Nutek Corporation Transmitter Users Manual

Users Manual

128-9319
1 of 2
3 Channel Remote Car Starter
FEATURES :
2 Three Button Programmable RF Transmitters
Three Channel Receiver (capable of accepting 4 transmitters)
External Superheterodyne Receiver Antenna w/PushButton Switch & LED
Keyless Entry Outputs
Trunk Release Output
On-Board Start Relay
On-Board Accessory Relay
On-Board Ignition 1 Relay
On-Board Ignition 2 Relay
Ignition 2 Relay Selectable On or Off During Cranking
On-Board Parking Light Relay
Ignition 3 / Shock By-Pass / GM VAT Output (relay required)
Tach Signal Learning Circuit
Two ( + ) and Two ( - ) Safety Shutdown Circuits
Alarm By-Pass Output
Accessory Outputs
(Pulse Before & After Start, During Crank & After
Shut Down)
Selectable Steady or Flashing Parking Lights for Run Indication
Selectable 5, 10, 15, 20, 45, 60 Minute Run Time
Selectable Door Lock Output Pulse Timing
Car Finder Mode
PATENTED: www.voxxintl.com/company/patents
Model PRO9556E
Owners Manual
5
Five
Five
128-9319
2 of 2
KEYLESS ENTRY
The Lock button on the transmitter is used to lock the vehicle's doors, the Unlock button is
used to unlock the vehicle's doors. To lock or unlock the doors simply press and release
the desired function button one time. As a keyless entry unit, for your convenience, the
parking lights will ash once when the doors are locked and twice when the door are
unlocked.
REMOTE CAR FINDER
The Lock or Unlock buttons are also used to access the car nder mode. This feature
is particularly useful in a crowded parking lot where nding your car may be difcult. To
access the car nder mode, while within range of your car, simply press and hold either
the lock or unlock button of your transmitter for three seconds. The parking lights will
begin to ash, making your vehicle more visible. The lights will stop automatically after
30 seconds. If you wish to turn off the car nder mode prior to the expiration of the 30
second timer, press and release either the lock or unlock button of your transmitter one
time.
REMOTE TRUNK RELEASE
If you have electric trunk release in your vehicle and the remote trunk release option
was added to your vehicle, simply press and hold the Key/Trunk button of your keychain
transmitter for 4 seconds or until the electric trunk of your vehicle opens.
REMOTE STARTING THE VEHICLE
This unit will not start the vehicle if any one of the following situations exist:
The vehicle's hood lid is opened.
The gear shift selector is not in Park.
The brake pedal is depressed.
The safety control switch is in the Off position.
1. To start the vehicle, press and release the Key/Trunk button two times within
2 seconds. The vehicle will start and remain running for the pre-programmed 5, 10,
15, 20 minute run cycle. As a visual indication, the parking lights will ash or remain
on depending on the setting by your installation center.
2. When you arrive at the vehicle, turn the ignition key to the ON position (not the spring
loaded start position), then step on the brake pedal to disengage the remote starter.
The vehicle will continue to run, but now on its own power.
NOTE: The engine will stop running before the pre-programmed run cycle has expired if
you perform any one of the following functions:
Press and release Key/Trunk button on the keychain transmitter two times within
2 seconds.
Depress the brake pedal.
Open the vehicle's hood.
Place the unit in the safety control disabled mode.
PUSH-BUTTON LED RECEIVER VALET/OVERRIDE/SAFETY CONTROL SWITCH
The Push-Button LED switch located in the receiver allows you to temporarily disable the
remote starting function of the system. This is recommended whenever the vehicle is being
serviced.
128-9319
3 of 2
To place the system in the service mode:
1. With the system disarmed/unlocked, and the ignition switch off, Press and Hold the
Push-Button, found on the windsheild receiver, in.
2. Turn the ignition switch on, off, on, off, on, off.
3. The LED begins to ash two short ashes followed by one long ashes and
continues this pattern until returned to normal mode of operation.
This puts the unit into the R/S Override mode indicating that the remote start is in the
service mode and will not start from RF or any other input Posse or otherwise.
To Exit R/S Override Mode:
1. With the system disarmed, Press and Hold the Push-Button, found on the windsheild
receiver, in.
2. Turn the ignition switch on, off, on, off, on, off.
3. The LED turns off, indicating that the R/S unit is fully functional one again.
PROGRAMMING NEW OR REPLACEMENT TRANSMITTERS
(BANK 1)
Transmitter Model Name, 143BPR Is Also Found On Back Of
Transmitter Case (Battery Use CR2032)
1) Turn the ignition key to the on position.
2) Press and release the valet/programming switch 3 times (Siren Chirps).
3) Press the Lock Button of each transmitter you want programmed until you hear a chirp
from the horn or siren.
4) Turn the ignition switch off.
The above action programs the Lock, Unlock, Start/Trunk, and Option 1 buttons which are
typical for most systems.
For additional channel programming beyond the 1 option button, you can use any unused
button or combination of buttons not in use.
In other words, to access option channel 5, 6, 7, you would do the following:
From step 3 above:
a) Press and release the valet/programming button 4 additional times to get to channel 5,
then Press any unused transmitter button or button combination to program.
b) From a, press and release the valet/programming button 1 time to get to channel 6, then
press any unused transmitter button or button combination to program.
c) From b, press and release the valet/programming button 1 time to get to channel 7, then
press any unused transmitter button or button combination to program.
NOTE: Not all systems have channels above 3, check with your
installation center for options your system may or may not have.
This remote has the ability to operate 2 Audiovox Alarms From A Single Transmitter. To toggle
on and off vehicle one or two,,,
Press the Trunk/Key button + the Lock button for 5 seconds.
The LED ashes 2 times. Release the buttons, to select 2nd vehicle mode.Program this trans-
mitter into the second vehicle's system. Any time you are in 2nd vehicle when the transmitter
is operated, the LED will ash twice for each function. When in in the prime vehicle mode,
the LED will ash once for each function.
145BPR
128-9319
4 of 2
© 2014 Voxx Electronics Corp., 150 Marcus Blvd., Hauppauge, NY 11788 128-9319
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference that may
cause undesired operation.
Warning!
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment
NOTE:The manufacturer is not responsible for any radio or TV interference caused by unauthorized modications to
this equipment. Such modications could void the user’s authority to operate the equipment
PROGRAMMED TRANSMITTER NOTIFICATION (PTN)
Every time after Disarm, when the ignition key is turned on, the unit's LED will report the
number of transmitters programmed into the system. This safety feature will alert you if an
unauthorized transmitter has been programmed into your vehicle's security system without
your knowledge. Typically from the factory, there will be 2 ashes and a pause, repeated
3 times, indicating that two transmitters are programmed into the system. If you note addi-
tional ashes, an additional transmitter may have been added without your knowledge or
authorization. If you notice a change in the transmitter LED report pattern, you can correct
this by looking up how to erase and reprogram your transmitters found in the transmitter
programming guide. This reprogram operation will erase all unauthorized or unwanted
transmitters.
Transmitter Battery Replacement:
1) Locate and remove the "00" point philips head screw on the back of the transmitter
case.
2) Carefully separate the front case from the rear.
3) Slide the CR2032 battery out from under the battery clip and dispose of properly.
4) Install the new battery with the (+) side facing up away from the circuit board.
5) Close the case and reassemble in reverse of disassembly
FUNCTION SETTING CHART
To be completed by installer
Run Time _____Min
Door Lock Timer ______Sec
Lights Pulse Steady
To purchase replacement transmitters or to get additional product
information go to: www.pursuitcarsecurity.com
