SATELLITE RADIO OWNER'S MANUAL
2
TABLE OF CONTENTS
Congratulations! ....................................................................................3
Activating Your Subscription .............................................................4
FCC Statement .......................................................................................5
Type I Radio ...........................................................................................6
Selecting SiriusXM From the Device List .................................... 7
Overview of Controls .......................................................................... 8
Browse Menu ........................................................................................ 9
Now Playing List ................................................................................ 10
Storing a Preset .................................................................................. 11
Recalling a Preset ............................................................................... 12
Displaying the SiriusXM Radio ID Number ................................ 13
Selecting a Dierent Device .......................................................... 14
Pairing the Device ............................................................................ 15
Type II Radio ....................................................................................... 16
Selecting SiriusXM From the Device List.................................... 17
Overview of Controls ........................................................................ 18
Browse Menu ....................................................................................... 19
Now Playing List ................................................................................. 20
Storing a Preset ................................................................................... 21
Recalling a Preset ............................................................................... 22
Displaying the SiriusXM Radio ID number ............................... 23
Selecting a Dierent Device ........................................................... 24
Pairing the Device ............................................................................. 25
Pairing the Device (Continued) ..................................................... 26
Troubleshooting ................................................................................. 27
Notice ..................................................................................................... 28
3
CONGRATULATIONS!
Thank you for your SiriusXM Satellite Radio purchase! This product was developed using Bluetooth® Streaming Audio technology to connect to
your vehicle's Bluetooth® enabled radio. This system was professionally installed and includes a pairing button mounted in your vehicle's glove
compartment.
All radio controls will operate in a similar manner as other paired Bluetooth® Streaming Audio devices, and will display your SiriusXM channels as
tracks. The current channel will always be shown, along with the artist and song title. There are 2 types of radios that this system was designed
to work with - Type I and Type II. Please reference the appropriate section of this owner's manual that best matches the radio in your vehicle.
Note: The SiriusXM Satellite Radio is a paired Bluetooth® device in your radio's paired device list. It was paired and connected during the
installation process. This product is designed to stay paired to your radio even if the battery is disconnected. This device must be paired again to
the radio if it is accidentally deleted from the device list, or if the radio is replaced or serviced. The pairing procedure is described in this manual.
OPERATIONAL STATEMENT
While the steering wheel mounted audio controls (if equipped) will provide limited functionality with the SiriusXM Device, actual operation of
the steering wheel mounted audio controls will vary from vehicle to vehicle and operation cannot be guaranteed. This is due to the vehicle's
design and not due to a defect or malfunction in the SiriusXM Satellite Radio device.
Due to the operation of the factory radio, prioritizing devices in the paired device list is not available. This may result in the radio pairing with
other devices such as cell phones, audio players, or tablets when the radio is turned on. This may occur even if the last device being used was
the SiriusXM Satellite Radio. This is an operating charactaristic of the radio and not a defect or malfunction of the SiriusXM Satellite Radio
Device. If this occurs, please reference page 7 or 17 for information to connect the radio to the SiriusXM Satellite Radio.
Due to the operation of the factory radio, text elds may be slow to refresh while changing channels quickly. This is a normal operating
charactaristic of the factory radio. It is recommended to use the "Browse" menu to search for channels by category for quicker response. Please
reference page 9 or 19 for more information on using the "Browse" menu.
Radio images in this manual are provided for reference and for informational purposes only. The actual radio displays may vary from vehicle to
vehicle, and this manual may not represent the actual menu and displays of the radio in any particular vehicle.
4
ACTIVATING YOUR SUBSCRIPTION:
You should be able to hear the SiriusXM preview channel on Channel 1. If you cannot hear the preview channels, please visit your
local dealer for troubleshooting. Note that the vehicle must be outside and the antenna must have a clear view of the sky to be
able to receive a signal.
After you can hear the Preview channel, tune to Channel 0 to nd the Radio ID of your tuner. You will need this number to activate
your subscription. Write this number down for reference.
Note: the SiriusXM Radio ID does not include the letters I, O, S, or F.
In the USA, you can activate online or by calling SiriusXM Listener Care:
• Visit www.siriusxm.com/activatenow
• Call SiriusXM Listener Care at 1-866-635-2349
For Canadian Subscriptions, please contact:
• Visit www.siriusxm.ca/activatexm
• Call XM Customer Care at 1-877-438-9677
As part of the activation process, the SiriusXM satellites will send an activation message to your tuner. When your radio detects
that the tuner has received the activation message, your radio will display: "<<Subscription Updated>>". Once subscribed, you
can tune to channels in your subscription plan. Note, the activation process usually takes 10 to 15 minutes, but may take up to an
hour. Your radio will need to be powered on and receiving the SiriusXM signal to receive the activation message.
