Ohsung Electronics URCMRX30 BASE STATION User Manual G User s Manual

Ohsung Electronics Co., Ltd. BASE STATION G User s Manual

User Manual

Order Number : GETEC-C1-18-065 FCC Part 15 Certification
Test Report Number : GETEC-E3-18-001 Page 1 / 1
EUT Type: BASE STATION
FCC ID.: OZ5URCMRX30
APPENDIX G
: USER’S MANUAL
MRX-30
Owner’s Manual
1
Introduction:
The MRX-30 Advanced Network System Controller controls is designed to meet the
needs of large residential or small commercial environments.
Only Total Control 2.0 software, products, and user interfaces are supported by this
powerful device.
Features and Benefits:
Stores and issues commands for all IP, IR, RS-232, Relays, Sensors, and
12V Triggers controlled devices.
Provides two-way communication with Total Control 2.0 remotes and keypads.
Easy rack-mounting via the included rack mounting ears.
Parts List:
The MRX-30 Advanced Network Controller includes:
1x MRX-30 System Controller
1x AC Power Adapter
1x Power Cord
1x Adjustment Tool
1x Ethernet Cable
12x IR Emitters 3.5mm (standard)
2
Front Panel Descriptions:
The front panel consists of three (3) indicator lights which illuminate
during usage:
1. Power: Indicates that the MRX-30 is powered when illuminated.
2. Ethernet: When the device has a valid Ethernet connection the
indicator light remains a solid blue.
3. Status Light: There are four (4) possible states:
On: Connected to LAN and internet.
Off: Connected to LAN, no internet, or Ethernet cable
unplugged.
4. Reset: Press to power cycle the device.
1
2
3
4
Rear Panel Description:
The rear panel ports are:
1. Relays: NO, NC, or COM: six (6) programmable relays.
2. 12V OUT: four (4) programmable outputs. Each may be
programmed to turn on, off, or momentarily toggle.
3. Sensors: six (6) sensor ports allow programming of state
dependant and triggered macros. Compatible with all
URC sensors.
4. Power: Attach the included power supply here.
5. LAN: RJ45 10/100/1000 Ethernet port.
6. IR Outputs: twelve (12) standard 3.5mm IR emitter ports with
individual output level adjustment screws.
7. RS232: six (6) RS-232 ports, supports TX, RX, and GND
connections for two-way communications.
3
1
2
3
4
5
6
7
4
Specifications:
Microprocessor: I.MX6Quad 1.2GHz
Memory: 8GB eMMc, 2GB RAM
Network: One 10/100/1000M RJ45 Ethernet port (two LED indicators)
Weight: 99.15 oz
Size: 16.92” (W) x 3.7” (H) x 8.66” (D)
Power: DC 12V/3.3A
Limited Warranty Statement
1. Limited Warranty and Disclaimers
Universal Remote Control, Inc. (“URC”) warrants that the URC equipment shall be
free from defects in material and workmanship under normal usage for one (1) year
from purchase when such is purchased from URC. This limited warranty is valid
only in the United States of America. URC warrants that the software will
substantially conform in any material respect to its functional specifications at the
time of delivery. URC SHALL NOT BE LIABLE FOR OPERATIONAL, TECHNICAL OR
EDITORIAL ERRORS AND/OR OMISSIONS MADE IN THE URC DOCUMENTATION.
URC DOES NOT WARRANT THAT THE URC SOFTWARE IS BUG-FREE OR ERROR
FREE OR THAT THERE ARE NO ERRORS/BUGS IN THE URC SOFTWARE.
URC warrants that at the time of purchase the URC equipment and the URC
software complied with all applicable regulations and policies of the Federal
Communications Commissions (“FCC”) regarding electromagnetic interference
caused by electronic/computing devices and to the extent that the URC equipment
and/or the URC software fails to so comply, URC shall, at its own expense, take all
reasonable measures to promptly cause such to comply.
URC equipment purchases from other than an authorized URC dealer or
distributor are without warranty.
THIS LIMITED WARRANTY DOES NOT COVER TECHNICAL ASSISTANCE FOR
HARDWARE OR SOFTWARE USAGE EXCEPT AS EXPRESSLY PROVIDED FOR
HEREIN, THE EQUIPMENT, SOFTWARE AND DOCUMENTATION OF URC ARE
SUPPLIED “AS IS” WITHOUT ANY WARRANTY, EXPRESS, STATUTORY OR IMPLIED,
OF ANY KIND. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, URC
EXPRESSLY DISCLAIMS ALL WARRANTIES, EXPRESS, STATUTORY OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY AND
5
FITNESS FOR A PARTICULAR PURPOSE. URC DOES NOT WARRANT, GUARANTEE,
OR MAKE ANY REPRESENTATIONS REGARDING THE USE OF, OR THE RESULTS
OF THE USE OF, THE EQUIPMENT, SOFTWARE OR DOCUMENTATION IN TERMS
OF CORRECTNESS, ACCURACY, RELIABILITY OR OTHERWISE. EXCEPT AS
EXPRESSLY PROVIDED FOR HEREIN, TECHNICAL SERVICES ARE SUPPLIED “AS
IS”, WITHOUT ANY WARRANTY, EXPRESS, STATUTORY OR IMPLIED, OF ANY
KIND. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, URC
EXPRESSLY DISCLAIMS ALL WARRANTIES, EXPRESS, STATUTORY OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF QUALITY OR
REASONABLE SKILL AND CARE, OR OUTCOME OR RESULTS.
WITHOUT IN ANY WAY LIMITING THE GENERALITY OF THE OTHER PROVISIONS
HEREIN, WARRANTY DOES NOT COVER: (I) DAMAGE FROM MISUSE, NEGLECT
OR ACTS OR NATURE, (II) MODIFICATIONS, (III) INTEGRATION WITH THIRD PARTY
CONTENT (IV) BEYOND THE WARRANTY PERIOD AND/ OR FAILURE TO FOLLOW
