuple.

Action: Re-edit the tuple and verify that the fields are all of the correct type.

0001/0032

Message:

[PRU_NAME] was attempting to perform an SDM "notification

Registration" and failed.

Table name = <table_name>

"Diagnostic String1"

"Diagnostic String2"

Description:

This log indicates the SDM Notification server may be down or

faulty.

Action:

Ensure that the SDM Notification Server is in a working state. If the

problem persists, retain all of the information regarding the problem and contact

your NT representative.

47

TOPS VSN Log and alarm messages

8. Common TOPS VSN log

messages - 0020

0001/0000

Message:

[PRU_name] could not insert Control Link PRU in data structure. It

is full. Maximum number of control links supported = [max_number]

Description:

The maximum number of controls links the system can support

has been reached. The maintenance notice PRU is still working but will only

send notices to the first [max_number] control links up.

Action:

No action

0001/0001

Message:

[PRU_name] could not insert a maintenance notice in data

structure. Structure is full. Maximum number of notices supported =

[max_number].

Description:

The maximum number of maintenance notices the system can

support has been reached.

Action:

The user must delete some notices.

0001/0002

Message:

[PRU_name] could not insert a DMS-link tuple in data structure.

Structure is full. Maximum number of links supported is [max_number].

Description:

The maximum number of DMS-links the system can support

has been reached.

Action:

The user must delete some links.

49

TOPS VSN Log and alarm messages

9. Voice interface resource manager

log messages - 0220

0000/0000

Message:

Error encountered attempting to load DTMF patterns. The symbol

[symbol] is referenced in the table [table_name] but not found in the table

[table_name].

Description:

Applications can not access the VIs because of a reference

error in an SDM table. This table can not be accessed by the user.

Action:

Contact NT to correct the problem.

0000/0001

Message:

Error encountered attempting to load DTMF patterns.

Description:

Applications can not access the VIs because of a reference

error in an SDM table. This table can not be accessed by the user.

Action:

Contact NT to correct the problem.

0000/0002

Message:

VIRM has been unable to load DTMF patterns. The specific

problem encountered is described in another log.

Major

Description:

The Voice Interface Resource Manager could not load an SDM

table. Either the previous, but usually the log immediately following this one,

identifies the specific problem.

Action:

The problem identified in the qualifying log must be corrected.

When corrected, the VIRM must be reload. The alarm clears once this is done.

0000/0003

Message:

Any outstanding alarms generated by the VIRM have been cleared.

Description:

This log is generated every time the VIRM PRU is brought into

service. There may not be any outstanding alarms when the VIRM is brought

into service.

Action:

No action.

51

TOPS VSN Log and alarm messages

10. Alarm Subsystem - 8722

0001/0001 Message: Alarm Interface Unit has RECEIVED an external alarm.

External ALIU input is: <string>.

Explanation: The ALIU has sensed remote activation of an alarm condition.

The string stating the error is one of the following:

FAN 1 FAILURE

POWER CONVERTER 1 FAILURE

POWER CONVERTER 2 FAILURE

FUSE FAILURE

FAN 2 FAILURE

POWER CONVERTER 3 FAILURE

POWER CONVERTER 4 FAILURE

USER 1 INPUT

USER 2 INPUT

USER 3 INPUT

Action: The system should be serviced according to the troubleshooting

procedures in NTP 450-1011-501. System troubleshooting should only be

performed by qualified service personnel (that is, a system administrator or

maintenance technician).

0001/0002 Message: Alarm Interface Unit has RECOVERED an external alarm.

External ALIU input is: <string>.

Explanation: The ALIU has sensed the clearing of the externally generated

alarm. The string stating the error is one of the following:

FAN 1

POWER CONVERTER 1

POWER CONVERTER 2

FUSE

FAN 2

POWER CONVERTER 3

POWER CONVERTER 4

USER 1 INPUT

USER 2 INPUT

USER 3 INPUT

Action: No action required by the user.

0005/0001 Message: The alarm subsystem has lost communication with the APTIO

port. Please check the status of the APTIO port <port-name>.

Explanation: The link between the alarm subsystem and the "alarm box" has

been disconnected. The alarm box is a separate visual indicator of alarms.

52 Alarm Subsystem (8722)

TOPS VSN Log and alarm messages

Action: The system administrator must check the status of the APTIO port

according to NTP 450-1011-301. If the fault has not been detected at the

port, the operation of the LIU must be checked. It must also be determined

if the cabling from the DNC to the LIU is intact.

0005/0002 Message: The alarm subsystem has recovered communication with the

APTIO port. APTIO port <string>.

Explanation: The alarm subsystem was able to reconnect with the APTIO

port and is now functioning properly. The link between the alarm subsystem

and the alarm box has been restored and is functioning normally.

Action: No action required by the user.

0020/0000 Message: Unable to access disk "LOCAL".

Explanation: This log indicates that a communication error has occurred to

the local system disk. Call processing will not be interrupted. Locality calls

will be handled according to parameter LOC_DEFAULT_PROMPT in the

user interaction table.

Action: If the problem persists, retain all of the information regarding the

problem and contact your NT representative.

0020/0001 Message: I/O Error <I/O-error-number> saving log to disk.

The new alarm subsystem history file was created successfully.

Explanation: The alarm subsystem has recovered from the error situation by

creating a new history file and starting fresh. The original history file was

renamed from ALARMHIST to ALARMHIST.YY_MM_DD.

Action: No action required by the user.

0020/0002 Message: Unrecoverable I/O Error <I/O-error-number> saving log to disk.

Action may be required by the system administrator.

Explanation: The alarm subsystem could not recover from the error

situation by creating a new history file and starting fresh.

Action: A system administrator with superuser authority must remove the

current alarm history file :LOCAL:PRU:LOGS:HISTORY:ALARMHIST and

then reload the alarm subsystem PRU.

0020/0003 Message: The alarm subsystem disk task was unable to find its initialization

file: :LOCAL:PRU:LOGS:AL:ALINIT.TEXT. Default values have been

supplied.

Explanation: The alarm system's initialization file is probably missing from

the system. The alarm subsystem initializes itself using available default

values.

Action: A system administrator with superuser authority must check the load

tape for the presence of the initialization file and replace this file if

necessary.

0020/0004 Message: The Current Alarm Service history file is larger than that specified

in the initialization file ':LOCAL:PRU:LOGS:AL:ALINIT'. A new alarm

subsystem history file was created successfully.

Explanation: The alarm subsystem has created a new history file and is

starting fresh. The original history file was renamed from ALARMHIST to

ALARMHIST.YY_MM_DD.

Action: No action required by the user.

53

TOPS VSN Log and alarm messages

11. ACPE resource manager log

messages - 9440

0000/0000

Message:

[PRU_name] has detected the termination of an ACPE identified

as [dead_PRU_name] [dead_PRU_number]. [Number_of_calls] will be

terminated.

Description:

An ACPE PRU has died. All calls the ACPE was processing at

the time the PRU died, are lost. If the ACPE died because of a fault, an alarm is

sounded. If the ACPE died because it was courtesied down, then no alarm is

generated.

Action:

Verify in SAS that the ACPEs go into service.

0000/0001

Message:

[PRU_name] has detected the activation of an ACPE identified as

[act._PRU_name] [act._PRU_number].

