OPPO Mobile Telecommunications R7SF Mobile Phone User Manual
GuangDong Oppo Mobile Telecommunications Corp., Ltd. Mobile Phone
User Manual
1
This user manual provides the product safety information. Before using the phone, please read the Important
Information Guide (IIG) carefully. OPPO has preinstalled the Quick Guide application and some operational
suggestions in your device, please read both carefully.
2
Declaration
OPPO is a trademark or registered trademark of a Guangdong OPPO MobileTelecommunications Corp., Ltd.
© 2010 OPPO. All rights reserved.
This device may contain commodities, technology or software subject to export laws and regulations from
Thailand and other countries. Diversion contrary to law is prohibited.
OPPO has a policy of ongoing development. Thus, OPPO reserves the right to make changes or
improvements to any of the products described in this document without prior notice.
The contents of this document are all provided "as it is". Except as required by applicable law, no warranties
of any kind, either express or implied, are made in relation to the accuracy, reliability or contents of this
document.
To the maximum extent permitted by applicable law, under no circumstances shall OPPO or any of
itslicensors be responsible for any loss of data or income or any special, incidental, consequential or indirect
damages howsoever caused.
Product's supplies as well as related application software and accessories might vary areas.
For detail information, please refer to OPPO authorized distributor.
This device may contain commodities, technology or software subject to export laws and regulations from
Thailand and other countries. Diversion contrary to law is prohibited.
3
Safety
Switch on safely
Road safety comes first
Switch off at gas station
Switch off when taking an airplane
Switch off around medical equipment
Operation is subject to the following two conditions:
Please read the following. instructions before useing the mobile phone Without following these instructions
it might be dangerous or illegal. Further information about safety are provided by this user manual.
(1) This device may not cause harmful interference, and (2) This device must not accept any interference
received, including interference that may cause undesired operation.
Do not switch on the device when phone use is prohibited or when it may cause interference or
danger.
Obey and follow all related local laws. Use both hands when driving. Road safety should always
come first.
Please do not use phone at gasoline / service stations, places near fuel and chemicals.
Mobile phones might cause interference. Phone use on airplanes is dangerous and prohibited.
Hospitals or healthcare organizations might use equipments which are sensitive to radio
frequencies. Please follow all the rules and regulations.
4
Interference
Switch off at blasting area
Please obey all related regulations. Please do not use this device at blasting area.
Appropriate use of the phone
The device is not water-resistant. Please keep it dry.
Water-resistance
Connect with other devices
Only qualified personnel or OPPO technician may install or repair this product.
Qualified service
Accessories and batteries
All wireless devices might be susceptible to interference, which could affect performance.
Use the phone only at appropriate places. After switching it on, please do not touch the antenna
area if possible.
Please use the exclusive accessories and batteries approved by OPPO. Accessories which are not
approved by OPPO may damage the phone and it may cause danger. may cause
When connecting with other devices, please read this user manual to learn more detailed and
accurate and safety instructions. Do not connect with incompatible products.
5
Battery precautions in use
Please do not press or pierce the battery with hard objects (for example needle or other sharp objects), to
avoid damage, battery leak, overheating or fire.
If there is battery leakage or strange smell, please immediately move it from open flame in order to
avoid fire or explosion.
Do not place or use the battery near fire, heater or other high temperature places. Otherwise, it may
cause battery leakage, overheat, explosion or fire.
Do not disassemble or modify the battery, as it may cause battery leakage, overheating, explosion or fire.
Do not expose the battery liquid to eyes. It might cause potential blindness. When happens, wash your
eyes immediately or go to the hospital if serious.
If there are any abnormalities like high temperature, discoloration, distortion, bulging, leakage, etc. during
operation, charging or preservation, please cease to use the device.
Battery liquid may be harmful if contacted with skin or clothes, your skin might be hurt. Please immediately
wash it with water, or go to hospital at once to seek medical help if necessary.
Please do not weld battery terminals. Otherwise, it may cause battery leakage, overheat, explosion and fire.
6
Warning: Please do not charge the battery over 12 hours.
The battery can be charged and discharged hundreds of times at least, but it will eventually wear out.
Do not dispose the battery as household waste. Dispose of the battery according to local regulations.
Please keep the battery away from moist or wet areas from moisture. Otherwise, it may cause battery
overheat, fuming and corrosion.
Do not place the battery directly in sunlight, or other high temperature areas. Otherwise, battery
leakage and overheaingt may make battery performance descend and service life affected. Keep the
battery in a well-ventilated area.
