Ohsung Electronics URCTKP7000 In-Wall 7 inch Touch Screen User Manual EMISSION TEST REPORT
Ohsung Electronics Co., Ltd. In-Wall 7 inch Touch Screen EMISSION TEST REPORT
Users Manual
Order Number
: GETEC-C1-12-053
FCC Part 15 subpart C
Test Report Number
: GETEC-E3-12-025
Page 1 / 1
EUT Type: In-Wall 7” Touch Screen
FCC ID.: OZ5URCTKP7000
APPENDIX H
: USER’S MANUAL
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
TKP-7000
In-Wall 7” Touch Screen
Owners Manual
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
TKP-7000 Owner’s Manual ©2012 URC,Inc.
The information in this manual is copyright protected. No part of this manual may be
copied or reproduced in any form without prior written consent from Universal Remote-
Control,Inc.
UNIVERSAL REMOTE CONTROL,INC. SHALL NOT BE LIABLE FOR OPERATIONAL,
TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN THIS MANUAL.
The information in this manual may be subject to change without prior notice.
All other brand or product names are trademarks or registered trademarks of their
respective companies or organizations.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
1 General Description
1.1 The TKP-7000 In-Wall Touch Screen is a stylish way to add total home control
that's always there when you need it. This elegant Touch Screen is ideal for
areas of your home where convenient system monitoring and control is
important.
1.2 Features
1.2.1 2-Way IP Home Theater AVRS
1.2.1.1 Now with the unique URC 2-Way database, you can control your
multi zone audio video receivers over your home network via the
MRX-10 Network System Controller.
1.2.2 2-Way IP Control of Media on PCs and iPods
1.2.2.1 The high speed of the LAN enables the TKP-7000 to display lists of
artists, albums or songs and to display the cover art of the selected
album on the Now Playing screen of the remote control from the
PSX-2 Personal Server or from a Mac or PC.
1.2.3 Backlit Color LCD screen
1.2.3.1 The TKP-7000 has a programmable 7” color touch screen. When any
button is pressed, the color LCD screen as well as the remote buttons,
will light up.
1.2.4 User Configurable Internet RSS for News, Sports, Stocks and Weather
1.2.4.1 The well known URC modules for News, Sports, Weather and Stocks
are all available updated to the TKP-2000 screen and of course, are
completely user set.
1.2.5 No batteries to replace...Ever!
1.2.5.1 The TKP-2000 is powered over the ethernet cable it’s connected to,
so you never have to worry about replacing batteries.
2 Installation
2.1 The TKP-7000 can fit into a standard 2 –Gang “J-box or Mud Ring” for
installation
2.1.1 The TKP-7000 is two separate pieces, the keypad and the mount. The
keypad section will fit onto the mounting section.
2.1.2 The mounting section will screw into the wall, and the TKP-7000 keypad
section would then snap into the mounting that is attached to the wall.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
3 Connectors
3.1 The back of the keypad will have 1 RJ45 jack that is used to connect the unit
to the Local Area Network (LAN) and to also give it power one ONE Cat5
connector.
4 Power Requirements
4.1 Power Over Ethernet (PoE): is the only way the TKP-7000 can be powered.
4.2 The TKP-7000 will need to be connected to PoE switch or a PoE injector to be
used.
5 Buttons
5.1 Reset: on the bottom of the keypad is a reset button, and when pressed it will
reset the keypad.
5.2 The TKP_7000 will be re-booted when the Reset button is pressed without loss
of programming.
5.3 The TKP-7000 will be reset to the factory default program if the Reset button is
pressed and held for 15 seconds.
6 LCD Screen
6.1 Screen Size: 7 Inch Diagonal (155mm x 91.5 mm)
6.2 Screen Resolution: 1024 X 600
6.3 Screen Type: Capacitive
6.4 Touch Feedback: Haptic feedback when the LCD is touched.
6.5 Multi Touch: The LCD can recognize multi finger touch.
6.6 Flick/Drag: The LCD supports finger flick and dragging.
7 Sound
7.1 The TKP-7000 will support a beep sound that’s volume can be adjust.
7.1.1 This Beep sound can also be turned off.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one more of the following
measures:
□ Reorient or relocate the receiving antenna.
□ Increase the separation between the equipment and receiver.
□ Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
□ Consult the dealer or an experienced radio/TV technician for help.
Warning!
Changes or modifications not expressly approved by the manufacturer could
void the user's authority to operate the equipment.
Note : The manufacturer is not responsible for any Radio or TV interference
caused by unauthorized modifications to this equipment. Such modifications
could void the user's authority to operate the equipment.
FCC Caution
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible
for compliance could void the authority to operate equipment.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
Regulatory Information to the user
□ CE conformity Notice
Products with “CE” marking comply with the EMC Directive
2004/108/EC and issued by the commission of the European
Community.
1) EMC Directive
○ Emission : EN 55022
○ Immunity : EN 55024
○ Power : EN-61000-3-2, 3
Universal Remote Control
Certification
CE
Type No.(Model No.)
T
KP
-
7000
Batch/Serial No.
-
Power Rating
DC 48V / 320mA
Frequency band
-
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
Declaration of Conformity
Company Name : Universal Remote Control Inc.
Company Address : 500Mamaroneck Avenue, Harrison, NY 10528, U.S.A
Contact Information : www.universalremote.com
Phone: (914)835-4484 Fax: (914)835-4532
Brand Name : UNIVERSAL remote control
Product Name : In-Wall 7” Touch Screen
Model Name : TKP-7000
This product herewith complies with the requirements of EMC Directive (2004/108/EC)
a issued bythe Commission of the European Community
Compliance with these directives implies conformity to the following European
Community
□ EMC Directive
○ EN 55022
○ EN 55024
○ EN 61000-3-2
○ EN 61000-3-3
List of test reports and/or certificate verified compliance with the standards above
□ EMC Directive
○ Report No.
○ Testing Laboratory : Gumi College EMC Center
Date of issue : February 2, 2012
Name and signature of authorized person : James Novak
Senior Product Manager
Universal Remote Control Inc.