Description:

An ACPE PRU has been brought into service.

Action:

No action.

0000/0002

Message:

Invalid call reference returned from the ACPE. Call returned: Tag =

[sent (ACPE-RM)_id_number], CallID = [returned_id_number], DMSref =

[DMS_CLLI], DMSID = [DMS_id], Voice Channel = [voice_channel_id].

Description:

The ACPE-RM made a request to the ACPE. When a

response was made by the ACPE, the identifying parameters did not match

those sent. The ACPE-RM ignored the response from the ACPE.

Action:

No action.

0000/0003

Message:

An illegal state transition occurred. Call affected was: Tag = [sent

(ACPE-RM)_id_number], CallID = [returned_id_number], DMSref =

[DMS_CLLI], DMSID = [DMS_id], Voice Channel = [voice_channel_id], Current

State = [current_call_state], Next State = [next_call_state].

Description:

This error should never occur.

Action:

No action.

0000/000A

Message:

SET entry invoked - Aborting a call. Call aborted is: CallID =

[returned_id_number], DMSref = [DMS_CLLI], DMSID = [DMS_id], Voice

Channel = [voice_channel_id].

Description:

The call has been manually aborted.

Action:

No action.

0000/000B

Message:

SET entry invoked - Making an ACPE inactive. The ACPE made

inactive was: [PRU_name] [PRU_number]. New load is: [load_id].

Description:

The ACPE PRU has been made inactive manually.

54 ACPE Resource Manager Log Messages (9440)

TOPS VSN Log and alarm messages

Action:

No action.

0000/000C

Message:

SET entry invoked - Changing the load on an ACPE. The ACPE

was: [PRU_name] [PRU_number].

Description:

The ACPE load has been set manually. This value is reset by

the next interaction with the ACPE.

Action:

No action.

0000/000F

Message:

SET entry invoked - The ObjectID passed is not supported. Object

Type was: [object_type]. Object Index was: [object_index].

Description:

The object is not curently supported.

Action:

No action.

0000/0010

Message:

SET entry invoked - Set on "call" failed. Call reference did not

match an active call.

Description:

The "set" did not operate properly. Invalid data was sent.

Action:

No action.

0000/0011

Message:

SET entry invoked - Set on "de-activating an ACPE" failed. PRU

number did not match an active ACPE.

Description:

The "set" did not operate properly. Invalid data was sent.

Action:

No action.

0000/0012

Message:

SET entry invoked - Set on "setting load" failed. PRU number did

not match an active ACPE.

Description:

The "set" did not operate properly. Invalid data was sent.

Action:

No action

0000/0013

Message:

SET entry invoked - Set on "setting load" failed. The load value

must be between 0 ..100.

Description:

The "set" did not operate properly. Invalid data was sent.

Action:

No action.

0000/0014

Message:

SET entry invoked - Set on "algorithm selection" failed. PRU

number did not match an active ACPE.

Description:

The "set" did not operate properly. Invalid data was sent.

Action:

No action.

0000/0015

Message:

SET entry invoked making an ACPE ACTIVE. The ACPE made

active was :[PRU_NAME], <ACPE_location>

Description:

This log indicates that an ACPE has been manually set to active.

Action:

No action required.

0000/0027

Message:

<PRU_name> (Tokenizer) Disk status over threshold. Stopping

collection.

Description:

Sample data collected is not written to disk because it is full.

The daily audit cleans the disk of sample data, at which time sample data is

written to disk again. Call processing continues as usual and no effect to

service is seen.

Action:

No action.

ACPE Resource Manager Log Messages (9440) 55

TOPS VSN Log and alarm messages

0000/0028

Message:

<PRU_name> (Tokenizer) Disk status is now lower than threshold.

Will start collection.

Description:

Sample data collected is now written to disk. The daily audit

has made room for new sample data. Call processing continues as usual and

no effect to service is seen.

Action:

No action.

0000/002A

Message:

<PRU_name> Tokenizer logged into server. Collection will start.

Server name = <server_id>.

Description:

Sample data is collected via server. Call processing continues

as usual and no effect to service is seen.

Action:

No action.

0000/002B

Message:

<PRU_name> Tokenizer located file server. Collection will start.

Server name = <server_id>.

Description:

File server has been located. File server is required for the

collection of sample data. Call processing continues as usual and no effect to

service is seen.

Action:

No action.

0001/0004

Message:

[PRU_name] could not query the ACPE [queried_PRU_name], for

its loading. The length of data returned did not match the length requested.

Description:

There has been a data mismatch between the ACPE-RM and

the ACPE. This mismatch is probably the result of incompatible PRU versions.

Action:

Both the ACPE-RM and the ACPE should be reloaded from tape,

and then brought back into service. Keep a record of the error for NT.

0001/0005

Message:

[PRU_name] could not query the ACPE [queried_PRU_name], for

its calls. The length of data returned did not match the length requested.

Description:

There has been a data mismatch between the ACPE-RM and

the ACPE. This mismatch is probably the result of incompatible PRU versions.

Action:

Both the ACPE-RM and the ACPE should be reloaded from tape,

and then brought back into service. Keep a record of the error for NT.

0001/0006

Message:

[PRU_name] has filled up it's table for handling ACPEs.

[PRU_name_2] will not be added. The maximum number of supported ACPEs

is <number>.

Description:

A maximum number of ACPEs are supported. The maximum

number has been reached and all others brought into service are ignored.

Action:

No action.

0001/0007

Message:

[PRU_name] has filled up it's table for handling calls. The maximum

number of supported calls is <number>.

Description:

A maximum number of calls are supported. The maximum

number has been reached and all others presented to the PRU are ignored.

Action:

No action.

0001/0020

Message:

[PRU_name] could not get a heap for the tokenizer task. No token

could be issued. [Two 80 character lines of optional data.]

Description:

Unable to issue tokens. Call processing continues as usual

and no effect to service is seen.

56 ACPE Resource Manager Log Messages (9440)

TOPS VSN Log and alarm messages

Action:

No action.

0001/0021

Message:

[PRU_name] Non success return from tokenizer task, from INIT

entry. No tokens will be issued. [Two 80 character lines of optional data.]

Description:

Unable to issue tokens because of unsuccessful return code

from tokenizer. Call processing continues as usual and no effect to service is

seen.

Action:

No action.

0001/0022

Message:

[PRU_name] Exception entry invoked. All tokens will be turned

off. [Two 80 character lines of optional data.] Error Class = <class_id>. Error

Type = <type_id>.

Description:

Unable to issue tokens and all issued tokens are stopped

because of exceptional entry. Call processing continues as usual and no effect

to service is seen.

Action:

No action.

0001/0023

Message:

[PRU_name] Tokenizer read an invalid server name. table =

TOKEN CONTROL. Server name = <server_id>.

Description:

Unable to issue tokens because of an invalid server name was

read. Call processing continues as usual and no effect to service is seen.

Action:

No action.

0001/0024

Message:

[PRU_name] Tokenizer read an invalid entry in a table. table =

TOKEN SCHEDULE. Key = <key_id>.

Description:

Unable to issue tokens because an invalid table entry was read.

Call processing continues as usual and no effect to service is seen.

Action:

No action.

0001/0025

Message:

[PRU_name] Tokenizer obtained a zero volume size from the

server name.