Do not use the battery or connect it a high-voltage power supply,tootherwise it may cause a short
circuit or burst.
Caution: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries
according to the instructions.
To save power and the battery life, please do as follows:extend
Please do not charge or make calls during rainstorm. Please do not place the charger near a container
with water in order to avoid charger overheating, electric leakage and other troubles caused by
splashing water.
7
If the charger is exposed to water or other liquid, please immediately unplug the power supply from
socket in order to avoid overheat, fire, electric shock and charger errors.
Please do not disassemble or modify charger, as it may cause personal injury, electric shock, fire and
charger damages.
Make sure to hold the charger correctly while unplugging it. Do not pull the power cord as it may get
damaged and cause electric shock or fire.
Do not place heavy objects on power cord or modify cables, as it may cause electric shock or fire.
Please do not touch the charger, cable and power socket with wet hands, as it may cause electric shock.
Please do not use the charger in moist places, otherwise it may cause short circuit, fire or damage to the
charger.
Before cleaning the device, please unplug it from the socket first.
When using features like Bluetooth and Wi-Fi, it will consume more energy. Please close those functions
when they are not in use.
The brighter the screen the more battery energy will be consumed; you may lessen the screen
brightness and minimize the sleep time in display settings.
8
Charger precautions in use
Please only use OPPO charger. Please ensure to use only the charger offered by the manufacturer. Using
unauthorized charger may cause danger and violate the authorization of the phone and the guarantee
article.
Please use the specified voltages for the given charger. As other voltages may cause leakage or fire. It
may also damage your phone and battery.
Please do not use an improper plug and outlet, make sure the plug and outlet are appropriate, therwise
it may cause fire.
Please do not use short-circuit charger, as it may cause electric shock, fuming or damages for charger.
Do not charge the battery under the following conditions:
Direct exposure to sunlight.
Areas with humidity, dust or huge vibration (as troubles might be caused).
Areas near TV, radio and other electrical appliances (image or sound effect might be affected).
Adapter shall be installed near the equipment and shall be easily accessible.
9
Driving safely
Safety should always come first when you are driving a car. If you decide to use the phone while driving,
make sure to follow related regulations in the area or country.
Please do not store or carry your mobile phone and accessories with liquid or inflammable gas.
Please always remember the safety airbag in your car will open rapidly in case of an accident so make
sure you do not place your phone and accessories on top of them.
Electromagnetic waves, the surrounding environment and even the magnets in your earphones will
disrupt the accuracy of the compass, so please only use it for reference.
If you don't want to disclose your location please do not use apps that can record your location, please
obey the rules, law and your local regulations.
When searching for location, buildings, directions and distance please do not rely solemnly on the map
in your phone, these applications are only for reference purposes. Map, directions and location are
provided by service provider, thus information is changing information all the time, and in some places
these features are not supported, so map routes and compass may be incorrect, incomplete or
unsupported.
10
Operating environment
On rare occasions, using the device in some vehicles may affect the electronic devices of the car. On this
occasion, please do not use the device to avoid losing security guarantee.
power on/off settings to ensure that your mobile phone would not power on automatically.
Interference
from radio wave may cause disoperation or other troubles for electronic equipment.
Mobile phones may interfere with normal operations of electronic equipment and medical devices. Please
observe related regulations while you are using mobile phones in these areas. Please check your power
on/off settings to ensure that your mobile phone would not power on automatically.
This special regulation shall be observed wherever you are. And you shall switch off the device when
phone use is prohibited or when it may cause interference or danger
When connecting the device or its accessories to other devices, please read the user manual and
familiarize yourself with the safety information. Do not connect to incompatible products.
When in places of bursting danger, please switch your device off. Do not charge and obey the
regulations. If sparks appear in those places it’s likely to cause burst or fire. In bursted areas please pay
attention to the signs and avoid danger, these places including gas stations, the bottom of a ship,
chemical factory, vehicles using gas, places where in the air there is chemicals and at places vehicles are
required to stop.
11
11
FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must not accept any interference
received, including interference that may cause undesired operation.
against harmful interference in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct t he interference by one or more of the following measures:
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
12
12
FCC Caution:
Any Changes or modifications not expressly approved by the party responsible for compliance could
void the user‘s authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
The country code selection is for non-US model only and is not available to all US model. Per FCC
regulation, all WiFi product marketed in US must fixed to US operation channels only.
Operations in the 5.15-5.25GHz band are restricted to indoor usage only.
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure to radio waves.
This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency
(RF) energy set by the Federal Communications Commission of the U.S. Government.
