User Manual
Oscillation mode
Carrier frequency range
Frequency
Max deviation
Dynamic range
T.H.D
Pre/De-Emphasis
Power supply
PLL synthesized
pre-programmed 16 switchable frequencies
+/-65 KHz ,with level limiting
>80 dB
<1%
<50 sm
1.2V*2AAtypeNi-MHrechargeable
battery or DC IN 5V
Group 1. 744~752 MHz
Mike
condenser microphone
Antenna
in side Loop ant.
R F output
10 mW (according to regulation)
C/N Ratio
>110 dB
Spurious
<-60 dBc
Battery
1.2V*2AAtypeNi-MHrechargeable
batteryorDCIN5V
Dimensions (L*W*H)
98*66*27 mm
Weight
80g (less battery)
S
peci
f
ications
/S
pecial Features
O
verall system
-4-
Transmitter
Group 2. 794~806 MHz
User's Guide
UHF-PLL
16-CH Switchable Tour Guilde
& Wireless Mic. Systems
WT-808T
F
unc
ti
on
6. 3.5mm MIC. Input jack
Using condenser MIC., when AUX with inpout,3.5mm MIC off.
3.Power switch & MIC. Volume
(1)Turn clockwise for Turn-ON and MIC.
Volume control , Min MAX.
(2)Turn anti-clockwise for Turn-off and MIC.
Volume control , MAX Min .
5.Built-In MIC
(1)When MIC or AUX with input, built-in microphone off.
(2)When MIC and AUX without input, built-in microphone on.
1.Channel Selection
(1) with16 ch. Selectable.
2.Tx LED Indicator
(1)When turn on,LED light up GREEN indicates
transmission normally.
(2)After using a period of time,LED light RED indicated
low battery, and still with transmission could stay
for about 30 minutes.
4.PL LED Indicator
(1)When indicate Red light and stop working, battery
need to recharging or change New batteries.
7. 3.5mm Aux Input jack
For connecting MP3 , CD play audio source , and send
audio source to receiver.
8.DC Input & Recharging jack
Could connect +5V switching adapter to provide power
or slow recharging internal rechargeable batteries.
PLTX
OFFCH.
MIC.
1 2
16