5
FCC STATEMENT:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any change or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate this
equipment.
Radiation Exposure Statement
This equipment complies with FCC radiation limits set forth for an uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
6
TYPE I RADIO
Select Device
Browse
Source
II Sound
SiriusXM
Preview Channel
Channel 1
Bluetooth Audio
Volume Tune
Audio
Car
Setup
Seek
Track
V
V
7
SELECTING SIRIUSXM FROM THE DEVICE LIST:
1. Access the Bluetooth® Streaming Audio source in the
vehicle's factory radio.
2. Press the "Select Device" button to display the list of
currently paired devices.
3. Find the "SiriusXM" device in the paired device list.
4. To the right of the label you will see an icon that looks like a
music note. Press this icon to select SiriusXM.
Note: If you wish to use another device to stream content into the radio
via Bluetooth®, use the same procedure to select the alternate device. This
will not remove the SiriusXM from the paired device list, and you can return
to listen to SiriusXM content at any time by following the steps above (see
page 14).
5. The main SiriusXM screen will now display. (See page 8 for
more information)
Select Device
Browse
Source
II Sound
Bluetooth Audio
Select
Device
System Settings Remove
Add
SiriusXM
Bluetooth Setup
Mobile Phone
Select
SiriusXM
Reorder
Select Audio Source
Audio
AM FM
Bluetooth®
Streaming
Audio source
8
OVERVIEW OF CONTROLS:
• Use the "Tune" knob or Track ^/v buttons to select channel
up or down.
• The "Tune" knob can also be used to navigate through the
radio's menus.
• Use the "Volume" knob to adjust volume.
• Press the "Browse" button to access the main menu.
• Press the "Bluetooth®" button to access the preset list.
• Use the "Sound" button to adjust the sound settings (Bass/
Treble/Balance/Fade/etc.)
• "II" (Pause) Button - No Function for SiriusXM content.
Actual screens and button conguration may dier from vehicle
to vehicle.
Select Device
Browse
Source
II Sound
SiriusXM
Preview Channel
Channel 1
Bluetooth Audio
Volume Tune
Audio
Car
Setup
Seek
Track
V
V
Tune Channel
Up or Down
Volume
Up or Down
Main Menu
Bluetooth®
Button
No Function Adjust Sound Settings
Display Paired
Device List
9
BROWSE MENU:
1. Press the "Browse" button on the main screen.
2. This will bring up the option for
Current Category
Categories (browse)
Store Preset
Recall Preset
SiriusXM Radio ID
3. Pressing the "Categories" button will bring up a category
list. To select a channel to listen to from a specic category, use
the "Scroll" arrows to bring up the desired category. Once the
desired category appears, touch it to select it.
4. Once selected, a list of all the channels within the selected
category will appear. Select the desired channel within the
category and it will tune the radio to that channel.
Note: At any time, pressing the (Return) button will
return to the previous menu/screen.
Now Playing
Select from the list
^
^
^
^
Pop
Rock
Hip-Hop
R&B
Dance/Electronic
Now Playing
Select from the list
^
^
^
^
Current Category: Rock
Categories
Store Preset
Recall Preset
SXM Radio ID: 1234ABCD
Scroll
Now Playing
Select from the list
^
^
^
^
Ch2: Hits 1
Ch3: Venus
Ch4: 40s on 4
Ch5: 50s on 5
Ch6: 60s on 6
Return to
Category
List
Now Playing
Select from the list
^
^
^
^
Ch2: Hits 1
Ch3: Venus
Ch4: 40s on 4
Ch5: 50s on 5
Ch6: 60s on 6
10
NOW PLAYING LIST:
1. Press the "Current Category" button at the top of the main
menu. This will access the "Now Playing List", which is a list of
the other channels within the currently selected category.
2. Select one of the channels within the "Now Playing List" to
select another channel, or press the (Return) button to
return the main screen.