URC WARRANTY CLAIM PROCEDURE.
The warranty limitations and warranty disclaimers may not apply to end user in
whole or in part, where such are restricted or excluded by applicable law and such
shall apply to the maximum extent permitted by applicable law.
In the event of any warranty claim, URC will, at its sole option, repair the URC
equipment using new or comparable rebuilt parts, or exchange the URC equipment
for new or rebuilt equipment. In the event of a defect, these are the end user’s
exclusive remedies.
All the URC equipment returned for service, exchange or repair require an RGA
number. To obtain an RGA number, you must complete a Return Request Form
which you may obtain by calling (914) 835-4484 or contacting URC at
returnrequest@universalremote.com. To obtain warranty service, end user must
deliver the URC equipment, freight prepaid, in its original packaging or packaging
affording adequate protection to URC at 420 Columbus Avenue, Valhalla, NY
10595. It is end user’s responsibility to backup any macro programming, artwork,
software or other materials that may have been programmed into the unit. It is
likely that such data, software, or other materials will be lost during service and
URC will not be responsible for any such damage or loss. A dated purchase
receipt, bill of sale, installation contract or other verifiable proof of purchase is
required. For the URC equipment support and other important information, please
visit URC's website available at www.universalremote.com or call the Customer
Service Center at (914) 835-4484.
This limited warranty only covers the URC equipment issues caused by defects in
material or workmanship during ordinary consumer use. It does not cover product
issues caused by any other reason, including but not limited to product issues due
to commercial use, acts of God, third-party installation, misuse, limitations of
technology, or modification of or to any part of the URC equipment. This limited
warranty does not cover the URC equipment sold as used, as is, refurbished, so
called "B stock" or consumables (such as batteries). This limited warranty is invalid
if the factory applied serial number has been altered or removed from the URC
equipment. This limited warranty specifically excludes the URC equipment sold by
unauthorized resellers.
With the exception of URC’s IR-only, broad-based consumer remotes, none of Page
36 URC’s PC programmable remotes or any of our Total Control® whole-house
equipment are authorized for online internet sales. Buying URC’s PC programmable
remotes or any of our Total Control® whole-house equipment online means
6
buying equipment that does not have a URC’s limited warranty. Such equipment is
not eligible for URC tech support or software support, either.
2. URC’s Limitations of Liability
IN NO EVENT SHALL URC BE LIABLE FOR INDIRECT, SPECIAL, INCIDENTAL,
EXEMPLARY, PUNITIVE OR CONSEQUENTIAL DAMAGES OF ANY KIND OR LOSS
OF PROFITS OR BUSINESS OPPORTUNITY, EVEN IF URC IS ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
IN NO EVENT SHALL URC BE LIABLE FOR LOSS OF OR DAMAGE TO DATA,
COMPUTER SYSTEMS OR COMPUTER PROGRAMS. URC’S LIABILITY, IF ANY, FOR
DIRECT DAMAGES OF ANY FORM SHALL BE LIMITED TO ACTUAL DAMAGES,
NOT IN EXCESS OF AMOUNTS PAID BY END USER FOR THE URC EQUIPMENT.
IN NO EVENT SHALL URC BE LIABLE FOR ANY EVENTS BEYOND ITS CONTROL,
INCLUDING ANY INSTANCE OF FORCE MAJEURE. IN NO EVENT SHALL URC BE
LIABLE FOR THE ACTS OR OMISSIONS OF END USER OR ANY THIRD PARTY.
THE LIMITATIONS OF LIABILITY MAY NOT APPLY TO END USER IN WHOLE OR IN
PART, WHERE SUCH ARE RESTRICTED LIMITED OR EXCLUDED BY APPLICABLE
LAW AND SUCH SHALL APPLY TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW.
URC SHALL NOT BE HELD RESPONSIBLE FOR THE STATEMENTS MADE BY
OTHERS.
SOME STATES OR JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO END USER. THIS LIMITED
WARRANTY GIVES END USER SPECIFIC LEGAL RIGHTS AND END USER MAY
HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE OR JURISDICTION TO
JURISDICTION.
End User Agreement
The terms and conditions of the End User Agreement available at
www.universalremote.com/eua.php shall apply.
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
7
Warning!
Changes or modifications not expressly approved by the manufacturer could void
the user's authority to operate the equipment.
Note : The manufacturer is not responsible for any Radio or TV interference caused
by unauthorized modifications to this equipment. Such modifications could void
the user's authority to operate the equipment.
FCC Caution
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the authority to operate equipment.
Regulatory Information to the user
CE conformity Notice
Products with “CE” marking comply EMC Directive 2014/30/EU issued by the
commission of the European Community.
1. EMC Directive
Emission
Immunity
Power
Declaration of Conformity
“Hereby, Universal Remote Control Inc. declares that this MRX-30 is in compliance
with the Essential requirements
