OKIN Refined Electric Technology RF27 Remote Control User Manual Instruction of RF2719 V0
OKIN Refined Electric Technology Co., Ltd. Remote Control Instruction of RF2719 V0
User Manual
Issue Department：Date： 2019.01.07
System Instruction Author：
Instruction of RF27 Edition： V0.0
Page 1 of 5
1/5
Instruction of RF27
1 Key description
1.1 appearance
Figure1buttonofremote
Issue Department：Date： 2019.01.07
System Instruction Author：
Instruction of RF27 Edition： V0.0
Page 2 of 5
2/5
2 Key description
Buttons
&LEDs Key value Specification
B1：CHILD LOCK Press and hold child lock button till the backlight
flashes remote enters locking or unlocking mode.
B2：PAIR press and hold pair button ,the remote enters pairing
mode
Issue Department：Date： 2019.01.07
System Instruction Author：
Instruction of RF27 Edition： V0.0
Page 3 of 5
3/5
B3：M
Click M button, the bed moves to M position, press
and hold M button for 5s, until backlight flashes,
the control set the current position as M position
B4： FLASH LIGHT
Click FLASH LIGHT button, open or close flash
light
B5：ZG
Click zeroG button, the bed moves to zeroG
position, press and hold zeroG button for 5s, until
backlight flashes, the control set the current
position as zeroG position
B6：HEAD UP Press and hold head up button, head actuator moves
out, stop when released
B7：TV/PC
Click TV/PC button, the bed moves to TV/PC
position, press and hold TV/PC button for 5s, until
backlight flashes, the control set the current
position as TV/PC position
B8：FOOT UP Press and hold foot up button, foot actuator moves
out, stop when released
B9： FLAT Press and hold flat button, the bed goes flat
B10： FOOTDOWN
Press and hold foot down button,foot actuator
moves out, stop when released
B11： ANTI SNORE
Click antisnore button, the bed moves to antisnore
position, press and hold antisnore button for 5s until
backlight flashes, the control set the current
position as antisnore position
B12： HEAD DOWN
Press and hold head down button, head actuator
moves out, stop when released
B13：LOUNGE
Click lounge button, the bed moves to lounge
position, press and hold lounge button for 5s, until
backlight flashes, the control set the current
position as lounge position
B14： MASSAGE HEAD Click massage head button to switch massage
intensity of head massage motors
B15： TIMER Click timer button to switch massage time
B16： MASSAGE FOOT Click massage foot button to switch massage
Issue Department：Date： 2019.01.07
System Instruction Author：
Instruction of RF27 Edition： V0.0
Page 4 of 5
4/5
intensity of foot massage motors
B17： MASSAGE
ON/OFF
Click massage on/off button to turn on/off head &
foot massage motors
B18： UNDER BED
LIGHT
Click under bed light button to turn on/off the under
bed light
B19： MASSAGE TYPE Click massage type button to switch massage mode
LED 1： LED 1 Massage time: 10 minutes
LED 2： LED 2 Massage time: 20 minutes
LED 3： LED 3 Massage time: 30 minutes
Other function
1: Zero G + Flat
Press and hold zeroG and flat button for 5s until
backlight
flashes, the memory positions of control box reset
to default settings
FCC Warning：
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Issue Department：Date： 2019.01.07
System Instruction Author：
Instruction of RF27 Edition： V0.0
Page 5 of 5
5/5
ISED RSS Warning:
This device complies with Innovation,Science and Economic Development Canada
licenceexemptRSS standard(s). Operation is subject to the following two conditions: (1) this
devicemay not cause interference, and (2) this device must accept any interference,
includinginterference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'ISED applicables aux appareils radioexempts de
licence.
L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,même si le
brouillage est susceptible d'en compromettre le fonctionnement.
ISED RF exposure statement:
This equipment complies with ISED radiation exposure limits set forth for an uncontrolled
environment.The device has been evaluated to meet general RF exposure requirement.
Le matériel est conforme aux limites de dose d'exposition aux rayonnements énoncés pour fac un
autre environnement.ce dispositif a été évalué à satisfaire l'exigence générale de l'exposition aux
rf.
B.15227 B.15226
CB.13.22.01
R5.113.00.011
R5.504.01.250
JLDP.10.023.000
JLDP.14.027.000
JLDP.05.032.000
R5.216.01.015C
R5.413.01.005
R5.217.01.016
JLDQ.9.001.130C
R5.410.01.009
NO. Product name Product code number
1 Head Motor B.15227 1
2Foot Motor B.15226 1
3Massage Motor JLDQ.9.001.130C 2
4 Massage Motor Cable R5.410.01.009 1
5Control Box CB.13.22.01 1
6Power Supply JLDP.10.023.000 1
7Power Cord R5.217.01.016 1
8 ANSI power cord R5.504.01.250 1
9Y cable R5.216.01.015C 1
10 Patch cord of LED strip R5.413.01.005 1
11 LED strip/ LED R5.113.00.011 1
12 USB Socket/USB JLDP.05.032.000 1
13 Double USB Chager JLDP.14.027.000 2
14 19Keys remote RF27 1
FCC ID: PCU-RF27
IC: 21319-RF27
FCC ID: PCU-CB1322
IC: 21319-CB1322