Access
Now Playing
List
Now Playing List
^
^
^
^
Ch 95: xL ComedyCentral
Ch 96: xL The Foxxhole
Ch 97: xL Blue Collar
Ch 98: Laugh USA
Ch 99: xL RawDog Comedy
Now Playing
Select from the list
^
^
^
^
Ch2: Hits 1
Ch3: Venus
Ch4: 40s on 4
Ch5: 50s on 5
Ch6: 60s on 6
Now Playing
Select from the list
^
^
^
^
Current Category: Rock
Categories
Store Preset
Recall Preset
SXM Radio ID: 1234ABCD
11
STORING A PRESET:
1. Select the desired station that you would like to save as a
preset.
2. Press the "Browse" button. (See page 9 for more information).
3. Press the "Store Preset" button.
4. Select the position in the preset list where you would like to
store the currently selected channel.
5. "Preset Stored" will be displayed on the screen to conrm that
the currently selected channel has been saved as a preset. Then
the display will return to the currently selected channel.
Now Playing
Select from the list
^
^
^
^
Current Category: Rock
Categories
Store Preset
Recall Preset
SXM Radio ID: 1234ABCD
Preset List
^
^
^
^
Preset 1: Ch 95 xL ComedyCentral
Preset 2: Ch 96 xL The Foxxhole
Preset 3: Ch 97 xL Blue Collar
Preset 4: Ch 98 Laugh USA
Preset 5: Ch 99 xL RawDog Comedy
Select Device
Browse
Source
II Sound
Preset Stored
Bluetooth Audio
Store
Preset
Button
Select
Preset
Location
12
RECALLING A PRESET:
1. Press the "Bluetooth®" button.
2. Select the channel from the list that you would like to recall.
3. The radio will return to the main screen and tune to the
selected preset.
OR.
1. Press the "Browse" button. (See page 9 for more information).
2. Press the "Recall Preset" button.
3. Select the channel from the list that you would like to recall.
4. The radio will return to the main screen and tune to the
selected preset.
Now Playing
Select from the list
^
^
^
^
Current Category: Rock
Categories
Store Preset
Recall Preset
SXM Radio ID: 1234ABCD
Preset List
^
^
^
^
Preset 1: Ch 95 xL ComedyCentral
Preset 2: Ch 96 xL The Foxxhole
Preset 3: Ch 97 xL Blue Collar
Preset 4: Ch 98 Laugh USA
Preset 5: Ch 99 xL RawDog Comedy
Select Device
Browse
Source
II Sound
Je Foxworthy
You might be a redneck...
xL Blue Collar
Bluetooth Audio
Track 97
Recall
Preset
Button
Select
Desired
Preset
Bluetooth®
Button
13
DISPLAYING THE SIRIUSXM RADIO ID NUMBER:
1. Press the "Browse" button. (See page 9 for more information).
2. Note the SiriusXM Radio ID number in the menu list.
OR:
1. Using the "Tune" knob, or the "All Channels" list from the
"Categories" menu, select channel 0.
2. The radio will tune to channel 0 and display the SiriusXM
Radio ID information in the data eld.
Now Playing
Select from the list
^
^
^
^
Current Category: Rock
Categories
Store Preset
Recall Preset
SXM Radio ID: 1234ABCD
XMID
Number
Select Device
Browse
Source
II Sound
1234ABCD
RADIO ID
Bluetooth Audio
14
SELECTING A DIFFERENT DEVICE:
1. Access the Bluetooth® Streaming Audio source in the
vehicle's factory radio.
2. Press the "Select Device" button to display the list of
currently paired devices.
3. Find the desired device in the paired device list. Select the
icon of the music note and it will change from the Bluetooth®
Streaming Satellite Radio device to the newly selected device.
Select Device
Browse
Source
II Sound
Bluetooth Audio
Select
Device
Reorder
Select Audio Source
Audio
AM FM
System Settings Remove
Add
SiriusXM
Bluetooth Setup
Mobile Phone
Other
Device
Bluetooth®
Streaming
Audio
15
PAIRING THE DEVICE:
If the Bluetooth® Streaming Satellite Radio device is accidentally
deleted from the paired device list, it must be re-paired to the
vehicle's radio before using the service.
1. Access the Bluetooth® Streaming Audio source in the vehicle's
radio. (See page 8, step 1 for more information).
2. Press the "Select Device" button to display the list of currently
paired devices.
3. Select the "Add" button to add the new device. At this point
the radio will enter discoverable mode, allowing the Streaming
Bluetooth® Satellite Radio device to connect.
4. Locate the pairing button for the Bluetooth® Streaming
Satellite Radio Device in the vehicle's glove compartment.
1. PRESS and HOLD the pairing button for 3 seconds. The
Status Indicator LED will start ashing RED quickly,
indicating the pairing procedure has started.
