User Manual

Issue department：Bedding Division Date： 2017-05-11

Product Function

instruction

Author： Kyle

No：RF367E

RF367E

Version： 1.1

Page 1 of 4

1

RF367E Functioninstruction

1. Electricalconfigurationdiagram：

2. FunctionPicture

RF367E

CU358-3-S

Issue department：Bedding Division Date： 2017-05-11

Product Function

instruction

Author： Kyle

No：RF367E

RF367E

Version： 1.1

Page 2 of 4

2

3. Processoftest

1.1. Head&Foot Lift+

Pressandmaintain,head&footliftstretchesout

1.2. Head& Foot Lift‐

Pressandmaintain,head&footliftstretchesretracts

1.3. HeadLift+

Pressandmaintain,headliftstretchesout

1.4. HeadLift‐

Pressandmaintain,headliftretracts

1.5. FootLift+

Pressandmaintain,footliftstretchesout

1.6. FootLift‐

Pressandmaintain,footliftretracts

1.7. FLAT

PressandreleasetheFLAT buttononremote，theheadandfootactuatorsmovestolowerposition(whenthe

actuatorisfree,canturnoffthevibrationmotorandturnofftheindicatorlightwhenpressonce)，stopwhen

pressanybuton；

Issue department：Bedding Division Date： 2017-05-11

Product Function

instruction

Author： Kyle

No：RF367E

RF367E

Version： 1.1

Page 3 of 4

3

1.13. Pairing

Pressthiskeyformorethan1second,theremotewillenterpairingmodeandablueLEDbesidesthepairingkey

willflash.Releasethiskeytostoppairing.Afterthepairingissuccessful,LEDwillstopflashing.

1.8. Zero‐G

Releaseafterpress,2liftsmovetoZero‐Gposition

1.9. LED Light

Lightswitchkey

1.10. Zzz

Releaseafterpress,2liftsmovetoZzzposition

1.1. Head&Foot Lift+

Pressandmaintain,head&footliftstretchesout

1.2. Head& Foot Lift‐

Pressandmaintain,head&footliftstretchesretracts

Issue department：Bedding Division Date： 2017-05-11

Product Function

instruction

Author： Kyle

No：RF367E

RF367E

Version： 1.1

Page 4 of 4

4

FCC：

AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidthe

user’sauthoritytooperatetheequipment.

Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:(1)This

devicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,including

interferencethatmaycauseundesiredoperation.

ISEDRSSWarning:

ThisdevicecomplieswithInnovation,ScienceandEconomicDevelopmentCanadalicence-exempt

RSSstandard(s).Operationissubjecttothefollowingtwoconditions:(1)thisdevice

maynotcauseinterference,and(2)thisdevicemustacceptanyinterference,including

interferencethatmaycauseundesiredoperationofthedevice.

LeprésentappareilestconformeauxCNRd'ISEDapplicablesauxappareilsradio

exemptsdelicence.

L'exploitationestautoriséeauxdeuxconditionssuivantes:

(1)l'appareilnedoitpasproduiredebrouillage,et

(2)l'utilisateurdel'appareildoitacceptertoutbrouillageradioélectriquesubi,

mêmesilebrouillageestsusceptibled'encompromettrelefonctionnement.