Description:

The tokenizer encountered an invalid volume size. Call

processing continues as usual and no effect to service is seen.

Action:

No action.

0001/0026

Message:

[PRU_name] Tokenizer encountered an invalid directory name.

Directory name = <directory_id>.

Description:

The tokenizer encountered an invalid directory name. Call

processing continues as usual and no effect to service is seen.

Action:

No action.

0001/0029

Message:

[PRU_name] Tokenizer could not log into server. Server name =

<server_id>.

Description:

The tokenizer had problems logging into the server. Call

processing continues as usual and no effect to service is seen.

Action:

No action.

57

TOPS VSN Log and alarm messages

12. Control link log messages - 9441

0000/0000

Message:

Data Link [link_identifier] to DMS [common_language_location

_identifier] is in service.

Description:

This log is generated when the X.25 Control Link has been

reset. At initialization time this log is considered a normal occurrence. At any

other time it is not. Data may have been lost depending on the activity in

progress at the time of the reset.

Action:

No action is required. The condition indicates that a link is now

available. If data was lost, if cannot be recovered.

0000/0001

Message:

Data Link [link_identifier] to DMS [common _language_location

_identifier] is out of service. Reason = [reason].

Description:

This log is generated when the X.25 Control Link is no longer

available for use. Data may have been lost depending on the activity in

progress at the time of the reset. The reason may be one of the following: 1)

X.25 PRU managing link is down ( The X.25 PRU is out of service), or 2) Link is

down (X.25 service associated with the physical link has been reset and is no

longer available).

Action:

No action is required if within 30 seconds a log is generated

indicating that the specified data link is now available. If this log does not follow,

check all physical connections. If all are in good order, the problem is likely

associated with a DMS failure (i.e.. MPC card). If the reason given is X.25 PRU

Failure, the PRU must be returned to service. If a return to service does not

happen automatically, it means the maximum fault count limit has been

exceeded. This indicates that the processor is in trouble.

0000/0002

Message:

Data Link PRU has bad initialization data.

Reason = [reason].

4

Description:

This log is generated when invalid data has been found in

"Datalink_Config" or "VSN_System" tables for a particular Data Link (DL) PRU.

The reason given may be one of the following: 1) too many links (more than 4

links have been configured for each DL PRU), 2) Data Link tables are missing 3)

no links defined in tables (no links are defined in Datalink_Config table), 4) X.25

PRU referenced in table does not exist (the X.25 PRU number in Datalink

Config table does not exist), 5) no call sanity timeout parameter defined in

VSN_System table, 6) No maximum calls allowed parameter defined in

VSN_System table, 7) no VSN identifier defined in VSN_System table, 8) two

different DMS CLLIs defined for one Data Link PRU.

Action:

Modify data entry in Datalink_Config or VSN_System tables, then

reinitialize the failed DL PRU.

58 Control Link Log Messages (9441)

TOPS VSN Log and alarm messages

0000/0003

Message:

A Datalink message was discarded. Destination = [DMS_or_VSN].

Reason = [reason].

Message Type = [message_type].

Description:

This log is generated when the X.25 Datalink software

encounters a problem sending a message. The reason is one of the following:

1) Message type received from application is not supported, 2) Message type

received on link is not supported, 3) problem relaying message to X.25

(outgoing message could not be sent to X.25 for transmission), 4) too many

messages for Datalink PRU to manage (PRU has received more messages than

it can send out), 5) problem relaying message to VSN application (message

received by AABS could not be relayed to VSN), 6) attempt to send message to

a DMS that is not supported, 7) attempt to send message with invalid callID.

Action:

If both data links have failed, then reboot the PRUs involved. If the

problem is not failed data links, contact NT for support.

0000/0004

Message:

Datalink PRU received a message from an unknown link. Software

location = [message_received_by].

4

Description:

This log indicates a serious internal problem. The location

given may be either 1) xmtHandler (Datalink's transmit handler), or 2) nData

Reply (Datalink's X.25 data acknowledgement entry).

Action:

Contact NT immediately.

0000/0005

Message:

Data Link PRU encountered an event while in an incorrect internal

state.

Event = @ & 27* current state = @ & 27*

Description:

This log indicates that a Datalink PRU encountered an event

that should not have happened while in its current internal state. This may

indicate an internal problem.

Run Time Parameters (RTP)

First RTP is a string indicating what the new event is.

Second RTP is a string indicating what the current state is.

Action:

If the problem persists, retain all of the information regarding the

problem and contact your NT representative.

0000/0006

Message:

Datalink PRU's outgoing message queue reached a module 10

length. Number of messages in queue = [num_message].

4

Description:

The Datalink PRU maintains a queue of messages that are

outbound, that is destined for the DMS. When this queue grow large, some

delays may occur in user interaction. This log indicates how large this queue

has grown when it reaches a size which is a multiple of 10.

Action:

No action required. This message is for informational purposes only.

0000/0007

Message:

An outgoing message was in the Data Link PRU's queue for an

abnormally long time. Time in milliseconds = [time].

4

Description:

The Datalink PRU maintains a queue of messages that are

outbound, that is destined for the DMS. When this queue grow large, some

delays may occur in user interaction. This log indicates how long a message has

been in the queue before it was transmitted if the time is greater than 3

seconds.

Action:

No action required. This message is for informational purposes only.

59

TOPS VSN Log and alarm messages

13. Application call processing

engine log messages - 9442

0000/0000

Message:

<PRU_name>, has just become operational. Call processing

capacity of this ACPE is now 24 out of 24 calls. All pending minor alarms against

this ACPE PRU will be cleared. [Two 80 character lines of optional data.]

Description:

This log is generated each time the ACPE is rebooted. If there

were alarms pending against the PRU they are cleared.

Action:

No action.

0000/0001

Message:

<PRU_name>, Initialization sequence aborted. Error or

inconsistency encountered while loading ACPE initialization data. [Two 80

character lines of optional data.]

Description:

An error or inconsistency was found in ACPE datafill. The

additional information is provided for NT, not operating company personnel.

Action:

Contact NT immediately.

0000/0002

Message:

<PRU_name>, Initialization error occurred; ACPE PRU initialization

sequence aborted. [Two 80 character lines of optional data.]

Description:

An error occurred while initializing the ACPE PRU. The

additional information is provided for NT, not operating company personnel.

Action:

Contact NT immediately.

0000/0100

Message:

<PRU_name>, encountered a call error. Automatic recovery will be

initiated. Other calls being processed by this ACPE should not be affected.

[Two 80 character lines of optional data.]

Description:

The error has only affected a single subscriber call. The ACPE

should recover itself. If this log is generated many times in a short period of

time, the ACPE has encountered a serious error and can not recover

automatically.

Action:

No action is required if this event occurs periodically. If this log

occurs often over a short period of time, take the ACPE PRU out of service, and

then return it to service.

0000/0102

Message:

<PRU_name>, has noted a call event. Calls in progress and new

calls should not be affected. [Two 80 character lines of optional data.]

Description:

The ACPE is simply reporting an anomaly.

Action:

No action.

0000/0103

Message:

<PRU_name>. Automatic recovery of a failed call has been

initiated. The call will be aborted/rejected as appropriate. [Two 80 character

lines of optional data.]

