MRF-100 R/F Interface Specification
Date: 03/21/03
Prepared by SG Ryoo
REVISION NO DATE
Rev 01 2003 03 21
MRF-100 RF Interface
1.Introduction 3. Structure Antenna
DC 9V IN JACK
Home Theater Master MRF-100 is RF interface that
is used in combination with MX-series RF remote controls.
The RF interface receives Radio Frequency signals sent from
the MX-series remotes and converts the RF signals to Infrared
signals to operate your TV, VCR DVD. Receiver,etc. IR Extender Jack
1to 6
2. Specification
Operation Distance
IR Blaster
IR Extender
RF Operation Distance POWER LED
100 FEET
30 FEET
10 FEET STATUS LED
Electrical Characteristic
Frequency
Power
418MHz MRF-100 RECEIVER
DC 9V 300mA
POWER ADAPTER
Others
EXTEND WIRE 2 METERS
Size 130 x 90 x 28
IR Extender Cable ( 6pcs)
MRF-100 RF Interface
5. LEDs
4. Install
Display signal status
POWER IR OUT
Adjust antenna
Connect DC9V Power supply.Connect IR Extender cable jack.
Display power status
6. Remote ID Setting
Please see the remote control manual for the details.
Attach the IR Extender Emitter to the receiving lens of your device.
Receiving Lens of the device
IR Extender Emitter