13
The exposure standard for wireless device employs a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted using standard operating
positions accepted by the FCC with the device transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level
of the device while operating can be well below the maximum value. This is because the device is designed
to operate at multiple power levels so as to use only the poser required to reach the network. In general,
the closer you are to a wireless base station antenna, the lower the power output.
While there may be differences between the SAR levels of various devices and at various positions, they all
meet the government requirement.
For body worn operation, this device has been tested and meets the FCC RF exposure guidelines for use
with an accessory that contains no metal and be positioned a minimum of 1.0cm from the body. Use of
other accessories may not ensure compliance with FCC RF exposure guidelines. If you do not use a
body-worn accessory and are not holding the device at the ear, position the handset a minimum of 1.0cm
from your body when the device is switched on.
14
This device was tested for typical body-worn operations with the back of the handset kept kept 1.5cm
away. To maintain compliance with RF exposure requirements, use accessories that maintain a 1.5cm
separation distance between the user's body and the back of the handset. The use of belt clips, holsters
and similar accessories should not contain metallic components in its assembly. The use of accessories
that do not satisfy these requirements may not comply with RF exposure requirements, and should be
avoided.
CE certification information (SAR)
Additional Important Health and Safety Information
Please do not use the phone if antenna is damaged. Otherwise, it may cause personal injury.
If you are using pacemaker, hearing aid, cochlear implant or other device, please use the phone
according to the doctor’s advice.
Do not place the phone near magnetic card and other magnetic objects, as information stored in a
floppy disc, memory card and credit card might be damaged by phone's magnetic radiation.
Please place drawing pins and other metallic objects far away from phone receiver. As there is magnetic
effect/field when the phone speaker works, these small metallic objects may be attracted to the device
and personal injury and phone damage may be caused.
115
Do not disassemble or modify the phone. Otherwise, it may cause phone damage, electric leakages and
circuit troubles.
Avoid the phone to expose in moisture area, water or other liquid, as it may cause overheat, electric
leakage and other problems may occur.
Do not force the display or use the display to beat other things. Otherwise, it may cause display
damage and leakage of the liquid inside the LCD. The liquid of the LCD may cause blindness if it
comes in contact with your eyes. If that happens, flush your eyes with water immediately (do not rub
your eyes) and go to hospital for help.
Your phone can only use OPPO authorized batteries and chargers. Using other products may cause
battery leakages, overheating or fire. OPPO will not take any responsibility for accidents or problems
caused by using accessories that are not approved by OPPO.
Due to the used of enclosure material, the mobile phone shall only be connected to a USB Interface of
version 2.0 or highier. The connection to so called power USB is prohibited.
Excessive sound pressure from earphones and headphones can cause hearing loss.
This Headset should only be used on this mobile phone.
16
d) Have a warning as specified in Zx.3;
1) Equipment provided as a package(player with its listening device), the acoustic output shall be ≦
100 dBA ,measured while playing the fixed “programme simulation noise” described in EN 50332-1;
2) A personal music player provided with an analogue electrical output socket for a listening device, the
electrical output shall be ≦ 150mV measured as described in EN 50332-2, while playing the fixed “
programme simulation noise” described in EN 50332-1.
e) Not exceed the following:
a) Protect the user from unintentional acoustic outputs exceeding those mentioned above;
b) Have a standard acoustic output level not exceeding those mentioned above, and automatically return
to an output level not exceeding those mentioned above when the power is switched off;
c) Provide a means to actively inform the user of the increased sound pressure when the equipment is
operated with an acoustic output exceeding those mentioned above. Any means used shall be
acknowledged by the user before activating a mode of operation which allows for an acoustic output
exceeding those mentioned above. The acknowledgement does not need to be repeated more than once
every 20 h of cumulative listening time;
All other equipment shal
17
Your phone is a product of superior design and craftsmanship and should be treated with care.
The following suggestions will help you observe warranty terms and prolong the life of the device.
If the screen comes in contact with liquid, metal dust or other objects, please clean immediately.
Please do not touch the connection port of the phone, because static electricity may harm the components
in the device.
Please do not press or twist the device (for example sit on it, put it in your back pocket or twist it), if you
twist it too hard., it may break the screen or the device.
Do not place the battery, phone or charger in micro-wave oven or high voltage equipment. Otherwise, it
may cause circuit damage, fire and other accidents.
Do not knock, shake or drop the phone to avoid troubles or fire.
Care and Maintenance
Please do not hit or scratch the screen with sharp objects; please do not place heavy objects on the
screen, or press any point on the screen for too long.