60 Application Call Processing Engine Log Messages (9442)

TOPS VSN Log and alarm messages

Description:

The ACPE is beginning automatic recovery. The failure has

only affected one subscriber call. If this log is generated many times in a short

period of time, the ACPE has encountered a serious error and can not recover

automatically.

Action:

No action is required if this event occurs periodically. If this log

occurs often over a short period of time, take the ACPE PRU out of service, and

then return it to service.

0000/0104

Message:

<PRU_name>, has encountered a serious error. The ACPE has

encountered a serious error which it cannot recover from. It will continue to

process calls, but at a diminished capacity. A minor alarm will be generated,

which can be cleared by rebooting this ACPE PRU. [Two 80 character lines of

optional data.]

Minor

Description:

The ACPE has encountered problems that have affected its

capacity to process calls.

Action:

No immediate action is required since the ACPE is still capable of

processing calls. When capacity is too low, reboot the PRU.

0000/0105

Message:

<PRU_name>, has detected a fatal error. This ACPE PRU has

detected a serious problem which prevents it from continuing to operate. Any

calls being processed will be aborted. [Two 80 character lines of optional data.]

Description:

The ACPE has encountered a serious problem. All calls being

processed at the time of the problem have been aborted. The ACPE PRU is

automatically rebooted by the system.

Action:

No immediate action is required because the PRU is rebooted

automatically. If the problem persists contact NT with a record each time the

problem occurred.

0000/0106

Message:

<PRU_name>, has encountered a serious error.

Description:

The ACPE has detected that the locality database is no longer

in service. All calls will continue to be processed; locality calls will be handled

according to the datafill of parameters of the field Locality_Check and

Loc_Default_Prompt in table User Interaction. [Two 80 character lines of

optional data]

Action:

No immediate action is required because the ACPE continues to

process calls, but at a reduced capacity.

0000/0107

Message:

<PRU_name>, Event

Description:

The ACPE has detected that the locality database is returning

to service. The ACPE will process locality calls when the Locality Database is in

the Working state.

Action:

No action is required.

0000/0108

Message:

<PRU_name>,Locality Prompt Too Long.

Description:

The ACPE could not play the locality prompt for this call

because it exceeds the maximum length that is currently handled (16,000

bytes, approximately 7.5 seconds). This call is handled according to the datafill

of parameter Loc_Default_Prompt in table User Interaction.

Action:

Shorten the prompt by using the Prompt Manager to eliminate the

pre-prompt silence or the post-prompt silence. If this procedure is not

adequate, a different prompt should be created.

Application Call Processing Engine Log Messages (9442) 61

TOPS VSN Log and alarm messages

0003/0001

Message:

ACPE error. Unable to initialize; duplicate datafill detected during

executor initialization: [duplicate_data_string] reading SDM table:

[table_name].

Description:

This log is generated if a duplicate string is detected by the

ACPE when reading an SDM table. This means there is ambiguous reference

in the datafill. The ACPE can not go into a working state.

Action:

Change the datafill for one of the entries. (The location of the

duplicate data is given. The first occurrence of the data string is not specified.)

0003/0002

Message:

ACPE error. Unable to initialize; unresolved reference:

[offending_reference] in SDM table: [table_name].

Description:

This log is generated when datafill in the specified table

references a symbol that cannot be found. The ACPE cannot go into a working

state.

Action:

The unresolved reference must be corrected. (The locations in

which the search took place are unspecified.)

0003/0003

Message:

ACPE error. Unable to initialize SDM table: [table name] is too

large. Maximum size is [number_of_entries].

Description:

This log is generated when the number of entries in a table

exceeds the maximum. The existing data structure is unable to hold all the data.

Action:

Reduce the size of the table. The maximum table size is hard coded

and cannot be changed.

0003/0004

Message:

ACPE detected Voice Interface error. [Error_type_detected].

Source of error was Voice Interface SRU located at cabinet [number], slot

[number], channel [number]. VI error code: [decimal], Executor Involved:

[executor_name].

Description:

This log is generated when the Voice Interface (VI) returns an

error condition that is not caused by user interaction. The call is usually aborted.

The [error_type_detected] gives a brief description of the error.

Action:

No action. If the problem persists, it may be necessary to change the

specified voice channel or the whole SRU.

0003/0005

Message:

ACPE error. A parameter error was detected by the executor

[executor_name]. Debugging Information: [parameter/value].

Description:

This log is generated when an executor detects an error in an

input parameter.

Action:

Contact NT

0003/0006

Message:

ACPE error. An attempt was made to concatenate two different

coding methods. The prompts were: [segment_file_1] and [segment_file_2].

Debugging Information: [parameter/value].

Description:

This log is generated when a MPLPC-coded prompt is

concatenated with a prompt coded in PCM.

Action:

Record all information and report the problem to NT.

0003/0008

Message:

ACPE error. An attempt has been made to allocate more

[procedure_variable_type] procedures than the associated data structure can

hold. This indicates that there was an error while creating the ACPE. The

maximum number of provars permitted in the structure is [number].

62 Application Call Processing Engine Log Messages (9442)

TOPS VSN Log and alarm messages

Description:

This log is generated when to many procedure variables have

been added to the ACPE data structure. The ACPE will not load.

Action:

Record all information and report the problem to NT.

0003/0009

Message:

ACPE error. A software error has been detected. See the debug

information for details. Debugging Information: [parameter/value].

Description:

This log is generated when there is an error in the code.

Action:

Record all information and report the problem to NT.

0003/000A

Message:

ACPE error. The maximum number of OMs, [number], which may

be declared in the SDM table [table_name] has been exceeded.

Description:

This log is generated when there are too many entries in a

specific table.

Action:

Record all information and report the problem to NT.

0003/000B

Message:

ACPE error. An unknown action string [offending_string] has been

found in the SDM table [table_name]. As a result the ACPE will not load.

Description:

This log is generated when an unknown screening code action

has been specified in an SDM table. The ACPE will not load.

Action:

Correct the screening code error using the help information in the

table editor.

0003/000C

Message:

ACPE error. An invalid screening code [offending_code] has

been found in the SDM table [table_name]. As a result the ACPE will not load.

Description:

This log is generated when an invalid screening code action

has been specified in an SDM table. The ACPE will not load.

Action:

Correct the screening code error using the help information in the

table editor.

0003/000D

Message:

ACPE error. The silence prompt for PCM/MPLPC was not loaded

but was referenced.

Description:

This log is generated when a silence should be played

between concatenated prompts but has not been loaded. The ACPE will not

load.

Action:

Record all information and report the problem to NT. The silence

must be loaded or all references to the silence must be deleted.

0003/000E

Message:

ACPE error. Unable to allocate VI channel for call. Call was

rejected. The template set requested was [template_name]. Debugging

Information: VIRM code: [decimal].

Description:

This log is generated when there are no VI channels available

to handle the call. Typically this log means that some channels are out of

service.

NOTE: This log occurs very often when channels are out of service, therefore

thresholding has been set at 100 over a period of two minutes. Thresholding

can be changed to suit the conditions.

Action:

Restore the VI channels that are down. If more than eight channels

are down, the SRU may be faulty. If the SRU is faulty replace it with the spare. If

the channels will be down for an extended period, the thresholding can be

changed or the whole log suppressed.

