User manual
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications
Any changes or modification not expressly approved by the party responsible could void the user's authority to operate the device.
3.Plug the receiver to PC with USB port,as Fig. 5.
4.Use page-up and page-down button to run your presentation,as Fig. 6.
Laser radiation
is emitted from
this aperture
AVOID EXPOSURE
LASER RADIATION
AVOID DIRECT
EYE EXPOSURE
LASER DIODE
WAVELENGTH:
630-680nm
MAX. OUTPUT<5mw
CLASS IIIa LASER
PRODUCT
T hi s pro du c t co m plie s
wi t h 21 C F R ch apt er 1 .
Su b ch apt er J .
Ma n ufa ct ure d by
OP C O M O. E . ( X IA M EN)
IN C . XI AME N , CHI NA
SAFETY PRECAUTIONS
Fig. 5
Fig. 6
1. Since a laser beam can be harmful to the eyes. Avoid direct eye exposure.
Do not look directly into the laser beam output aperture during operation.
2. Be aware that laser light, when reflected off a mirror-like surface, can also be dangerous.
3. Use of controls, adjustments, or performance of procedures other than given in
USER INSTRUCTIONS may result in hazardous laser light exposure.
4. This product is safe to use in normal operations as described in these instructions.
Avoid direct eye exposure to laser beam. Keep out of
reach of children.
WARNING:NOT A TOY!
Keep Away From Children
May Be Harmful To Eyes
Warning Labels are located on the product as shown:
Laser radiation
is emitted from
this aperture
AVOID EXPOSURE
LASER RADIATION
AVOID DIRECT
EYE EXPOSURE
LASER DIODE
WAVELENGTH:
630-680nm
MAX. OUTPUT<5mw
CLASS IIIa LASER
PRODUCT
This prod uct c ompl ies
with 21 CF R ch apter 1.
Subc hapte r J.
Manu factu red b y
OPCO M O.E . (XI AMEN )
INC. XIAM EN, C HINA
USER Manual
1.Turn-on the Laser bar, insert the battery as
Fig. 3, then close the Laser bar.
Laser radiation
is emitted from
this aperture
AVOID EXPOSURE
LASER RADIATION
AVOID DIRECT
EYE EXPOSURE
LASER DIODE
WAVELENGTH:
630-680nm
MAX. OUTPUT<1mw
CLASS II LASER
PRODUCT
This pro du ct c om pl ies
with 21 CFR ch ap ter 1.
Subch ap ter J.
Manu fac tur ed by
OPCO M O .E . (X IA MEN )
I
NC. X IAM EN , C HI NA
AA Batter y
GE
Laser radiation
is emitted from
this aperture
AVOID EXPOSURE
LASER RADIATION
AVOID DIRECT
EYE EXPOSURE
LASER DIODE
WAVELENGTH:
630-680nm
MAX. OUTPUT<1mw
CLASS II LASER
PRODUCT
2. Unplug the Receiver,as Fig. 4.
Identify the pa
Feature
rts
Page up Page down
Laser ON/OFF button Pen Clip
Operation
Our product is a presentation tool for laptop computer users. The Presenter allows you to wirelessly
control your presentation from distances up to 50 feet(15 meters). Also an integrated laser pointer
and full function mouse empowers you with maximum control and flexibility during
presentations.Change slides in a presentation without having to be next to your computer or waving
hand signals across the room to a colleague changing slides for you.
Compact pen body design to build Red laser wireless transmitter, receiver USB
dongle with single AA battery, all in one.
Red laser pointer with remote page-up / down control
Easy to go USB dongle just plug and play without driver
Convenient page up and page down remote control up to 50 feet away for
presentation
Receiver
Fig. 3
Fig. 4
Fig. 2
Fig. 1
indication
Federal Communications Commission (FCC) Statement
15.21
You are cautioned that changes or modifications not expressly approved by the part responsible for
compliance could void the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates,uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Operation is subject to the following two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may cause undesired operation
of the device.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
End users must follow the specific operating instructions for satisfying RF exposure compliance. This
transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
