User Manual

Issue department：Bedding Division Date： 2017-05-11

ProductFunction

instruction

Author： Kyle

RF367A/RF367B/RF367C

Version： 1.1

Page 1 of 3

1

RF367A/RF367B/RF367CFunctioninstruction

Electricalconfigurationdiagram：

2. FunctionPicture

RF367A

CU358-3-S

RF367A RF367B RF367C

Issue department：Bedding Division Date： 2017-05-11

ProductFunction

instruction

Author： Kyle

RF367A/RF367B/RF367C Version： 1.1

Page 2 of 3

2

2. Foot Lift +

Press and maintain, foot lift stretches out

3. Head Lift +

Press and maintain, head lift stretches out

4.Head Lift -

Press and maintain, head lift retracts

5.FLAT

Press and release the FLAT button on remote，the head and foot actuators moves to lower position(when the actuator

is free, can turn off the vibration motor and turn off the indicator light when press once )，stop when press any

buton； 

6. Zero-G

Release after press, 2 lifts move to Zero-G position

3.Processoftest

1. Foot Lift -

Press and maintain, foot lift retracts

7. Head Lift +

Press and maintain, head lift stretches out

8. Foot Lift +

Press and maintain, foot lift stretches out

9. Zero-G

Release after press, 2 lifts move to Zero-G position

10.Pairing

PressHead+andZGkeyformorethan1second,theremotewillenterpairingmodeandablueLEDbesidesthe

pairingkeywillflash.Releasethiskeytostoppairing.Afterthepairingissuccessful,LEDwillstopflashing.

Issue department：Bedding Division Date： 2017-05-11

ProductFunction

instruction

Author： Kyle

RF367A/RF367B/RF367C Version： 1.1

Page 3 of 3

3

FCC：

Any Changes or modifications not expressly approved by the party responsible for compliance could void the

user’sauthoritytooperatetheequipment.

Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:

(1)Thisdevicemaynotcauseharmfulinterference,and

(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.

ISEDRSSWarning:

ThisdevicecomplieswithInnovation,ScienceandEconomicDevelopmentCanada

licenceexemptRSSstandard(s).Operationissubjecttothefollowingtwoconditions:

(1)thisdevicemaynotcauseinterference,and

(2)thisdevicemustacceptanyinterference,includinginterferencethatmaycauseundesired

operationofthedevice.

LeprésentappareilestconformeauxCNRd'ISEDapplicablesauxappareilsradio

exemptsdelicence.

L'exploitationestautoriséeauxdeuxconditionssuivantes:

(1)l'appareilnedoitpasproduiredebrouillage,et

(2)l'utilisateurdel'appareildoitacceptertoutbrouillageradioélectriquesubi,

mêmesilebrouillageestsusceptibled'encompromettrelefonctionnement.