Application Call Processing Engine Log Messages (9442) 63

TOPS VSN Log and alarm messages

0003/000F

Message:

ACPE error. Unable to allocate T1 channel for call. Call was

rejected. The CLLI of the DMS from which the call originated was [DMS_CLLI].

The voice channel on which the call was received was [channel_id]. Debugging

Information: T1RM code: [decimal].

Description:

This log is generated by the T1 Resource Manager when it is

unable to allocate T1 resources for the call. The T1RM return code is given.

Action:

No action is required.

0003/0010

Message:

ACPE error. Unable to connect VI channel to voice channel via the

VNM. Debugging Information: VNM code: [decimal].

Description:

This log is generated by the Voice Network Manager when it is

unable to connect the T1 to the VI. The VNM return code is given.

Action:

No action is required, but the error should be reported to NT.

0003/0011

Message:

ACPE error. Unable to release VI speech slave in cabinet

[cabinet_number], slot [slot_number] and channel [channel_id]. Debugging

Information: VI code: [decimal].

Description:

This log is generated by the VI. It is automatically reported to

the VI Resource Manager. It may indicate problems with the VI channel.

Action:

No action is required.

0003/0012

Message:

ACPE error. Error encountered while attempting to release the

voice bus slots being used by both the VI channel at cabinet [cabinet_number],

slot [slot_number] and channel [channel_id] and a T1 channel. Debugging

Information: VNM error code: [decimal].

Description:

This log is generated by the Voice Network Manager (VNM)

when it determines that slots have not been allocated for the T1 and VI. This

assessment by the VNM may not be accurate. The log indicates that the

release of the voice bus slots failed.

Action:

No action is required.

0003/0013

Message:

ACPE error. Error encountered while attempting to release a T1

channel. Debugging Information: T1RM error code: [decimal].

Description:

This log is generated when unexpected code is received by

the T1 Resource Manager during a release attempt.

Action:

No action is required.

0003/0014

Message:

ACPE error. Error encountered while attempting to release THE VI

channel at cabinet [cabinet_number], slot [slot_number], channel [channel_id].

VIRM error code: [decimal].

Status

Description:

This log is generated when unexpected code is received by

the AudToMem routine. This error may indicate a memory problem.

Action:

No action is required.

0003/0015

Message:

ACPE error. Unable to load prompts from audio files. The error

was not an I/O error. Error code from routine AudToMem: [decimal].

Status

Description:

This log is generated when unexpected code is received by

the VI Resource Manager during a release attempt.

Action:

Contact NT immediately.

0003/0016

Message:

no locality processing available for current call

64 Application Call Processing Engine Log Messages (9442)

TOPS VSN Log and alarm messages

Description:

The ACPE could not determine the locality treatment for the

current call because the Locality Database is either a new set of locality prompts,

or a new set of locality prompts is being saved. This call will be handled

according to the datafill of parameters Locality_Check and Loc_Default_Prompt

in table User Interaction.

Action:

No immediate action is required because the ACPE continues to

process calls,(at a diminished capacity).

0003/0017

Message:

no locality call processing for current call.

Description:

The ACPE could not determine the locality treatment for the

current call because the Locality Database is not in the Working state. This call

will be handled according to the datafill of parameters Locality_Check and

Loc_Default_Prompt in table User Interaction.

Action:

No action is required because the ACPE continues to process

calls,(at a diminished capacity).

0003/001A

Message:

[PRU_NAME], error. An invalid name plus locality mode, <invalid

mode>, has been found in table "LOC_SCREEN_CODES". As a result ACPEs

will not load.

Description:

This log indicates that the valid values for the name plus locality

mode field are given in the help information in the table editor.

Action:

The table must be corrected before the ACPEs will load.

0003/0018

Message:

ACPE failed to communicate with the Locality Database.

Description:

This call will be handled according to datafill of the parameters

Locality_Check and Loc_Default_Prompt in table User Interaction. Debugging

information is provided.

Action:

No action is required because the ACPE continues to process

calls,(at a diminished capacity).

0003/0200

Message:

State table log

Description:

This is a log that is generated by the state table for application

TABS. Two lines of state data are provided.

Action:

Action as indicated in the message.

0003/0201

Message:

Log generated by state table for application <TABS>. [Call

abnormally terminated. See trace back for detail.]

Current state : <state code> via input: <event #>

Called from : <state code> via input: <event #>

Status

Description:

This log is generated by the state table when it encounters an

error during an event sequence.

Action:

Contact NT immediately. Record the state and event codes listed in

the log and report them to the NT representative.

65

TOPS VSN Log and alarm messages

14. T1 resource manager log

messages - 9443

0000/0000

Message:

[PRU_name] reports internal software error. [Two 80 character

lines of optional data.]

Description:

The identified PRU is reporting a fatal internal error. The

reason for the error may one of many (too many to list) but is clearly identified in

the body of the message.

Action:

Document the error and message precisely, and then contact NT.

The PRU must be reloaded.

0000/0001

Message:

[PRU_name] reports administration error. Error = [string]. [Two 80

character lines of optional data].

Description:

The identified PRU is reporting an administration error. The

reason for the error is one of the following: 1) Operation successful, 2) Bad

parameter used, 3) Object versions do not match, 4) Object already exists, 5)

Object not marked, 6) Object marked by another session, 7) Object marked by

user profile editor, 8) File contains maximum number of objects, 9) Failed to

apply an update session, 10) Object name not found, 11-14) Obsolete, 15)

Administration is busy notifying registered tasks, 16) Administration cannot get

sufficient memory space.

Action:

Make sure that T1 SRU configuration data is initialized.

Configuration data is accessed from Digital Trunk Link under SAS configuration.

(When attempting to save configuration data from T1 Maintenance the Digital

Trunk Link configuration agent must not be active.)

0000/0002

Message:

[PRU_name] reports software error for T1 SRU in Cabinet

[ID_number], Slot [Id_number]. [Two 80 character lines of optional data.]

Description:

The identified PRU is reporting a software error in the T1 SRU.

The reason for the error is one of the following: 1) Failed to locate configuration

data for T1 SRU, 2) Failed to locate trunk mapping data for T1 SRU, 3) Fatal error

detected in the T1 audit task. Task exiting, 4) Fatal error in call processing task.

Task exiting, 5) Call Processing task for T1 SRU has exited. Task restarting, 6)

Call processing task for T1 SRU has exited. Task cannot be restarted, 7) Audit

task for T1 SRU has exited. Task restarting, 8) Audit task for T1 SRU has exited.

Task cannot be restarted, 9) Failure in trunk status query to T1 SRU, 10) Failure

in trunk timeslot query to T1 SRU.

Action:

Make sure that T1 configuration data has been initialized. Record all

information and report it to NT,

0000/0003

Message:

[PRU_name] reports a T1 maintenance error. [Two eighty

character lines of system generated information.]

66 T1 Resource Manager Log Messages (9443)

TOPS VSN Log and alarm messages

Description:

A T1 Maintenance error has been reported.

Action:

Exit, then re-access T1 Maintenance.

0001/0000

Message:

T1 Link Error for T1 SRU in Cabinet [cabinet_id], Slot [slot_id].

Condition = [string]. Error Level = [string].

Description:

There is a link error for the T1 SRU at the specified location.

