User Manual

Issue department：Bedding Division Creation

time： 2018-08-10

ProductFunction

instruction

founder： Kyle

No：RF2406

RF2406 version： 1.1

Page 1 of 6

1

RF2406 Functioninstruction

1. Elctricalconfigurationdiagram：

‐ Refertothefollowingconnectiondiagramforassembly

CB0920

RF2406

FCC: PCU-RF2406

IC:21319-RF2406

FCC: PCU-CB0920

IC:21319-CB0920

Issue department：Bedding Division Creation

time： 2018-08-10

ProductFunction

instruction

founder： Kyle

No：RF2406

RF2406

version： 1.1

Page 2 of 6

2

2. FunctionPicture

FOOTDOWN

FLAT

HEADUP

Head&FootUp

FOOTUP

HEADDOWN

Issue department：Bedding Division Creation

time： 2018-08-10

ProductFunction

instruction

founder： Kyle

No：RF2406

RF2406 version： 1.1

Page 3 of 6

3

3. Processoftest

3.1 Pairing

Pairingmethod：

3.1.1Power‐onpair：

Themaincontrolboxispoweredandtheindicatorlightisalwayson.Theremotecontrolispaired

withthemaincontrolbox；

3.1.2Doubleclickonthepairbuttonpaircode：

Intheworkingmode,themaincontrolboxdouble‐clicksthecodebutton,theblueindicatorlights

up,andtheremotecontrollerispairedwiththemaincontrolbox.；

Pairingmethod：

1. 1.Thecontrolboxentersthecodemode,thebluelightisalwayson,andifitisnoton,repeat

step1；

2. Simultaneouslypressandholdtheremotecontrol'sHEADUPandHEADDOWN

3. ThecontrolboxbluelightflashesandentersBluetoothpairingmode.；

4. Atthistime,anybuttonoftheremotecontrolisoperated,andthecontrolboxhasanaction,

thatis,thepairingissuccessful.。

3.2 FLAT

PressandreleasetheFLATbuttononremote，theheadandfootactuatorsmovestolowerposition(whenthe

actuatorisfree,canturnoffthevibrationmotorandturnofftheindicatorlightwhenpressonce)，stopwhen

pressanybuton；；

3.3 HeadMotor

Pressheadupandmaintain,headliftstretchesout；

Pressheaddownandmaintain,headliftretracts；

3.4 FootMotor

Pressfootupandmaintain,headliftstretchesout；

Pressfootdownandmaintain,headliftretracts；

Issue department：Bedding Division Creation

time： 2018-08-10

ProductFunction

instruction

founder： Kyle

No：RF2406

RF2406 version： 1.1

Page 4 of 6

4

3.5 Head&FootUptest

Presshead&footupandmaintain,twoliftsstretchesout；

FCC Warning:

Any Changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause

undesired operation.

ISED RSS Warning:

This device complies with Innovation,Science and Economic Development Canada

licenceexemptRSS standard(s). Operation is subject to the following two conditions:

(1) this devicemay not cause interference, and

(2) this device must accept any interference, includinginterference that may cause

undesired operation of the device.

Le présent appareil est conforme aux CNR d'ISED applicables aux appareils radioexempts de

licence.

L'exploitation est autorisée aux deux conditions suivantes:

(1) l'appareil ne doit pas produire de brouillage, et

(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,même si le brouillage

est susceptible d'en compromettre le fonctionnement.