2. The LED will start to ash GREEN quickly, indicating that
it is connecting with the radio.
3. Finally, the LED will begin to slowly ash GREEN to
indicate that it has successfully paired to the vehicle's
radio.
5. "SiriusXM" will now display on the paired device list. Select
the music note icon to the right of the SiriusXM icon to select the
device.
Select Device
Browse
Source
II Sound
Bluetooth Audio
System Settings Remove
Add
Bluetooth Setup
System Settings Remove
Add
SiriusXM
Bluetooth Setup
SiriusXM
Device
Add
Device
Select
Device
Pairing Button
Status Indicator LED
16
TYPE II RADIO
Volume Tune
Audio
Seek
Track
V
V
Source
Bluetooth Audio
Browse
Track Time
Connect Tracks
SiriusXM
Preview Channel
Channel 1
Setup
Map
17
SELECTING SIRIUSXM FROM THE DEVICE LIST:
1. Access the Bluetooth® Streaming Audio source in the
vehicle's factory radio.
2. Press the "Connect" button to display the list of currently
paired devices.
3. Find the "SiriusXM" device in the paired device list.
4. Press the "SiriusXM" icon.
Note: If you wish to use another device to stream content into the radio
via Bluetooth®, use the same procedure to select the alternate device. This
will not remove the SiriusXM from the paired device list, and you can return
to listen to SiriusXM content at any time by following the steps above (see
page 24).
5. The main SiriusXM screen will now display. (See page 18 for
more information)
Select
Device
Select
SiriusXM
Source
Bluetooth Audio Browse
Track Time
Connect Tracks
SiriusXM
Preview Channel
Channel 1
Connect Audio Player
Add New
SiriusXM
Mobile Phone
Bluetooth
Audio
Bluetooth Audio
FM
87.9
MHz
AM
530
kHz
BT
844-711-880
Ed Sheeran
ALL
18
OVERVIEW OF CONTROLS
• Use the "Tune" knob or Track ^/v buttons to select channel
up or down.
• The "Tune" knob can also be used to navigate through the
radio's menus.
• Use the "Tracks" button to access the Preset list.
• Use the "Volume" knob to adjust volume.
• Press the "Browse" button to access the main menu.
• Use the " " (Sound) button to adjust the sound settings
(Bass/Treble/Balance/Fade/etc.)
• " /II" (Play/Pause) buttons - No Function for SiriusXM
content.
Actual screens and button conguration may dier from vehicle
to vehicle
Volume Tune
Audio
Seek
Track
V
V
Source
Bluetooth Audio
Browse
Track Time
Connect Tracks
SiriusXM
Preview Channel
Channel 1
Setup
Map
Tune Channel
Up or Down
Volume
Up or Down
Paired
Device List
No Function Adjust Sound Settings
Access
Preset List
Tune Channel
Up or Down
Browse
19
BROWSE MENU:
1. Press the "Browse" button on the main screen.
2. This will bring up the option for
Current Category
Categories (browse)
Store Preset
Recall Preset
SiriusXM Radio ID
3. Pressing the "Categories" button will bring up a category
list. To select a channel to listen to from a specic category, use
the "Scroll" arrows to bring up the desired category. Once the
desired category appears, touch it to select it.
4. Once selected, a list of all the channels within the selected
category will appear. Select the desired channel within the
category and it will tune the radio to that channel.
Note: At any time, pressing the (Return) button will
return to the previous menu/screen.
Select from the list
Pop
Rock
Hip-Hop
R&B
Dance/Electronic
Now Playing
V
V
V
V
Select from the list
Current Category: Rock
Categories
Store Preset
Recall Preset
SXM Radio ID: 1234ABCD
V
V
V
V
Now Playing
Scroll
Select from the list
Ch2: Hits 1
Ch3: Venus
Ch4: 40s on 4
Ch5: 50s on 5
Ch6: 60s on 6
V
V
V
V
Now Playing
Return to
Category
List
Now Playing
Select from the list
^
^
^
^
Ch2: Hits 1
Ch3: Venus
Ch4: 40s on 4
Ch5: 50s on 5
Ch6: 60s on 6
20
NOW PLAYING LIST:
1. Press the "Browse" button in the upper right hand corner of
the screen.
2. Select the "Current Category" button at the top of the menu.
This will access the "Now Playing List", which is a list of the other
channels within the currently selected category.