The reason (condition) for the error is one of the following: 1) Bipolar violation,

2) Frame slip, 3) Frame loss, 4) Frequency converter unlock, 5) VBus collision,

6) Line fail, 7) Transmit clock fail, 8) 5ms clock, 9) Peripheral loopback, 10)

Yellow alarm, 11) Red alarm, 12) A/B buffer overrun.

The error level is one of the following: 1) Error Cleared, 2) Maintenance Limit

Attained, 3) Out-of-service limit attained. If the maintenance level is reached,

the link is still operational. If the out-of-service limit is reached, the T1 link is

taken out of service.

Action:

Adjust thresholds using digitial trunk link configuration service.

Make sure that the synchronization manager is operational, and that the T1 link

is connected properly.

0001/0001

Message:

T1 Link Event for T1 SRU in Cabinet [cabinet_id], Slot [slot_id].

Event = [string].

Description:

There is a link event for the T1 SRU at the specified location.

The event is either of the following: 1) Channels reconnected for T1 link, or 2)

Channels disconnected for T1 link. When the channels have been

disconnected all voice channels have been taken out of service. When the

channels have been reconnected, the number of voice channels specified by

the maintenance limit are available for use.

Action:

Refer to previous log for direction.

0002/0000

Message:

Voice Link Event for T1 SRU. Event = Link placed in Standby

BusiedOut\Standby Inservice\\state.

Global Event

Description:

One of the T1 links has experienced a change in state. If a link

is placed “StandBy BusiedOut” or “Standby InService”, the state change is

normal and has been made either by program control or as requested through

T1 Maintenance.

Action:

First RTP is an integer (decimal) indicating the cabinet number of the

T1. Next RTP is an integer (decimal) indicating the slot number of the T1. Next

number is an integer (selector) specifying the event.

0002/0001

Message:

Voice Trunk Event for T1 SRU in Cabinet [cabinet_id], Slot

[slot_id]. Channel = [channel#_id]. Event = [string]. DMS CLLI = [DMS_id],

Trunk ID = [trunk_id].

Description:

One of the following voice trunk events occurred for the T1

SRU at the specified location: 1) Trunk placed in remote answer state, 2) Trunk

placed in remote seized state, 3) Trunk placed in seize failure state, 4) Trunk

placed in trunk failure state, 5) Channel allocation failure. Trunk not found in T1

configuration, 6) Channel allocation failure. Trunk not available (not inservice),

7) Call aborted on trunk due to T1 failure or T1 maintenance action,

Action:

If trunk state is remote answer or remote seized, clear condition by

making the far-end go on-hook. If trunk state is seize failure or trunk failure,

clear error through T1 maintenance. If trunk state indicates an allocation

problem, make sure that the DMS CLLI and TrunkID are correctly datafilled

under the Digital Trunk Link configuration service.

T1 Resource Manager Log Messages (9443) 67

TOPS VSN Log and alarm messages

0003/0000

Message:

[PRU_name] has cleared any outstanding T1 Voice Link Alarms.

Description:

This log is generated each time the PRU is rebooted. If there

were alarms pending against the PRU they are cleared.

Action:

No action.

0003/0001

Message:

Voice Link Alarm Event for T1 SRU. Event = Major alarm set for

failed Standby InService link.

Major

Description:

A Major Alarm has been set for failed (SysBusy) T1 link.

Action:

Clear the alarm by causing the link to leave the SysBusy state - either

by clearing the error condition, rebooting the T1 SRU, reconfiguring the link to

Offline, or by removing the SRU from the System Map under SAS -

CONFIGURATION. User action is required.

First RTP is an integer (decimal) indicating the cabinet number of the T1. Next

RTP is an integer (decimal) indicating the slot number of the T1. Next number is

an integer (selector) specifying the event.

0003/0002

Message:

Voice Link Alarm Event for T1 SRU. Event = Major Alarm Cleared

for Standby InService link..

Description:

A Major Alarm has been cleared for a T1 link.

Action:

No action is required.

First RTP is an integer (decimal) indicating the cabinet number of the T1. Next

RTP is an integer (decimal) indicating the slot number of the T1. Next number is

an integer (selector) specifying the event.

0003/0003

Message:

Voice Link Alarm Event for T1 SRU. Event = Minor Alarm set for

Standby BusiedOut link.

Minor

Description:

A Minor Alarm has been set for a failed (SysBusy) T1 link.

Action:

Clear the alarm by causing the link to leave the SysBusy state, either

by clearing the error condition, rebooting the T1 SRU, reconfiguring the link to

Offline, or by removing the SRU from the System Map under SAS -

CONFIGURATION. User action is required.

0003/0004

Message:

Voice Link Alarm Event for T1 SRU in Cabinet. Event = Minor

Alarm Cleared for Standby BusiedOut link..

Description:

A Minor Alarm has been cleared for a T1 link.

Action:

No action is required.

69

TOPS VSN Log and alarm messages

15. Locality database log messages -

944E

0000/0000

Message:

The Locality Database has just become operational. Locality

queries can now be processed. Any pending minor alarms against the Locality

Database have been cleared.

Description:

This is an information message only.

Action:

None.

0000/0001

Message:

The LDB has detected a serious problem which prevents it from

initializing.

"Diagnostic String 1"

"Diagnostic String 2"

Description:

A serious error was encountered by the LDB PRU during

initialization. The LDB PRU will be automatically rebooted by the system. The

first diagnostic string describes the nature of the problem, and the second

diagnostic string gives more information on the problem.

Action:

No action is required unless the condition persists.

0000/0002

Message:

The LDB has detected a serious problem in initialization in either a

query handler or the MMI which it cannot recover from. Initialization will

continue. A minor alarm will be generated, which can be cleared by rebooting

the LDB PRU or from the Alarm Query MMI.

"Diagnostic String 1"

"Diagnostic String 2"

Description:

The first diagnostic string describes the nature of the problem.

This string will indicate whether the log concerns a query handler or the MMI. If

it concerns a query handler, it will show the current number of query handlers.

The second diagnostic string gives more information about the problem.

Action:

No explicit action is required immediately, as the LDB can continue

with initialization, but with diminished capacity, as indicated in the log message.

If the query processing capacity is too low, or if the MMI processing has failed,

the LDB PRU should be rebooted.

0000/0003

Message:

The Locality DataBase has detected a problem in initialization of

Custom Branding information. Initialization will continue.

"Diagnostic String 1"

"Diagnostic String 2"

70 Locality Database Log Messages (944E)

TOPS VSN Log and alarm messages

Description:

The diagnostic strings, which are filled by the LDB PRU,

describe the nature of the problem. The problem reported may be with the

custom branding information found in the Custom Brands and Carrier Brands

SDM tables, or in the Locality Database brand index fields. These problems may

be the result ofi references to non-existent branding segment prompts in the

Locality Database, references to non-existent brand indexes, and lack of data

store memory.

Action:

No explicit action is required immediately, as the LDB can continue

with initialization, as the Locality Database can continue with initialization.

Correct the problem and reboot the Locality Database to restore Custom

Branding service.

0000/0102

Message:

The LDB has encountered a serious error which it cannot recover

from in either a query handler or the MMI. It will continue to process LDB

queries, but at a diminished capacity. A minor alarm will be generated, which

can be cleared by rebooting the LDB PRU.