Do not use the phone around flammable, explosive gas as it may cause phone damage and fire.
18
Do not use ethanol, thinner agent or benzene, etc. to clean the phone. If there is oil, stain or otherdirt
that cannot be easily please use tissue or soft cloth with water to clean it, do not use removed, your
fingernails or knife to avoid scratching the screen.
Do not place the phone in areas with high temperature, high humidity and lots of dust as it may damage
the device.
Your phone, battery and charger are not waterproof, please do not use it in bathroom or other humid
area and avoid contact with rain.
Avoid using special adhesive protectors as the glue may cause damage to the painting.
Do not place the phone on uneven or unstable table to avoid dropping the device.
Do not paint the phone. Paint may clog the moving parts and may cause the phone disoperation.
Use soft clean and dry to clean the phone, battery and charger.
Please keep the phone out of the reach of children, in order to protect them from causing injuries.
Dirt in the socket may cause poor contact or connection with the charger and your phone may power
down without charging. Regularly clean the power socket.
19
Hereby, Guangdong OPPO Mobile Telecommunications Corp., Ltd.declares that this device is in
compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Notice: Observe the national local regulations in the location where the device is to be used. This device
may be restricted for use in some or all member states of the European Union (EU).
When the phone is transmitting or saving info, please do not uninstall the SIM card, otherwise youmay
lose some important information or harm your device.
Use only the supplied or approved replacement antenna. Modified accessories may damage the phone
or violate administer regulations of radio devices.
Warning: Before using the phone, please read these health and safety information carefully. Some
people may get dizzy or convulsion when seeing flashing lights for example lights from playing games or
watching videos, if you have this kind of symptoms please consult your doctor.
This device only supports a standard Micro SIM card, using non-standard SIM card may harm the device.
EU Regulatory Conformance
5G wifi indoor used only.
20
Thank you for using OPPO mobile phone. We will provide our product with comprehensive warranty
services in accordance with applicable national laws and regulations. In case of any conflict between the
following policies and the National Policies, or Commissions, the national policies shall prevail.
1. Within 7 days from the purchasing date, if any performance fault listed in the Schedule "Performance
Failure Table" occurs on your device, consumer can claim for replacement or maintenance.
2. Within 12 months from the purchasing date, if any performance fault listed in the "Performance
Failure Table" occurs on your device, consumer can claim for maintenance. The accessories such as
charger, data cable, headset and battery (including internal battery) have a 6-month warranty.
3. Please be sure to fill in your mobile phone warranty card in a complete, correct and truthful manner,
ask the dealer to issue an invoice and keep it in a safe place.
4. Valid purchase invoice: the invoice shall indicate the serial number of the mobile phone, factory serial
number (batch number) of the accessories (battery and charger), product model, sales date, Seller's seal,
amount and so on.
OPPO Mobile Warranty Information
I: Service Terms
21
5. A valid warranty card and invoice are essential for protecting your warranty rights. (Valid warranty card
and invoice: the information filled in shall be complete, true and correct without alteration). If you lose the
valid invoice and warranty card and are unable to provide us with a photocopy of them, we will provide
your mobile phone with a 12-month warranty service beginning from the 90th day after the manufacturing
date of your mobile phone.
6. Our warranty does not cover the other accessories for the product (for instance: the user manual,
warranty card, etc).
Note: The warranty above is only valid for the products sold in India. OPPO Mobiles India Pvt.Ltd. has
the power of final review and interpretation for the warranty policy.
22
1. Your warranty is only valid under normal use of your device. All man-made damages and any of the
following conditions are out of free warranty, but a repair can be still implemented at your own cost:
A. The warranty period has expired;
B. Damage caused by human factors, including damages caused by usage under improper operating
environment and the failure to the user manual;
C. The customer disassembles, repairs or modifies the device without the Company's authorization or has it
repaired at a repair shop that is not included in the Company's approved repair network;
D. Damage caused by a force majeure (such as floods, fires, earthquakes and lighting);
E. The user is unable to provide the warranty card and valid proof of purchase or the product model and
barcode do not match or are altered;
F. Natural wear and tear of the product (such as casing, keypad, display screen, antenna and other
accessories);
G. Faults, damages or defects not caused by the company;
H. Barcode and warranty labels are damaged and unrecognizable.
II. Warranty Instructions and Conditions
23
2. Others
A. External damages (including wear, tear, and scratches) are not entitled to the warranty service;
5. All components, parts and accessories replaced during the warranty period shall become the property
of the Company.