2. Select one of the channels within the "Now Playing List" to
select another channel, or press the (Return) button to
return the main screen.
Access
Now Playing
List
Now Playing
Select from the list
^
^
^
^
Ch2: Hits 1
Ch3: Venus
Ch4: 40s on 4
Ch5: 50s on 5
Ch6: 60s on 6
Select Track
Current Category: Entertainment
Ch 1: XM Preview
Ch 102: xL Indie
Ch 103: xL SXM Talk
Ch 105: EW Radio
V
V
V
V
Select from the list
Current Category: Rock
Categories
Store Preset
Recall Preset
SXM Radio ID: 1234ABCD
V
V
V
V
Now Playing
Source
Bluetooth Audio Browse
Track Time
Connect Tracks
Preset Saved
150
21
STORING A PRESET:
1. Select the desired station that you would like to save as a
preset.
2. Press the "Browse" button. (See page 18 for more information).
3. Press the "Store Preset" button.
4. Select the position in the preset list where you would like to
store the currently selected channel.
5. "Preset Stored" will be displayed on the screen to conrm that
the currently selected channel has been saved as a preset. Then
the display will return to the currently selected channel.
Store
Preset
Button
Select from the list
Current Category: Rock
Categories
Store Preset
Recall Preset
SXM Radio ID: 1234ABCD
V
V
V
V
Now Playing
Select from the list
Preset 1: Ch 1 XM Preview
Preset 2: Ch 150 Caliente
Preset 3: Ch 3 XM Preview
Preset 4: Ch 4 XM Preview
Preset 5: Ch 5 XM Preview
V
V
V
V
Select
Preset
Position
Source
Bluetooth Audio Browse
Track Time
Connect Tracks
Preset Saved
150
22
RECALLING A PRESET:
1. Press the "Tracks" button.
2. Select the channel from the list that you would like to recall.
3. The radio will return to the main screen and tune to the
selected preset.
OR.
1. Press the "Browse" button. (See page 18 for more information).
2. Press the "Recall Preset" button.
3. Select the channel from the list that you would like to recall.
4. The radio will return to the main screen and tune to the
selected preset.
Recall
Preset
Button
Select from the list
Current Category: Rock
Categories
Store Preset
Recall Preset
SXM Radio ID: 1234ABCD
V
V
V
V
Now Playing
Select from the list
Preset 1: Ch 1 XM Preview
Preset 2: Ch 150 Caliente
Preset 3: Ch 3 XM Preview
Preset 4: Ch 4 XM Preview
Preset 5: Ch 5 XM Preview
V
V
V
V
Select
Preset
Position
Source
Bluetooth Audio Browse
Track Time
Connect Tracks
SiriusXM
Preview Channel
Channel 1
Tracks
Button
23
DISPLAYING THE SIRIUSXM RADIO ID NUMBER:
1. Press the "Browse" button. (See page 18 for more information).
2. Note the SiriusXM Radio ID number in the menu list.
OR:
1. Using the "Tune" knob, or the "All Channels" list from the
"Categories" menu, select channel 0.
2. The radio will tune to channel 0 and display the SiriusXM Radio
ID information in the data eld.
Select from the list
Current Category: Rock
Categories
Store Preset
Recall Preset
SXM Radio ID: 1234ABCD
V
V
V
V
Now Playing
XMID
Number
Source
Bluetooth Audio Browse
Track Time
Connect Tracks
1234ABCD
RADIO ID
24
SELECTING A DIFFERENT DEVICE:
1. Access the Bluetooth® Streaming Audio source in the
vehicle's factory radio.
2. Press the "Connect" button to display the list of currently
paired devices.
3. Find the desired device in the paired device list. Select
the device from the list and it will change from the currently
selected device to the newly selected device.
Bluetooth Audio
FM
87.9 MHz
AM
530 kHz
BT
844-711-880
Ed Sheeran
ALL
Select
Device
Select
Other
Device
Source
Bluetooth Audio Browse
Track Time
Connect Tracks
SiriusXM
Preview Channel
Channel 1
Connect Audio Player
Add New
SiriusXM
Mobile Phone
Bluetooth®
Streaming
Audio
25
Bluetooth®
Streaming
Audio
PAIRING THE DEVICE:
If the Bluetooth® Streaming Satellite Radio device is accidentally
deleted from the paired device list, it must be re-paired to the
vehicle's radio before using the service.
1. Access the Bluetooth® Streaming Audio source in the
vehicle's radio. (See page 18 for more information).