"Diagnostic String 1"

"Diagnostic String 2"

Description:

The first diagnostic string describes the nature of the problem.

This string will indicate whether the log concerns a query handler or the MMI. If it

concerns a query handler, it will show the current number of query handlers.

The second string contains more information on the problem.

Action:

No explicit action is required immediately, as the LDB can continue to

process queries, but with diminished capacity, as indicated in the log message.

If the query processing capacity is too low, or if the MMI processing has failed,

the LDB PRU should be rebooted.

0000/0103

Message:

The LDB has detected a serious problem which prevents it from

continuing to operate. Any queries being processed will be aborted. All MMI

operations will be aborted.

"Diagnostic String 1"

"Diagnostic String 2"

Description:

The first diagnostic string describes the nature of the problem,

the second string gives additional information on the problem.

Action:

A serious error was encountered by the LDB PRU. The LDB PRU will

be automatically rebooted by the system, so that no action is required, unless

the condition persists.

0000/0104

Message:

The LDB has detected an internal software error.

"Diagnostic String 1"

"Diagnostic String 2"

Description:

A serious internal software error was encountered by the LDB.

If the error is a fatal error and the LDB is unable to continue processing, all

queries being processed by the LDB PRU will be aborted. All MMI operations

will be aborted. The first diagnostic string describes the nature of the problem,

the second string gives additional information on the problem.

Action:

All information on this error should be recorded and reported to NT

service personnel. The LDB PRU will be automatically rebooted by the system,

so that no further action is required, unless the condition persists.

0000/0105

Message:

The LDB has received an error from a system operation.

"Diagnostic String 1"

"Diagnostic String 2"

Locality Database Log Messages (944E) 71

TOPS VSN Log and alarm messages

Description:

A serious error was received from a system operation. If the

error is a fatal error and the LDB is unable to continue processing, all queries

being processed by the LDB PRU will be aborted. All MMI operations will be

aborted. The first diagnostic string describes the nature of the problem, the

second string gives additional information on the problem.

Action:

All information on this error should be recorded and reported to NT

service personnel. The LDB PRU will be automatically rebooted by the system,

so that no further action is required, unless the condition persists.

0000/0106

Message:

The LDB has encountered an error trying to transfer a prompt

requested by the ACPE to the ACPE executor data space.

"Diagnostic String 1"

"Diagnostic String 2"

Description:

The LDB has either received an error from an ACPE executor

during a prompt transfer, or was unable to start the transfer with the ACPE

executor, or has no transfer tasks available to allocate to the ACPE. The first

diagnostic string describes the nature of the problem, the second string gives

additional information on the problem.

Action:

No action is required unless the condition persists, in which case

the LDB PRU should be rebooted.

0000/0201

Message:

An error occurred which caused the print task to fail. The Locality

Database will not be printed. Call processing will not be affected.

"Diagnostic String 1"

"Diagnostic String 2".

Description:

This log indicates that if successive attempts to print the

Locality Database fail, the Locality Database PRU is to be rebooted.

Action:

If the problem persists, retain all of the information regarding the

problem and contact your NT representative.

0000/VQ003

Message:

The user has chosen to install a prompt set that is missing a

language version of an announcement(s) that existed in the loaded set. Calls

requested in the missing language version will be handled according to the

parameter LOC_LANG_UNAVAIL.

Description:

Informational message only.

Action:

No action is required.

73

TOPS VSN Log and alarm messages

16. ACPE Maintenance Position log

messages - 9445

9945/0004

Message:

@1 Initialization sequence aborted. Error or inconsistency

encountered while loading the ACPE Maintenance Position initialization data.

xxxxx

xxxxx

Description:

@1 is the reporting PRU, namely the ACPE Maintenance

Position.

xxxxx are two strings that describe the error that was encountered.

Action:

An error has occurred during the ACPE Maintenance Position

initialization. The problem may be resolved by rebooting the ACPS Maintenance

Position PRU. This initialization error does not affect call processing. Please

save this information and contact your NT representative.

0445/0005

Message:

@1 aborted.

A serious software error has occurred that caused the ACPE Maintenance

Position MMI to terminate.

xxxxx

xxxxx

Description:

@1 is the reporting PRU, namely the ACPE Maintenance

Position.

xxxxx are two strings that describe the error that was encountered.

Action:

This software error does not affect call processing. Please save this

information and contact your NT representative.

75

TOPS VSN Log and alarm messages

17. Prompt manager log messages -

9451

0100/0101

Message:

User logged in

<user name>

Description:

This message is informative only, confirming that the user with

the <user name> has logged in.

Action:

None.

0100/0102

Message:

User logged out

<user name>

Description:

This message is informative only, confirming that the user with

the <user name> has logged out.

Action:

None.

0100/0103

Message:

Archive Successful

Description:

This message indicates that an archive function has been

completed successfully.

Action:

None.

0100/0104

Message:

Restore Successful

Description:

This message indicates that a database was successfully

restored from magnetic tape.

Action:

None

0100/0105

Message:

Install successful

<set issue>

Description:

This message indicates that a database was successfully

installed in the TOPS VSM from disk.

Action:

None.

0100/0106

Message:

Librarian rebuilding

Description:

This is a progress message indicating that the library is in the

process of being built, and that queries to the database are not possible.

Action:

None.

0100/0107

Message:

Librarian starting

0100/0108

Message:

Librarian running

0100/0109

Message:

Librarian shutdown

76 Prompt Manager Log Messages (9451)

TOPS VSN Log and alarm messages

0200/0201

Message:

Forced Exit

<procedure name>

<reason for exit>

0200/0202

Message:

Archive Failure

<reason for failure>

0200/0203

Message:

Restore Failure

<reason for failure>

0200/0204

Message:

Bad system command

<procedure name>

<command>

0200/0205

Message:

Install unsuccessful

0300/0301

Message:

Cannot open file

<detail>

0300/0302

Message:

Cannot create file

<detail>

0300/0303

Message:

Read failure

<detail>

0300/0304

Message:

Write failure

<detail>

0400/0401

Message:

No VI channel

0400/0402

Message:

VI error

<detail>

0500/0501

Message:

Lib daemon error

Timeout

0500/0502

Message:

Lib daemon error

Library Corrupt

Restore from backup

Description:

0500/0503

Message:

Lib daemon error

Librarian Dead

Reboot DVIX

<detail>

77

TOPS VSN Log and alarm messages

18. Suppressed and Thresholded

Logs

This section lists the system logs which have been suppressed or thresholded.

The format for suppressed logs is <Config Number> <Report Number/Error

Number>. The format for thresholded logs is <Config Number> <Report

Number/Error Number> <Maximum Threshold> <Duration>

Suppressed Logs

0000 00010002 KERNEL INNER CI

0002 41010001 VTP: ERROR 1

0002 41010011 VTP: PHYSICAL DEST IS NON-EXISTENT.

0002 41020037 OAR, Rendezvous error

0002 41050003 SAS, BAD FIELD NUMBER.

0002 4106003B Tape Server, mode conflict

0003 0001FFFF PRU operational

0003 0002FFFF PRU non-operational

0003 0003FFFF PRU operational

0003 0004FFFF PRU operation

0003 0005FFFF PRU appears OK!

