Users Manual

Issue department：Bedding Division Date： 2017-05-11

ProductFunction

instruction

Author： Kyle

JLDK.29.05.01

Version： 1.1

Page 1 of 4

1

JLDK.29.05.01 Functioninstruction

1. Electricalconfigurationdiagram：

2. FunctionPicture

12 13

Issue department：Bedding Division Date： 2017-05-11

ProductFunction

instruction

Author： Kyle

JLDK.29.05.01 Version： 1.1

Page 2 of 4

2

3. Processoftest

1.HEAD MASSGAE+

3kindsofstrengthofmassagehead+stopstatus,cycle

2.TIMER

AllMassageoff

Control time

3. FOOT MASSGAE +

Pressandmaintain,footliftstretchesout

4.HEAD MASSGAE-

3kindsofstrengthofmassagehead- retracts

5.MASSAGE TYPE

6. FOOT MASSGAE -

Pressandmaintain,footlift retracts

7. Head Up

3kindsofstrengthofmassagehead+stopstatus,cycle

8. Foot Up

3kindsofstrengthofmassagefoot+stopstatus,cycle

9.HeadDown

Pressandmaintain,headliftstretchesoutand head lift retracts

10.FootDown

Pressandmaintain,footliftstretchesoutand foot lift retracts

11.Zero-G

Releaseafterpress,2liftsmovetoZero‐Gposition

Issue department：Bedding Division Date： 2017-05-11

ProductFunction

instruction

Author： Kyle

JLDK.29.05.01 Version： 1.1

Page 3 of 4

3

16. Pairing

Pressthiskeyformorethan1second,theremotewillenterpairingmodeandablueLEDbesidesthepairingkey

willflash.Releasethiskeytostoppairing.Afterthepairingissuccessful,LEDwillstopflashing.

12.Memory1

CustomMemoryLocation1

13. Memory2

CustomMemoryLocation2

14. Memory3

CustomMemoryLocation3

15.FLAT

PressandreleasetheFLAT buttononremote，theheadandfootactuatorsmovestolowerposition(whenthe

actuatorisfree,canturnoffthevibrationmotorandturnofftheindicatorlightwhenpressonce)，stopwhen

pressanybuton；

Issue department：Bedding Division Date： 2017-05-11

ProductFunction

instruction

Author： Kyle

JLDK.29.05.01 Version： 1.1

Page 4 of 4

4

FCC Warning：

AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidthe

user’sauthoritytooperatetheequipment.

Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:(1)This

devicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,including

interferencethatmaycauseundesiredoperation.

ISEDRSSWarning:

ThisdevicecomplieswithInnovation,ScienceandEconomicDevelopmentCanadalicenceexempt

RSSstandard(s).Operationissubjecttothefollowingtwoconditions:(1)thisdevice

maynotcauseinterference,and(2)thisdevicemustacceptanyinterference,including

interferencethatmaycauseundesiredoperationofthedevice.

LeprésentappareilestconformeauxCNRd'ISEDapplicablesauxappareilsradio

exemptsdelicence.

L'exploitationestautoriséeauxdeuxconditionssuivantes:

(1)l'appareilnedoitpasproduiredebrouillage,et

(2)l'utilisateurdel'appareildoitacceptertoutbrouillageradioélectriquesubi,

mêmesilebrouillageestsusceptibled'encompromettrelefonctionnement.