2. Press the "Connect" button to display the list of currently
paired devices.
3. Select the "Yes" button to add the new device.
4. Locate the pairing button for the Bluetooth® Streaming
Satellite Radio in the vehicle's glove compartment.
1. PRESS and HOLD the pairing button for 3 seconds. The
Status Indicator LED will start ashing RED quickly,
indicating the pairing procedure has started.
2. The LED will start to ash GREEN quickly, indicating
that it is connecting with the radio.
3. Finally, the LED will begin to slowly ash GREEN to
indicate that it has successfully paired to the vehicle's
radio.
Source
Bluetooth Audio
Connect
Audio player is not connected
Source
Connect Audio Player
Yes
There are no audio players registered.
Would you like to add one now?
No
Connect Bluetooth
Cancel
Registration Waiting
Please operate the device to register it.
Device Name : CAR MULTIMEDIA
Device Address : 1C994C838B782
Passcode : 0000
Select "Yes" to
Add Device
Select to
Connect
Device
Pairing Button
Status Indicator LED
26
PAIRING THE DEVICE; (Continued):
5. "SiriusXM" will now display on the paired device list. Select
the "SiriusXM" device to select.
Connect Audio Player
Add New
SiriusXM
Select
SiriusXM
27
Problem Solution
SiriusXM is inoperative. • Verify that the radio is tuned to the Bluetooth® Audio and "SiriusXM" is selected as the audio device.
• Verify that the SiriusXM unit is paired to the radio's Bluetooth device list.
• Visit your local dealer.
Pairing lost or Device removed from
the radio's paired device list.
• Re-pair the device to the radio. See page 9 or 19 for instructions on how to pair the device.
No SXM Signal message displayed on
radio display.
• Verify the vehicle is outside and the SiriusXM antenna has a clear view of the sky.
• Move the vehicle to a dierent location.
• Visit your local dealer.
Check SXM Tuner message displayed
on radio display.
• Visit your local dealer.
Check SXM Antenna message
displayed on radio display.
• Visit your local dealer.
Subscription Updated message
displayed on radio display
• This is normal operation. This is just an advisory message informing you that a change to the subscription
has been detected. Tune to a dierent channel to clear the message, no further action is required.
Channel Not Available message
displayed on radio display.
• You have tuned to a channel that no longer exists (either by recalling a preset or going to the last playing
channel after starting the vehicle). Change to a dierent channel.
Ch Unsubscribed message displayed
on radio display.
• You have tuned to a channel you have not subscribed to (either by recalling a preset or going to the last
playing channel after starting the vehicle). Tune to a dierent channel.
• Your subscription has expired. Contact SiriusXM for subscription information.
Choppy or degraded audio quality. • Disconnect and reconnect the SiriusXM device to the vehicle's radio. See page 8 or 18 for instructions on
how to reconnect the device.
• Verify any other devices are turned o (Wireless hot-spots, microwave ovens, computers, remote control
toys, wireless microphones, alarm systems, intercoms, room monitors, ourescent lights, and electrical
appliances). Also, other RF Emitting devices may cause interference and undesired operation.
SiriusXM device does not
automatically reconnect to the
vehicle's radio.
• This is normal operation. The radio may prioritize devices according to response time as the radio turns on
and powers up. This is a function of the radio, and not a defect or malfunction of the SiriusXM device.
Other issue not listed. • Visit your local dealer.
TROUBLESHOOTING
28
NOTICE:
Portions of this software are:
Copyright (c) 2004-2005, Swedish Institute of Computer Science.
All rights reserved.
Redistribution and use in source and binary forms, with or without modication, are permitted provided that the following
conditions are met:
1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following
disclaimer in the documentation and/or other materials provided with the distribution.
3. Neither the name of the Institute nor the names of its contributors may be used to endorse or promote products derived
from this software without specic prior written permission.
THIS SOFTWARE IS PROVIDED BY THE INSTITUTE AND CONTRIBUTORS "AS IS'' AND ANY EXPRESS OR
IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE INSTITUTE
OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR
SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON
ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE
OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.
This le is part of the Contiki operating system.
Trademark Notice:
Sirius, XM, and all related marks and logos are trademarks of Sirius XM Radio Inc. All rights reserved.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. And any use of such marks
is under license. Other trademarks and trade names are those of their respective owners.
© 2014 VOXX ELECTRONICS CORP., 150 Marcus Blvd. Hauppauge, NY 11788 4280610
Rev. A 10/2014
