User Manual
Model: 89100 PlayPad for Gear VR
FCC ID: RA3-89100
Y
B
A
X
R3 L3
Left Sticker HOME Low battery indicator
Power/BT status Back
Right Sticker
Power Bluetooth
D-pad
Power input
R1
L1 L2 R2
2. Function Instruduction
3. Operation Instruction
1) To turn on, press the Power button for 3 seconds ,
The Power indicator will flash once.
2) Connect to Samsung S7 mobile phone:
a. Turn on S7 Bluetooth to wait for pairing.
b. Press Bluetooth button for 3 seconds, the BT status LED flushes
before it is connected. The LED is steady blue when connected.
3) Use this PlayPad as regular Game Controller.
4) The Low Battery indicator will light when battery is low.
Connect Type-C connector to Power input to charge the device.
5) To turn off, press the Power button for 3 second.
1. Description:
This PlayPad works is designed to work with Samsung S7 mobile phone,
when S7 is installed in Gear VR. It is a Bluetooth game pad with built-in
battery.