B. Faults caused by the Internet and wireless information service providers (operators) are not covered by
the warranty;
3. If any of our products is required to be fixed, you may take it to any warranty shop in our national
warranty network;
4. If the product requires repair since water enters the device or it is seriously damaged by human factors,
the customer needs to sign the repair agreement form with the OPPO Customer Service Centre firstly;
C. Our warranty does not cover services verbally promised by the dealer which violate principles set forth
on the warranty card. For products that meet the replacement requirements, you can go to our nearest
approved warranty service centre for replacement. Upon replacement, if the device is faulty, we can replace
it with a device of the same specification and model; if any accessory is faulty, the faulty accessory will be
replaced. Both replacements are free of charge.
24
III: Considerations for Sending the Device for Repair and Collecting It
1. When completing the OPPO Mobile Phone Repair Form, the customer must fill in valid information in
clear handwriting as required (name, address, phone number and fault symptoms);
2. Before sending your device for repair, please back up all information and data you have saved on the
mobile phone (such as phone numbers, text messages and pictures) before you delete them to prevent loss
or damage during the testing and inspection processes. In any circumstances, OPPO Customer Service
Centre and its staff will not be responsible or obligated to back up or recover your information and data, or
accept responsibility for any consequence arising from the loss, damage or leakage of your information and
data. Please ensure the legality of the information and data you have saved. To respect your privacy, we will
not transmit, backup or examine your information and data(unless they are necessary for us to provide you
with services), and we reserve the right to refuse to provide services for illegal content;
3. The Customer shall collect the mobile phone by presenting the OPPO Mobile Phone Repair Form. In case
the Customer loses the Customer Copy, the Customer shall go through the loss reporting procedures with
his/her personal ID or valid proof of identity before collecting the mobile phone.
25
Name Performance failure
Device
Failure of functions listed in the user manual
No display / typos / drain plan
Cannot boot / cannot login or communicate
No vibration
Dial error
Accidental shutdown
Button control failure
No sound in one direction or abnormal volume
Unable to make/receive calls normally
Poor SIM card contact
Charger
Battery
External wired
headset
Except failure caused by networks
Performance Failure Table
Casing breakage due to structural or material factors; does not work or unable to
work normally; unable to charge normally using the designated charger
The phone is still unable to work normally after charging, and the judgment criteria
is that the battery capacity is no less than 80%
26
At OPPO Mobiles we understand that our responsibility doesn’t end at selling you our products.
OPPO Mobiles has been working in the area of safe disposal of electronic waste. Since mobiles, tablets and
other electronic items are made of hazardous constituents. Under our global policy as well the legislation
passed by the Ministry of Environment and Forests (MoEF), called E-waste (Management & Handling) Rules,
2011, which came into effect from 1st May 2012.
• OPPO Mobiles will seek shared responsibility and cooperation from customers in reducing the
environmental impact of their products.
• OPPO Mobiles will comply with all the applicable laws related to e-waste management.
As a part of e-waste recycling initiative, OPPO Mobiles has partnered with an authorized e waste company
named as 3R Recycler for collection, dismantling and disposing E-waste collected from all over India. 3R
vision is to look at e-waste not just as waste, but as an important resource that can be made useful instead
of shunning it as a social and environmental burden with their fully automated facility for e-waste recycling.
For further information about e-waste recycling and our e-waste recycling partner & their process you may
log on to www.3rrecycler.com or write an email to admin@3rrecycler.com.
Call us: Toll Free No.- 1800 200 2450.
Recyling Initiative
27
27
Contact Us
If you have any enquiries, feedback or suggestions on our products and services, please contact us
through the following channels:
Hotline: 1800-103-2777
Email: service@oppomobile.in
Website: www.oppomobile.in
28
OPPO Mobile Phone Repair Records
Maintenance Record #2
Service Center Name:
Maintenance Date:
Fault Description:
Maintenance Description:
Original IMEI / ESN:
New IMEI / ESN:
Maintenance personnel signature:
OPPO Mobile Phone Repair Records
Maintenance Record #1
Service Center Name:
Maintenance Date:
Fault Description:
Maintenance Description:
Original IMEI / ESN:
New IMEI / ESN:
Maintenance personnel signature:
User Information:
Product Information & Dealer Information:
Model/Color/IMEI:
Dealer's Name:
Date of purchase (DD/MM/YY):
User Name:
Zip Code:
User Address:
Phone No.:
E-mail:
WARRANTY CARD
V0.4.4
5198019
Important Information Guide
