Novatel Wireless WG9703A CDPD BOOSTER User Manual

Novatel Wireless Inc. CDPD BOOSTER

Contents

USER MANUAL

Item Qty Part Description Detail Reference Desg.
11 AMP0030 Power Amp, 6W, 836 mhz PF0030 U3
21 AMP82563 MMic GaAs RF amp .1-6 GHz MGA-82563 U9
31 AMPVAM7M MMIC RF Amp 180-0711-05-001, IET0021AC U8
47 CAP102K2X Capacitor,10%,0603,X7R 1000 pF, 580-0102-05-010, IET0025AC C15,C13,C12,C11,C9,C8,C1
54 CAP108RL Electrolytic Capacitor, 1000 uF Digikey order # P5634A-ND C27,C26,C25,C5
66 CAP104Z2Y Capacitor,+80/-20%,0603,Y5V 0.1uF, 580-0104-05-020, IET0027AC C20,C18,C14,C10,C7,C6
75 CAP105Z3Y Capacitor,+80 -20%,0805,Y5V,16V, 1 uf, 580-0105-05-020, IET0028AC C29,C28,C19,C3,C2
81 CAP156K7T Capacitor,10%,1508,TANTALUM 15 uF, 570-0156-05-010, IET0032AC C24
92 CAP680J2C Capacitor,5%,0603,COG,50V 68pf, 580-0680-05-005, IET0237AC C21,C16
10 1 CON4PRA connector, booster power order # WM3901-ND, Mfg # 39-29-104B J1
11 2 CONTNCRA Connector, tnc, right angle PCB mount IMS P# 1121.02.2620.009 J3,J2
12 2 DIO4CS1 Diode, Detector MA4CS102A, RF Detector, 270-0102-05-001, IET0056AC CR3,CR2
13 1 DIR15SM Directional Coupler 15dB 100 watt 1D1304-15 DC1
14 1 FIL887S0001 Saw Filter,881 Mhz HWCB606, 260-0001-05-003, IET0058AC FL2
15 1 FILDUPL Duplexer,Ceramic, 836Mhz,881Mhz DFY2R836CR881BHA, 260-0001-05-005, IET0060AC FL1
16 1 FILDUPL10W Duplexer,10W DFYKR836CR881HHA FL3
17 2 INDR10K3M Inductor,10%,0805,Multilayer 100 nh, 260-0100-05-001, IET0072AC L2,L1
18 1 LEDRED LED, SURFACE MOUNT, RED SSF-LXH305ID-TR DS1
20 2 OPA0662 CMOS DUAL OP AMP LPC662 AIM U5,U4
21 1 PCB970301 printed circuit board, booster
23 7 RES103J20 Resistor,5%,0603,Thick Film,200ppm 10 K, RM73B1JT103J, IET0084AC R44,R37,R28,R27,R26,
R25,R20
24 6 RES104J20 Resistor,5%,0603,Thick Film,200ppm 100 K, RM73B1JT104J, IET0085AC R36,R31,R30,R21,R19, R18
25 1 RES112J20 Resistor,5%,0603,Thick Film,200ppm 1.1k, RM73B1JT112J R35
26 2 RES121J20 Resistor,5%,0603,Thick Film,200ppm 120 ohm, RM73B1ET121J R39,R15
27 1 RES164J20 Resistor,5%,0603,Thick Film 160K RM73B1JT164J, IET0225AC R13
28 1 RES180J20 Resistor,5%,0603,Thick Film,200ppm 18 ohm, RM73B1JT180J, IET0096AC R41
29 2 RES240J20 Resistor,5%,0603,Thick Film,200ppm 24 ohm, RM73B1JT240J, IET0102AC R33,R32
30 1 RES274J20 Resistor,5%,0603,Thick Film,200ppm 270 K, RM73B1JT274J, IET0105AC R17
31 2 RES301J20 Resistor,5%,0603,Thick Film,200ppm 300 ohm, RM73B1JT301J, IET0106AC R43,R42
32 1 RES471J10 Resistor,5%,0402,Thick Film, 200ppm 470 OHM, RM73BIET471J R22
33 1 RES223J20 Resistor,5%,0603,Thick Film,200ppm 22 K, RM73B1JT223J, IET0100AC R14
34 2 RES510J20 Resistor,5%,0603,Thick Film,200ppm 51 ohm, RM73B1JT510J, IET0115AC R29,16
35 1 RES560JL3 56 ohm, Power resistor, 3 watt, wirewound DK Order # ALSR3J-56-ND R1
36 1 RES621J2C Resistor,5%,0603,Thick Film,200ppm 620 ohm R10
37 4 RES750J20 Resistor,5%,0603,Thick Film,200ppm 75 ohm, RM73BIJT750J, IET0341AC R40,R38,R24,R23
38 1 SPLT01R 0deg Splitter/Combiner STH-01R S1
39 1 SSY970301 subassembly, booster packaging
40 1 VRG1245 Voltage Regulator, 4.5 V, Sot23L TK11245AMTL, 240-0045-05-001, IET0135AC VR3
41 1 VRG29302 Voltage Regulator, 12.0 v. ,TO-236-5P MIC29302BU VR2
43 1 XTR85633 Transistor,NPN,RF,7 GHz NE85633-T1B, 280-0001-05-002, IET0136AC Q1