0003 0006FFFF system initialization complete

0003 0007FFFF enabled

0003 0008FFFF RM registration

0003 0009FFFF RM de-registration

0003 000AFFFF Reload if crashes

0003 000BFFFF System time set thru SAS

0003 000DFFFF taken out of service

0003 000EFFFF X.25, LIU PORT OFFLINE

0003 000FFFFF PRU initializing

0004 00020005 OAR BAD COMMAND

006D 0000000D OM file audit.

006D 0000001C OMCA: I/F ERROR.

006D 0000002D Number of initiated OMR processors

006D 00000032 Invalid group in OMC file

006D 00000035 No valid OM group

78 3. Suppressed and Thresholded Logs

TOPS VSN Log and alarm messages

006D 00000038 File audit status

006D 00000039 OMCA: LOCATE ERROR

006D 0000003A OMCA: LOCATE ERROR (REPORTER)

0220 00000003 VIRM CLEARING ANY ALARMS

8004 00020007 COULD NOT SEND NOTIFICATION

800C 00010002 OAR, change state

800C 00010003 OAR, registration

800C 00020005 OAR, unable to start activity

800C 0002000C OAR, bad response

800D 00020005 INIT REQUEST FOR M4020

800D 00020008 Bus control error return code 0001

8021 00010001 Long audit response

8022 0002010B SAM help hard key

8022 00020117 SAM

8022 00010207 Alpha operational

8022 00020113 SAM, no response

8026 0002003A VNM: SD_DROPS_SLOTS

8028 00020002 HAG, ADMIN READ ERROR ON SN

RECORD.

8029 0002002C SAS, SFH RETURN CODE

802E 00020000 SSM T1 Link Switch

802E 00020001 SSM T1 Link Switch

8220 00010300 XCM X.25 Link is up

8220 00010301 X.25, XCM: LINK IS DOWN

8220 00010400 X.25, MLP PORT IS DOWN

8220 00020500 NCT: CLIENT REQUEST IGNORED

852E 00100002 Job manager, Job complete successfully

852E 00100005 Job manager, start job

852E 00100006 Job manager, job started

8602 00010008 TNAP registration

8700 00010001 Campus resource manager

8700 00010002 Campus resource manager

8700 00010003 Campus resource manager

8700 00010004 Campus resource manager

8700 00010005 Campus resource manager

8700 0001000C Campus resource manager

Suppressed and Thresholded Logs 79

TOPS VSN Log and alarm messages

700 00020001 Campus resource manager

8700 00020002 Campus resource manager

8700 00020003 Campus resource manager

8700 00020004 Campus resource manager

8700 00020005 Campus resource manager

8700 00020006 Campus resource manager

8700 00020007 Campus resource manager

8700 00020008 Campus resource manager

8700 00020009 Campus resource manager

8700 00020010 Campus resource manager

8700 00020011 Campus resource manager

8700 00024104 Campus resource manager

8700 00030001 Campus resource manager

8700 00030002 Campus resource manager

8700 00030005 Campus resource manager

8700 00030007 Campus resource manager

8700 00040001 Campus resource manager

8700 00040003 Campus resource manager

8700 00040004 Campus resource manager

8720 00010001 UNKNOWN LOG REPORT

8720 00030006 CLEANING UP OF ALARMS

8720 00500002 Logger cache has been modified

8723 00010001 QMAN printer ok

8800 00010001 Server file audit completed.

9440 00000001 ACPE-RM detected ACPE

9442 0003000F Unable to allocate T1 channel

9443 00030000 CLEARING ANY ALARMS

Thresholding Logs

0004 00020002 100 2 TIMEOUT XMITTING ERRORS

006D 00000005 255 2 Task error on File audit

006D 0000000D 255 2 File I/O errors

006D 0000000E 100 30 OMR locate Job MGR

006D 00000037 255 2 Report End time exceeded

0201 00020015 8 1 TRBUFFER TASK RESULT

800C 00020004 255 2 OAR unable to start job

8026 00020031 48 5 VNM release error due to nil taskid

852E 00200002 255 2 Job could not be started

8531 00200004 255 2 Unable to communicate with Job Mgr

9441 00000007 24 1 CONTROL LINK TIME IN Q

9441 00000006 8 1 CONTROL LINK MODULUS

9442 00030010 48 2 VNM connect error

9442 00030011 48 2 Unable to release speech slave

9442 00030012 48 2 VNM release error

80 3. Suppressed and Thresholded Logs

TOPS VSN Log and alarm messages

9442 00030013 48 2 T1 release error

9442 00030014 48 2 VI release error

C302 00020018 100 2 VTP return code error

C302 00020010 100 2 Link Error

C302 00020017 100 2 Port Error

C302 0002000F 100 2 No response from peer

81

TOPS VSN Log and alarm messages

19. DMS notices

Some events which occur in the TOPS VSN must be reported to the DMS switch.

The report takes the form of a notification message. The list which follows

identifies the log/alarm messages sent to the DMS. table VSNALARM on the

DMS, which is datafilled by the operating company, adds severity and textual

information to the notification message before it is output on the DMS side. The

event ID given here corresponds directly to the alarm code in table

VSNALARM.

Sub-

system Report & Error

Number Event Event ID Severity Alarm

8720 0003 0002 Faulty PRU 1 minor Yes

8720 0003 0004 PRU Recovered 1 No

8720 0003 0001 Faulty SRU Device 2 minor Yes

8720 0003 0003 SRU Device Recovered 2 No

8720 0002 0001 Disk Full 3 critical Yes

8720 0002 0004 Disk Space Reclaimed 3 No

8722 0001 0001 External Alarm 4 major Yes

8722 0001 0002 External Alarm Recovered 4 No

8722 0002 0001 External. Alarm 4 major Yes

8722 0002 0002 External Alarm Recovered 4 No

8722 0003 0001 External Alarm 4 minor Yes

8722 0003 0002 External Alarm Recovered 4 No

9443 0003 0001 Inserv T1 Failed 5 major Yes

9443 0003 0002 Inserv T1 Recovered 5 No

9443 0003 0003 Busied T1 Failed 6 minor Yes

9443 0003 0004 Busied T1 Recovered 6 No

9442 0000 0104 ACPE Capacity Lost 7 minor Yes

9442 0000 0000 ACPE Recovered 7 No

83

TOPS VSN Log and alarm messages

20. Abbreviations

A list of abbreviations used in this Publication follows:

ACPE Application call processing engine

CLLI Common language location indicator

DD Data dictionary

DMS Digital multiplex system

DNC Dynamic network control

DTMF Dual tone multifrequency

IEEE Institute of Electrical and Electronic Engineers

IO Input output

LDB Locality database

MMI Man machine interface

NT Northern Telecom

OM Operational measurement

PCM Pulse code modulation

PRU Program resource unit

RM Resource manager

SAS System administration service

SDM Service data manager

SRU Shared resource unit

TOPS Traffic operator position system

VI Voice interface

VIRM VI resource manager

VNM Voice network manager

VSN Voice service node

VTP Virtual transport protocol

Network operations systems

TOPS

Voice service node

Log and alarm messages

Copyright © 1995 Northern Telecom

All rights reserved.

TOPS and DMS are trademarks of Northern Telecom.

NTP 450-1301-511

Release: VSN04

Version: 03.01

Standard

August 1995

Printed in the United States of America
